SAAB 9-3 2006 Owners Manual

141 Interior equipment
Interior lightingThe interior lighting consists of one front and
one rear roof light, floor lighting, and cour-
tesy lights in the doors (certain variants
only). The light switch for the interior lighting
is located on the roof console by the rear-
view mirror.When the switch is in the mid-position (door-
activated), the interior lighting will come on:
 When the car is unlocked.
 When a door is opened and the ignition is
OFF.
 When the remote control is removed from
the ignition switch.
The lighting goes out:
 When the car is locked.
 When the ignition is turned on.
 Approx. 20 s after closing all doors.
The lights are dimmed out gradually.
If a door is left open and the light switch is in
position 2 or 3 and the ignition is OFF, the interior lighting will be switched off automat-
ically after 20 minutes to save the battery.
The glove box lighting is switched on and off
automatically when the glove box is opened
and closed.1 Interior lighting always off
2 Interior lighting controlled by the doors
3 Interior lighting on continuously
Rear lighting1 Reading lights
2 Roof light
93U S M 06.book Page 141 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

142 Interior equipmentSun visorIlluminated vanity mirrors are provided on
the sun visors. The lighting comes on when
the cover is raised.
Trunk lightingThe trunk lighting is switched on and off
when the trunk lid is opened and closed.
If the trunk lid is left open, the lighting will be
switched off automatically after 20 minutes
to prevent the battery from running flat.
Cup holder3Cup holders are provided in the fascia, in
the center console compartment between
the front seats and rear seat cushion (Sport
Sedan and SportCombi). The cup holder
between the seats can be raised if you wish
to use the compartment for storage.
WARNING
 The cup holder should not be used to
hold cups made of china or glass as
these can cause personal injury in the
event of a crash.
 Use only paper mugs, plastic bottles
or aluminium cans.
 Avoid spillage, particularly of hot
drinks.NOTICETake care not to spill any liquid on the
audio system , the ignition switch or the
like when using the cup holders. Soft
drinks in particular can cause malfunc-
tions.
Sun visor with vanity mirror93U S M 06.book Page 142 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

143 Interior equipment
Cup holder in fascia
Cup holder in center console compart-
ment between front seats
3
Cup holder in rear seat cushion
3
93U S M 06.book Page 143 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

144 Interior equipmentPower Outlet3You can use the electrical socket in the stor-
age compartment under the armrest
between the front seats to charge a mobile
phone, for example. There is a recess on
each side of the compartment which will
accept a lead so that you can close the lid
without damaging the charger lead.
Storage compartmentsThere are additional storage compartments
below the front ashtray and in the doors.
WARNING
The maximum output of the cigarette
lighter socket is 240 W (20 A). The rating
of the socket in the compartment between
the seats is the same. Overloading can
result in melting or even fire.
WARNING
The glove box must be closed while trav-
elling. An open glove box door could
cause personal injury in the event of a
crash.
Open the glove box with the button on the
left of the moulding.
Convertible has lockable glove box. Use
the traditionally key, see page 56.
93U S M 06.book Page 144 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

145 Interior equipment
Sliding cover in glove box to admit cold
air
3.
This allows the storage of chocolate dur-
ing hot weather for example.
Storage compartment between front seats
Storage pocket on front edge of seats
3
Storage pocket on back of seats
3
Card holder
93U S M 06.book Page 145 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

146 Interior equipmentTrunkFolding down the rear seat, Sport SedanConvertible: The rear seat cannot be folded.
WARNING
 Never drive the car if the backrest is not correctly locked into
position as this increases the risk of personal injury in the
event of heavy braking or a crash.
 Never leave a child or animal unattended in the car. During
sunny weather the temperature in the passenger and trunk
can climb to 160–180°F (70–80°C). Small children are very
susceptible to heat stroke.
 Keep hands well clear of all moving parts.
 Never place heavy objects on the parcel shelf. There is always
a danger of loose objects being thrown forward and causing
injury if the car should brake suddenly or be involved in a
crash. See also page 204.
 When folding the backrest back upright, make sure that it is
locked correctly on both sides. This is imperative since the
center safety belt is mounted in the backrest.
 When folding the backrest back upright, make sure that it is
locked correctly on both sides. This is imperative since other-
wise objects in the trunk could force their way into the cabin
during heavy breaking or a crash.
 Adjust the head restraints for the rear seats to be occupied to
a suitable height before riding in the car.
93U S M 06.book Page 146 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

147 Interior equipment
For greater flexibility, the rear seat is split so that the narrow and
the wide part can be folded down separately.
Next to the hinges in the trunk are handles for unlocking the rear seat
backrests.
The operation is easier if the front seats are not too far back and
the rear seat head restraints are fully lowered.
1 Unlock the backrest by pulling the appropriate handle in the
trunk.
2 Fold the backrest forward.
Note: When returning the backrest to its upright position, make
sure that it locks properly in place and that the safety belt does
not get caught.
If the left-hand backrest is not properly locked in position, the follow-
ing message is displayed on the SID (equivalent message displayed
for right-hand backrest):
Trunk Release Handle, see page 149.
Emergency opening of the narrow backrest, Sport Sedan, see
page 150.Rear left seat backrest
unlocked.93U S M 06.book Page 147 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

148 Interior equipmentLoad-through hatch, Sport SedanConvertible: There is no load-through hatch.
A load-through hatch is incorporated in the rear seat backrest to
enable long, narrow items to be carried inside the car.
Before loading or unloading long items, switch off the engine and
apply the parking brake. This avoids the danger of the car moving
off if a long item were to knock the gear or selector lever into gear.
 Fold down the armrest and open the hatch by lifting the handle.
There is a lock on the rear side of the hatch. Use this to lock or unlock
the hatch.
To lock: Open the hatch and lock the lock. Close the hatch. The
hatch is now locked.
To unlock: Fold down the wide section of the backrest and unlock
the lock. Alternatively, you can unlock the hatch from the trunk.
WARNING
 Always secure the load firmly, for example using the middle
safety belt. This reduces the danger of personal injury result-
ing from the displacement of the load on hard braking or in the
event of a crash.
 Do not exceed the load capacity of the car, as this will alter its
handling characteristics (see page 294).93U S M 06.book Page 148 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

149 Interior equipment
Trunk Release HandleThere is a glow-in-the-dark trunk release
handle located inside the trunk on the latch.
This handle will glow following exposure to
light. Pull the release handle down to open
the trunk from inside.
Tie down eyes, Sport SedanThere are tie down eyes in the trunk that
should be used to secure loads. In general,
loads should be placed as far forward and
as low down as possible in the trunk.
NOTICEThe trunk release handle was not
designed to be used to tie down the trunk
lid or as an anchor point when securing
items in the trunk. Improper use of the
trunk release could damage it.
WARNING
 Lay heavy bags on the floor. Place
smaller and lighter bags on top.
 Secure heavy and bulky items using
the lashing eyes provided in the trunk.
This will avert the danger of luggage
flying around if the car should brake
suddenly or be involved in a crash.
 Secure small items if the backrest is
folded down. Small items can also be
thrown around inside the car and
cause personal injury.
 The elastic cargo net3 is only
designed for light objects that are to be
kept in place while driving
 Elastic cargo net3: WARNING. Avoid
eye injury. DO NOT overstretch.
ALWAYS keep face and body out of
recoil path. DO NOT use when strap
has visible signs of wear or damage.
 The rear seat must be in the upright
position to protect against load
displacement in the event of a crash.
Tie down eyes in the trunk
Trunk Release Handle93U S M 06.book Page 149 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

150 Interior equipment
Trunk lightingOn the underside of the parcel shelf is a light
that is switched on and off when the trunk is
opened and closed.
If the trunk lid is left open, the lighting will be
switched off automatically after 20 minutes
to prevent the battery from running flat.
Emergency opening of the
narrow backrest, Sport SedanThe narrow section of the backrest can be
opened in an emergency if the car is without
electricity (not possible to open trunk lid)
and you need to access the trunk for a warn-
ing triangle, for example.
 Remove the cover and depress the yellow
lever forward.
Tools and spare wheel, see page 270.  Do not exceed the load capacity of the
car, as this will alter its handling char-
acteristics (see page 294).
 Match your speed and driving style to
how the car is loaded. The handling
characteristics of the car can be
affected since a load in the trunk will
alter the car’s center of gravity.Cover over emergency opening lever, on
parcel shelf
93U S M 06.book Page 150 Friday, February 18, 2005 1:15 PM
