Seat Ibiza 2020 Directive 2014/53/EU Bluetooth

Page 66 of 90 Report No. : 60404487 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
5.7.6.1 Norway and Sweden
To the end of the subclause the following is added:
The screen of the television distribution system is
normally not earthed a t the entrance of the building and
there is normally no equipotential bonding system within
the building. Therefore the protective earthing of the
building installation needs to be isolated from the screen
of a cable distribution system.
It is however acce pted to provide the insulation external
to the equipment by an adapter or an interconnection
cable with galvanic isolator, which may be provided by a
retailer, for example.
The user manual shall then have the following or similar
information in Norwegian a nd Swedish language
respectively, depending on in what country the
equipment is intended to be used in:
“Apparatus connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection t o protective
earthing – and to a television distribution system using
coaxial cable, may in some circumstances create a fire
hazard. Connection to a television distribution system
therefore has to be provided through a device providing
electrical isolation below a certain frequency range
(galvanic isolator, see EN 60728 - 11)”
NOTE In Norway, due to regulation for CATV - installations, and in
Sweden, a galvanic isolator shall provide electrical insulation below 5
MHz. The insulation shall withstand a dielectric strength of 1,5 kV
r.m.s., 50 Hz or 60 Hz, for 1 min.

Translation to Norwegian (the Swedish text will also be
accepted in Norway):
“Apparater som er koplet til beskyttelsesjord via
nettplugg og/eller via annet jordtilkoplet utstyr – og er
tilkoplet et ko aksialbasert kabel - TV nett, kan forårsake
brannfare. For å unngå dette skal det ved tilkopling av
apparater til kabel - TV nett installeres en galvanisk
isolator mellom apparatet og kabel - TV nettet.”
Translation to Swedish:
”Apparater som är kopplad till sk yddsjord via jordat
vä gguttag och/eller via annan utrustning och samtidigt
är kopplad till kabel - TV nät kan i viss a fall medfőra risk
főr brand. Főr att undvika detta skall vid anslutning av
apparaten till kabel - TV nät galvanisk isolator finnas
mellan apparaten och kabel - TV nätet.”. N/A

Page 67 of 90 Report No. : 60404487 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
5.7.6.2 Denmark
To the end of the subclause the following is added:
The warning (marking safeguard) for high touch current
is required if the touch current or the protective current
exceed the limits of 3,5 mA . N/A
B.3.1 and
B.4 Ireland and United Kingdom
The following is applicable:
To protect against excessive currents and short - circuits
in the primary circuit of direct plug - in equipment , tests
according to Annexes B.3.1 and B.4 shall be conducted
using an external miniature circuit breaker complying
with EN 60898 - 1, Type B, rated 32A. If the equipment
does not pass these tests, s uitable protective devices
shall be included as an integral part of the direct plug -
in equipment , until the requirements of Annexes B.3.1
and B.4 are met N/A
G.4.2 Denmark
To the end of the subclause the following is added:
Supply cords of single phase a ppliances having a rated
current not exceeding 13 A shall be provided with a plug
according to DS 60884 - 2 - D1:2011.
CLASS I EQUIPMENT provided with socket - outlets with earth
contacts or which are intended to be used in locations where
protection against ind irect contact is required according to the
wiring rules shall be provided with a plug in accordance with
standard sheet DK 2 - 1a or DK 2 - 5a.
If a single - phase equipment having a RATED CURRENT
exceeding 13 A or if a poly - phase equipment is provided with
a su pply cord with a plug, this plug shall be in accordance with
the standard sheets DK 6 - 1a in DS 60884 - 2 - D1 or EN 60309 -
2.
Mains socket outlets intended for providing power to
Class II apparatus with a rated current of 2,5 A shall be
in accordance DS 60884 - 2 - D1:2011 standard sheet
DKA 1 - 4a.
Other current rating socket outlets shall be in
compliance with Standard Sheet DKA 1 - 3a or DKA 1 -
1c.
Mains socket - outlets with earth shall be in compliance
with DS 60884 - 2 - D1:2011 Standard Sheet DK 1 - 3a, DK
1 - 1c, DK1 - 1d, D K 1 - 5a or DK 1 - 7a
Justification:
Heavy Current Regulations, Section 6c N/A

Page 68 of 90 Report No. : 60404487 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
G.4.2 United Kingdom
To the end of the subclause the following is added:
The plug part of direct plug - in equipment shall be
assessed to BS 1363: Part 1, 12.1, 12.2, 12.3, 12.9,
12 .11, 12.12, 12.13, 12.16, and 12.17, except that the
test of 12.17 is performed at not less than 125 °C.
Where the metal earth pin is replaced by an Insulated
Shutter Opening Device (ISOD), the requirements of
clauses 22.2 and 23 also apply. N/A
G.7.1 Un ited Kingdom
To the first paragraph the following is added:
Equipment which is fitted with a flexible cable or cord
and is designed to be connected to a mains socket
conforming to BS 1363 by means of that flexible cable
or cord shall be fitted with a ‘stan dard plug’ in
accordance with the Plugs and Sockets etc (Safety)
Regulations 1994, Statutory Instrument 1994 No. 1768,
unless exempted by those regulations.
NOTE "Standard plug" is defined in SI 1768:1994 and essentially
means an approved plug conforming t o BS 1363 or an approved
conversion plug. N/A
G.7.1 Ireland
To the first paragraph the following is added:
Apparatus which is fitted with a flexible cable or cord
shall be provided with a plug in accordance with
Statutory Instrument 525: 1997, “13 A Plug s and
Conversion Adapters for Domestic Use Regulations:
1997. S.I. 525 provides for the recognition of a standard
of another Member State which is equivalent to the
relevant Irish Standard N/A
G.7.2 Ireland and United Kingdom
To the first paragraph the f ollowing is added:
A power supply cord with a conductor of 1,25 mm 2
is
allowed for equipment which is rated over 10 A and up
to and including 13 A. N/A

Page 69 of 90 Report No. : 60404487 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
ZC ANNEX ZC, NATIONAL DEVIATIONS (EN)
N/A
10.5.2 Germany
The following requirement applies:
For the o peration of any cathode ray tube intended for
the display of visual images operating at an acceleration
voltage exceeding 40 kV, authorization is required, or
application of type approval (Bauartzulassung) and
marking.
Justification:
German ministerial dec ree against ionizing radiation
(Röntgenverordnung), in force since 2002 - 07 - 01,
implementing the European Directive 96/29/EURATOM.
NOTE Contact address:
Physikalisch - Technische Bundesanstalt, Bundesallee 100,
D - 38116 Braunschweig,
Tel.: Int +49 - 531 - 592 - 63 20,
Internet: http://www.ptb.de N/A

Page 70 of 90 Report No. : 60404487 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
ATTACHMENT TO TEST R EPORT
IEC 62368 - 1
EUROPEAN GROUP DIFFE RENCES AND NATIONAL DIFFERENCES
(AUDIO/VIDEO, INFORM ATION AND COMMUNICAT ION TECHNOLOGY EQUIP MENT - PART 1: SAFET Y
REQUIREMENTS)
Differences according to ............... :
EN IEC 62368 - 1:2020+A11:2020
Attachment Form No . ..................... :
EU_GD_IEC62368_1C
Attachment Originator ................... :
UL(Demko)
Master Attachment ......................... :
2020 - 03 - 10
Copyright © 2020 IEC System for Conformity Testing and Certification of Electrical Equipment
(IECEE), Geneva, Switzerland . All rights reserved.
CENELEC COMMON MODIFICATIONS (EN)
P
Clause numbers in the cells that are shaded light grey are clause references in EN
IEC 62368 - 1:2020+A11:2020. All other clause numbers in that column, except for
those in the paragraph below, r efers to IEC 62368 - 1:2018.

Clauses, subclauses, notes, tables, figures and annexes which are additional to
those in IEC 62368 - 1:2018 are prefixed “Z”. P
Add the following annexes:
Annex ZA (normative) Normative references to international publications
with their corresponding European publications
Annex ZB (normative) Special national conditions
Annex ZC (informative) A - deviations
Annex ZD (informative) IEC and CENELEC code designations for flexible
cords P
1 Modification to Clause 3 .
N/A
3.3.19 Sound exposure
Replace 3.3.19 of IEC 62368 - 1 with the following definitions: N/A
3.3.19.1
momentary exposure level, MEL
metric for estimating 1 s sound exposure level from
the HD 483 - 1 S2 test signal applied to both channels,
based on EN 50332 - 1: 2013, 4.2.

Note 1 to entry: MEL is measured as A - weighted levels in dB.
Note 2 to entry: See B.3 of EN 50332 - 3:2017 for additional
information. N/A

Page 71 of 90 Report No. : 60404487 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
3.3.19.3
sound exposure, E

A - weighted sound pressure ( p ) squared and
integrated over a stated period of time, T

Note 1 to entry: The SI unit is Pa 2
s.
N/A
3.3.19.4
sound exposure level, SEL

logarithmic measure of sound exposure relative to a
reference value, E 0 , typically the 1 kHz
threshold of hearing in humans.

Note 1 to entry: SEL is measured as A - weighted levels in dB.

dB

Note 2 to entry: See B.4 of EN 50332 - 3:2017 for additional
information. N/A
3.3.19.5
digital signal level relative to full scale, dBFS

levels reported in dBFS are always r.m.s. Full scale
level, 0 dBFS, is the level of a dc - free 997 -
Hz sine wave whose undithered positive peak value
is positive digital full scale, leaving the code
corresponding to negative digital full scale unused

Note 1 to entry: It is invalid to use dBFS for non - r.m.s. levels.
Because the definition of full scale is based on a sine wave, the
level of signals with a crest factor lower than that of a sine wave
may exceed 0 dBFS. In particular, square wave signals may
reach +3,01 dBFS. N/A
2 Modification to Clause 10
N/A
10.6 Safeguards against acoustic energy sources
Replace 10.6 of IEC 62368 - 1 with the following: N/A
10.6.1.1 Introduction

Safeguard requirements for protection against long -
term exposure to excessive sound pressure
levels from personal music players closely coupled
to the ear are speci fied below. Requirements
for earphones and headphones intended for use
with personal music players are also covered.
A personal music player is a portable equipment
intended for use by an ordinary person , that:

– is designed to allow the user to listen t o audio or
audiovisual content / material; and N/A

Page 72 of 90 Report No. : 60404487 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
– uses a listening device, such as headphones or
earphones that can be worn in or on or
around the ears; and
– has a player that can be body worn (of a size
suitable to be carried in a clothing pocket) and
i s intended for the user to walk around with while in
continuous use (for example, on a street,
in a subway, at an airport, etc.).

EXAMPLES Portable CD players, MP3 audio players, mobile
phones with MP3 type features, PDAs or similar equipment.

Personal m usic players shall comply with the
requirements of either 10.6.2 or 10.6.3.

NOTE 1 Protection against acoustic energy sources from telecom
applications is referenced to ITU - T P.360.

NOTE 2 It is the intention of the Committee to allow the
alternative met hods for now, but to only use the dose
measurement method as given in 10.6.5 in future. Therefore,
manufacturers are encouraged to implement 10.6.5 as soon as
possible.

Listening devices sold separately shall comply with
the requirements of 10.6.6.
These requirements are valid for music or video
mode only.
The requirements do not apply to:
– professional equipment;

NOTE 3 Professional equipment is equipment sold through
special sales channels. All products sold through
normal electronics stores are consid ered not to be professional
equipment.

– hearing aid equipment and other devices for
assistive listening;
– the following type of analogue personal music
players:
• long distance radio receiver (for example, a
multiband radio receiver or world band radio
receiver, an AM radio receiver), and
• cassette player/recorder;

NOTE 4 This exemption has been allowed because this
technology is falling out of use and it is expected that
within a few years it will no longer exist. This exemption will not
be extended t o other technologies.

– a player while connected to an external amplifier
that does not allow the user to walk around
while in use.

For equipment that is clearly designed or intended
primarily for use by children, the limits of the
relevant toy standards may apply.

The relevant requirements are given in

Page 73 of 90 Report No. : 60404487 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
EN 71 - 1:2011, 4.20 and the related tests methods
and measurement distances apply.
10.6.1.2 Non - ionizing radiation from radio frequencies in
the range 0 to 300 GHz

The amount of non - ionizing radiat ion is regulated by
European Council Recommendation 1999/519/EC of
12 July 1999 on the limitation of exposure of the
general public to electromagnetic fields (0 Hz to 300
GHz).
For intentional radiators, ICNIRP guidelines should
be taken into account for L imiting Exposure to Time -
Varying Electric, Magnetic, and Electromagnetic
Fields (up to 300 GHz). For hand - held and body
mounted devices, attention is drawn to EN 50360
and EN 50566. N/A
10.6.2 Classification of devices without the capacity to estimate so und dose
N/A
10.6.2.1 General

This standard is transitioning from short - term based
(30 s) requirements to long - term based (40 hour)
requirements. These clauses remain in effect only
for devices that do not comply with sound dose
estimation as stipulated in EN 50332 - 3.

For classifying the acoustic output L Aeq , T ,
measurements are based on the A - weighted
equivalent sound pressure level over a 30 s period.

For music where the average sound pressure (long
term L Aeq , T ) measured over the duration of the song
is lower than the average produced by the
programme simulation noise, measurements may be
done over the duration of the complete song. In this
case, T becomes the duration of the song.

NOTE Classical music, acoustic music and broadcast typically
has an av erage sound pressure (long term L Aeq , T ) which is much
lower than the average programme simulation noise. Therefore, if
the player is capable to analyse the content and compare it with
the programme simulation noise, the warning does not need to be
given as long as the average sound pressure of the song does
not exceed the required limit.
For example, if the player is set with the programme simulation
noise to 85 dB, but the average music level of the song is only 65
dB, there is no need to give a warning or ask an
acknowledgement as long as the average sound level of the song
is not above the basic limit of 85 dB. N/A
10.6.2.2 RS1 limits (to be superseded, see 10.6.3.2)

RS1 is a class 1 acoustic energy source that does
not exceed the following:
– for equi pment provided as a package (player with
its listening device), and with a proprietary connector
between the player and its listening device, or where N/A

Page 74 of 90 Report No. : 60404487 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
the combination of player and listening device is
known by other means such as setting or automatic
detec tion, the L Aeq , T acoustic output shall be ≤ 85 dB
when playing the fixed “programme simulation
noise” described in EN 50332 - 1.
– for equipment provided with a standardized
connector (for example, a 3,5 phone jack) that
allows connection to a listening device for general
use, the unweighted r.m.s. output voltage shall be ≤
27 mV (analogue interface) or - 25 dBFS (digital
interface) when playing the fixed “programme
simulation noise” described in EN 50332 - 1.
– The RS1 limits will be updated for all devices as
per 10.6.3.2.
10.6.2.3 RS2 limits ( to be superseded, see 10.6.3.3)

RS2 is a class 2 acoustic energy source that does
not exceed the following:
– for equipment provided as a package (player with
its listening device), and with a proprietary connector
between the player and its listening dev ice, or when
the combination of player and listening device is
known by other means such as setting or automatic
130 detection, the L Aeq , T acoustic output shall be ≤
100 dB(A) when playing the fixed “programme
simulation noise” as described in EN 50332 - 1.
– for equipment provided with a standardized
connector (for example, a 3,5 phone jack) that
allows connection to a listening device for general
use, the unweighted r.m.s. output voltage shall be ≤
150 mV (analogue interface) or - 10 dBFS (digital
interface) when playing the fixed “programme
simulation noise” as described in EN 50332 - 1. N/A
10.6.2.4 RS3 limits

RS3 is a class 3 acoustic energy source that
exceeds RS2 limits. N/A
10.6.3 Classification of devices (new)
N/A
10.6.3.1 General

Previous limits (10.6.2) created abundant false
negative and false positive PMP sound level
warnings. New limits, compliant with The
Commission Decision of 23 June 2009, are given
below. N/A
10.6.3.2 RS1 limits (new)

RS1 is a class 1 acoustic energy source that does
not exceed the following:
– for equipment provided as a package (player with
its listening device), and with a proprietary connector
between the player and its list ening device, or where
the combination of player and listening device is N/A

Page 75 of 90 Report No. : 60404487 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
known by other means such as setting or automatic
detection, the L Aeq , T acoustic output shall be ≤ 80 dB
when playing the fixed “programme simulation
noise” described in EN 50332 - 1.
– for equipment provided with a standardized
connector (for example, a 3,5 phone jack) that
allows connection to a listening device for general
use, the unweighted r.m.s. output voltage shall be ≤
15 mV (analogue interface) or - 30 dBFS (digital
interface) w hen playing the fixed “programme
simulation noise” described in EN 50332 - 1.
10.6.3.3 RS2 limits (new)

RS2 is a class 2 acoustic energy source that does
not exceed the following:
– for equipment provided as a package (player with
its listening device ), and with a proprietary connector
between the player and its listening device, or where
the combination of player and listening device is
known by other means such as setting or automatic
detection, the weekly sound exposure level, as
described in EN 503 32 - 3, shall be ≤ 80 dB when
playing the fixed "programme simulation noise"
described in EN 50332 - 1.
– for equipment provided with a standardized
connector (for example, a 3,5 phone jack) that
allows connection to a listening device for general
use, the unw eighted r.m.s. output level, integrated
over one week, as described in EN50332 - 3, shall be
≤ 15 mV (analogue interface) or - 30 dBFS (digital
interface) when playing the fixed “programme
simulation noise” described in EN 50332 - 1. N/A
10.6.4
Requirements f or maximum sound exposure
N/A
10.6.4.1 Measurement methods

All volume controls shall be turned to maximum
during tests.

Measurements shall be made in accordance with EN
50332 - 1 or EN 50332 - 2 as applicable. N/A
10.6.4.2 Protection of persons

Except as given below, protection requirements for
parts accessible to ordinary persons , instructed
persons and skilled persons are given in 4.3.

NOTE 1 Volume control is not considered a safeguard.

Between RS2 and an ordinary person , the basic
safeguard may be r eplaced by an instructional
safeguard in accordance with Clause F.5, except
that the instructional safeguard shall be placed on
the equipment, or on the packaging, or in the
instruction manual. N/A
