.When waxing the vehicle, be careful
not to apply the wax to the camera. If it
comes in contact with the camera,
moisten a clean cloth with a diluted
neutral detergent to remove the wax.
.The camera lens has a hard coating
to help prevent scratches. However,
when washing the vehicle or cleaning
the camera lens, be careful not to
scratch the camera lens. Do not use a
washing brush directly on the camera
lens. The image quality of the rear view
camera may deteriorate.
.Strong light shined on the camera
lens may develop vertical lines around
the light source. This is not a malfunc-
tion.
.Under fluorescent light, the display
may flicker. However, this is not a
malfunction.
.The image of the rear view camera
may be slightly different from the actual
color of the objects.
&How to use the rear view
cameraWhen the shift lever (MT models) or select
lever (CVT models) is set to“R”, the rear
view camera automatically displays the
rear view image from the vehicle. When
the lever is set to other positions, the
image before setting to“R”is displayed.
1. Set the ignition switch to“ON”.
2. Set the shift lever (MT models) or
select lever (CVT models) to“R”.NOTE.The image of the rear view camera
has priority over other screen displays.
Therefore, while the rear view camera is
in operation, the operations of other
screens are disabled. To operate other
screens, set the shift lever or select
lever to a position other than“R”.
.The image of the rear view camera is
horizontally reversed as is the case
with the vehicle rear view mirror or the
side view mirror.
.It may be difficult to see the image of
the rear view camera in the following
cases. This is not a malfunction of the
camera.
–The vehicle is in a dark place (at
night, in a tunnel, etc.).
–The vehicle is in an extremely hotor cold place.
–An object (such as raindrops,
snow, dirt, etc.) that disturbs the
view of the rear view camera sticks
to the lens of the camera.
–Strong light shined directly on
the camera lens (occasionally, there
are vertical lines on the screen).
!Rear view image cancel delay func-
tion
The rear view image cancel delay function
will keep the rear view image displayed
after shifting the shift lever/select lever out
of the“R”position before the screen
returns to the previous screen.
Interior equipment/Rear view camera
6-14

(353,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
To turn on the rear view image cancel
delay function:
1. Touch the rear view image screen.1)“Delay”key2. Touch the“Delay”key.
It is possible to turn on/off the function by
touching the“Delay”key.NOTEIf the rear view screen is not touched
for 5 seconds, both the“Delay”and
“Display Adjustment”keys will turn off.
Touch the rear view screen to display
the keys again.
When the rear view image cancel delay
function is on, the rear view image screen
can be automatically returned to the
previous screen if any of the following aremet.
.9 seconds have passed since the shift
lever/select lever has shifted from the“R”
position to another position.
.The vehicle speed exceeds 5 mph (8
km/h).
.The select lever is shifted into the“P”
position (CVT models).
&Viewing range on the screen
CAUTION
The range that can be viewed with
the rear view camera is limited.
Always be sure to check with your
eyes when moving backward and
proceed slowly.
Range of viewRange of view
–CONTINUED–
Interior equipment/Rear view camera
6-15
6

(354,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Image from cameraThe area from the rear end of the bumper
can be viewed. Areas at both ends of the
bumper and areas just under the bumper
cannot be viewed.
Also, the image from the rear view camera
looks shorter than the actual distance.
Range of viewImage from cameraThe area above the camera cannot be
viewed. If there is an object that has a wide
projection on its upper part such as a sign
pole behind the vehicle, the projectioncannot be seen on the screen.
&Help lineThe help line (distance marker and vehicle
width line) is a guide to help you realize the
actual distance from the screen image.Help lines
1) Vehicle width line (oblique vertical line)
2) Approx. 10 feet (3 m) from the bumper
(green horizontal line)
3) Approx. 3 feet (1 m) from the bumper
(yellow horizontal line)
4) Approx. 1.5 feet (0.5 m) from the bumper
(red horizontal line)
5) Vehicle centerline
6) Warning messageWhen the shift lever/select lever is set to
position“R”, the monitor screen displays
the help lines together with the rear view
Interior equipment/Rear view camera
6-16

(355,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
image.
CAUTION
.When moving backward, always
check the back with your eyes
without relying on the help lines.
.The actual position may be differ-
ent from the indication of the help
lines.
.Differences may occur due to
number of passengers or loaded
cargo.
.When the vehicle is on a slope or
when the vehicle is inclined
against the road, the indication
is different from the actual posi-
tion.
.Be sure to observe the displayed
warning message.NOTEIf you shift to“R”within several
seconds after turning on the ignition
switch, the warning message may not
be displayed. After turning the ignition
switch“ON”, wait for several seconds,
and then shift to“R”. The warning
message will then be displayed.!Difference between screen image
and actual road
The distance markers show the distance
for a level road when the vehicle is not
loaded. It may be different from the actual
distance depending on the loading condi-
tions or road conditions.
!When there is an upward slope at
the back
1) 3 feet (1 m)The distance on the screen looks farther
than the actual distance.!When there is a downward slope
at the back
1) 3 feet (1 m)The distance on the screen looks nearer
than the actual distance.NOTEWhen cargo is loaded, the rear view
distance on the screen may look farther
than the actual distance as in an
upward slope.
–CONTINUED–
Interior equipment/Rear view camera
6-17
6

(356,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Feature of distance marker1) 3 feet (1 m) line
2) 10 feet (3 m) lineThe distance marker shows the distance
on the road. If there is a car or other object
close behind, distance cannot be correctly
displayed.
&Display adjustment1. Touch the rear view image screen.1) Display Adjustment key2. Touch the“Display Adjustment”key.1) Back key
3. Touch“+”or“”to change the setting.
4. After setting, touch the back key to
display the rear view image again.
Interior equipment/Rear view camera
6-18

(357,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Front View Monitor (if
equipped)The image from the camera mounted
inside the front grille is displayed in the
multi-function display (color LCD). This
eliminates blind spots and allows the driver
to check the forward direction of both
sides.
WARNING
.Never rely on only the Front View
Monitor when driving the vehicle.
The image on the monitor screen
may be different from the actual
situation. If you drive the vehicle
by viewing only the monitor im-
age, a collision or an unexpectedaccident may occur. When driv-
ing the vehicle, always check the
traffic around the vehicle directly
with your eyes and the mirrors.
.Always operate the vehicle as
you would without the Front View
Monitor.
.Do not use the Front View Monitor
in the following situations.
–You are driving on a dirt road
or a road covered in snow.
–The camera malfunctions (e.g.
the lens or bracket is broken).
.If the outside temperature is low,
the monitor screen may become
dark or the image may become
dim. In particular, the image of a
moving object may be distorted
or disappear from the screen.
You must always check the traffic
around the vehicle directly with
your eyes when driving it.
&How to access the Front View
Monitor1) VIEW switchTo change over to the camera screen,
perform either of the following operations
when the ignition switch is in the“ON”
position.
.Press the VIEW switch
.Shift the select lever from“R”to“D”
(only when the Camera Shift Link is set to
“On”) (for details, refer to“Camera shift link
setting”F3-58.)
–CONTINUED–
Interior equipment/Front View Monitor
6-19
6

(358,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&How to cancel the Front View
Monitor!Manual cancellation
Press the VIEW switch again.
!Automatic cancellation
If any of the following conditions are met,
the Front View Monitor is canceled auto-
matically.
After accessing the Front View Monitor
by pressing the VIEW switch:
.You press the VIEW switch.
.Approximately 3 minutes have passed
since the last operation.
.The vehicle speed becomes 12.5 mph
(20 km/h) or more*.
.The select lever (CVT models) is
shifted to the“P”position.
.The parking brake is applied.
*: The Front View Monitor can be activated
when pressing the VIEW switch, regard-
less of the vehicle speed.
After accessing the Front View Monitor
by using the select lever:
.Shift the select lever into the“P”
position.
.The vehicle speed becomes 5 mph (8
km/h) or more*.
.Approximately 9 seconds have passedsince the last operation.
.The parking brake is applied.
*: When the Front View Monitor is acti-
vated at speeds of more than 12.5 mph (20
km/h), to cancel the Front View Monitor,
the vehicle speed needs to be decreased
to less than 12.5 mph (20 km/h) and then
increased to more than 12.5 mph (20
km/h).
&Range of image on screenA) Traffic intersection with a poor visibility
view
B) Parking facing a wall
1) Range of displayed image
2) Obstacles (e.g., buildings, fences or
other vehicles)
Interior equipment/Front View Monitor
6-20

(359,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
WARNING
Because the range of the image
captured by the camera is limited,
always check the traffic around the
vehicle directly with your eyes when
driving the vehicle.NOTE.The range of the displayed image
may differ depending on the vehicle
status or the road surface status.
.Because the Front View Monitor
system uses a specially designed lens,
the sense of distance in the displayed
image is different from the actual dis-
tance.
.The camera image may be difficult to
view in the following situations. This is
not a malfunction.
–Dark place (at night)
–High or low temperature around
the lens
–Water contacts lens or in high
humidity (rainy weather)
–There is foreign materials (such
as mud) around the camera
–Sunlight or headlight beam di-
rectly shines towards the camera
lens
.Under an artificial light such as afluorescent lamp, sodium-vapor lamp
or mercury lamp, the lighted portion
may look like it is flickering (flicker
phenomenon).
.While the display has cooled down,
the image may leave traces or become
darker than usual, causing a difficulty
in viewing the screen. Always check the
traffic around the vehicle directly with
your eyes while driving the vehicle.
.The following incidents should not
be deemed a malfunction.
–The camera lens may become
foggy when the humidity is high on
a rainy day.
–The light from a vehicle or build-
ing located ahead may be reflected
towards the camera image while
driving at night.
–In a dark place or while driving at
night, the camera image may be
adjusted to make noises less visi-
ble. Therefore, the image may look
like a monochromatic image or the
image colors may differ from the
actual colors. The camera image
may be deteriorated in regard to
sharpness at the center and four
corners of the screen. This is not a
malfunction.
&Guiding line1) Guiding line
2) Warning messageThe guiding line that indicates the width
and the front end of your vehicle is
displayed on the display.&Handling of camera
CAUTION
Observe the following instructions.
Otherwise, the system may malfunc-
tion.
.Do not apply any strong impact to
the camera such as banging it or
hitting it with an object. The
mounting angle may change.
–CONTINUED–
Interior equipment/Front View Monitor
6-21
6

(360,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
.The camera unit is a waterproof
structure. Do not attempt to re-
move, disassemble or modify the
unit.
.Do not rub strongly or polish the
camera lens with a hard brush or
abrasive compounds. The lens
may be scratched resulting in an
adverse effect to the camera
image.
.The camera lens is made of glass
or plastic. Do not allow any
organic solvent, body wax, oil
film remover or glass coating
agent to become attached on the
lens surface. If any becomes
attached, remove it immediately.
.Do not expose the camera lens to
any sudden temperature change,
for example, spraying hot water
on it in cold weather.
.Do not apply the water jet of a
high pressure washer to the cam-
era or the surrounding area when
cleaning the vehicle. The impact
by the strong water pressure may
cause the camera to come off.
Also, water may enter inside the
camera and cause a malfunction.
.If the camera is exposed to any
impact, it may lead to malfunctionof the camera. Have the camera
inspected by your SUBARU deal-
er as soon as possible.
.Do not use a steam cleaner under
any circumstances. Some types
of steam cleaners inject hot
steam.
.The camera surface may be da-
maged by a flying stone.
NOTEIf the camera lens is contaminated, no
sharp image is available. When the
camera is contaminated with water
drops, snow or mud, wash it with water
and wipe away any moisture with a soft
cloth. If it heavily gets dirty, wash it with
a neutral detergent.
Interior equipment/Front View Monitor
6-22

(363,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Fuel..........................................................................7-3
Fuel requirements.................................................. 7-3
Fuel filler lid and cap............................................. 7-5
State emission testing (U.S.only).........................7-7
Preparing to drive...................................................7-8
Starting and stopping theengine..........................7-9
General precautions when starting/stopping
engine................................................................. 7-9
Models without push-button start systems............7-10
Models with push-button start systems ................. 7-11
Remote engine start system (dealer option)...........7-14
Manual transmission............................................7-16
Shifting speeds.....................................................7-17
Driving tips...........................................................7-18
Driver’s Control Center Differential
(C.DIFF/DCCD) (STI)...........................................7-18
To change mode of driver’s control center
differential..........................................................7-19
Auto mode............................................................7-20
Manual mode........................................................7-21
Temporary release................................................7-22
Continuously variable transmission....................7-23
Select lever...........................................................7-24
Selection of manual mode.....................................7-25
Shift lock function.................................................7-27
Driving tips...........................................................7-28
SI-DRIVE (if equipped)..........................................7-28
Intelligent (I) mode................................................7-28
Sport (S) mode.....................................................7-29
Sport Sharp (S#) mode..........................................7-29SI-DRIVE switch....................................................7-30
Limited slip differential (LSD)(STI).....................7-31
Power steering......................................................7-31
STI .......................................................................7-31
Except STI............................................................7-32
Braking..................................................................7-33
Braking tips..........................................................7-33
Brake system.......................................................7-33
Disc brake pad wear warning indicators................7-34
High performance brake system (STI)...................7-34
Red caliper with sports brake pad (if equipped) .... 7-34
ABS (Anti-lock BrakeSystem).............................7-35
ABS self-check.....................................................7-35
ABS warning light.................................................7-35
Electronic Brake Force Distribution (EBD)
system................................................................7-36
Steps to take if EBD system malfunctions .............7-36
Vehicle Dynamics Controlsystem......................7-37
Vehicle Dynamics Control system monitor ............7-39
Vehicle Dynamics Control OFF switch...................7-39
Tire pressure monitoring system (TPMS)
(U.S.-spec. models)...........................................7-40
Parking your vehicle............................................7-42
Parking brake (models without electronic parking
brake system)....................................................7-42
Electronic parking brake (models with electronic
parking brake system).......................................7-43
Parking tips..........................................................7-45
Auto Vehicle Holdfunction..................................7-46
To turn on/off the Auto Vehicle Hold function........7-47
To operate the Auto Vehicle Hold function ............7-48
Starting and operating
7
