SAAB 9-5 2005 Owners Manual

249 Customer Assistance and Information
Vehicle Data Collection and
Event Data RecordersYour vehicle, like other modern motor vehi-
cles, has a number of sophisticated com-
puter systems that monitor and control sev-
eral aspects of the vehicle’s performance.
Your vehicle uses on-board vehicle comput-
ers to monitor emission control components
to optimize fuel economy, to monitor condi-
tions for air bag deployment and, if so
equipped, to provide anti-lock braking and
to help the driver control the vehicle in diffi-
cult driving situations. Some information
may be stored during regular operations to
facilitate repair of detected malfunctions;
other information is stored only in a crash
event by computer systems commonly
called event data recorders (EDR).
In a crash event, computer systems, such
as the Air Bag Sensing and Diagnostic
Module (SDM) in your vehicle may record
information about the condition of the vehi-
cle and how it was operated, such as data
related to engine speed, brake application,
throttle position, vehicle speed, steering
wheel angle, lateral acceleration, safety belt
usage, air bag readiness, air bag perfor-
mance, and the severity of a collision. This
information has been used to improve vehi-
cle crash performance and may be used to
improve crash performance of future vehi-
cles and driving safety. Unlike the data
recorders on many airplanes, these on-
board systems do not record sounds, such
as conversation of vehicle occupants.To read this information, special equipment
is needed and access to the vehicle or the
SDM is required.
Saab will not access information about a
crash event or share it with others other than
 with the consent of the vehicle owner or, if
the vehicle is leased, with the consent of
the lessee,
 in response to an official request of police
or similar government office,
 as part of Saab’s defense of litigation
through the discovery process, or
 as required by law.
In addition, once Saab collects or receives
data, Saab may
 use the data for Saab research needs,
 make it available for research where
appropriate confidentiality is to be main-
tained and need is shown, or
 share summary data which is not tied to a
specific vehicle with non-Saab organiza-
tions for research purposes.
Others, such as law enforcement, may have
access to the special equipment that can
read the information if they have access to
the vehicle or SDM.
If your vehicle is equipped with OnStar®,
please check lthe OnStar® subscription
service agreement or manual for informa-
tion on its operations and data collection.
ProCarManuals.com

250 Customer Assistance and Information(This page has been left blank)
ProCarManuals.com

251 Specifications
General_______________ 252
Engine _______________ 254
Fuel__________________ 254
Engine oil _____________ 255
Engine variants ________ 256
Electrical system_______ 257
Drive belts ____________ 257
Manual gearbox________ 258
Automatic transmission _ 258
Suspension ___________ 259
Steering ______________ 259
Brake system__________ 259
Wheels and tires _______ 260
Plates and labels _______ 262
IB603
Specifications
ProCarManuals.com

252 SpecificationsGeneral Overall length, including bumpers:
9-5 Sedan _______________________ 190.0 in (4827 mm)
9-5 SportWagon __________________ 190.1 in (4828 mm)
Overall width, including door mirrors ____ 80.4 in (2042 mm)
Maximum height:
9-5 Sedan _______________________ 58.1 in (1475 mm)
9-5 SportWagon __________________ 59.1 in (1501 mm)
Wheelbase _______________________ 106.4 in (2703 mm)
Ground clearance at gross vehicle weight approx. 4.6 in
(116 mm)
Tr a c k :
Front __________________________ 59.9 in (1522 mm) *)
Rear ___________________________ 59.9 in (1522 mm) *)
Turning circle (curb to curb) ___________ 37,1 ft (11.3 m)
Turning circle (measured at vehicle extremi-
ties) ____________________________ 39,0 ft (11.9 m)
Number of seats (incl. driver) _________ 5
*) Specified track applies to wheel sizes:
6 x 15 & 6.5 x 16

Permissible load (in addition to driver) = GVW minus curb weight
The maximum permissible axle load, front or rear, must not be exceeded.
The maximum permissible axle load, front or rear, must not be exceeded. Chassis number in engine bay Weight ready for driving (i.e. with full fuel
tank, washer-fluid reservoir, standard tools
and spare wheel) ___________________ 3460–3780 lbs.
(1570–1715 kg)
Gross vehicle weight (GVW) ___________ 4390–4710 lbs.
(1990–2135 kg)
Maximum axle load:
Front ___________________________ 2590 lbs. (1175 kg)
Rear, 9-5 Sedan ___________________ 2310 lbs. (1050 kg)
Rear, 9-5 SportWagon ______________ 2480 lbs. (1125 kg)
Weight distribution:
Curb weight, front/rear ______________ 60/40 %
GVW, front/rear ___________________ 50/50 %
Maximum roof load __________________ 220 lbs (100 kg)
ProCarManuals.com

253 Specifications
Trailer:
Luggage compartment Volume (SAE):
9-5 Sedan _______________________ 15.9 cu.ft.
(450 litres)
9-5 SportWagon, rear seat upright ____ 31.4 cu. ft.
(890 litres)
9-5 SportWagon, rear seat folded_____ 73.0 cu. ft.
(2067 litres)
Luggage compartment, length, 9-5 Sedan:
Rear seat upright _________________ 43.0 in (1092 mm)
Rear seat folded down _____________ 67.5 in (1714 mm)
Luggage compartment, length, 9-5 Sport-
Wagon:
Rear seat upright _________________ 42.8 in (1087 mm)
Rear seat folded __________________ 68.2 in (1732 mm)
WARNING
 The GVW and maximum axle loads must not be exceeded.
Note that if some accessories (e.g. towbar, CD changer) are
fitted, the available load capacity is reduced by the weight of
these.
 When carrying a load in the luggage compartment, make sure
that it is tied down securely, particularly when part or all of the
rear seat is folded down.
Maximum towing speed, trailer with brakes 60 mph (100 km/h)
Trailer with brakes _________________ Maximum weight:
3500 lbs (1588 kg)
Trailer without brakes ______________ Maximum weight:
1000 lbs (450 kg)
Maximum load on ball hitch __________ 110–165 lbs
(50–75 kg)
The above speed and weight restrictions are those specified by
Saab Automobile AB.
Note that local restrictions may apply to trailer speeds and
weights (see page 161).
ProCarManuals.com

254 SpecificationsEngine
Fuel
4-cylinder ________________________ Four cylinders, twin
overhead cams-
hafts, 16 valves and
two balancer shafts.
Cylinder bores _____________________ 3.54 in (90 mm)
Stroke ___________________________ 3.54 in (90 mm)
Swept volume _____________________ 139.7 cu.in
(2.290 litres)
Idling speed _______________________ 825 rpm (man.)
860 rpm (aut.)
Antifreeze_________________________ Saab-approved
antifreeze
Coolant capacity ___________________ 7.8 qts (7.4 litres)Fuel-tank capacity ____________ 18.5 gal. (70 litres)
For optimum performance Saab
recommends: _______________ 2.3t 185 hp (Linear) –
AON 90.
2.3T 220 hp (Arc) and
2.3 Turbo 250 hp (Aero) –
AON 93.*
* If AON 90 is used some decrease in engine power can occur.
Gasoline with a lower octane rating can be used, although not
lower than AON 87. However, engine performance will fall
slightly and heavy loading and laboring should be avoided. For
optimum performance, use the recommended grade of fuel.
For further information on fuel, see page 140.
ProCarManuals.com

255 Specifications
Engine oil To meet demands in Saab's extended service intervals all eng-
ines are filled with specially designed synthetic factory fill oils.
Long service intervals, fuel economy and environmental issues
are the base for our choice of oil. By using oils approved by Saab
you minimise the tendencies for oil sludge build, by that protec-
ting the engine from harmful, wear increasing, deposits.Approved oils:
All gasoline engines - Fully Synthetic Engine Oil fulfilling
GM-LL-A-025 requirements.Oil used at, or in-between, service must be approved according
to the engine specified classification to render possible the
usage of Saab Automobile AB specified service intervals.Servicing/Oil changes:To be able to use recommended service intervals the need to
use only approved engine oils is vital.
Use only engine oils
approved for your engine.
Service should be done according
to the recommended service intervals to optimize your engine's
function through out its entire life. Saab Automobile AB will not
take responsibility for any damage that might occur due to neg-
lecting to meet above mentioned requirements.
At your Saab dealers you can find Saab Genuine or Mobil eng-
ine oils. Among those there are oils specially designed to meet
your engines specific needs. We recommend that you, with the
help of our skilled service personnel, choose your oil from that
sortiment.
Other oil companies also have engine oils approved according
to GM specifications. Oils meeting these standards may be
identified as synthetic. However, not all synthetic oils will meet
your engines requirements. You should only use oil that meets
your engines specific requirements (GM-LL-A-025).
Recommended oil viscositiesViscosity is a measurement of the oils thickness. The thickness
influences, among other things, the fuel economy. For best func-
tion Saab recommends:For gasoline engines:SAE 0W-30
SAE 5W-30
or
SAE 0W-40 engine oilExtra engine oil additivesDon't add anything to your oil. The recommended oils are all you
will need for good engine performance and protection.
ProCarManuals.com

256 Specifications
Engine variants
When to change engine oilYour vehicle will display when it is time for servicing on the SID,
based on the mileage and time since the last service.
Under normal circumstances the service indication will come
after:
Saab 9-5, 15,000 miles (24,000 km) or 1 year.
For this service system to work it is of outmost importance that
the right engine oil is used.
When the message for service is displayed you need to have the
required service done as soon as possible.
After the service your service personnel will reset the service
indicator. It is important to reset the service indicator in order to
optimize the time to the next service.
Oil capacity incl. filter (on changing) ____ 4.1 qts (4.0 litres)
2.3t EcopowerRating, EEC at 5500 rpm ___________ 185 hp (136 kW)
Maximum torque, EEC at 1800 rpm ___ 206.5 ft.lb
(280 Nm)
Compression ratio _________________ 9.3:12.3T EcopowerRating, EEC at 5500 rpm ____________ 220 hp (161 kW)
Maximum torque, EEC at 1800 rpm ____ 228.6 ft.lb
(310 Nm)
Compression ratio _________________ 9.3:1 2.3 Turbo EcopowerRating, EEC at 5500 rpm ____________ 250 hp (184 kW)
Maximum torque, EEC at 1900 rpm 258.0 ft.lb.
(350 Nm)
Compression ratio _________________ 9.3:1
ProCarManuals.com

257 Specifications
Electrical system Drive belts Voltage __________________________ 12 V
Battery capacity ___________________ 70 Ah
Starter motor ______________________ 1.4 kW
Alternator rating ____________________ 140 A/14 V
Firing order _______________________ 1–3–4–2
Spark plugs:
2.3t ____________________________ NGK
BCPR 6ES-11
Electrode gap ____________________ 0.0141 in (1.05 mm)
2.3T and 2.3 Turbo ________________ NGK
PFR 6H-10
Electrode gap ____________________ 0.0374 in (0.95 mm)
Engine variants Outside lengthDrive belt _________________________ 95.08 in
(2415 mm)Drive belt
IB929
ProCarManuals.com

258 SpecificationsManual gearbox Automatic transmission Type ____________________________ All-synchromesh
5-speed with final
drive and differen-
tial
Oil ______________________________ Saab MTF 0063
Oil capacity _______________________ 1.9 qts (1.8 litres)
Oil volume (on changing) ____________ 1.6 qts (1.5 litres)
Clutch type _______________________ Hydraulic, single
dry-plate clutch of
diaphragm-spring
type
Speed (mph / km/h) at 1000 rpm in 5th gear: 27–29 / 43–47Type _____________________________ Electronically con-
trolled 5-speed,
fully automatic with
hydraulic torque
converter, plane-
tary gear set and
integral final drive
Lock-up function in
selector positions 3,
4 and 5.
Selector-lever positions ______________ P R N D M L
Transmission-fluid capacity, dry transmis-
sion (incl. torque converter and oil cooler) 7.4 qts (7 litres)
Transmission fluid ___________________ Saab 3309 (mineral
oil based)
Clutch type ________________________ Hydraulic plate clut-
ches, brake bands
and one-way coup-
lings
Speed (mph / km/h) at 1000 rpm in 5th gear: 29–30 / 46–48
ProCarManuals.com
