SUBARU OUTBACK 2005 4.G Owners Manual

5-46
Audio
"
While the player is in the loading mode, if you press
“FM” or “AM” button, the player will enter standby
mode. Press the “CD” button to start playback. " Loading all the magazine (Full disc loading mode)
0
1. If you continue to press the “LOAD” button for more
than 1.5 seconds, the player will produce beep sound
and will enter the full disc loading mode.
2. When the disc number indicator and “ALL LOAD”
indicator start flashing, insert a disc within 15 seconds.
If a disc is successfully loaded during this period, the
disc number indicator will stop blinking and will steadi-
ly light. 3. When the loading of a disc is complete, the next
disc number indicator will blink. Then repeat Step 2.
4. When the magazine is filled with discs by repeating
Steps 2 and 3, the player will start playback of the
discs, beginning with the one inserted first.
If you fail to insert any disc during each 15 seconds in-
terval, the full disc loading mode will be canceled, and
the player will start playback of the disc inserted first. !
How to play back a CD or make a pause
" When there is no CD inserted:
Insert a CD by referring to “How to insert a CD(s)”.
When a CD is loaded, the player will start playback of
the CD, beginning with the first track.
LOAD
UB5216BA

5-47
Audio
– CONTINUED –
"When there are CDs loaded:
Press a desired one of the “Disc select” buttons the
disc number indicator of which steadily lights up. The
player will then start playback of the selected CD, be-
ginning with the first track.
If a disc that the player cannot read has been loaded,
the player will eject that disc and proceed to the nextdisc. !
To select a song from its beginning
" Forward direction
Briefly press the “ ” side of the TUNE/TRACK but-
ton to skip to the beginning of the next track/file (track).
Each time the button is pressed, the indicated track/
file (track) number will increase.
NOTE
In an MP3 folder, skipping past the last track/file (track) will take you back to the first track/file
(track) in the folder.
123 456
UB5210AA
TUNE
TRACK
UB5211BA

5-48
Audio
"
Backward direction
Briefly press the “ ” side of the TUNE/TRACK but-
ton to skip to the beginning of the current track/file
(track). Each time the button is pressed, the indicated
track/file (track) number will decrease.
NOTE
In an MP3 folder, skipping past the first track/file
(track) will take you to the last track/file (track) in the folder. !
Fast-forwarding and fast-reversing
" Fast-forwarding
Press the “ ” side of the TUNE/TRACK button con-
tinuously for more than 0.5 second to fast-forward thedisc/folder.
Release the button to stop fast-forwarding.
NOTE
If you fast-forward to the end of the last track/file
(track), fast-forwarding will stop and the player will start playback beginning with the first track/file(track).
TUNE
TRACK
UB5211CA
TUNE
TRACK
UB5211BA

5-49
Audio
– CONTINUED –
"Fast-reversing
Press the “ ” side of the TUNE/TRACK button con-
tinuously for more than 0.5 second to fast-reverse the disc/folder.
Release the button to stop fast-reversing.
NOTE
If you fast-reverse to the beginning of the first
track/file (track), fast-reversing will stop and the
player will start playback. !
Repeating
" To repeat the currently playing track/file (track)
To repeat a track/file (track), briefly press the “RPT”
button while the track/file (track) is playing. The dis-
play will show “RPT”, and the track/file (track) will be
repeated.
To cancel the track/file (track) repeat-play mode, brief-
ly press the “RPT” button twice. The “RPT” indication
will go off, and the normal playback mode will be re- sumed.
NOTE " Each time you briefly press the button, the mode
will change to the next one in the sequence shown
TUNE
TRACK
UB5211CA
RPT
RDM
UB5217BA

5-50
Audio
below.
If you accidentally press the button and cancel the
track/file (track) repeat-play mode, press it again
to reselect the repeat-play mode. "
The repeat-play mode will be cancelled if you
perform any of the following steps: "Press the “RPT” button
" Press the “ ” button
" Press the disc select button
" Select the radio mode
" Press the “ ” or “ ” side of the SEEK/
SCAN button " Turn off the power of the audio equipment.
" Turn the ignition switch to the “OFF” position. "
To repeat the currently playing disc/folder
To repeat the currently playing disc/folder, press the
“RPT” button twice while a track/file (track) is playing.
The display will show “D-RPT”, and the disc/folder will
be played repeatedly.
To cancel the disc/folder repeat play mode, press the “RPT” button once more. The “D-RPT” indication will
go off, and the normal playback mode will be resumed.
NOTE " Each time you briefly press the button, the mode
will change to the next one in the sequence shown
below.
RPT D-RPT CANCEL
RPT
RDM
UB5217BA

5-51
Audio
– CONTINUED –
If you accidentally press the button and cancel the
disc/folder repeat-play mode, press it again to re-
select the disc/folder repeat-play mode. "The disc/folder repeat-play mode will be can-
celled if you perform any of the following steps:
"Press the “RPT” button
" Press the “ ” button
" Press the disc select button
" Select the radio mode
" Press the “ ” or “ ” side of the SEEK/
SCAN button " Turn off the power of the audio equipment.
" Turn the ignition switch to the “OFF” position. !
Random playback
Press the “RPT” button briefly during disc/folder play-
back to play all of the tracks/files (tracks) on the disc/
folder in a random order. The display will show “RDM”,
and all of the tracks on the disc/folder will be played in
a random order.
To cancel random playback, press the “RPT” button
again for at least 1.5 second. The “RDM” indication will
go off, and the normal playback mode will be resumed.
NOTE
Random playback will be cancelled if you perform
any of the following steps: " Press the “RPT” button
RPT D-RPT CANCEL
RPT
RDM
UB5217BA

5-52
Audio
"
Press the “ ” or “ ” side of the SEEK/SCAN
button " Press the “ ” button
" Press the disc select button
" Select the radio mode
" Turn off the power of the audio equipment.
" Turn the ignition switch to the “OFF” position.
! Auto tuning (scan mode)
The scan mode lets you listen to the first 10 seconds
of each track/file (track) in succession. Press the “ ”
side of the SEEK/SCAN button for 1.5 second or long-
er to start scanning upward beginning with the track/
file (track) following the currently selected one. Press the “ ” side of the button to start scanning down-
ward beginning with the track/file (track) preceding the
currently selected one. When all tracks/files (tracks) in
the disk/folder have been scanned, normal playback
will be resumed. To cancel the scan mode, press the
“ ” or “ ” side of the button for 1.5 second or long- er.
NOTE
The scan mode will be cancelled if you perform
any of the following steps: "
Press the “RPT” button
" Press the “ ” or “ ” side of the TUNE/
TRACK button" Press the “ ” or “ ” side of the SEEK/SCAN
button " Press the “ ” button
" Press the disc select button
" Select the radio mode
" Turn off the power of the audio equipment.
" Turn the ignition switch to the “OFF” position.
SEEK
SCAN
UB5212DA

5-53
Audio
– CONTINUED –
!Display selection
If you press the “TEXT” button for 0.5 second or longer
during playback, the indication will change to the next
one in the sequence shown below. !
Page (track/folder title) scroll
If, having pressed the “TEXT” button to select track ti-
tle or folder title display, you press the “TEXT” button
again for less than 0.5 second, the title will be scrolled
so you can see all of it. You will see eight characters
at a time.
NOTE
The display is designed to show titles for up to
eight pages (64 characters in total). However, it
may in some cases show titles for only up to four
pages (32 characters in total).
TEXT
UB5218BA
Folder number/file (track) number Track title
Folder title
TEXT
UB5218BA

5-54
Audio
!
Folder selection
Press the “ ” side of the SEEK/SCAN button briefly
to select the next folder. Press the “ ” side of the
button briefly to go back to the previous folder. The
folder title will be shown each time you press one of the buttons.
NOTE " Selecting folders in this way is possible only
within a single disc. " Only MP3 folders are recognized when an at-
tempt to select the next or previous folder is made.
If no appropriate folder exists on the disc, press-
ing the “ ” or “ ” side of the SEEK/SCAN but- ton has no effect. !
How to unload CDs from the player
" Ejecting a CD from the player
Of the discs loaded, you can select and remove only
one disc.
0
1. Use the disc select button to select the disc to be
ejected.
SEEK
SCAN
UB5212DA123 456
UB5210AA

5-55
Audio
– CONTINUED –
2. Briefly press the “ ” button. The selected disc
will be ejected. The disc number indicator will flash at
this time. When you remove the ejected disc, the disc
number indicator will go off.
To remove more discs in succession, repeat Steps 1
and 2. "
Ejecting all discs from the player (All disc ejec-tion mode)
0
1. If you continue to press the “ ” button, the play-
er will produce beep sound and will enter the all disc
ejection mode. At this time, the disc number indicator
and “ALL EJECT” indicator will flash.
2. Remove the disc that has been ejected. The other
discs loaded will then be ejected one after another. If
you do not remove the disc that has been ejected, the
“All disc ejection mode” will be canceled.
NOTE "Avoid driving the vehicle with a CD sticking out,
because vibration might make it fall out.
UB5215BA
UB5215BA
