WARNING!(Continued)
•Block the wheel diagonally opposite the wheel to be
raised.
• Set the parking brake firmly and set an automatic
transmission in PARK; a manual transmission in
REVERSE.
• Never start or run the engine with the vehicle on a
jack.
• Do not let anyone sit in the vehicle when it is on a
jack.
• Do not get under the vehicle when it is on a jack. If
you need to get under a raised vehicle, take it to a
service center where it can be raised on a lift.
• Only use the jack in the positions indicated and for
lifting this vehicle during a tire change.
• If working on or near a roadway, be extremely
careful of motor traffic.
• To assure that spare tires, flat or inflated, are securely
stowed, spares must be stowed with the valve stem
facing the ground.
CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated in the Jacking
Instructions for this vehicle.
Jack Warning Label
6
WHAT TO DO IN EMERGENCIES 259

1. Loosen (but do not remove) the wheel lug bolts byturning them to the left one turn while the wheel is still
on the ground.
2. There are two jack engagement locations on each side of the vehicle body.CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated.
NOTE: The rear jacking location is located in front of the
rear tire and in front of the leaf spring mount.
Assembled JackJacking Engagement Locations
260 WHAT TO DO IN EMERGENCIES

NOTE:The front jacking location is located behind the
front tire and in front of the driver/passenger door.WARNING!
Being under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never get any part of your body
under a vehicle that is on a jack. If you need to get
under a raised vehicle, take it to a service center where
it can be raised on a lift.
3. Place the wrench handle and lug bolt adapter on the jack screw and turn to the right until the jack head is
Rear Jacking LocationFront Jacking Location
6
WHAT TO DO IN EMERGENCIES 261

properly engaged in the described location.Do not raise
the vehicle until you are sure the jack is securely
engaged.
4. Raise the vehicle by turning the jack screw to the right, using the wrench handle and lug bolt adapter. Raise the
vehicle only until the tire just clears the surface and
enough clearance is obtained to install the spare tire.
Minimum tire lift provides maximum stability.
WARNING!
Raising the vehicle higher than necessary can make the
vehicle less stable. It could slip off the jack and hurt
someone near it. Raise the vehicle only enough to
remove the tire.
5. Remove the wheel lug bolts. For vehicles with wheel covers, remove the cover from the wheel by hand. Do
not pry the wheel cover off. Then pull the wheel off the
hub.
6. Install the spare tire. Lightly tighten the wheel lug bolts.
WARNING!
To avoid the risk of forcing the vehicle off the jack, do
not tighten the wheel nuts fully until the vehicle has
been lowered. Failure to follow this warning may
result in personal injury.
Mounting Spare Tire
262 WHAT TO DO IN EMERGENCIES

CAUTION!
Be sure to mount the spare tire with the valve stem
facing outward. The vehicle could be damaged if the
spare tire is mounted incorrectly.
NOTE: Do not install the wheel cover on the spare tire.
7. Lower the vehicle by turning the jack screw to the left.
8. Refer to “Torque Specifications” in this section for proper wheel lug bolt torque.
9. Lower the jack to its fully-closed position.
10. Stow the damaged wheel/spare tire with the cable and wheel spacer before driving the vehicle.
11. Install the winch extension and rotate the wrench
handle clockwise until the winch mechanism indica-
tion window turns yellow and the operator hears “3
clicks” from the device to show the wheel is properly
stowed under the vehicle.
Winch Mechanism Properly Engaged (Yellow DOT Will
Appear In The Winch Indication Window)
6
WHAT TO DO IN EMERGENCIES 263

CAUTION!
In the case that the yellow dot does not appear in the
winch mechanism window refer to step 11 above, the
operator should repeat the spare tire installation pro-
cedure. If the yellow dot does not appear in the winch
indication window, place and secure the damaged
wheel into the vehicle and seek dealer assistance to the
winch mechanism.12. Stow the jack, jack handle and winch handle tools back
in the storage compartment.
WARNING!
A loose tire or jack thrown forward in a collision or
hard stop could endanger the occupants of the vehicle.
Always stow the jack parts and the spare tire in the
places provided. Have the deflated (flat) tire repaired
or replaced immediately.
13. Check the spare tire pressure as soon as possible. Correct the tire pressure, as required.
For vehicles with aluminum wheels:
1. Remove the adapter bracket and bolts from the storage bag in the glove compartment.
Winch Mechanism NOT Properly Engaged (Black Window
Will Appear)
264 WHAT TO DO IN EMERGENCIES

2. Take the retainer and position it inside the circularbracket. 3. Tighten the knob on the bolt to secure it to the bracket.
Adapter/Bracket Union
Securing The Bracket
6
WHAT TO DO IN EMERGENCIES 265

4. Position the tire vertically and lay the mounted adapteron the inner part of the rim. Using the supplied bolts,
fasten the wheel to the adapter using the bolt install
wrench. Tighten the bolts with the wrench extension
and wrench handle. 5.
Follow the steps above for proper spare tire stowage.
Wheel Covers
CAUTION!
Use a back-and-forth motion to remove the hub cap.
Do not use a twisting motion when removing the hub
cap, damage to the hub cap finish may occur.
The wheel covers on the vehicle are held in place by the
wheel lug bolts and can be removed after the wheel lug
bolts are taken off.
Alloy Wheel MountingWheel/Bolts Attaching To Mounting Bracket
266 WHAT TO DO IN EMERGENCIES

JUMP-STARTING PROCEDURES
If your vehicle has a discharged battery it can be jump-
started using a set of jumper cables and a battery in another
vehicle or by using a portable battery booster pack. Jump-
starting can be dangerous if done improperly so please
follow the procedures in this section carefully.
NOTE:When using a portable battery booster pack follow
the manufacturer ’s operating instructions and precautions.
WARNING!
Do not attempt jump-starting if the battery is frozen. It
could rupture or explode and cause personal injury.
CAUTION!
Do not use a portable battery booster pack or any other
booster source with a system voltage greater than
12 Volts or damage to the battery, starter motor, alter-
nator or electrical system may occur.
Preparations For Jump-Start
The vehicle’s jump starting remote posts are located under
the hood, in the engine compartment on the driver’s side. The Remote Positive
(+)Post is covered with a protective
cap located on the side of the Front Power Distribution
Center.
The Remote Negative (-)Post is located on the core support
closest to the front of the vehicle.
Jump Starting Remote Post Locations
A — Remote Positive (+)Post
B — Remote Negative (-)Post
6
WHAT TO DO IN EMERGENCIES 267

WARNING!
•Take care to avoid the radiator cooling fan whenever
the hood is raised. It can start anytime the ignition
switch is ON. You can be injured by moving fan
blades.
• Remove any metal jewelry such as rings, watch
bands and bracelets that could make an inadvertent
electrical contact. You could be seriously injured.
• Batteries contain sulfuric acid that can burn your
skin or eyes and generate hydrogen gas which is
flammable and explosive. Keep open flames or
sparks away from the battery.
1. Set the parking brake, shift the automatic transmission into PARK and turn the ignition to the OFF position.
2. Turn off the heater, radio, and all unnecessary electrical accessories.
3. If using another vehicle to jump-start the battery, park the vehicle within the jumper cables reach, set the
parking brake and make sure the ignition is OFF.
WARNING!
Do not allow vehicles to touch each other as this could
establish a ground connection and personal injury
could result.
Jump-Starting Procedure
WARNING!
Failure to follow this jump-starting procedure could
result in personal injury or property damage due to
battery explosion.
CAUTION!
Failure to follow these procedures could result in
damage to the charging system of the booster vehicle
or the discharged vehicle.
Connecting The Jumper Cables
1. Connect the positive (+)end of the jumper cable to the
remote positive (+)post of the discharged vehicle.
