1D1-10 M162 ENGINE COOLING
THERMOSTAT
Removal & Installation Procedure
1. Drain the coolant from the radiator.
2. Loosen the hose mounting clamp (6) and remove the heater
hose (7).
3. Unscrew the three bolts (5) and remove the thermostat cover
bracket, thermostat cover and the thermostat in order.
Installation Notice 1 Thermostat Cover
2 Thermostat
3 O-ring
4 Thermostat Cover Bracket5 Bolt (M6 X 25, 3 pieces).........................9-11 Nm
6 Hose Mounting Clamp
7 Heater Hose
Do not separate the thermostat cover and thermostat.
4. Replace the O-ring if necessary.
5. Check the leakage in the cooling system.
Tightening Torque 9 - 11 Nm

M162 ENGINE COOLING 1D1-11
OIL COOLER PIPE LINE
Preceding Work : Removal of upper intake manifold
Tightening Torque 9 - 11 Nm 1 Upper Intake Manifold
2 Bolt (M6 X 35, 1 piece)...........................9-11 Nm
3 Bolt (M6 X 16, 2 pieces).........................9-11 Nm4 Oil Cooler Pipe Line
5 O-ring .................................................... Replace
Removal & Installation Procedure
1. Drain the coolant.
2. Unscrew the bolts (2, 3) and remove the oil cooler pipe line (4).
Replace the O-ring with new one.
Installation Notice
3. Installation should follow the removal procedure in the
reverse order.
4. Fill up the coolant as specified.
5. Check the leaks in the cooling system.

1D1-12 M162 ENGINE COOLING
COOLING FAN AND VISCOUS CLUTCH
Preceding Work : Removal of cooling fan shroud
1 Cooling Fan Pulley
2 Viscous Clutch
3 Cooling Fan4 Bolt (M6 X 12, 4 pieces).........................9-11 Nm
5 Bolt (M10 X 45, 1 piece).................40.5-49.5 Nm

M162 ENGINE COOLING 1D1-13
Tools Required
603 589 00 40 00 Counter Holder
Removal & Installation Procedure
1. Hold the cooling fan pulley using the counter holder (special
tool : 603 589 00 40 00) and remove the cooling fan after
unscrewing the four bolts (4).
Installation Notice
2. Remove the bolt (5) from the viscous clutch and remove
the viscous clutch from the cooling fan pulley.
Installation Notice
Tightening Torque 9 - 11 Nm
Tightening Torque 40.5 - 49.5 Nm
3. Installation should follow the removal procedure in the
reverse order.

1D1-14 M162 ENGINE COOLING
COOLING FAN SHROUD
Removal & Installation Procedure
1. Pull out the 2 clips (1) from the fan shroud assembly.
2. Remove the lower fan shroud (2).
Notice
For installation, exactly align the lower fan shroud pin into
the hole of the fan shroud assembly (4) and insert the
clips.
3. Remove the bolts (3) and then remove the cooling fan
shroud assembly (4). 1 Clip
2 Lower Fan Shroud
3 Bolt
Installation Notice
4. Installation should follow the removal procedure in the
reverse order.
Tightening Torque 7 Nm4 Fan Shroud Assembly
5 Radiator

M162 ENGINE COOLING 1D1-15
RADIATOR
Preceding Work : Removal of cooling fan shroud
1 Radiator Inlet Coolant Hose
2 Radiator Outlet Coolant Hose
3 Make Up Coolant Hose
4 Automatic Transmission Oil Cooling Hose
5 Automatic Transmission Oil Cooling Line6 Bolt
7 Insulator
8 Stopper
9 Bolt............................................................. 7 Nm
10 Radiator

1D1-16 M162 ENGINE COOLING
Removal & Installation Procedure
1. Drain coolant from the radiator.
2. Remove the coolant thermo connector from the radiator.
3. Remove the each coolant hoses.
Tightening Torque 14 Nm
4. Remove the automatic transmission oil cooling hose.
Installation Notice
5. Remove the automatic transmission oil cooling line bolts
and then remove the oil cooling line.
6. Remove the radiator upper mounting bolts and then
remove the bracket and insulator.
7. Remove the radiator.
8. Check the radiator pin for crack, damage, leakage and
bending and replace if necessary.
9. Installation should follow the removal procedure in the
reverse order.
10. Do cooling system leakage test.

Circulation Type
Radiation
Capability
SECTION 1D2
M161 ENGINE COOLING
Specifications . . . . . . . . . . . . . . . . . . . . . . . 1D2-1
General Specifications . . . . . . . . . . . . . . . . . 1D2-1
Fastener Tightening Specifications . . . . . . . . 1D2-2
Special Tools . . . . . . . . . . . . . . . . . . . . . . . 1D2-3
Special Tools Table . . . . . . . . . . . . . . . . . . . . 1D2-3
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . 1D2-4
System Leakage Test . . . . . . . . . . . . . . . . . . 1D2-4
Maintenance and Repair . . . . . . . . . . . . . . 1D2-5
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . 1D2-5Coolant Drain and Fill Up . . . . . . . . . . . . . . . 1D2-5
Cooling Fan and Viscous Clutch . . . . . . . . . . 1D2-7
Coolant Pump . . . . . . . . . . . . . . . . . . . . . . . . 1D2-9
Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . 1D2-11
Thermostat Housing Assembly . . . . . . . . . . 1D2-12
Removal and Installation of Cooling
Fan Shroud . . . . . . . . . . . . . . . . . . . . . . . 1D2-14
Removal and Installation of Radiator . . . . . 1D2-15
SPECIFICATIONS
GENERAL SPECIFICATIONS
CAUTION: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
Description
Water Cooling Forced Circulation
Down Flow
61,500 kcal/h
58,000 kcal/h
680 x 415 x 25 mm
680 x 415 x 28 mm

f 460, 9 Blades
ALUTEC-P78, Dragon Power Coolant A
50 : 50
10.5 L
3.4 L
1.4 bar Application
Cooling Type
Radiator
Dimension(Width´Height´Thickeness)
Cooling Fan
Anti-Freeze Agent
Mixing Ratio of Anti-Freeze Agen with Water (Anti-Freeze Agent : Water)
Coolant Capacity
Reservoir Capacity
Cap Operating Pressure (Reservoir Tank Pressure Cap)

1D2-2 M161 ENGINE COOLING
FASTENER TIGHTENING SPECIFICATIONS
N
· ·· ·
·m
30
22.5 - 27.5
9 - 11
9 - 11
9 - 11
40.5 - 49.5
3 - 7
3 - 7 Application
Coolant Drain Plug
Engine Hanger Bracket and Coolant Outlet
Port Bolt
Thermostat Cover Bracket Bolt
Oil Cooler Pipe Line Bolt
Cooling Fan Bolt
Viscous Clutch Bolt
Automatic Transmission Oil Cooling Hose Bolt
Cooling Fan Shroud Bolt

M161 ENGINE COOLING 1D2-3
SPECIAL TOOLS
SPECIAL TOOLS TABLE
124 589 15 21 00
Tester603 589 00 40
Counter Holder
111 589 02 01 00
Open End Wrench111 589 00 40 00
Open End Wrench
