check engine RENAULT SCENIC 2011 J95 / 3.G Engine And Peripherals EDC16C36 Repair Manual

13B-98V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF056
CONTINUED 3
1.DEFNOTESPriorities when dealing with a number of faults:
Deal with fault DF013 Sensor supply voltage no. 3, 1.DEF
first, if it is present or stored.
Check the condition of the air flowmeter connector (see Wiring Diagram Technical Note, Megane II ph2, Scenic
II ph2, component code 799).
Check the condition of the engine management computer connector (see Wiring Diagram Technical Note,
Mégane II ph2, Scénic II ph2, component code 120).
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check for continuity and absence of interference resistance of the following connections:
– Connection code 3DW between components 799 and 120.
– Connection code 3DV between components 799 and 120.
– Connection code 3KJ between components 799 and 120.
If there is a repair method (see Technical Note 6015A, Repairing electrical wiring, Wiring: Precautions for
repair), repair the wiring, otherwise replace it.
Check the condition of the flowmeter: no visible damage to the nearby flowmeter element.
If the fault is still present, replace the air flowmeter.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-99V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF059
PRESENT
OR
STOREDCOMBUSTION MISFIRES ON CYLINDER 1
1.DEF: Above maximum threshold
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault is declared present after:
– engine speed is between idling speed and 1050 rpm PR055 Engine speed,
–PR064 Coolant temperature ≥ 50°C.
Priorities when dealing with a number of faults:
Apply the interpretation of faults DF026 CYLINDER 1 INJECTOR CONTROL
CIRCUIT and DF249 Injector control first if they are present or stored.
Special notes:
Check that the stored injector codes are consistent with those engraved on each
injector. If not, run command SC002 Enter injector codes and follow the procedure,
After an injector has been replaced, run command SC002 Enter injector codes and
command SC036 Reintialise programming and follow the procedure.
IMPORTANT
Possible absence of combustion on one cylinder even though the injector is properly
fed.
Cylinder no. 1 is located at the timing end.
Do not disconnect the injectors when the engine is running.
When removing or refitting an injector, follow the cleanliness and safety instructions
(see MR 364 (Mégane) or 370 (Scénic), Mechanical, 13B, Diesel injection, Diesel
injector: Removal - Refitting).
EDC16C36_V44_DF059/EDC16C36_V4C_DF059/EDC16C36_V48_DF059/EDC16C36_V50_DF059/EDC16C36_V54_DF059/
EDC16C36_V58_DF059
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-100V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF059
CONTINUED
DF059 appears on the diagnostic tool when the engine management computer has detected a fault during the
combustion phase several times in succession.
Several components may be responsible:
– the piston rings,
– the piston,
– the valves,
– the injector,
– the heater plug sealing.
If the fault is present:
– remove the injector concerned,
– if there is no obvious fault in the way the injector has been fitted (notably the injector washer), swap the injector
with another from the engine.
– Run commands SC002 Enter injector codes and SC036 Reintialise programming and follow the procedures.
– Restart the engine.
– If the injector concerned produces another combustion misfire in its new position, replace it.
If the fault is stored:
check that no customer complaint has been declared; clear the fault and carry out a road test.
If the fault is still present, apply test 10: Incorrect injector operation.
If the fault is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-101V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF060
PRESENT
OR
STOREDMISFIRING ON CYLINDER 2
1.DEF: Above max threshold
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault is declared present after:
– engine speed is between idling speed and 1050 rpm PR055 Engine speed,
–PR064 Coolant temperature ≥ 50°C.
Priorities when dealing with a number of faults:
Apply the interpretation of faults DF027 CYLINDER 2 INJECTOR CONTROL
CIRCUIT and DF249 Injector control first if they are present or stored.
Special notes:
Check that the stored injector codes are consistent with those engraved on each
injector. If not, run command SC002 Enter injector codes and follow the procedure.
After an injector has been replaced, run command SC002 Enter injector codes and
command SC036 Reintialise programming and follow the procedure.
IMPORTANT
Possible absence of combustion on one cylinder even though the injector is properly
fed.
Cylinder no. 1 is located at the timing end.
Do not disconnect the injectors when the engine is running.
When removing or refitting an injector, follow the cleanliness and safety instructions
(see MR 364 (Mégane) or 370 (Scénic), Mechanical, 13B, Diesel injection, Diesel
injector: Removal - Refitting).
EDC16C36_V44_DF060/EDC16C36_V4C_DF060/EDC16C36_V48_DF060/EDC16C36_V50_DF060/EDC16C36_V54_DF060/
EDC16C36_V58_DF060
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-102V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF060
CONTINUED
DF060 appears on the diagnostic tool when the engine management computer has detected a fault during the
combustion phase several times in succession.
Several components may be responsible:
– the piston rings,
– the piston,
– the valves,
– the injector,
– the heater plug sealing.
If the fault is present:
– remove the injector concerned,
– if there is no obvious fault in the way the injector has been fitted (notably the injector washer), swap the injector
with another from the engine.
– Run commands SC002 Enter injector codes and SC036 Reintialise programming and follow the procedures.
– Restart the engine.
– If the injector concerned produces another combustion misfire in its new position, replace it.
If the fault is stored:
check that no customer complaint has been declared; clear the fault and carry out a road test.
If the fault is still present, apply test 10: Incorrect injector operation.
If the fault is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-103V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF061
PRESENT
OR
STOREDMISFIRING ON CYLINDER 3
1.DEF: Above max threshold
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault is declared present after:
– engine speed is between idling speed and 1050 rpm PR055 Engine speed,
–PR064 Coolant temperature ≥ 50°C.
Priorities when dealing with a number of faults:
Apply the interpretation of faults DF028 Cylinder 3 injector control circuit and DF249
Injector control first if they are present or stored.
Special notes:
Check that the stored injector codes are consistent with those engraved on each
injector. If not, run command SC002 Enter injector codes and follow the procedure.
After replacing an injector, run commands SC002 Enter injector codes and SC036
Reinitialise programming, follow the procedures.
IMPORTANT
Possible absence of combustion on one cylinder even though the injector is properly
fed.
Cylinder no. 1 is located at the timing end.
Do not disconnect the injectors when the engine is running.
When removing or refitting an injector, follow the cleanliness and safety instructions
(see MR 364 (Mégane) or 370 (Scénic), Mechanical, 13B, Diesel injection, Diesel
injector: Removal - Refitting).
EDC16C36_V44_DF061/EDC16C36_V4C_DF061/EDC16C36_V48_DF061/EDC16C36_V50_DF061/EDC16C36_V54_DF061/
EDC16C36_V58_DF061
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-104V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF061
CONTINUED
DF061 appears on the diagnostic tool when the engine management computer has detected a fault during the
combustion phase several times in succession.
Several components may be responsible:
– the piston rings,
– the piston,
– the valves,
– the injector,
– the heater plug sealing.
If the fault is present:
– remove the injector concerned,
– if there is no obvious fault in the way the injector has been fitted (notably the injector washer), swap the injector
with another from the engine.
– Run commands SC002 Enter injector codes and SC036 Reintialise programming and follow the procedures.
– Restart the engine.
– If the injector concerned produces another combustion misfire in its new position, replace it.
If the fault is stored:
check that no customer complaint has been declared; clear the fault and carry out a road test.
If the fault is still present, apply test 10: Incorrect injector operation.
If the fault is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-105V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF062
PRESENT
OR
STOREDMISFIRING ON CYLINDER 4
1.DEF: Above max threshold
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault is declared present after:
– engine speed is between idling speed and 1050 rpm, PR055 Engine speed
–PR064 Coolant temperature ≥ 50°C.
Priorities when dealing with a number of faults:
Apply the interpretation of faults DF029 CYLINDER 4 INJECTOR CONTROL
CIRCUIT and DF249 Injector control first if they are present or stored.
Special notes:
Check that the stored injector codes are consistent with those engraved on each
injector. If not, run command SC002 Enter injector codes and follow the procedure.
After replacing an injector, run commands SC002 Enter injector codes and SC036
Reinitialise programming, follow the procedures.
IMPORTANT
Possible absence of combustion on one cylinder even though the injector is properly
fed.
Cylinder no. 1 is located at the timing end.
Do not disconnect the injectors when the engine is running.
When removing or refitting an injector, follow the cleanliness and safety instructions
(see MR 364 (Mégane) or 370 (Scénic), Mechanical, 13B, Diesel injection, Diesel
injector: Removal - Refitting).
EDC16C36_V44_DF062/EDC16C36_V4C_DF062/EDC16C36_V48_DF062/EDC16C36_V50_DF062/EDC16C36_V54_DF062/
EDC16C36_V58_DF062
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-106V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF062
CONTINUED
DF062 appears on the diagnostic tool when the engine management computer has detected a fault during the
combustion phase several times in succession.
Several components may be responsible:
– the piston rings,
– the piston,
– the valves,
– the injector,
– the heater plug sealing.
If the fault is present:
– remove the injector concerned,
– if there is no obvious fault in the way the injector has been fitted (notably the injector washer), swap the injector
with another from the engine.
– Run commands SC002 Enter injector codes and SC036 Reintialise programming and follow the procedures.
– Restart the engine.
– If the injector concerned produces another combustion misfire in its new position, replace it.
If the fault is stored:
check that no customer complaint has been declared; clear the fault and carry out a road test.
If the fault is still present, apply test 10: Incorrect injector operation.
If the fault is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-107V9 MR-372-J84-13B450$102.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF065
PRESENT
OR
STOREDCOMBUSTION MISFIRES
1.DEF: Above max threshold
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault is declared present after:
– engine speed is between idling speed and 1050 rpm PR055 Engine speed,
– a coolant temperature ≥ 50°C PR064 Coolant temperature.
Priorities when dealing with a number of faults:
DF249 Injector control, present or stored,
DF026 Injector 1 control circuit, present or stored,
DF027 Injector 2 control circuit, present or stored,
DF028 Injector 3 control circuit, present or stored,
DF029 Injector 4 control circuit, present or stored.
IMPORTANT
When removing or refitting an injector, observe the cleanliness and safety instructions
(see MR 364 (Mégane) or 370 (Scénic), Mechanical, 13B, Diesel injection, Diesel
injector: Removal - Refitting).
IMPORTANT
Possible absence of combustion on one cylinder even though the injector is properly
fed.
Do not disconnect the injectors when the engine is running.
EDC16C36_V44_DF065/EDC16C36_V4C_DF065/EDC16C36_V48_DF065/EDC16C36_V50_DF065/EDC16C36_V54_DF065/
EDC16C36_V58_DF065
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58
