Night time driving
1. Drive more slowly at night than in the
daytime, for the visual range is restricted
at night.
2. Don’t overtake other vehicles at night.
Darkness bothers your sense of speed
and hinders your judgement on the
vehicle-to-vehicle distance.
3. Don’t use the high headlight beam
unless its use is inevitable. Its dazzle
may blitz the driver of the oncoming
vehicle, thus causing an accident.
4. Always keep the window glasses clean.
Don’t operate the windshield wiper when
the windshield glass is dry or the wiper
blade and glass may get damaged.8-5DRIVING TIPS AND SAFE DRIVING
MARGIN FOR SAFETY
It is important to allow yourself a margin for
safety during driving so that you can cope
with erroneous or unexpected driving of
other drivers. For that, observe the
following.
Drive at a safe speed.
Maintain a sufficient distance between
your vehicle and the vehicle ahead.
Don’t force yourself to overtake other
vehicles.
Don’t make quick start, hard steering or
sudden stops.
Allow an ample time in the driving
schedule.
Observe traffic rules and regulations.
CONCLUSION
A perfect driver does not exist. The
endeavour of every motorist should be to
strive for perfection. Safety consciousness
not only ensures your safety and the safety
of other road users, it also helps reduce the
wear and tear on your vehicle, prolongs its
life, gives more mileage and ensures a
comfortable driving experience.
Follow the do’s and don’ts listed, and
driving will never be the same again.
76G-08-007 76G-08-008
76G-08-009

Downloaded from www.Manualslib.com manuals search engine 8376G-74E
INSPECTION AND MAINTENANCE
9
INSPECTION AND MAINTENANCE
Periodic Maintenance Schedule ......................................................................... 9-1
Alto ............................................................................................................. 9-2
Alto K-10 .................................................................................................... 9-6
Drive Belt ............................................................................................................ 9-10
Engine Oil and Filter .......................................................................................... 9-11
Gear Oil ............................................................................................................... 9-14
Engine Coolant ................................................................................................... 9-15
Windscreen Washer Fluid ................................................................................. 9-18
Air Cleaner .......................................................................................................... 9-18
Spark Plugs........................................................................................................9-19
Fuel Filter Replacement .................................................................................... 9-21
Brakes.................................................................................................................9-21
Parking Brake ..................................................................................................... 9-23
Steering ............................................................................................................... 9-23
Clutch Pedal ....................................................................................................... 9-24
Tyres ..................................................................................................................9-24
Tubeless Tyre (if equipped) .............................................................................. 9-27
Battery .................................................................................................................9-28
Fuses..................................................................................................................9-29
Bulb Replacement .............................................................................................. 9-32
Wiper Blades......................................................................................................9-35

Downloaded from www.Manualslib.com manuals search engine 84
76G-74E
You should take extreme care when
working on your vehicle to prevent
accidental injury. Here are a few
precautions that you should be
especially careful to observe:
Do not leave the engine running in
garages or other confined areas.
When the engine is running, keep
hands, clothing, tools, and other
objects away from the fan and water
pump belt. Even though the fan may
not be moving, it can automatically
turn on without warning. When it is necessary to do service
work with the engine running, make
sure that the parking brake is
applied fully and the transmission is
in Neutral.
Do not touch ignition wires or other
ignition system parts when starting
the engine or when the engine is
running, or you could receive an
electric shock.
Be careful not to touch a hot
engine, exhaust manifold and pipes,
muffler, radiator and water hoses.
Do not allow smoking, sparks, or
flames around gasoline or the
battery. Flammable fumes are
present.
Do not get under your vehicle if it
is supported only with the portable
jack provided in your vehicle.
Be careful not to cause accidental
short circuits between the positive
and negative battery terminals.
Keep used oil, coolant, and other
fluids away from children and pets.
Dispose of used fluids properly;
never pour them on the ground, into
sewers, etc.INSPECTION AND MAINTENANCE9-1
w ww w
w WARNING
w ww w
w WARNING
V VV V
V
V VV V
V
PERIODIC MAINTENANCE SCHEDULEThe following table shows when regular
maintenance on your vehicle is required.
This table shows in kilometres and months
when inspections, adjustments, lubrication
and other services should be performed.
MARUTI SUZUKI recommends that
maintenance on your MARUTI SUZUKI
vehicle be performed by MARUTI
SUZUKI Authorised Dealer/Service
Station.
Whenever it becomes necessary to
replace parts on your vehicle, it is
recommended that you use MARUTI
GENUINE PARTS (MGP).
w ww w
w WARNINGCAUTION
76G-09-001

Downloaded from www.Manualslib.com manuals search engine 8576G-74E
INSPECTION AND MAINTENANCE
9-2
A....Adjust. I....Inspect and correct or replace if necessary.
T....Tighten to specified torque. C....Clean.
R....Replace or change. O....Rotate
L....Lubricate.
Note:
This table includes services as scheduled up to 80,000 km mileage. Beyond 80,000 km, carry out the same services at the same
intervals respectively.Interval: This interval should be judged
FREE INSPECTIONS
PERIODIC MAINTENANCE SERVICE AT COST
by odometer reading or months, km (x 1,000) 1 5 10 20 30 40 50 60 70 80
whichever comes first. months 1 6 12 24 36 48 60 72 84 96
ENGINE
1. Water pump drive belt (tension, wear) A I I I I I I R A I
2. Engine coolant (level, leakage) I I I R I R I R I R
3. Engine oil (API GRADE SF, SG, SH) & Oil filter R I R R R R R R R R
4. Cooling system hoses and connections (leakage, damage) I I I I I I I I I I
5. Engine bolts (All cylinder head and manifold fixings) – – T – T – T – T –
6. Engine mounting (loose, damage) – – T – T – T – T –
7. Valve clearance – A – A – A – A – A
8. Camshaft timing belt (damage, wear) – – – I – I – I – I
Replace every 1,00,000 km
9. Exhaust system (noise, leakage or otherwise defective) – I – I – I – I – I
10. Positive crankcase ventilation System (Hoses, connections and valve) – I – I – I – I – I
IGNITION
1. Ignition wiring, (damage, deterioration) – – – I – I – I – I
2. Spark plugs (clean and adjust the gap) – – I R I R I R I R
3. Distributor cap and rotor (wear and deterioration)* – – – I – I – I – I
*For LX only
ALTO

Downloaded from www.Manualslib.com manuals search engine 86
76G-74E
INSPECTION AND MAINTENANCE9-3Interval: This interval should be judged
FREE INSPECTIONS
PERIODIC MAINTENANCE SERVICE AT COST
by odometer reading or months, km (x 1,000) 1 5 10 20 30 40 50 60 70 80
whichever comes first. months 1 6 12 24 36 48 60 72 84 96
FUEL
1. Air cleaner Paved-road Clean every 5,000 km. Replace every 40,000 km.
Dusty condition Clean every 2,500 km or as required. Replace every 40,000 km. More frequent
replacement if dust condition is severe.
2. Accelerator cable and Throttle shafts – I&L I&L I&L I&L I&L I&L I&L I&L I&L
3. Fuel tank cap, fuel lines & connections(leakage,damage) – I – – – I – – – I
4. Fuel filter (leakage) I I I I I R I I I R
CLUTCH AND TRANSMISSION
1. Clutch pedal (play) I I I I I I I I I I
2. Clutch slipping (dragging or excessive damage) I I I I I I I I I I
3. Manual Transmission/Transfer and Differential oil (level, leakage) I I I R I R I R I R
DRIVE SHAFTS
1. Drive shafts boots (bent of boots damage) – I I I I I I I I I
BRAKE
1. Brake fluid (level, leakage) I I I R I R I R I R
2. Brake pedal (pedal-to-wall clearance) I I I I I I I I I I
3. Parking brake lever and cable (play, damage) I I I I I I I I I I
4. a. Brake discs and pads, (wear) – I I I I I I I I I
b. Brake drums & shoes – – I I I I I I I I
5. Master cylinder and wheel cylinder or calliper (oil leakage, boot kit) I I I I I R I I I R
6. Brake hoses and pipes (leakage, damage) I I I I I I I I I I

Downloaded from www.Manualslib.com manuals search engine 8776G-74E
INSPECTION AND MAINTENANCE
9-4
Interval: This interval should be judged
FREE INSPECTIONS
PERIODIC MAINTENANCE SERVICE AT COST
by odometer reading or months, km (x 1,000) 1 5 10 20 30 40 50 60 70 80
whichever comes first. months 1 6 12 24 36 48 60 72 84 96
WHEEL
1. Tyres (air pressure, abnormal wear, crack, rotation) I I&O I&O I&O I&O I&O I&O I&O I&O I&O
2. Wheels (damage) I I I I I I I I I I
3. Front wheel bearings (loose, damage) – I I I I I I I I I
4. Rear wheel bearings (loose, damage) – I I I I I I I I I
FRONT AND REAR SUSPENSION
1. Suspension strut (oil leakage, damage) I I I I I I I I I I
2. Suspension arms and knuckle supports (loose,damage) – I I I I I I I I I
3. Rear spring (damage) – I I I I I I I I I
4. Shock absorbers (oil leakage, damage) I I I I I I I I I I
5. All bolts and nuts (loose) – T T T T T T T T T
6. Suspension arms and Tension rods – I I I I I I I I I
STEERING
1. Steering wheel (play, loose) I I I I I I I I I I
2. All rods and arms (loose, damage, wear) I I I I I I I I I I
ELECTRICAL
1. Battery electrolyte (level, leakage) I I I I I I I I I I
2. Wiring harness connection (looseness, damage) – I I I I I I I I I
3. Lighting system (operation, stains, damage) I I I I I I I I I I
4. Horn (operation) I I I I I I I I I I
5. System voltage – I I I I I I I I I
BODY
1. All chassis bolts and nuts (tighten) – I T T T T T T T T
2. All Latches, Hinges & Locks (function) I I&L I&L I&L I&L I&L I&L I&L I&L I&L

Downloaded from www.Manualslib.com manuals search engine 88
76G-74E
INSPECTION AND MAINTENANCE9-5Interval: This interval should be judged
FREE INSPECTIONS
PERIODIC MAINTENANCE SERVICE AT COST
by odometer reading or months, km (x 1,000) 1 5 10 20 30 40 50 60 70 80
whichever comes first. months 1 6 12 24 36 48 60 72 84 96
ROAD TEST
1. Operation of Brakes, Gear shifting & speedometer I I I I I I I I I I
2. Body and Chassis noise I I I I I I I I I I
AIR CONDITIONER (if equipped)
1. Check belt tension I I I I I I I I I I
2. Tighten compressor mounting bolts – T T T T T T T T T
3. Check all hose joints, tighten if necessary I I I I I I I I I I
4. Check functioning of Recirc flap I I I I I I I I I I
5. Clean condenser with low pressure water – C C C C C C C C C
6. Check belt for frayed edges, change if necessary – I I I I I I I I I
7. Check all mounting bolts – I I I I I I I I I

Downloaded from www.Manualslib.com manuals search engine 8976G-74EA....Adjust. I....Inspect and correct or replace if necessary.
T....Tighten to specified torque.C....Clean.
R....Replace or change.O....Rotate
L....Lubricate.Note:
This table includes services as scheduled up to 80,000 km mileage. Beyond 80,000 km, carry out the same services at the same intervals respectively.
INSPECTION AND MAINTENANCE
9-6
ALTO K10

Downloaded from www.Manualslib.com manuals search engine 90
76G-74E
INSPECTION AND MAINTENANCE9-7

Downloaded from www.Manualslib.com manuals search engine 9176G-74E
INSPECTION AND MAINTENANCE
9-8
