Page 41 of 84
Navigation 51
Route Options
3Select (calculate)
4Select (start).
Detour
You can specify a detour distance from your current position. The sys-
tem will calculate an alternative route according to the distance specifi-
cation, enabling you to take a detour.
1Press the button, then select (route
options), and then select (detour).
2Select a detour distance using , , ,
or (whole route).
The system will then calculate an alternative route that detours
from the current location within the specified distance.
When driving on the freeway, make a selection from among , 15 mi, 25 mi and .
3Select (start).
NOTE
If you are driving off the route, it is not possible to calculate a detour route.
Impreza_B1962BE-A.book Page 51 Wednesday, May 7, 2008 9:01 PM
Page 42 of 84
52 Navigation
Route Options
Route preferences
Use this function to specify preferred route search conditions. The sys-
tem will start recalculating the route according to your specified condi-
tions.
1Press the button, then select (route
options), and then select (route preferences).
2Specify conditions by selecting keys.
Each time you select a key, it will toggle between "usage" and
"non-usage" of the corresponding roads or ferries.
3Select (calculate).
NOTE
• The (calculate) key can be selected during route guidance.
• The route calculation will not always be able to follow the specified condi-
tions.
Destination and waypoints
You can change the destination or waypoints for the route calculation
by using this function.
■ Addition of waypoints
Use the following procedure to add new waypoints to the current route
for recalculation.
1Press the button, then select (route
options), and then select (destination and way-
points).
2Select (add).
Impreza_B1962BE-A.book Page 52 Wednesday, May 7, 2008 9:01 PM
Page 43 of 84
Navigation 53
Route Options
3Set a waypoint using any method available from the
screen.
4Specify the order in which all the set waypoints are to be
visited.
Choose the location of the waypoint to be added, and then
select (add).
5Select (calculate).
NOTE • When a new destination is set usin g (destination), it will replace the
current destination and the route calculation will be carried out again.
• Step 4 must be performed for the second and any subsequent waypoints.
• Repeat Steps 1 to 4 for each waypoint to be set.
■ Modifying destination or waypoint positions
Use this procedure to modify the destination or waypoint positions. The
screen will display the calculated ro ute and the positions of the destina-
tion or waypoints that you will be able to modify.
1Press the button, then select (route
options), and then select (destination and way-
points).
2Select (list).
3Select (change location).
Impreza_B1962BE-A.book Page 53 Wednesday, May 7, 2008 9:01 PM
Page 44 of 84
54 Navigation
Route Options
4Select the key corresponding to the location that is to be
modified.
The map for the area around your current location will be dis-
played.
5Scroll the map to bring the crosshair to the location
and then select .
6Select (calculate).
■ Modifying visiting order
You can change the order for visiting your waypoints by using this pro-
cedure.
1Press the button, then select (route
options), and then sele ct (destination and way-
points)
2Select (list).
3Select the waypoint keys according to the order of your
visit.
If you wish to cancel the visiting order number indication, select (undo).
4When you complete the sequencing, the visiting order
will be updated automatically.
5Select .
6Select(calculate).
Impreza_B1962BE-A.book Page 54 Wednesday, May 7, 2008 9:01 PM
Page 45 of 84
Navigation 55
Route Options
■Deleting destination or waypoints
Use this procedure when you wish to delete the previously set destina-
tion or waypoint.
1Press the button, then select (route
options), and then sele ct (destination and way-
points).
2Select (delete).
3Select the key corresponding to the destination or way-
point you wish to delete.
4Confirmation message will be displayed. Select
(yes).
Select (no) to cancel the deletion.
5Select (calculate).
Impreza_B1962BE-A.book Page 55 Wednesday, May 7, 2008 9:01 PM
Page 46 of 84
56 Navigation
Route Options
■Deleting destination and all waypoints
You can delete the destination and a ll previously set waypoints in a sin-
gle process.
1Press the button, then select (route
options), and then sele ct (destination and way-
points).
2Select (delete all).
3Confirmation message will be displayed. Select
(yes).
Select (no) to ca ncel the deletion.
Display route
Use this function to display the entire route. You can also specify an area
you wish to avoid and prompt the system to recalculate the route
accordingly.
1Press the button, then select (route
options), and then select (display route).
2Select (turn list).
The entire route screen will appear and then it will change to the
Turn List screen.
Impreza_B1962BE-A.book Page 56 Wednesday, May 7, 2008 9:01 PM
Page 47 of 84
Navigation 57
Route Options
(avoid ):
Select this key if you wish to sp ecify any areas to avoid from the
list of street names.
(Reroute ):
The system will recalculate the route.
If the data for the route cannot be shown on one screen, scroll the
screen using the and keys.
3When the Reroute is selected: Select (start).
Route preview
The system can show you an automated simulation of the calculated route.
1Press the button, then select (route
options), and then select (route preview).
2Start the simulation drive according to the calculated
route using the keys on the screen as follows:
: Move to the start point.
: The simulation drive will start toward the start point. After the
start, this key will be displayed as ,and when it is
selected, the simulation drive will switch to high-speed driving.
: The simulation drive will stop.
: The simulation drive will start toward the destination. After the start, this key will be displayed as , and
when it is selected, the simu lation drive will switch to
high-speed driving.
Impreza_B1962BE-A.book Page 57 Wednesday, May 7, 2008 9:01 PM
Page 48 of 84
58 Navigation
Route Options
: Move to the destination.: The EDIT ROUTE PREVIEW screen will be displayed. (See Page 58.)
NOTE
The visual speed of the simulation vehicle varies with the map scale selected.
The speed appears to be faster with a wide-area map than with a zoom-in map.
■Setting conditions for simulation drive
You can change the simulation drive conditions using this procedure.
1Press the button, then select (route
options), and then select (route preview).
2Select (edit).
The EDIT ROUTE PREVIEW screen will appear.
(to destination or next waypoint):
The simulation drive will stop at the destination or the next way-
point.
(to next POI):
The simulation drive will stop at a point of interest that has been
set up on the route.
(delete):
A selected POI will be deleted.
Impreza_B1962BE-A.book Page 58 Wednesday, May 7, 2008 9:01 PM
Page 49 of 84
Navigation 59
Route Options
POI keys:
When you select one of the six POI category keys, the system will
retrieve the selected POI from the Quick POI storage and display it on
the map. When you select the (others)
key, you can find POIs of other categories. For more details, See Page
63.
If, for example, the (to next POI) category
key is selected and a simulation drive is started, your simulation
vehicle will then stop at a restaurant on the route.
If you then select (information), the system will display
information on the restaurant.
.
Selecting allows you to make a phone call to the phone
number displayed.
* The Bluetooth Phone is required to be set in advance.
NOTE
You must finish the simulation drive before you actually start to drive. Although
the simulation drive will automatically stop when you actually start to drive, not
finishing it properly can lead to an erro r in the display of your vehicle's current
position.
Impreza_B1962BE-A.book Page 59 Wednesday, May 7, 2008 9:01 PM
Page 50 of 84
60 Navigation
Navigation Setup
Setting Your Navigation System
Using the functions available from the Navigation Setup
screen, you can change the map display conditions and alter
the route guidance conditions.
1Press the button.
2Select (navigation setup).
The NAVIGATION SET UP screen will appear.Select any of the displayed functions as necessary. This screen
consists of two pages. Change the page by using
the or keys.
