Ram ProMaster 2015 Owner's Manual

1. Loosen (but do not remove) the wheel lug bolts byturning them to the left one turn while the wheel is
still on the ground.
2. There are two jack engagement locations on each side of the vehicle body.CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated.
Assembled JackJacking Engagement Locations
6
WHAT TO DO IN EMERGENCIES 309

NOTE:The rear jacking location is located in front of the
rear tire and in front of the leaf spring mount. NOTE:
The front jacking location is located behind the
front tire and in front of the driver/passenger door.
Rear Jacking LocationFront Jacking Location
310 WHAT TO DO IN EMERGENCIES

WARNING!
Being under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never get any part of your body
under a vehicle that is on a jack. If you need to get
under a raised vehicle, take it to a service center
where it can be raised on a lift.
3. Place the wrench handle and lug bolt adapter on the jack screw and turn to the right until the jack head is
properly engaged in the described location. Do not
raise the vehicle until you are sure the jack is
securely engaged. 4. Raise the vehicle by turning the jack screw to the right,
using the wrench handle and lug bolt adapter. Raise
the vehicle only until the tire just clears the surface and
enough clearance is obtained to install the spare tire.
Minimum tire lift provides maximum stability.
WARNING!
Raising the vehicle higher than necessary can make
the vehicle less stable. It could slip off the jack and
hurt someone near it. Raise the vehicle only enough
to remove the tire.
5. Remove the wheel lug bolts. For vehicles with wheel covers, remove the cover from the wheel by hand. Do
not pry the wheel cover off. Then pull the wheel off the
hub.
6. Install the spare tire. Lightly tighten the wheel lug bolts.
6
WHAT TO DO IN EMERGENCIES 311

CAUTION!
Be sure to mount the spare tire with the valve stem
facing outward. The vehicle could be damaged if the
spare tire is mounted incorrectly.
WARNING!
To avoid the risk of forcing the vehicle off the jack,
do not tighten the wheel nuts fully until the vehicle
has been lowered. Failure to follow this warning may
result in personal injury.
NOTE: Do not install the wheel cover on the spare tire.
7. Lower the vehicle by turning the jack screw to the left.
8. Refer to “Torque Specifications” in this section for proper wheel lug bolt torque.
9. Lower the jack to its fully-closed position.
10. Stow the damaged wheel/spare tire with the cable and wheel spacer before driving the vehicle.
Mounting Spare Tire
312 WHAT TO DO IN EMERGENCIES

11. Install the winch extension androtate the wrench
handle clockwise until the winch mechanism indi-
cation window turns yellow and the operator hears
“3 clicks” from the device to show the wheel is
properly stowed under the vehicle.
Winch Mechanism Properly Engaged (Yellow DOT Will
Appear In The Winch Indication Window)
Winch Mechanism NOT Properly Engaged (Black Window Will Appear)
6
WHAT TO DO IN EMERGENCIES 313

CAUTION!
In the case that the yellow dot does not appear in the
winch mechanism window refer to step 11 above, the
operator should repeat the spare tire instillation
procedure. If the yellow dot does not appear in the
winch indication window, place and secure the dam-
aged wheel into the vehicle and seek dealer assis-
tance to the winch mechanism.
12. Stow the jack, jack handle and winch handle tools back in the storage compartment.
WARNING!
A loose tire or jack thrown forward in a collision or
hard stop could endanger the occupants of the ve-
hicle. Always stow the jack parts and the spare tire in
the places provided. Have the deflated (flat) tire
repaired or replaced immediately.
13. Check the spare tire pressure as soon as possible. Correct the tire pressure, as required.
314 WHAT TO DO IN EMERGENCIES

For vehicles with aluminum wheels:
1. Remove the adapter bracket and bolts from the storagebag in the glove compartment.
2. Take the retainer and position it inside the circular bracket. 3. Tighten the knob on the bolt to secure it to the bracket.
Adapter/Bracket Union
Securing The Bracket
6
WHAT TO DO IN EMERGENCIES 315

4. Position the tire vertically and lay the mountedadapter on the inner part of the rim. Using the
supplied bolts, fasten the wheel to the adapter using
the bolt install wrench. Tighten the bolts with the
wrench extension and wrench handle. 5.
Follow the steps above for proper spare tire stowage.
Alloy Wheel MountingWheel/Bolts Attaching To Mounting Bracket
316 WHAT TO DO IN EMERGENCIES

Wheel Covers
CAUTION!
Use a back-and-forth motion to remove the hub cap.
Do not use a twisting motion when removing the hub
cap, damage to the hub cap finish may occur.
The wheel covers on the vehicle are held in place by the
wheel lug bolts and can be removed after the wheel lug
bolts are taken off.
JUMP-STARTING PROCEDURES
If your vehicle has a discharged battery it can be jump-
started using a set of jumper cables and a battery in
another vehicle or by using a portable battery booster
pack. Jump-starting can be dangerous if done improperly
so please follow the procedures in this section carefully. NOTE:
When using a portable battery booster pack
follow the manufacturer ’s operating instructions and
precautions.
CAUTION!
Do not use a portable battery booster pack or any
other booster source with a system voltage greater
than 12 Volts or damage to the battery, starter motor,
alternator or electrical system may occur.
WARNING!
Do not attempt jump-starting if the battery is frozen.
It could rupture or explode and cause personal injury.
6
WHAT TO DO IN EMERGENCIES 317

Preparations For Jump-Start
The vehicle’s jump starting remote posts are located
under the hood, in the engine compartment on the
driver’s side.
The Remote Positive(+)Post is covered with a protective
cap located on the side of the Front Power Distribution
Center.
The Remote Negative (-)Post is located on the core
support closest to the front of the vehicle.
Jump Starting Remote Post Locations
A — Remote Positive (+)Post
B — Remote Negative (-)Post
