key SUBARU LEGACY 2010 5.G Navigation Manual

Navigation 41
Setting Route
1
First, choose either of the two procedures below to fol-
low the "home" category.Press the button.
2
Select (home) or the preset keys (Preset 1)
through (Preset 5).
NOTE(home) and the preset keys (Preset 1) through (P reset
5) are displayed only when you have stor ed the home location and other loca-
tions in the memory. 3
Select (destination) or (waypoint).The map including the home location or the selected location will
be displayed.
■ "Point of Interest" categoryYou can use a selection from the "Point of Interest" listing as the des ti-
nation or a waypoint.
1
Press the button and select (point of inter-
est).
2
Enter the name of the desired point of interest and
select .
: Use this key to delete the character last entered. Select it repeatedly if you want to delete all of the characters
entered.
NOTE
During character entry, the system shows the point of intere st list automatically
when the amount of matching points of interest is four or less .
EN(Hokubei)_Legacy_02_Navi-a.fm Page 41 Friday, May 1, 2009 11:21 AM

42 NavigationSetting Route3
Select the desired point of interest from the list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
NOTE
• If two or more points of interest share the same name, they will both be listed
on the screen. Choose an appropriate one from the list.
• If there are two or more points of interest with the same name,
select (category) or (City) to shorten the list.
• Displayed information about a specific facility might not include recent
changes. It is recommended that you check the location or bu siness days/
hours of a desired point of interest before departure.4
Select (destination) or (waypoint).
■ "Previous Destination" category
This method allows you to choose one of the most recently used 100
destinations or waypoints as th e new destination or waypoint.
1
Press the button, select , and then
select (previous destination).
2
Select a desired location from the Previous Destination
list.
:Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
NOTE • You can select (name) or (date) to c hange the
sequence in which previous destinations are displayed.
• Selecting displays the start point of the
previous route guide.3
Select (destination) or (waypoint).
Legacy_B2462BE-A.book Page 42 Wednesday, April 22, 2009 5:32 PM

Navigation 43
Setting Route
■"Select from Map" categoryYou can specify a location on the map that was last displayed and use it
for setting the destination or a waypoint.1
Press the button and select (select from
map).
2
Scroll the map until the crosshair is at the desired
destination or waypoint.
3
Select (destination) or (waypoint).
■ "Freeway Entrance/Exit" category
You can use the name of a Freeway entrance or exit selected from the
"Freeway Ent./Exit" list for setting the destination or a waypoint.1
Press the button, select , and then select
(Freeway Ent./Exit).
2
Enter the name of the desired freeway and select .
: Use this key to delete the character last entered. Select it repeatedly if you want to delete all of the characters
entered.
NOTE
During character entry, the system shows the freeway name lis t automatically
when the amount of matching freeways is four or less.3
Select the name of the freeway from the list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
Legacy_B2462BE-A.book Page 43 Wednesday, April 22, 2009 5:32 PM

44 NavigationSetting Route
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
4
Select(entrance) or (exit).
5
Select the name of the street from which you will enter
the freeway or to which you will go after leaving the free-
way.
: Select this key before you can enter the street name.
: Use this key to search through the list by distance. : Use this key to search throug
h the list by name (alphabeti-
cal search)
6
Select (destination) or (waypoint).
■ "Emergency" category
This function allows the nearest police station or hospital to be set as
the destination.1
Press the button and select (emergency).
2
Select either (Police sta-
tion) or (Hospital).The nearest police stations or hospitals will be displayed accord-
ingly.
Legacy_B2462BE-A.book Page 44 Wednesday, April 22, 2009 5:32 PM

Navigation 45
Setting Route
3
Select the desired institution from the list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
: Sorts the list by distance.
: Sorts the list in alphabetical order by name.
4
Select (destination) or (waypoint).
NOTE
Displayed information about each facility might be changed. It is recommended
that you check the location or business days/hours before de parture.
■"Coordinates" categoryYou can set destinations or waypoi nts using their latitudes and longi-
tudes as follows:1
Press the button, sele ct , and then select
(coordinates).
2
Enter the latitude of the desired location.Use the numeric keys together with the [°] (degrees), ['] (minutes),
and ["] (seconds) keys.
: Use this key to delete the character last entered. Select it repeatedly if you want to delete all of the characters
entered.
Legacy_B2462BE-A.book Page 45 Wednesday, April 22, 2009 5:32 PM

46 NavigationSetting Route3
Enter the longitude of the location.
: Use this key to switch over to the north latitude.
: Use this key to switch over to the south latitude. : Use this key to switch over to the west longitude.
: Use this key to switch over to the east longitude. : Use this key to delete the character last entered. Select it repeatedly if you want to delete all the characters entered.
4
Select (OK).
5
Select (destination) or (waypoint).
■ "Intersection" category
You can use a intersection defined by two street names as a location f or
setting your destination or a waypoint.1
Press the button, select , and then
select (Intersection).
2
Enter the name of the first street and then select .
: Use this key to delete the character last entered. Select it repeatedly if you want to delete all of the characters
entered.
NOTE
During character entry, the system shows the street name lis t automatically
when the amount of matching streets is four or less.
Legacy_B2462BE-A.book Page 46 Wednesday, April 22, 2009 5:32 PM

Navigation 47
Setting Route
3
Select the street from the "Intersection" list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
4
Specify the second street using the same procedure as
the first street. Select (List).
5
When there are two or more candidates, a list of intersec-
tions will be displayed. Select an intersection of the des-
tination.
NOTE
No intersection is defined if
• the two streets do not cross each other,
• the two streets are a freeway and a highway,
• either street is for right or left turns only,
• both are one-way streets,
• either street is for U-turns,
• the two streets cross on the inside lane,
• either street is an on/off ramp, and/or
• either street is a frontage street.6
Select (destination) or (waypoint).
Legacy_B2462BE-A.book Page 47 Wednesday, April 22, 2009 5:32 PM

48 NavigationSetting Route■"Phone number" categoryThis function allows buildings and the like to be located using their
phone numbers.1
Press the button, select , and then select (phone number).
2
Enter the phone number starting with the area code.
: Use this key to delete the character last entered. Select it repeatedly if you want to delete all of the characters
entered.
3
Select .
4
Select your destination.
NOTE
If a number of candidates exist as a result of, for example, di fferent area codes,
these will be displayed in a list. The desired destination can the n be selected
from the list.5
Select (destination) or (waypoint).
Legacy_B2462BE-A.book Page 48 Wednesday, April 22, 2009 5:32 PM

Navigation 51
Route GuidanceRoute Guidance ScreenDuring route guidance, the system can indicate on a second
screen the directions in which you must make turns at the
next and following intersection in either of two ways: "turn
arrow" or "turn list". Specify your preferred method of indica-
tion as follows:
1
Select (screen configuration).
2
Select for turn arrow indication or for turn list
indication.If you do not need to make any further selections, select .
The displayed keys will be hidden.
Turn direction is indicated by an arrow.Turn directions are indicated in a list. list>
EN(Hokubei)_Legacy_02_Navi-a.fm Page 51 Friday, May 1, 2009 11:28 AM

52 NavigationRoute GuidanceZoom-in Map at IntersectionBefore you arrive at an intersection, the system will automati-
cally show a zoom-in map of the intersection on a second
screen to make the guidance clearer.As you approach an intersection during route guidance, a zoom-in map
of the intersection automatically appe ars on a second screen. After you
drive past the intersection, the zoom-in map disappears.
As you approach a fork on a freeway during route guidance, a zoom-in
map of the freeway automatically a ppears on a second screen, making
the route guidance clearer.
NOTE
Use the following procedure to recall the most recently disp layed zoom-in map
of an intersection or a freeway fork.
1. Select (screen configuration).
2. Select (re-display of intersection/range guidance). If you do not need to make any further selections, select . The displayed
keys will be hidden.
EN(Hokubei)_Legacy_02_Navi-a.fm Page 52 Friday, May 1, 2009 11:28 AM
