RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-28
HEATING
Distribution unit: Removal - Refitting
STANDARD HEATING
61A
aFit the (Ms. 583)  (4) on the heater matrix inlet and
outlet hoses.
aSeparate the heater matrix inlet and outlet hose clips

Page 32 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-29
HEATING
Distribution unit: Removal - Refitting
STANDARD HEATING
61A
-the instrument panel (see Instrument panel: Re-
moval - Refitting) (83A, Instrument panel),
-the control panel (see 61A, Hea

Page 33 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-30
HEATING
Distribution unit: Removal - Refitting
STANDARD HEATING
61A
REFITTING
I - REFITTING PREPARATION OPERATION
aRefit the components to the distribution unit:
-the heating resistor,
-the cab

Page 34 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-31
HEATING
Distribution unit: Removal - Refitting
STANDARD HEATING
61A
aRefit the air outlet pipe onto the air filter unit.
aFit the air filter unit air inlet pipe.
aRefit:
-the scoop under the sc

Page 35 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-32
HEATING
Distribution unit: Removal - Refitting
AIR CONDITIONING
61A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aDrain the coolant circuit using the refrigerant
charging station (see 62A, Air con

Page 36 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-33
HEATING
Distribution unit: Removal - Refitting
AIR CONDITIONING
61A
aLoosen the clip (3) of the air outlet pipe on the air fil-
ter unit.
aRemove the air outlet pipe from the air filter unit (4

Page 37 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-34
HEATING
Distribution unit: Removal - Refitting
AIR CONDITIONING
61A
aFit the (Ms. 583)  (8) on the heater matrix inlet and
outlet hoses.
aSeparate the heater matrix inlet and outlet hose clips

Page 38 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-35
HEATING
Distribution unit: Removal - Refitting
AIR CONDITIONING
61A
aRemove:
-the bolts (10) from the distribution unit,
-the dashboard cross member (see Dashboard
cross member: Removal - Refit

Page 39 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-36
HEATING
Distribution unit: Removal - Refitting
AIR CONDITIONING
61A
aRefit the storage compartment.
aRefit the radio (see Radio: Removal - Refitting)
(86A, Radio).
aRefit the tweeters (see Twee

Page 40 of 122

RENAULT TWINGO 2009 2.G Air Conditioning Owners Guide 61A-37
HEATING
Distribution unit: Removal - Refitting
AIR CONDITIONING
61A
aCheck for leaks (see 62A, Air conditioning, Refrig-
erant circuit: Check, page 62A-7) .
