SUZUKI XL7 2007 2.G User Guide
Manufacturer: SUZUKI, Model Year: 2007, Model line: XL7, Model: SUZUKI XL7 2007 2.GPages: 274, PDF Size: 6.12 MB
Page 11 of 274
0-4
78J00-03E
Page 12 of 274
SEATS AND RESTRAINT SYSTEMS
1
78J00-03E
SEATS AND RESTRAINT SYSTEMSFront Seats .......................................................................... 1-1
Rear Seats ............................................................................ 1-6
Safety Belts .......................................................................... 1-9
Child Restraints ................................................................... 1-18
Airbag System ..................................................................... 1-33
Restraint System Check ..................................................... 1-42
Page 13 of 274
1-1 SEATS AND RESTRAINT SYSTEMS
78J00-03E
Front SeatsManual Seats
808318
Lift the bar located under the front of the
seat to unlock it. Slide the seat to where
you want it and release the bar. Try to
move the seat with your body to be sure
the seat is locked in place.
Driver Seat Height Adjuster
1618867
If your vehicle has a manual driver seat
height adjuster, it is located on the out-
board side of the seat near the front of the
seat cushion. To raise the seat, move the
lever upward repeatedly until the seat is at
the desired height. To lower the seat, move
the lever downward repeatedly until the
seat is at the desired height.
Power Seat
1407195
If the vehicle has a power seat, the control
used to operate it is located on the out-
board side of the driver’s seat. To adjust
the seat do any of the following:
Move the seat forward or rearward by
sliding the control forward or rearward.
Raise or lower the front part of the seat
cushion by moving the front of the con-
trol up or down.
Raise or lower the rear part of the seat
cushion by moving the rear of the control
up or down.
WARNING
You can lose control of the vehicle if
you try to adjust a manual driver’s
seat while the vehicle is moving. The
sudden movement could startle and
confuse you, or make you push a
pedal when you do not want to.
Adjust the driver’s seat only when the
vehicle is not moving.
Page 14 of 274
1-2 SEATS AND RESTRAINT SYSTEMS
78J00-03E
Manual Lumbar
1211985
If your vehicle has this feature, the knob is
located on the front of the driver seat lower
cushion on the inboard side.
Turn the knob clockwise or counterclock-
wise to increase or decrease the lumbar
support.
Heated Seats
1761660
If your vehicle has heated seats, the
switches are located on the instrument
panel near the climate controls.
The ignition must be on for the heated
seats to operate.
Press the switch, nearest to the seat, once
to turn the heated seat on to the high set-
ting. Both indicator lights will be lit. Press
the switch a second time to turn the heated
seat to the low setting. One indicator light
will be lit. Press the switch a third time to
turn the heated seat off.
Manual Reclining Seatbacks
WARNING
You can lose control of the vehicle if
you try to adjust a manual driver’s
seat while the vehicle is moving. The
sudden movement could startle and
confuse you, or make you push a
pedal when you do not want to.
Adjust the driver’s seat only when the
vehicle is not moving.
WARNING
If the seatback is not locked, it could
move forward in a sudden stop or
crash. That could cause injury to the
person sitting there. Always push
and pull on the seatback to be sure it
is locked.
Page 15 of 274
1-3 SEATS AND RESTRAINT SYSTEMS
78J00-03E
Driver’s seat with manual recline and
manual height adjuster shown
1618868
To adjust the seatback on the driver’s seat,
lift the lever on the rear outboard side of
the seat and move the seatback to the
desired position. Then release the lever to
lock the seatback in place.Passenger seat with folding seatback
option shown
1618866
To adjust the seatback on the front passen-
ger’s seat, lift the lever on the outboard
side of the seat and move the seatback to
the desired position. Then release the
lever to lock the seatback in place. If your
front passenger’s seat is a flat folding seat,
you must fully raise the lever to disengage
the seatback.
806881
WARNING
Sitting in a reclined position when
your vehicle is in motion can be dan-
gerous. Even if you buckle up, your
safety belts cannot do their job when
you are reclined like this.
The shoulder belt cannot do its job
because it will not be against your
body. Instead, it will be in front of
you. In a crash, you could go into it,
receiving neck or other injuries.
The lap belt cannot do its job either.
In a crash, the belt could go up over
your abdomen. The belt forces would
be there, not at your pelvic bones.
This could cause serious internal
injuries.
(Continued)
Page 16 of 274
1-4 SEATS AND RESTRAINT SYSTEMS
78J00-03E
Do not have a seatback reclined if your
vehicle is moving. Head Restraints
805677
Adjust the head restraint so that the top of
the restraint is at the same height as the
top of the occupant’s head. This position
reduces the chance of a neck injury in a
crash.
1525254
Pull the head restraint up to raise it. To
lower the head restraint, press the button,
located on the top of the seatback, and
push the restraint down.
The third row head rests adjust like the
front seat head restraints.
1811484
The third row seat head rests can be
removed from the seatback. To do this,
press the button, located on the top of the
seatback, and pull them out from the seat-
back. Store the head rest, front side facing
up, in the compartment behind the third
row, by inserting the head rest posts into
the slots in the storage area.
WARNING
(Continued)
For proper protection when the vehi-
cle is in motion, have the seatback
upright. Then sit well back in the seat
and wear your safety belt properly.
Page 17 of 274
1-5 SEATS AND RESTRAINT SYSTEMS
78J00-03E
Passenger Folding SeatbackThe front passenger’s seatback may fold
flat.
To fold the seatback, do the following:
1) Lower the head restraint all the way.
2) Lift the bar under the front of the seat to
unlock it. Slide the seat as far back as it
will go and release the bar. Try to move
the seat back and forth to make sure it
is locked into place.
1618866
3) Lift the recliner lever, located on the
outboard side of the seat, up fully and
fold the seatback forward until it disen-
gages.
1618864
4) Continue to fold the seat forward until it
locks in the folded position.
5) Pull up on the seatback to be sure it is
locked.
WARNING
If you fold the seatback forward to
carry longer objects, such as skis, be
sure any such cargo is not near an
airbag. In a crash, an inflating airbag
might force that object toward a per-
son. This could cause severe injury
or even death. Secure objects away
from the area in which an airbag
would inflate. For more information,
refer to “Where Are the Airbags?” in
this section and refer to “Loading
Your Vehicle” in “Your Driving, the
Road, and Your Vehicle” in the “Driv-
ing Your Vehicle” section.
WARNING
Things you put on this seatback can
strike and injure people in a sudden
stop or turn, or in a crash. Remove or
secure all items before driving.
Page 18 of 274
1-6 SEATS AND RESTRAINT SYSTEMS
78J00-03E
To raise the seatback, do the following:
1) Lift the recliner lever, located on the
outboard side of the seat, up fully and
push up on the seatback.
2) Continue raising the seatback until the
seatback re-engages.
3) Push and pull on the seatback to make
sure it is locked in place.
The recliner lever is also used to recline
the seatback while a passenger is seated.
Refer to “Manual Reclining Seatbacks” in
this section.
Rear SeatsSplit Folding the Second Row SeatThe second row split bench seatbacks
have four available positions – folded for-
ward, upright, partially reclined, or fully
reclined. Both of the seatbacks can be
moved to any of the four positions indepen-
dent of the other seatback position. To fold the seatback down, do the follow-
ing:
1) Ensure all three of the safety belts are
unbuckled and removed from the child
comfort guide, and the front seatbacks
are not reclined.
2) Lower the headrest.
1406907
3) Lift the lever located on the top of the
seatback to release the seatback.
4) Fold the seatback forward.
WARNING
If the seatback is not locked, it could
move forward in a sudden stop or
crash. That could cause injury to the
person sitting there. Always push
and pull on the seatback to be sure it
is locked.
WARNING
If the seatback is not locked, it could
move forward in a sudden stop or
crash. That could cause injury to the
person sitting there. Always push
and pull on the seatback to be sure it
is locked.
WARNING
A safety belt that is improperly
routed, not properly attached, or
twisted will not provide the protection
needed in a crash. The person wear-
ing the belt could be seriously
injured. After raising the rear seat-
back, always check to be sure that
the safety belts are properly routed
and attached, and are not twisted.
CAUTION
Folding a rear seat with the safety
belts still fastened may cause dam-
age to the seat or the safety belts.
Always unbuckle the safety belts and
return them to their normal stowed
position before folding a rear seat.
Page 19 of 274
1-7 SEATS AND RESTRAINT SYSTEMS
78J00-03E
5) Push and pull on the seatback to make
sure it is locked.
To recline the seatback, do the following:
1) Lift and hold the lever located on top of
the seatback.
2) Tilt the seatback rearward, then release
the lever when the seatback is in the
desired position.
3) Push and pull on the seatback to make
sure it is locked.
Folding and Tumbling the Seat(s)
To fold and tumble the seat, do the follow-
ing:
1) Make sure that there is nothing under,
in front of, or on the seat.2) Fold the seatback forward.
Leaving the seatback in this position
creates a flat load floor.
If the seatback cannot fold flat, try mov-
ing the front seat forward and/or put the
front seatback in the upright position.
1831564
3) Use the pullstrap to release the rear of
the seat from the floor. As you use the
pullstrap, pull forward on the seat to lift
it into its tumbled position.Returning the Seat(s) to the Sitting
Position
To return the seat to the sitting position, do
the following:
1) Pull the seat down until it latches to the
floor. Push and pull on the seat cushion
to make sure it is locked.
2) Lift the seatback and push it rearward.
Push and pull on the seatback to make
sure it is locked.
WARNING
Be sure to return the seat to the pas-
senger seating position when fin-
ished. Push and pull on the seat to
make sure it is locked into place.
Never use the third row seating posi-
tion while the second row is folded,
or folded and tumbled. This could
cause injury in a sudden stop or
crash.
CAUTION
Folding a rear seat with the safety
belts still fastened may cause dam-
age to the seat or the safety belts.
Always unbuckle the safety belts and
return them to their normal stowed
position before folding a rear seat.
WARNING
If the seatback is not locked, it could
move forward in a sudden stop or
crash. That could cause injury to the
person sitting there. Always push
and pull on the seatback to be sure it
is locked.
Do not hit or entrap any part of a third
row seat occupant’s body when
returning the folded or tumbled sec-
ond row seat to the floor.
Page 20 of 274
1-8 SEATS AND RESTRAINT SYSTEMS
78J00-03E
Third Row SeatIf the vehicle has a third row seat, the seat-
back(s) can be folded.
Folding the Seatback(s)
To fold the seatback, do the following:
1) Remove all items on the seat cushion.
1811392
2) Lift the lever, located on the top of the
seatback on the outboard side of the
seat and fold the seatback forward.Unfolding the Seatback(s)
To return the seatback to the upright posi-
tion, do the following:
1) Open the liftgate to access the pullstrap
for the seat.
2) Use the pullstrap on the seatback to
pull the seatback up until it locks into
the upright position.
3) Push and pull on the seatback to make
sure it is locked.
WARNING
Be sure to return the seat to the pas-
senger seating position when fin-
ished. Push and pull on the seat to
make sure it is locked into place.
Never use the third row seating posi-
tion while the second row is folded,
or folded and tumbled. This could
cause injury in a sudden stop or
crash.
CAUTION
Folding a rear seat with the safety
belts still fastened may cause dam-
age to the seat or the safety belts.
Always unbuckle the safety belts and
return them to their normal stowed
position before folding a rear seat.
WARNING
If the seatback is not locked, it could
move forward in a sudden stop or
crash. That could cause injury to the
person sitting there. Always push
and pull on the seatback to be sure it
is locked.
