SUZUKI AERIO 2007 1.G Manual PDF

Downloaded from www.Manualslib.com manuals search engine 4-6 INSTRUMENT PANEL
54G27-03E
Open Door Warning Light
54G391
This light remains on until all doors are
completely closed.“O/D OFF” Indicator Light
(if equipped)
54G142
When the ignition switch is turned to the
“ON” position with the 4-speed automatic
transaxle in the 4-speed mode (3-speeds
plus overdrive), this light comes on briefly
to let you know the light is working.
When the automatic transaxle is converted
to the 3-speed mode (overdrive is off) with
the ignition switch in the “ON” position, this
indicator comes on and stays on.
“CRUISE” Indicator Light
(if equipped)
52D113
When the cruise control system is on, this
light will be on.“SET” Indicator Light (if equipped)
65D474
When the vehicle’s speed is controlled by
the cruise control system, this light will be
on.
Turn Signal Indicators
50G055
When you turn on the left or right turn sig-
nals, the corresponding green arrow on the
instrument panel will flash along with the
respective turn signal lights.
When you turn on the hazard warning
switch, both arrows will flash along with all
of the turn signal lights.High Beam Indicator Light
50G056
This indicator comes on when headlight
high beams are turned on.
Warning and Indicator Lights: 8

Downloaded from www.Manualslib.com manuals search engine 4-7 INSTRUMENT PANEL
54G27-03E
Daytime Running Light (D.R.L.) Indi-
cator Light (if equipped)
60B245
With the D.R.L. system, the headlights
light, but are dimmer than the low beam,
when the following three conditions are all
met. Whenever the D.R.L. system is oper-
ating, the D.R.L. indicator light remains on.
Conditions for D.R.L. system operation
1) The engine is running.
2) The parking brake is released.
3) The lighting switch is at either the “OFF”
or the “middle” position.
A/T Selector Position
Indicator (if equipped)
54G453
When the ignition switch is in the “ON”
position, this indicator shows the selector
position of automatic transaxle.
Speedometer/Odometer/Trip
meter
54G524
(1) Speedometer
(2) Odometer/Trip meter
(3) Odometer/Trip meter selector knob
Speedometer
The speedometer indicates vehicle speed
in km/h and/or mph.
Odometer and trip meter
When the ignition switch is turned to “ON”,
the display shows the odometer or trip
meter.
The odometer records the total distance
the vehicle has been driven. The trip meter
can be used to measure the distance trav-
eled on short trips or between fuel stops.
(1) (2) (3)
EXAMPLE
Warning and Indicator Lights: 8
A/T Selector Position Indicator: 8
Speedometer/Odometer/Trip meter: 8

Downloaded from www.Manualslib.com manuals search engine 4-8 INSTRUMENT PANEL
54G27-03E
54G488
The display shows three types of indica-
tion; odometer, trip meter A and trip meter
B. Push the selector knob (3) quickly to
switch the indication among the three. You
can use the two trip meters (A and B) inde-
pendently.
65D481
Hold in the indication selector knob (3) for
about 2 seconds to reset the trip meter to
zero.
Brightness Control
54G455
(1) Brightness control knob
When the lighting switch is turned to the
second or third position, you can control
the brightness of instrument panel lights.
To change the brightness, push the bright-
ness control knob (1) quickly. Each time
you push the knob (1), the instrument
panel lights get dimmer then return to the
brightest condition after the meter lights
become the dimmest and the other instru-
ment panel lights are turned off.
CAUTION
Keep track of your odometer reading
and check the maintenance schedule
regularly for required services.
Increased wear or damage to certain
parts can result from failure to per-
form required services at the proper
mileage intervals.
(3)
(3)
About 2 seconds
(1)
EXAMPLE
Speedometer/Odometer/Trip meter: 8
Meter Illumination Control:

Downloaded from www.Manualslib.com manuals search engine 4-9 INSTRUMENT PANEL
54G27-03E
Tachometer
54G456
The tachometer indicates engine speed in
revolutions per minute.
Fuel Gauge
54G457
When the ignition switch is in the “ON”
position, this gauge gives an approximate
indication of the amount of fuel in the fuel
tank. “F” stands for full and “E” stands for
empty.
If the indicator gets off the graduation of
“E” (not character “E”), refill the tank as
soon as possible.
NOTE:
The indicator moves a little depending on
road conditions (for example, slope or
curve) and driving conditions because of
fuel moving in the tank.If the low fuel warning light (1) comes on,
fill the fuel tank immediately.
NOTE:
The activation point of the low fuel warning
light (1) varies depending on road condi-
tions (for example, slope or curve) and
driving conditions because of fuel moving
in the tank.
The mark (2) indicates that the fuel filler
door is located on the left side of the vehi-
cle.
CAUTION
Never drive with the engine speed
indicator in the red zone or severe
engine damage can result.EXAMPLE
(2)
(1)
Tachometer:
Fuel Gauge:

Downloaded from www.Manualslib.com manuals search engine 4-10 INSTRUMENT PANEL
54G27-03E
Temperature Gauge
54G458
When the ignition switch is in the “ON”
position, this gauge indicates the engine
coolant temperature. Under normal driving
conditions, the indicator should stay within
the normal, acceptable temperature range
between “H” and “C”. If the indicator
approaches “H”, overheating is indicated.
Follow the instructions for engine overheat-
ing in the “EMERGENCY SERVICE” sec-
tion.
Hazard Warning Switch
54G510
Push in the hazard warning switch to acti-
vate the hazard warning lights. All four turn
signal lights and both turn signal indicators
will flash simultaneously. To turn off the
lights, push the switch again.
Use the hazard warning lights to warn
other traffic during emergency parking or
when your vehicle could otherwise become
a traffic hazard.
Rear Window Defroster
Switch (if equipped)
54G610
When the rear window is fogged, push this
switch to clear the window. An indicator
light below the switch will be lit when the
defroster is on. The defroster will only work
when the ignition switch is in the “ON” posi-
tion. To turn off the defroster, push the
switch again.
CAUTION
The rear window defroster uses a
large amount of electricity. Be sure to
turn off the defroster after the win-
dow has become clear.
Temperature Gauge: 8
Hazard Warning Switch: 8
Rear Window Defroster Switch:

Downloaded from www.Manualslib.com manuals search engine 4-11 INSTRUMENT PANEL
54G27-03E
Outside Rearview Mirrors
Defroster Switch (if equipped)
54G447
When the outside rearview mirrors are
fogged, push this switch to clear the mirror.
An indicator light above the switch will be lit
when the defroster is on. The defroster will
only work when the ignition switch is in the
“ON” position. To turn off the defroster,
push the switch again.
Fog Light Switch (if equipped)
54G448
The front fog light comes on when the fog
light switch is pushed in with the lighting
switch turned to the third position and the
beams set to the low beam position.
Cigarette Lighter and Ashtray
(if equipped)
54G460
Push the lid and open to use the cigarette
lighter and ashtray.Cigarette Lighter (if equipped)To use the cigarette lighter, push it all the
way into the receptacle and release it. It
will automatically heat up and will pop out
to its normal position when it is ready for
use.
CAUTION
The outside rearview mirrors
defroster uses a large amount of
electricity. Be sure to turn off after
the mirrors have become clear.
CAUTION
Holding the cigarette lighter in can
overheat and damage the lighter.
Release the lighter after you push it
in.
Outside Rearview Mirrors Defroster Switch:
Fog Light Switch: 8
Cigarette Lighter and Ashtray: 3, 8

Downloaded from www.Manualslib.com manuals search engine 4-12 INSTRUMENT PANEL
54G27-03E
AshtrayTo remove the front panel ashtray for
cleaning, pull the ashtray out of its holder.
54G157
To remove the rear ashtray, push down on
the tongue and pull the ashtray out of its
holder.
Information Display
54G525
(1) Clock
(2) Thermometer
(3) “PASS AIRBAG OFF” indicator
(4) Front passenger’s seat belt reminder
light
CAUTION
To avoid damage to the cigarette
lighter socket, do not use it as an
accessory power source. Some
accessories’ power plug can damage
the inner mechanism of the cigarette
lighter socket.
WARNING
Make sure tobacco is fully extin-
guished before closing the ashtrays.
Never throw waste in the ashtrays: it
could create a fire hazard.
(1)
(2)
(3)
(4)
Cigarette Lighter and Ashtray: 3, 8
Information Display:

Downloaded from www.Manualslib.com manuals search engine 4-13 INSTRUMENT PANEL
54G27-03E
Clock and Thermometer
54G649
The time and outside temperature is
shown when the ignition switch is in the
“ACC” or “ON” position.
The background brightness is fixed to the
normal level of brightness whenever the
lighting switch is OFF. When the lighting
switch is turned to the second or third posi-
tion, the background brightness of the time
and outside temperature indication will be
reduced. To return the normal background
brightness, push the “ILLUMI” knob (a).
Each time you push the “ILLUMI” knob (a)
with the lighting switch in the second or
third position, the background brightness
will switch between normal and reduced
brightness.
When the lighting switch is turned to the
second or third position again after being
off, the background brightness level will bethe same level that was set the last time
that the lighting switch was in the second
or third position.
Clock (1)
To set the clock, push the “ILLUMI” knob
(a) and continue holding. Follow the
instructions below while holding the
“ILLUMI” knob (a).
 To set the hour display, push the “H”
knob (b) repeatedly to advance the hour
display. To advance the hour display
quickly, hold in the “H” knob (b) for about
1 second and continue holding.
 To set the minute display, push the “M”
knob (c) repeatedly to advance the
minute display. To advance the minute
display quickly, hold in the “M” knob (c)
for about 1 second and continue holding.
Thermometer (2)
The thermometer shows the outside tem-
perature. The indication is switched
between °F and °C each time you push the
“°F/°C” knob (d).
If the outside temperature nears freezing,
the mark (e) will come on.
NOTE:
The thermometer will not indicate the
actual outside temperature when driving at
low speed, or when stopped.
Front Passenger’s Seat Belt
Reminder Light
54G515
The front passenger’s seat belt reminder
light is located in the information display. If
there is a passenger in the front seat and
the front passenger’s seat belt is unbuck-
led about 10 seconds after the ignition
switch is turned to the “ON” position, this
light will come on and then blink. When the
light comes on, a buzzer will also sound
intermittently for about 6 seconds. The
reminder will repeat several times under
certain conditions until the front passen-
ger’s seat belt is buckled. After repeating
several times, the reminder will be can-
celed even if the front passenger’s seat
belt remains unbuckled.
For details about the seat belt reminder,
refer to “Seat Belts and Child Restraint
(a)
(b)
(1)
(2)
(c)
(d) (e)
Information Display:

Downloaded from www.Manualslib.com manuals search engine 4-14 INSTRUMENT PANEL
54G27-03E
Systems” in the “BEFORE DRIVING” sec-
tion.
“PASS AIRBAG OFF” Indicator
54G527
The “PASS AIRBAG OFF” indicator is
located on the information display. When
the ignition switch is turned to the “ON”
position, this indicator comes on for several
seconds to let you know the indicator is
working.
This indicator will come on and remain on
when the front passenger sensing system
has turned off the front passenger’s air
bag.
For details about the front passenger sens-
ing system, refer to “Supplemental
Restraint System (advanced air bags)” in
the “BEFORE DRIVIING” section.
Glove Box
54G528
To open the glove box, pull the latch lever.
To close it, push the lid until it latches
securely.
WARNING
It is absolutely essential that the
driver and passengers wear their seat
belts at all times. Persons who are
not wearing seat belts have a much
greater risk of injury if an accident
occurs. Make a regular habit of buck-
ling your seat belt before putting the
key in the ignition.
WARNING
Never drive with the glove box lid
open. It could cause injury if an acci-
dent occurs.
Information Display:
Glove Box: 3

Downloaded from www.Manualslib.com manuals search engine 4-15 INSTRUMENT PANEL
54G27-03E
Heating and Air Conditioning
SystemThere are various types of heating and air
conditioning system as follows:
 Heating System
 Manual Heating and Air Conditioning
System
 Automatic Heating and Air Conditioning
System (Climate Control)
Air Outlet
54G476
1. Windshield defroster outlet
2. Side defroster outlet
3. Side outlet
4. Center outlet
5. Floor outlet
1
1
2
2
3 3
5 5
5 54
Heating and Air Conditioning System: 4
