USB RAM PROMASTER 2023 Owners Manual

3
INTERIOR STORAGE AND EQUIPMENT ............... 44 Storage..............................................................44
USB Control — If Equipped ..............................45
Power Outlets ...................................................46
Power Inverter — If Equipped...........................47
Auxiliary Switches — If Equipped .....................47
Wireless Charging Pad —
If Equipped .......................................................48
WINDOWS ............................................................. 49
Power Windows ...............................................49
Window Bar Grates — If Equipped...................49
Wind Buffeting .................................................50
HOOD....................................................................... 50
Opening .............................................................50
Closing...............................................................51
CARGO AREA FEATURES ...................................... 51
GETTING TO KNOW YOUR
INSTRUMENT PANEL
BASE / MIDLINE INSTRUMENT CLUSTER........... 52
Base / Midline Instrument Cluster
Descriptions ......................................................53
INSTRUMENT CLUSTER......................................... 54
Instrument Cluster Descriptions .....................55
INSTRUMENT CLUSTER DISPLAY ........................ 56
Location And Controls ......................................56
Change Engine Oil — If Equipped ....................57
Main Menu........................................................57
Settings .............................................................59 WARNING LIGHTS AND MESSAGES ....................65
Red Warning Lights ..........................................65
Yellow Warning Lights ......................................68
Yellow Indicator Lights .....................................72
Green Indicator Lights .....................................72
Blue Indicator Lights ........................................73
White Indicator Lights ......................................73
ONBOARD DIAGNOSTIC SYSTEM — OBD II ........ 74
Onboard Diagnostic System
(OBD II) Cybersecurity ......................................74
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS.............................................................74
STARTING AND OPERATING
STARTING THE ENGINE ........................................76
Automatic Transmission ..................................76
Normal Starting ................................................76
Tip Start Feature .............................................76
Cold Weather Operation
(Below –22°F Or −30°C) ...............................76
Extended Park Starting ....................................76
If Engine Fails To Start .....................................77
After Starting ....................................................77
ENGINE BLOCK HEATER — IF EQUIPPED ...........77
ENGINE BREAK-IN RECOMMENDATIONS ..........78
PARKING BRAKE ....................................................78
Electric Park Brake (EPB) ................................78 AUTOMATIC TRANSMISSION .............................. 81
Ignition Park Interlock (Keyless Vehicle) ........ 81
Brake/Transmission Shift Interlock (BTSI)
System ............................................................. 81
9-Speed Automatic Transmission ................... 82
POWER STEERING ................................................ 85
ACTIVE SPEED LIMITER — IF EQUIPPED ............ 86
Activation .......................................................... 86
Exceeding The Set Speed ................................ 86
Deactivation ..................................................... 86
INTELLIGENT SPEED ASSIST (ISA) —
IF EQUIPPED ........................................................... 87
Activation .......................................................... 87
Exceeding The Set Speed ................................ 87
Deactivation ..................................................... 87
CRUISE CONTROL SYSTEMS — IF EQUIPPED ... 87
Cruise Control .................................................. 88
Adaptive Cruise Control (ACC) ......................... 89
TRAFFIC SIGN ASSIST SYSTEM —
IF EQUIPPED ........................................................... 98
Activation/Deactivation ................................... 98
Traffic Sign Assist Modes ................................ 98
Indications On The Display .............................. 99
ACTIVE DRIVING ASSIST SYSTEM —
IF EQUIPPED ......................................................... 100
Operation ....................................................... 100Turning Active Driving Assist
On Or Off ........................................................ 101

23_VF_OM_EN_USC_t.book Page 3

GETTING TO KNOW YOUR VEHICLE45
USB CONTROL — IF EQUIPPED

The USB ports are located on the instrument panel to
the right of the radio. This feature allows an external
USB device to be plugged into the USB port.

Plugging in a smartphone device to a USB port
may activate Android Auto™ or Apple CarPlay®
features, if equipped. For further information, refer
to “Android Auto™” or “Apple CarPlay®” in the
Owner’s Manual Supplement.
NOTE:Two devices can be plugged in at the same time,
and both ports will provide charging capabilities.
Only one port can transfer data to the system at
a time.
For example, if a device is plugged into the Type A
USB port and another device is plugged into the
Type C USB port, a message will appear and allow
you to select which device to use.
Different scenarios are listed as follows when a
non-phone device is plugged into the smaller and
larger USB ports, and when a phone device is
plugged into the smaller and larger USB ports:
“A new device is now connected. Previous
connection was lost.”
“(Phone Name) now connected. Previous
connection was lost.”
“Another device is in use through the same USB
port. Please disconnect the first device to use
the second device.”

Plugging in a phone or another USB device may cause
the connection to a previous device to be lost.

AUX Jack And USB Ports

By using a USB cable to connect an external device:

The device can be played on the vehicle’s sound
system, providing the artist, track title, and
album information on the radio display.
NOTE:Depending on track configuration, track infor -
mation may not be present on the radio display.
The device can be controlled using the radio
buttons to play, and browse the contents of the
device.
The audio device battery charges when plugged
into the USB port.
NOTE:Charge unsupported devices with the Charge Only
USB ports. If an unsupported device is plugged into
a Media USB port, a message will display on the
touchscreen that the device is not supported by
the system.
USB Charging Port
The USB connector port can be used for charging
purposes only. Use the connection cable to
connect an external USB device to the vehicle's
USB charging port.
NOTE:If the device battery to be charged is completely
depleted, it may take awhile to charge.
1 — Media USB C and A Ports
WARNING!
Do not plug in or remove the external device
while driving. Failure to follow this warning could
result in a collision.
2

23_VF_OM_EN_USC_t.book Page 45

242SERVICING AND MAINTENANCE
Interior Fuses
The interior fuse panel is part of the Body Control
Module (BCM) and is located on the driver's side
under the instrument panel.
NOTE:Please contact an authorized dealer for BCM fuse
replacement.

Fuse PanelFuse Panel Cavity Locations

CavityMini Fuse Description
F315 Amp Beige INT/A
F33 7.5 Amp Brown +30 TTM
F34 7.5 Amp Brown Clearance Lights
F36 15 Amp Blue +30 (ACM / USB Power Out / USB Recharge / TBM / RRM / DLC)
F37 7.5 Amp Brown INT (IPC – DASM / AEB)
F38 20 Amp Yellow Central Locking
F42 5 Amp Beige INT (BSM / BRAKE NC) / EPS
F43 20 Amp Yellow Bi-Directional Washer Pump
F47 20 Amp Yellow Driver Power Window
F48 20 Amp Yellow Passenger Power Window
F49 5 Amp Beige INT (RRM / TTM / SBDU / XAN / JHC / RFX)
F50 7.5 Amp Brown INT (ORC)
F51 7.5 Amp Brown INT (REAR CAMERA-AUX) / HALF / DRVM/ PAM / CVPM / EMC / TCM / STM / ASS / SGW

23_VF_OM_EN_USC_t.book Page 242

286 Gauges Fuel
............................................................. 69Gear Ranges.................................................... 82Gear Selector Override.................................. 217Glass Cleaning............................................... 268Gross Axle Weight Rating..................... 123, 125Gross Vehicle Weight Rating................ 123, 124GuideBody Builders................................................ 8GVWR............................................................ 123
H
HazardDriving Through Flowing, Rising, Or Shallow Standing Water
..................................... 131Hazard Warning Flashers.............................. 193Head Restraints............................................... 28HeadlightsAutomatic.................................................... 34Cleaning.................................................... 266High Beam.................................................. 34High Beam/Low Beam Select Switch.......... 34Passing........................................................ 34Switch......................................................... 33Heated Mirrors................................................ 33Heated Seats................................................... 26Heater, Engine Block....................................... 77High Beam/Low Beam Select (Dimmer)
Switch.............................................................. 34Hill Start Assist.............................................. 155
HitchesTrailer Towing........................................... 126Hood Prop........................................................ 50Hood Release.................................................. 50
I
Ignition............................................................. 16Switch.......................................................... 16Illuminated Entry.............................................. 38Immobilizer (Sentry Key).................................. 16Inside Rearview Mirror............................30, 193Instrument ClusterDescriptions................................................ 55Display......................................................... 56Display Controls........................................... 56Menu Items................................................. 57Instrument Panel Lens Cleaning................... 267Intelligent Speed Assist................................... 87Interior And Instrument Lights......................... 36Interior Appearance Care.............................. 266Interior Lights................................................... 36Intermittent Wipers (Delay Wipers).................. 39InverterPower.......................................................... 47iPod/USB/MP3 Control.................................... 45
J
Jack Location................................................ 196Jack Operation.............................................. 196Jacking And Tire Changing............................ 196
Jacking And Tire Changing
S
..................... 196Jacking And Tire Changing Instructions......... 197Jump Starting................................................ 214
K
Key Fob............................................................13Programming Additional Key Fobs...............15Key Fob Battery Service (Remote
Keyless Entry)..................................................14Key Fob Programming (Remote
Keyless Entry)..................................................15Keyless Enter ‘n Go™.......................................22Passive Entry...............................................22Keys.................................................................13Replacement...............................................15Sentry (Immobilizer).....................................16
L
Lane Change Assist..........................................35LaneSense.................................................... 116Lap/Shoulder Belts....................................... 172Latches......................................................... 191Hood............................................................50Lead Free Gasoline....................................... 270Leaks, Fluid................................................... 191Life Of Tires................................................... 258Light Bulbs........................................... 191, 244

23_VF_OM_EN_USC_t.book Page 286

290 Transmission Automatic
........................................... 81, 236Fluid.......................................................... 274Maintenance............................................. 236Transmission Fault Warning Light................... 68Transporting Pets.......................................... 190Tread Wear Indicators................................... 258
U
Uconnect SettingsCustomer Programmable Features
.... 22, 134Passive Entry Programming......................... 22Uniform Tire Quality Grades........................... 264Unleaded Gasoline........................................ 270Untwisting Procedure, Seat Belt.................... 174USB................................................................. 45
V
Vehicle Certification Label............................ 123Vehicle Identification Number (VIN).............. 269Vehicle Loading.......................... 123, 124, 253Vehicle Modifications/Alterations...................... 8Vehicle Storage.......................................43, 265Voice Command............................................... 29Voice Recognition System (VR)........................ 29
W
Warning Lights (Instrument Cluster
Descriptions)
.................................................... 69Warning Lights And Messages......................... 65Warranty Information.................................... 278WasherAdding Fluid.............................................. 226Washing Vehicle........................................... 266WaterDriving Through........................................ 131
Wheel And Wheel Tire Care........................... 262Wheel And Wheel Tire Trim........................... 262Wind Buffeting.................................................50Window Fogging...............................................43Windows..........................................................49Power...........................................................49Windshield Defroster.................................... 190Windshield Washers....................... 38, 39, 226Fluid.............................................................39Windshield Wiper Blades.............................. 231Windshield Wipers....................................38, 39Wipers Blade Replacement........................... 231Wipers, Intermittent.........................................39Wipers, Rain Sensitive.....................................39Wireless Charging Pad.....................................48

23_VF_OM_EN_USC_t.book Page 290
