121 Instruments and controlsShown below are several examples of air distribution.
Windshield
Panel
Floor, front and rear
Windshield – floor (front and rear)
93U S M 06.book Page 121 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

122 Instruments and controls
Formation of ice and mist in extreme weather
conditionsIt is only in the most extreme conditions that icing and misting of
window glass are likely to be a problem, such as in torrential rain or
severe cold coupled with high relative humidity, or when passengers
are perspiring heavily or wearing wet clothes. The following mea-
sures are recommended if such problems should occur:
1 Select and set the temperature to 70°F (21°C)
2 Select . If this is not enough...
3 Increase the fan speed. If this is not enough...
4 Select a higher temperature.
Panel – floor (front and rear)
Windshield – panel – floor (front and rear)
93U S M 06.book Page 122 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

123 Instruments and controls
The seat cushions and backrests of the front
seats are heated.
Heating is thermostatically controlled.
Heating is controlled manually but can also
be automatic. Refer to Profiler on page 124.
Three heating levels are available. Pressing
the button once will turn the heating on at full
power. Pressing the button a total of 4 times
will turn the heating off.
 = full.
 = medium.
 = low.
CalibrationCalibration is performed automatically
every fifth time the car is started after having
been switched off for more than 2 hours or
if the battery has been disconnected.ProgrammingA number of functions can be customized
under Profiler (see page 124). Further cus-
tomizations can be made at a workshop. We
recommend that you contact a Saab dealer.Tips(before contacting a workshop. We recom-
mend that you contact a Saab dealer)
 If you feel that the ACC system is not func-
tioning satisfactorily, select "Default
Settings" under Profiler (see page 124.
 To prevent the smell of washer fluid from
entering the car, recirculation can be acti-
vated automatically while the windshield
is washed. The recirculation symbol will
however not light up. This function is
optional; contact a workshop. We recom-
mend that you contact a Saab dealer. This
automatic recirculation is the factory
default setting as long as the system is
working in full "AUTO" model with no
customized settings.
Electric heating, front
seats3
93U S M 06.book Page 123 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

124 Instruments and controlsACC- ConvertibleWhen the soft top is folded, the ACC system
switches to manual temperature control.
There are eleven temperature settings: 0–
10.
The system adjusts itself as follows:
 AUTO goes out.
 Heating, air distribution and fan speed are
not affected.
 Recirculation and rear window heating
are cut out.
 The A/C compressor is switched off (man-
ual activation is possible by pressing the
AC button).
All manual selections are possible with the
exception of rear window heating.
When the soft top is raised, the system
reverts to the AUTO mode and the previous
set temperature.
Note: When the soft top or all the windows
are open in a hot, humid climate, turning the
air conditioning on manually can cause con-
densation to form on cold surfaces, such as
the air ducts.
ProfilerSome of the functions of the ACC system
can be customized.
1 Press the CUSTOMIZE button to go to
Profiler.
2 Select Climate System using the
INFO dial.
3 Press in the INFO dial.
4 Select Rear Defroster, Heated Seats,
Fan Settings, Air Distribution, A/C Mode,
Dual/Single Zone or Default Settings by
turning the dial.
5 Confirm this selection by pressing the
INFO dial.
Once you have adjusted the ACC system
settings under Profiler, CUSTOMIZE will
appear on the ACC display.
ACC display when soft top folded
93U S M 06.book Page 124 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

125 Instruments and controls
Explanation of how the ACC system can be
customized under Profiler.
Climate System
Rear Defroster
AutoManual
Heated Seats
AutoManual
Fan Settings
High speedMedium speedLow speed
Air Distribution
AutoManual
WindshieldPanelFloor
A/C Mode
AutoA/C off
Dual/Single Zone
Dual zoneSingle zone
Default Settings
Are you sure?Ye s N o
Rear Defroster
Auto:The rear window and door mirror
heating is controlled automatically.
This is one of the Default Settings.
Manual:
The rear window and door mirror
heating is switched on with
the button on ACC panel.
Convertible: The rear window heating can-
not be turned on when the soft top is folded.
Heated Seats
Auto:
The front seat heating is controlled
automatically.
Select the level by repeatedly
pressing the appropriate button on
the ACC panel: 2 arrows on symbol
= standard; 3 arrows = high; 1 arrow
= low. The selected heating setting
is saved when the engine is
switched off. Note: The symbol on
the ACC panel goes out if the heat-
ing is turned off automatically by the
system.
Manual:
See Electric heating, front seats 3
on page 123
.
This is one of the Default Settings.
93U S M 06.book Page 125 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

126 Instruments and controlsFan Settings
High speed:
This selection give a slightly higher
fan speed than Medium speed
though with continued automatic
regulation.
Medium speed:
Normal automatic fan speed. This is
one of the Default Settings.
Low speed:
This selection give a slightly lower
fan speed than Medium speed
though with continued automatic
regulation.
Convertible: Fan speed is not regulated
automatically when the soft top is open.
Air Distribution
Auto:
The ACC system adapts air tem-
perature and distribution to the pre-
vailing conditions. This is one of the
Default Settings
.
Manual:
Windshield:
The ACC system directs almost
all air to the windshield.
Panel:
The ACC system directs almost
all air to air vents in the fascia.
Floor:
The ACC system directs almost
all air to the floor.
A/C Mode
Auto:
Automatic engagement and disen-
gagement of the A/C. This is one of
the Default Settings.
A/C off:
A/C compressor OFF (see also
page 118). The A/C compressor
can be activated temporarily by
pressing the AC or AUTO button
while on the road and if the outside
temperature is above 41°F (+5°C).
The A/C will be off the next time the
engine is started, if the engine has
been switched off for more than
2hours.
Convertible: The A/C compressor is
switched off when the soft top is folded
down.
Further customizations to this function can
be made at a workshop. We recommend
taht you contact a Saab dealer.
 The A/C compressor can be on even
when the soft top is folded down.
 The A/C compressor can be set to
operate as when the soft top was last
folded down.Dual/Single Zone
Dual zone:
Individual temperature setting for
each zone (see page 116). The sys-
tem saves the settings when the
engine is switched off. This is one of
the Default Settings.
Single zone:
Common temperature setting when
the engine is started. If the temper-
ature setting for the passenger zone
is changed, the system will switch to
Dual zone control. Single zone con-
trol will return the next time the
engine is started having been
switched off for more than 2 hours.
93U S M 06.book Page 126 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

127 Interior equipment
Steering wheel
adjustment __________ 128
Electric windows _______ 129
Rearview mirrors_______ 132
Sunroof 3 _____________ 138
Interior lighting ________ 141
Cup holder 3 __________ 142
Power Outlet 3 _________ 144
Storage compartments __ 144
Trunk ________________ 146
Interior equipment
3Asterisk means: equipment not fitted in all cars
(can depend on model variant, engine variant,
market specification, options or accessories).93U S M 06.book Page 127 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

128 Interior equipmentSteering wheel
adjustmentThe height and reach of the steering wheel
can be adjusted.
There is a release lever under the steering
column.
1 Pull down the lever to release the steer-
ing wheel.
2 Adjust the position of the steering wheel.
3 Raise the lever to the locked position to
lock the steering wheel in position.
When returning the release lever to its
locked position, you may need to adjust the
position of the steering wheel slightly to
allow the lock mechanism to engage cor-
rectly.
Steering wheel lock, see page 162.
Horn signalActivate the horn by pressing one of the
three areas shown above on the steering
wheel pad.
WARNING
Only adjust the steering wheel while the
car is stationary so that you are not
distracted from the traffic.
Lever for steering wheel adjustment
93U S M 06.book Page 128 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

129 Interior equipment
Electric windowsThe electric windows are operated by
means of switches in the door armrests.
For the electric windows to work, the remote
control must be in the ON position in the
ignition switch.
At the end of a journey and having removed
the remote control, you can still operate the
windows, so long as neither of the front
doors has been opened.Windows having the automatic closing func-
tion (option) can be operated as long as the
car is unlocked and until 20 minutes has
passed since the remote control was
removed from the ignition switch.
To openPress down the front edge of the button one
step.
The window will stop when it is fully open or
when the button is released.
Automatic opening: Press the button all
the way down and release it.
Comfort opening3Comfort opening is the remote opening of
windows and the sunroof.
Press and hold the unlocking button on the
remote control until the windows and
optional sunroof start to open (approx. 2 s).
During comfort opening of the windows,
sunroof (option) and soft top, the range is
reduced by approximately half.
Convertible: For the remote opening of the
soft top, refer to page 66.
WARNING
Bear in mind the pinch hazard when clos-
ing the side windows. May cause serious
or fatal injuries!
Always remove the remote control
from the ignition switch when you
leave the car. This will prevent
personal injury caused by the activa-
tion of the electric windows, for exam-
ple, due to children playing.
 The person operating the electric
window is responsible for ensuring
that no one, especially a child, has
their head, hands or fingers in the
window openings, before raising the
window.
 Do not stick any part of the body or the
head out through an open window
while the car is moving.
Window switches
Window switch in rear door
93U S M 06.book Page 129 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

130 Interior equipmentTo closeRaise the front edge of the button one step.
The window will stop when it is fully closed
or when the button is released.
Automatic closing3: Raise the button all
the way and release it. If the window does
not close automatically, refer to Calibration
on page 131.
Pinch protection3On certain model variants, the front electric
windows are equipped with pinch protec-
tion. This is activated if something gets
trapped between the window pane and door
frame when the window is closed. The
window will stop and lower slightly.
Temporary overriding the pinch protec-
tion
If dirt, ice or similar create so much resis-
tance that the pinch protection cuts in (the
window cannot be closed), the pinch protec-
tion can be temporarily disengaged and the
window closed.
1 Make sure the ignition is ON.
2 Press and hold the button on the
driver’s door while operating the window
in question.
3 Close the window in question.
The pinch protection will be active the next
time a window is operated.
WARNING
Take care when closing a window to
ensure that no one gets caught.
WARNING
Make sure nothing obstructs the window
when it is closed without pinch protection.
Button for temporary deactivation of rear
door window switches and temporary
override of window pinch protection
93U S M 06.book Page 130 Friday, February 18, 2005 1:15 PM
ProCarManuals.com
