DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP10 Engine hesitation
NOTESOnly consult this customer complaint after a full check with the diagnostic tool.
See Feature, Function: Fuel supply management (timing, flow rate and pressure),
Flow capacity function (VLC) section.
Check that the fuel tank is correctly filled and that the fuel is correct by running TEST 13 Diesel fuel conformity
check.
Check the low pressure circuit by running TEST 1 Low pressure circuit check.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Is the engine wiring harness cut or pinched? Carry out the necessary repairs.
Is the compression in order? Carry out the necessary repairs.
Is the valve clearance set correctly? Carry out the necessary repairs.
YES
NO
NO
YES
NO
A
YES
DDCR_V44_ALP10/DDCR_V48_ALP10

13B-182
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP10
CONTINUED
Check the high pressure pump by running
TEST 6 High pressure system check.The vehicle has entered the "Flow capacity
function" program. This function is activated more
easily when: the external temperature is high, the
fuel level in the tank is at 1/4, the vehicle is laden
and if the vehicle speed is high. Is the "Flow capacity function"
programming active (ET563)?
Check the computer:
Check that the computer connectors are
properly locked.
Check the condition of the computer
connections (bent pin, signs of corrosion,
silicone, etc.).
If the connector(s) is faulty and if there is a
repair procedure (see Technical Note 6015A,
Repairing electrical wiring, Wiring:
Precautions for repair), repair the connector,
otherwise replace the wiring.Check the diesel filter.
Has the diesel fuel filter reached its full mileage?
Replace the diesel filter (see MR 364 (Mégane II)
or MR 370 (Scénic II), Mechanical, 13A, Fuel
supply, Fuel filter: Removal - Refitting).
Contact the Techline if the customer complaint is
still present.
Contact the Techline if the customer complaint
is still present.
A
YES
NO
YES

13B-183
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
OCR*: opening cyclic ratio
ALP11 Loss of power
NOTESSpecial note:
Only consult this customer complaint after a full check with the diagnostic tool.
See explanation for flow capacity function in system operation.
In this case, the lack of power is due to insufficient vacuum for the OCR * setpoint given.
Is the "Flow capacity function" programming
active (ET563)?Check the diesel filter.
Is it close to the replacement mileage?
Using the diagnostic tool, check that the injector
codes (C2I) are correctly entered on the identification
screen. If not, configure the correct injector codes
using command SC002 Enter injector codes.Replace the diesel filter (see MR 364
(Mégane II) or MR 370 (Scénic II),
Mechanical, 13A, Fuel supply, Fuel filter:
Removal - Refitting).
Check the air inlet circuit by running TEST 5 Inlet
circuit check.
Is the engine oil level correct? Top up the oil level.
Is the catalytic converter clogged or damaged?Replace the catalytic converter (see MR
364 (Mégane II) or MR 370 (Scénic II),
19B, Exhaust, Catalytic converter:
Removal - Refitting).
YES
NO
NO
YES
NO
YES
YES
A
NO
DDCR_V44_ALP11/DDCR_V48_ALP11

13B-184
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP11
CONTINUED
Check that the turbocharger is working properly.
Run TEST 11 Air line at the turbocharger.
Run TEST 10 Turbocharger solenoid valve check.
Run TEST 12 Turbocharger.
Are the components in good condition? Carry out the necessary repairs.
Check the low pressure circuit by running TEST 1 Low pressure circuit check.
Check the injectors by running TEST 3 Injector check.
Check the high pressure system by running TEST 6 High pressure system check.
Is the compression in order? Carry out the necessary repairs.
Is the valve clearance set correctly? Carry out the necessary repairs.
Contact the Techline if the customer complaint is still
present.
A
NO
NO
YES
NO
YES
NO
YES

13B-185
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP12 Too much power
NOTESOnly consult this customer complaint after a full check with the diagnostic tool.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Check the air inlet circuit by running TEST 5 Inlet circuit check.
Check that the engine has not sucked up its oil (engine racing).
Check the injectors: run TEST 3 Injector check.
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
DDCR_V44_ALP12/DDCR_V48_ALP12

13B-186
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP 13 Excessive consumption
NOTESOnly consult this customer complaint after a full check with the diagnostic tool.
Check that the fuel tank is correctly filled and that the fuel is correct by running TEST 13 Diesel fuel conformity
check.
Check the levels of engine oil and coolant.
Is the fuel temperature sensor leaking?Replace the fuel temperature sensor
(see MR 364 (Mégane II) or MR 370
(Scénic II), Mechanical, 13B, Diesel
injection, Rail pressure sensor:
Removal - Refitting).
Check the low pressure circuit by running TEST 1 Low pressure circuit check.
Check the injectors by running TEST 3 Injector check.
Visually check that there are no leaks on the high pressure circuit by running TEST 7 High pressure circuit
sealing check.
Check the air inlet circuit by running TEST 5 Inlet circuit check.
YES
NO
A
DDCR_V44_ALP13/DDCR_V48_ALP13

13B-187
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP 13
CONTINUED
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Is the compression in order? Carry out the necessary repairs.
Is the catalytic converter clogged or damaged?Replace the catalytic converter (see MR
364 (Mégane II) or MR 370 (Scénic II),
Mechanical, 19B, Exhaust, Catalytic
converter: Removal - Refitting).
Check that the turbocharger is working properly.
Run TEST 11 Air line at the turbocharger.
Run TEST 10 Turbocharger solenoid valve
check.
Run TEST 12 Turbocharger.
Is the turbocharger in order? Carry out the necessary repairs.
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
A
NO
YES
YES
NO
YES
NO

13B-188
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP14 Engine races when accelerator is released or when changing gear
NOTESOnly consult this customer complaint after a full check with the diagnostic tool.
Check that there are no obstacles that might impede the accelerator pedal travel (carpet, point of resistance, etc.).
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Visually check the condition of the engine wiring harness.
Is the clutch clearance set correctly? Carry out the necessary repairs.
Check that the engine has not sucked up its oil (engine racing).
Is the compression in order? Carry out the necessary repairs.
Check that the turbocharger is working properly.
Run TEST 11 Air line at the turbocharger.
Run TEST 10 Turbocharger solenoid valve check.
Run TEST 12 Turbocharger.
Is the turbocharger in order?Carry out the necessary repairs.
NO
YES
NO
YES
NO
YES
A
DDCR_V44_ALP14/DDCR_V48_ALP14

13B-189
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP14
CONTINUED
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
A
YES

13B-190
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP15 Engine dies on pulling away
NOTESOnly consult this customer complaint after a full check with the diagnostic tool.
Is the clutch clearance set correctly? Carry out the necessary repairs.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Check the air inlet circuit by running TEST 5 Inlet circuit check.
Is the catalytic converter clogged or damaged?Replace the catalytic converter (see MR
364 (Mégane II) or MR 370 (Scénic II),
Mechanical, 19B, Exhaust, Catalytic
converter: Removal - Refitting).
Check the low pressure circuit by running TEST 1 Low pressure circuit check.
Visually check the condition of the engine wiring harness.
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
NO
YES
YES
NO
DDCR_V44_ALP15/DDCR_V48_ALP15
