466 IN CASE OF EMERGENCY
F82–10 Amp Red Steering Column Control Module / Cruise
Control
F83 ––No Connection
F84 –15 Amp Blue ASBM / HVAC / ICS / Rear Heated Seat
Switches
F85 –10 Amp Red Airbag Module
F86 –10 Amp Red Airbag Module
F87 –10 Amp Red Air Suspension / ITBM / Steering Column
Control Module / MOD Gateway CAN-C
Trailer TPM (HD Only)
Air Suspension / Trailer Tow / DC/DC
Converter (Voltage Stabilizer) / Steering
Column Control Module / Occupant
Classification Sensor (DS 1500 Only)
F88 –15 Amp Blue Instrument Panel Cluster
F90/F91 –20 Amp Yellow IGN or BATT Customer Selectable – If Equipped
(HD Only)
Power Outlet (Rear Seats) Customer Selectable
(DS 1500 Only)
F93 –20 Amp Yellow Cigar Lighter - If Equipped
Cavity
Cartridge Fuse Micro Fuse Description

IN CASE OF EMERGENCY 467
F94–10 Amp Red Shift-By-Wire / Transfer Case Switch (DS 1500
Only)
Shift-By-Wire / Transfer Case Switch / Module
TPM Trailer (HD Only) / Module Gateway
Can-C Trailer TPM (HD Only)
F95 –10 Amp Red Rearview Camera / Park Assist / CHMSL
Camera / Blind Spot Sensor / Surround View
Camera (HD Only)

Rear Camera / Park Assist / Blind Spot Sensor /
Compass (DS 1500 Only)

F96 –10 Amp Red Rear Seat Heater Switch / Trunk Lamp With
Flashlamp Charger / Truck Lamp - If Equipped
(DS 1500 Only)
Trailer Camera – If Equipped (HD Only)
F97 –25 Amp Clear Rear Heated Seats And Heated Steering Wheel –
If Equipped (DS 1500 Only)
F97 –20 Amp Yellow Front Heated Seat Passenger – If Equipped (HD
Only)
F98 –25 Amp Clear Front Heated Seats – If Equipped (DS 1500
Only)
F98 –20 Amp Yellow Front Heated Seat Driver – If Equipped (HD
Only)
Cavity
Cartridge Fuse Micro Fuse Description
6

468 IN CASE OF EMERGENCY
(Continued)
F99–10 Amp Red HVAC / DASM (DS 1500 Only)
HVAC / In-Car Temperature Sensor / CSG
MOD / Humidity Sensor (HD Only)
F100 –10 Amp Red Upfitters – If Equipped (HD Only)
F101 –15 Amp Blue SSV Only
F101 –20 Amp Yellow Rear Heated Seat Right (HD Only)
F102 –20 Amp Yellow Rear Heated Seat Left / Run RLY #3 Coil (HD
Only)
F103 –10 Amp Red HeadLamp AFLS (HD Only)
F104 –20 Amp Yellow Power Outlets (Instrument Panel / Center
Console) / Trunk – If Equipped (DS 1500 Only)
UCI Port / USB Rear (HD Only)
Cavity
Cartridge Fuse Micro Fuse Description
CAUTION!
• When installing the power distribution center cover, it is important to ensure the cover is properly positioned
and fully latched. Failure to do so may allow water to
get into the power distribution center and possibly
result in an electrical system failure.
• When replacing a blown fuse, it is important to useonly a fuse having the correct amperage rating. The use
of a fuse with a rating other than indicated may result
in a dangerous electrical system overload. If a properly
rated fuse continues to blow, it indicates a problem in
the circuit that must be corrected. CAUTION!
(Continued)

544 SERVICING AND MAINTENANCE
Consult an authorized tire dealer for tire repairs and addi-
tional information.
Damaged Run Flat tires, or Run Flat tires that have experi -
enced a loss of pressure should be replaced immediately
with another Run Flat tire of identical size and service
description (Load Index and Speed Symbol). Replace the tire
pressure sensor as well as it is not designed to be reused.
Run Flat Tires — If Equipped
Run Flat tires allow you the capability to drive 50 miles
(80 km) at 50 mph (80 km/h) after a rapid loss of inflation
pressure. This rapid loss of inflation is referred to as the Run
Flat mode. A Run Flat mode occurs when the tire inflation
pressure is of/or below 14 psi (96 kPa). Once a Run Flat tire
reaches the run flat mode it has limited driving capabilities
and needs to be replaced immediately. A Run Flat tire is not
repairable. When a run flat tire is changed after driving with
underinflated tire condition, please replace the TPM sensor
as it is not designed to be reused when driven under run flat
mode (14 psi (96 kPa)) condition. NOTE:
TPM Sensor must be replaced after driving the vehicle on a
flat tire condition.
It is not recommended driving a vehicle loaded at full
capacity or to tow a trailer while a tire is in the run flat mode.

See the tire pressure monitoring section for more information.

Tire Spinning
When stuck in mud, sand, snow, or ice conditions, do not
spin your vehicle's wheels above 30 mph (48 km/h) or for
longer than 30 seconds continuously without stopping.
Refer to “Freeing A Stuck Vehicle” in “In Case Of Emer
-
gency” for further information.
WARNING!
Fast spinning tires can be dangerous. Forces generated
by excessive wheel speeds may cause tire damage or
failure. A tire could explode and injure someone. Do not
spin your vehicle's wheels faster than 30 mph (48 km/h)
for more than 30 seconds continuously when you are
stuck, and do not let anyone near a spinning wheel, no
matter what the speed.

555
(Continued)
NOTE:
If your vehicle is equipped with a Tire Pressure Information
System (TPIS):
• The Tire Pressure Information System (TPIS) uses uniquesensors in the inner rear wheels to help identify them from
the outer rear wheels, because of this, the inner and outer
wheel locations can’t be switched.
• After a tire rotation is completed, as shown below, the system can auto learn the locations of each sensor ID. Auto
learning/localization occurs when the vehicle ignition
status is changed from Off to On and speeds of greater
than 5 mph (8km/h) are obtained and remain over 5 mph
(8km/h) for at about a 15 minute period. You may need to
drive for 20 minutes to account slower speeds and stops.
• If the tires are rotated incorrectly, The auto localization of the TPIS sensors will fail to locate correctly resulting in
incorrect locations for the pressure values displayed in the
instrument cluster.
DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES
The following tire grading categories were established by
the National Highway Traffic Safety Administration. The
specific grade rating assigned by the tire's manufacturer
in each category is shown on the sidewall of the tires on
your vehicle.
All passenger vehicle tires must conform to Federal safety
requirements in addition to these grades.
CAUTION!
• 3500 Dual Rear Tires may only have one approved direction of rotation. This is to accommodate the asym -
metrical design (tread pattern) of the On/Off-Road tire
and the use of Outline White Letter (OWL) tires.
• When replacing a flat, the spare tire may have to be remounted on the rim, or installed at a different loca -
tion, to maintain the correct placement of the tire on the
wheel relative to the tire/wheel position on the truck.
For example, if the spare is used to replace an outer rear
tire it will have to be remounted on the rim so that the
wheel is dished inward. That way the tread design of
asymmetrical tires and the white writing of the OWL
tires will maintain proper position. CAUTION!
(Continued)
7

592 MULTIMEDIA
Compass Settings — If Equipped
After pressing the “Compass Settings” button on the touchscreen, the following settings will be available:Setting Name Selectable Options
Variance 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
NOTE:
• Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences the variance should be set for the zone where the vehicle is driven, per the zone map. Once properly set, the compass will auto -
matically compensate for the differences, and provide the most accurate compass heading.
• Keep magnetic materials away from the top of the instrument panel, such as iPod's, Mobile Phones, Laptops and Radar Detectors. This is where the compass module is located, and it can cause interference with the compass sensor, and it may
give false readings.
Perform Compass Calibration On
Off
NOTE:
Press the “Calibration” button on the touchscreen to change this setting. This compass is self-calibrating, which eliminates
the need to manually reset the compass. When the vehicle is new, the compass may appear erratic until it is calibrated. You
may also calibrate the compass by pressing the “ON” button on the touchscreen and completing one or more 360-degree
turns (in an area free from large metal or metallic objects). The compass will now function normally.

685
Seat Belt Reminder .............................................................. 179Security Alarm..................................................................... 181
Service ................................................................................... 446Side Marker .......................................................................... 457
Traction Control .................................................................. 204
Transfer Case ....................................................................... 317Turn Signals ........................................... 71, 191, 289, 447, 452
Warning Instrument Cluster Descriptions .............. 181, 191
Limited-Slip Differential ................................................ 337, 530
Load Shed Battery Saver Mode............................................. 177
Load Shed Battery Saver On ................................................. 177
Load Shed Electrical Load Reduction .................................. 177
Load Shed Intelligent Battery Sensor ................................... 177
Loading Vehicle ...................................................................... 410 Tires....................................................................................... 537
Locks Automatic Door..................................................................... 39
Child Protection .................................................................... 39
Power Door ............................................................................ 35
Low Tire Pressure System ..................................................... 220
Lubrication, Body ................................................................... 517
Lug Nuts/Bolts ....................................................................... 565 M
Maintenance............................................................................. 100
Maintenance Free Battery ...................................................... 506
Maintenance Schedule ........................................................... 499 Malfunction Indicator Light (Check Engine) ......................184
Manual Park Release .........................................................................492
Service ...................................................................................677
Media Hub ...............................................................................643
Memory Seat ..............................................................................45
Methanol...................................................................................568
Mirrors ........................................................................................57 Electric Powered ....................................................................60
Heated .....................................................................................63
Memory...................................................................................45
Outside....................................................................................59
Rearview .............................................................57, 58, 59, 441 Trailer Towing .......................................................................62
Modifications/Alterations Vehicle.....................................................................................15
Monitor, Tire Pressure System ..............................................220
Mopar Parts..............................................................................676
MP3 Control ............................................................................. 643
Multi-Function Control Lever .................................................67 N
Navigation System (Uconnect GPS) .....................................397
New Vehicle Break-In Period ................................................297 O
Occupant Restraints ................................................................230
Octane Rating, Gasoline (Fuel)..............................................567
