69 9-3 Convertible
Safety belts, rear seat,
ConvertibleThe two rear seats have three-point safety
belts with inertia reels.
Fasten the belt by pulling the belt and insert-
ing the tongue in the buckle. Check that it is
securely fastened.
Position the lap part low across the hips.
Grasp the shoulder belt close to the buckle
and pull the belt towards the shoulder to
tighten the lap belt part.
The belt must be as far in on the shoulder as
possible.
Press the red button on the belt buckle to
release the belt.
Refer to page 251 for how to check the func-
tion of the safety belts, cleaning, etc.
For how to secure loads on the rear seat,
refer to page 16.
WARNING
 If cargo has to be placed on a seat, it
must be properly secured with the
safety belt. This reduces the risk of the
cargo being thrown about during hard
braking or a crash, which could cause
personal injury.
 Check that the belt is not twisted or
lying against sharp edges.
 Make sure you use the correct seat-
belt buckle.Safety belts, rear seat, Convertible
ProCarManuals.com

70 9-3 ConvertibleRollover Pop-up BarsThe Rollover Pop Up Bars, which are
located behind each rear seat head
restraint, along with the windshield frame
and the seatbelt pretensions, are designed
to deploy in the event of a crash or rollover.
WARNING
You can be severely injured or killed in a
crash if you are not wearing your safety
belt - even if you have airbags and Roll-
over Pop Up Bars. Wearing your safety
belt during a crash helps reduce your
chance of hitting things inside the vehicle
or being ejected from it.
 The Rollover Pop Up Bars have pow-
erful springs that rapidly extend the
bars in rollover crashes, as well as in
moderate to severe crashes in which
the airbags deploy. Rollover Pop Up
Bars are supplemental to the safety
belts. They are designed to work with
safety belts but do not replace them.
 Rollover Pop Up Bars deploy with
great force, and you could be injured if
your arm or other body part, or if an
object is covering the bars when they
deploy. Don't put anything on the
cover of the Rollover Pop Up Bars.
The path of the Rollover Pop Up Bars
must be kept clear.
 The Rollover Pop Up Bars are
designed to deploy only once. If they
deploy, take your vehicle to your Saab
dealer immediately to have the Rollo-
ver Pop Up Bars repaired so that they
operate properly in the event of a
crash or rollover.NOTICETo avoid the risk of damage to the soft top
do not operated the soft top while the
bars are extended.
Rollover Pop-up Bars
ProCarManuals.com

71 9-3 Convertible
Electric windows
To openSoft top raised – The windows open individ-
ually.
Soft top folded – The button for the front
window opens both side windows.
Automatic opening: Press the button all
the way down and release it. If the soft top
is folded, the rear side window is also low-
ered.
To closeSoft top raised – The windows are operated
individually.
Soft top folded – The button for the front
window closes both side windows.
Automatic closing of a front side
window: Raise the button all the way and
release it. The rear side window must be
fully closed. Pinch protection (option) is
available for the front side windows.
For further information on the electric win-
dows, refer to page 123.Deactivating the passenger door
window buttonWith the button on the driver’s door,
you can deactivate the window button on
the passenger door.
The illuminated switch will change color
from green to amber (deactivated).
WARNING
Bear in mind the pinch hazard when clos-
ing the side windows. May cause serious
or fatal injuries!
Always remove the remote control
from the ignition switch when you
leave the car to prevent personal
injury caused by the activation of the
electric windows, for example, due to
children playing.
 The person operating the electric
window is responsible for ensuring
that no one, especially a child, has
their head, hands or fingers in the
window openings, before raising the
window.
 Do not stick any part of the body or the
head out through an open window
while the car is moving.
Window switches
ProCarManuals.com

72 9-3 ConvertibleCalibrating front electric
windows with pinch protection(option)
The window lifts should be calibrated if auto-
matic closing does not work or if the battery
has been disconnected. The pinch protec-
tion will not work if the windows are not
calibrated.
Perform calibration as follows:
1 Make sure the soft top is raised.
2 Make sure the doors are closed.
3 Let the engine idle.
4 Press and hold the soft top button up
until a chime sounds.
During calibration, the four windows will
be raised and lowered several times.
If calibration fails twice in a row, have the car
checked and rectified at a Saab dealer.
Interior lightingThe interior lighting consists of a front roof
light, two front reading lights, footwell light-
ing and courtesy lighting in the doors. The
light switches are located in the roof con-
sole.
The cabin lighting comes on:
 When a door is opened and the ignition is
OFF.
 When the remote control is removed from
the ignition switch.
The lighting goes out:
 When the car is locked.
 When the ignition is turned on.
 Approx. 20 s after closing all doors.
The lights are dimmed out gradually.
If a door is left open with the ignition OFF,
the interior lighting goes out automatically
after 5 min so as not to drain the battery.
The interior lighting can be switched off
completely.
1 Open the driver’s door.
2 Turn off the cabin lighting with the center
button, see illustration.
This is canceled when the ignition switch is
turned to position ON or when the car is
locked with the remote control.
Front interior lighting - Convertible1 Left-hand reading light
2 Cabin light
3 Right-hand reading light
ProCarManuals.com

73 9-3 Convertible
Glove boxThe glove box lighting comes on when the
compartment is opened and goes out when
it is closed.
For changing bulbs, refer to page 223.Sun visorAn illuminated vanity mirror is provided on
the inside of the sun visors. The lighting
comes on when the cover is raised and goes
out when it is closed.Trunk lightingThe trunk lighting comes on and goes out
when the trunk lid is opened and closed.
If the trunk lid is left open, the lighting will be
switched off automatically after 20 min to
prevent the battery from running flat.
For changing bulbs, refer to page 225.
Unlocking the trunk lid
manuallyIf the trunk lid is not unlocked by the central
locking system, it can be unlocked
manually.
1 Take the traditional key out of the remote
control by pressing the emblem on the
reverse (see page 48).
2 Carefully prise off the round cover using
your nails, a credit card or similar so as
not to damage the paintwork.
3 Unlock the trunk lid using the traditional
key.
Contact a Saab dealer to have the central
locking system checked.
Unlocking the trunk lid manually
ProCarManuals.com

74 9-3 ConvertibleManually opening the
fuel filler doorConvertible
If the fuel filler door, which is controlled by
the central locking system, does not unlock,
proceed as described below.
Check fuse 7 in the fuse panel at the end of
the fascia (see page 229). If this fuse has
blown or the new fuse blows, the fuel filler
door can be opened as follows:
1 Open the two cut-out openings in the
side trim on the right-hand side of the
luggage compartment.
2 Loosen the two screws (do not unscrew
them fully). Lift up the screws and press
them out of their key hole slots.
Contact a Saab dealer to have the central
locking system checked.
Placing two golf bags
in the trunkThere is sufficient space in the trunk of the
Convertible for two golf bags. Proceed as
follows.
1 Start by inserting the narrow end of the
first bag to the right.
2 Lie down the bag. Turn the bag so that it
lies on its widest side and slide it for-
ward, in under the soft top storage (see
illustration).
3 Put in the second bag in the same way
as the first, but lie it on its narrow side
(see illustration).
Manually opening the fuel filler door, Con-
ver tible
ProCarManuals.com

75 9-3 Convertible
Spoiler on trunklid
Wind deflectorA wind deflector is available as an acces-
sory. Follow the fitting instructions supplied
with the wind deflector carefully.CargoWing(accessory)
WARNING
Some models have a spoiler on the trunk-
lid. Avoid getting fingers and hands
trapped between the spoiler and rear
fender when closing the trunklid.NOTICEIf play arises in any part of the
CargoWing, contact a Saab workshop
immediately to have this corrected. If
such play is not eliminated, the
CargoWing may come loose while driv-
ing.
Position of first golf bag Position of second golf bag
ProCarManuals.com

76 9-3 Convertible(This page has been left blank)
ProCarManuals.com

77 Instruments and controls
Warning and indicator
lights _______________ 78
Instruments ___________ 82
Information display,
main instrument panel _ 85
Saab Information Display
(SID) ________________ 87
Switches _____________ 96
Wipers and washers ____ 100
Manual climate-control
system ______________ 103
Automatic climate-
control system (ACC)__ 108
Instruments and controls
ProCarManuals.com

78 Instruments and controls
Warning and indicator
lightsThe following warning and indicator lights
are found on the main instrument panel.This warning light illuminates when a fault
arises in the antilock brake system.
The following message is shown on the
Saab Information Display (SID):
The brake system will continue to function
but without ABS modulation.
This light comes on when the battery is not
being charged by the alternator. If the light
comes on during driving, stop as soon as
possible and switch off the engine.
Check the drive belt, see page 210.
Antilock braking warningAntilock brake malfunction.
Contact Saab dealer.Charge warning light
Main instrument panel1 Tachometer
2 Speedometer
3 Turbo gauge
4 Fuel gauge5 Engine temperature gauge
6 Information display
7 Trip meter reset button
Main instrument panel (Arc panel shown)
U.S. shown, Canada similar
