SUBARU WRX 2018 Owners Manual

(330,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Commands for Bluetooth audio
control
Voice command Function
Pause Pause play
Track Up Select the next track
Track DownSelect the current
track
Repeat?1 track
Repeat, Repeat All,
Group RepeatSelect a repeat mode
1 Track Repeat Repeat single track
Repeat All Repeat all tracks
Group RepeatRepeat tracks on
group
Shuffle?Shuffle All,
Group Shuffle, Shuffle
OFFSelect a random play
mode
Shuffle All Shuffle all tracks
Group ShuffleShuffle tracks on
group
Shuffle OFFTurn off shuffle
Audio/Voice command system
5-86

(331,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
What to do if...&TroubleshootingIf there is a problem with the hands-free system or a Bluetooth device, first check the table below.
When using the hands-free system with a Bluetooth device
Symptom Likely cause SolutionPage
Cell
phoneThis
system
The hands-free system or Bluetooth
device does not work.The connected device may not be a
compatible Bluetooth cell phone.For USA customers, please visit
www.subaru.com for details. Outside of the
USA customers, contact your local dealer to
arrange a demonstration in order to confirm
whether or not the device can be paired with
the vehicle.*—
The Bluetooth version of the connected
cell phone may be older than the
specified version.Use a cell phone with Bluetooth version 1.1 or
higher (recommended: Ver. 2.1 + EDR or
higher).*5-66
*: For details, refer to the owner’s manual that came with the cell phone.
–CONTINUED–
Audio/What to do if...
5-87
5

(332,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
When registering/connecting a cell phone
Symptom Likely cause SolutionPage
Cell
phoneThis
system
A cell phone cannot be registered.An incorrect passcode was entered on
the cell phone.Enter the correct passcode on the cell phone. *—
The registration operation has not
been completed on the cell phone
side.Complete the registration operation on the cell
phone (approve registration on the phone).*—
Old registration information remains
on either this system or the cell phone.Delete the existing registration information from
both this system and the cell phone, then register
the cell phone you wish to connect to this system.*5-67
A Bluetooth connection cannot be
made.Another Bluetooth device is already
connected.Manually connect the cell phone you wish to use to
this system.—5-67
Bluetooth function is not enabled on
the cell phone.Enable the Bluetooth function on the cell phone. *—
Automatic Bluetooth connection on
this system is set to off.Set automatic Bluetooth connection on this system
to on when the ignition switch is turned to the“ACC”
or“ON”position.—5-67
*: For details, refer to the owner’s manual that came with the cell phone.
Audio/What to do if...
5-88

(333,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
When using the phonebook
Symptom Likely cause SolutionPage
Cell
phoneThis
system
Phonebook data cannot be trans-
ferred manually.The profile version of the connected cell
phone may not be compatible with
transferring phonebook data.For USA customers, please visit
www.subaru.com for details. Outside of the
USA customers, contact your local dealer to
arrange a demonstration in order to confirm
whether or not the device can be paired with
the vehicle.*—
Transfer operation on the cell phone has
not completed.Complete transfer operation on the cell phone
(approve transfer operation on the phone).*—
Phonebook data cannot be edited.Editing function is not available on this
system.——5-77
*: For details, refer to the owner’s manual that came with the cell phone.
–CONTINUED–
Audio/What to do if...
5-89
5

(334,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
In other situations
Symptom Likely cause SolutionPage
Cell
phoneThis
system
Even though all conceivable mea-
sures have been taken, the symptom
status does not change.The cell phone is not close enough to
this system.Bring the cell phone closer to this system.——
The cell phone is the most likely cause of
the symptom.Turn the cell phone off, remove and reinstall
the battery pack, and then restart the cell
phone.*—
Enable the cell phone’s Bluetooth connection. *—
Stop the cell phone’s security software and
close all applications.*—
Before using an application installed on the cell
phone, carefully check its source and how its
operation might affect this system.*—
*: For details, refer to the owner’s manual that came with the cell phone.
Audio/What to do if...
5-90

(335,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Appendix&Certification.Bluetooth
The Bluetooth word mark and logo are
registered trademarks of Bluetooth SIG,
Inc. and any use of such marks by Clarion
Co., Ltd. is under license..SiriusXM Satellite Radio (if
equipped)
SiriusXM
TM
and all related marks and
logos are trademarks of SiriusXM Radio
Inc. All rights reserved.
.Pandora (if equipped)
Pandora, the Pandora logo, and other
Pandora marks are trademarks or regis-
tered trademarks of Pandora Media, Inc.,
or its subsidiaries worldwide.
If you have any issues with the Pandora
application on your mobile phone, please
direct them to
[email protected].
.iPod
“Made for iPod”and“Made for iPhone”
mean that an electronic accessory has
been designed to connect specifically to
iPod or iPhone respectively, and has been
certified by the developer to meet Apple
performance standards. Apple is not re-
sponsible for the operation of this device or
its compliance with safety and regulatory
standards. Please note that the use of this
accessory with iPod or iPhone may affect
wireless performance.
iPhone, iPod, iPod classic, iPod nano,
iPod touch, and iTunes are trademarks of
Apple Inc., registered in the U.S. and other
countries..How to get the source code using the
open source
This system implements software using
theopensource.Forcustomerswho
would like to get the source code of the
software, it is available by downloading it
from the web site of Clarion Co., Ltd.
For details, refer to the following web site.http://www.clarion.com/us/en/support/in-
dex.html
&Certification for the Hands-
free system.U.S.-spec. models
CAUTION
FCC WARNING
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
–CONTINUED–
Audio/Appendix
5-91
5

(336,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
.Canada-spec. models
This transmitter must not be co-located or
operated in conjunction with any other
antenna or transmitter.
&Certification for Mexico mod-
els.IFETEL RCPCLPF14-250
Clarion PF-3547
.IFETEL RCPCLPF14-253
Clarion PF-3688
Audio/Appendix
5-92

(339,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Interior lights...........................................................6-2
Dome light............................................................. 6-2
Map lights.............................................................. 6-2
OFF delay timer..................................................... 6-3
Sun visors...............................................................6-3
Sun visor extension plate
(models with the EyeSight system)....................... 6-4
Vanity mirror with light........................................... 6-4
Storage compartment.............................................6-5
Glove box.............................................................. 6-5
Center console...................................................... 6-5
Cup holders.............................................................6-6
Front passenger’s cup holder................................. 6-6
Rear passenger’s cup holder.................................. 6-7
Bottle holders..........................................................6-8
Accessory power outlets........................................6-8
Use with a cigarette lighter (if equipped) ................ 6-9
Ashtray (if equipped)............................................6-10
Floor mat (if equipped)..........................................6-11
Coat hook...............................................................6-11
Under-floor storage compartment.......................6-12
Rear view camera.................................................6-13
How to use the rear view camera..........................6-14
Viewing range on the screen.................................6-15
Help line...............................................................6-16
Display adjustment...............................................6-18
Front View Monitor(if equipped).........................6-19
How to access the Front View Monitor..................6-19
How to cancel the Front View Monitor...................6-20
Range of image on screen....................................6-20
Guiding line..........................................................6-21
Handling of camera..............................................6-21
Interior equipment
6

(340,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Interior lights
CAUTION
When leaving your vehicle, make
sure the lights are turned off to
avoid battery discharge.&Dome light1) ON
2) DOOR
3) OFFThe dome light switch has the following
three positions.
ON:The light remains on continuously.
OFF:The light remains off.DOOR:The dome light illuminates auto-
matically after any of the following opera-
tions.
.Opening any of the doors.
.Unlocking the doors using the keyless
access function (if equipped). Refer to
“Unlocking”F2-11.
.Unlocking the doors using the remote
keyless entry system. Refer to“Remote
keyless entry system”F2-18.
.Turning the ignition switch from the
“ACC”position to the“LOCK”/“OFF”posi-
tion.
&Map lightsType AType BTo turn on the map light, push the switch.
To turn it off, push the switch again.
Interior equipment/Interior lights
6-2

(341,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Automatic illumination (type A map
lights)
The map lights illuminate automatically in
the following cases.
.Any of the doors is opened.
.The doors are unlocked using the
keyless access function (if equipped).
Refer to“Unlocking”F2-11.
.The doors are unlocked using the
remote keyless entry transmitter.
.The ignition switch is turned from the
“ACC”position to the“LOCK”/“OFF”posi-
tion.&OFF delay timerThe following lights have an automatic
illumination function.
.dome light (when the dome light switch
is in the“DOOR”position)
.map light (type A)
After being illuminated automatically,
these lights remain on for several seconds
and then gradually turn off after all doors
are closed.
While the lights are illuminated, the lights
turn off immediately after any of the
following operations.
.Turning the ignition switch from the
“LOCK”/“OFF”position to the“ACC”or
“ON”position..Locking all doors using the keyless
access function (if equipped).
.Locking all doors using the remote
keyless entry system.
The setting for the period of time in which
the lights remain on (OFF delay timer) can
be changed by a SUBARU dealer. Contact
your SUBARU dealer for details. Also, the
setting can be changed by operating the
multi-function display (color LCD). For
details, refer to“Interior light setting”F3-
61.
Sun visorsTo block out glare, swing down the visors.
To use the sun visor at a side window,
swing it down and move it sideways.
–CONTINUED–
Interior equipment/Sun visors
6-3
6
