TOYOTA 4RUNNER 2000 Owners Manual

1072000 4Runner (OM35762U)
(k) If you cannot shift the selector le-
ver out of Pº position
If you cannot shift the selector lever from
the Pº position even though the brake
pedal is depressed, use the shift lock
override lever. For instructions, see If you
cannot shift automatic transmission selec-
tor leverº in Section 4.
Manual transmission
The shift pattern is as shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest your foot on the pedal while driving,
because it will cause clutch trouble. And
do not use the clutch to hold the vehicle
when stopped on an uphill gradeÐuse the
parking brake.
Recommended shifting speeds
The transmission is fully synchronized and
upshifting or downshifting is easy.
For the best compromise between fuel
economy and vehicle performance, you
should upshift or downshift at the following
speeds:3RZ- FE engine
Upshifting
gear km/h (mph)
1 to 2 24 (15)
2 to 3 40 (25)/58 (36)
*
3 to 4 64 (40)/72 (45)*
4 to 5 72 (45)/85 (53)*
Downshifting
gear km/h (mph)
2 to 1 24 (15)
3 to 2 40 (25)
4 to 3 64 (40)
5 to 4 72 (45)
*: Applicable under heavy acceleration
conditions.
5VZ- FE engine
gear km/h (mph)
1 to 2 or 2 to 1 24 (15)
2 to 3 or 3 to 2 40 (25)
3 to 4 or 4 to 3 64 (40)
4 to 5 or 5 to 4 72 (45)
Downshift to the appropriate gear if accel-
eration is needed when you are cruising
below the above downshifting speeds.
ProCarManuals.com

1082000 4Runner (OM35762U)
Upshifting too soon or downshifting too
late will cause lugging and, possibly, ping-
ing. Regularly revving the engine to maxi-
mum speed in each gear will cause ex-
cessive engine wear and high fuel
consumption.
Maximum allowable speeds
To get on a highway or to pass slower
traffic, maximum acceleration may be nec-
essary. Make sure you observe the follow-
ing maximum allowable speeds in each
gear:
Two- wheel drive models
gear km/h (mph)
1 48 (29)
2 90 (55)
3 139 (86)
4 165 (102)
Four- wheel drive models
3RZ- FE engine
gear km/h (mph)
H2º and H4º L4º
1 45 (28) 17 (11)
2 84 (52) 32 (20)
3 130 (81) 50 (31)
4 165 (102) 64 (39)5VZ- FE engine
gear km/h (mph)
H2º and H4º L4º
1 48 (29) 18 (11)
2 89 (55) 34 (21)
3 127 (79) 49 (31)
4 165 (102) 64 (39)
NOTICE
Do not downshift if you are going
faster than the maximum allowable
speed for the next lower gear.
Good driving practice
If it is difficult to shift into reverse, put
the transmission in neutral, release the
clutch pedal momentarily, and then try
again.
When towing a trailer, in order to main-
tain engine braking efficiency, do not
use the fifth gear.
CAUTION
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.
NOTICE
Make sure the vehicle is completely
stopped before shifting into reverse.
ProCarManuals.com

1092000 4Runner (OM35762U)
Use the front drive control lever to se-
lect the following transfer modes.
H2º (high speed position, two- wheel
drive): Lever at H2º
Use this for normal driving on dry hard-
surfaced roads. This position gives greater
economy, quietest ride and least wear.
H4º (high speed position, four- wheel
drive): Lever at H4º
Use this for normal driving on wet, icy or
snow- covered roads. This position pro-
vides greater traction than two- wheel
drive.
Nº (neutral position): Lever at Nº
No power is delivered to the wheels. The
vehicle must be stopped.L4º (low speed position, four- wheel
drive): Lever at L4º
Use this for maximum power and traction.
Use L4º for climbing or descending steep
hills, off- road driving, and hard pulling in
sand, mud or deep snow.
The four- wheel drive indicator light comes
on when the H4º, Nº or L4º mode is
selected.
See (c) Shifting procedure (lever type)º
for further instructions.
H2º mode
H4º mode
H4Lº, L4Lº or Nº mode
Four- wheel drive systemÐ
(a) Front drive control
(lever type)(a) Front drive control
(lever/button type)
ProCarManuals.com

11 02000 4Runner (OM35762U)
Use the front drive control lever and
4WDº button to select the transfer and
center differential modes.
H2º mode (high speed position, two-
wheel drive): Lever at H2´H4º, 4WDº
button left out
Use this for normal driving on dry hard-
surfaced roads. This position gives greater
economy, quietest ride and least wear and
better vehicle control.
H4º mode (high speed position, four-
wheel drive, center differential un-
locked): Lever at H2´H4º, 4WDº button
pushed in
Use this for normal driving on all types of
roads, from dry hard- surfaced roads to
wet, icy or snow- covered roads. This
position provides greater traction than
two- wheel drive.H4Lº mode (high speed position, four-
wheel drive, center differential locked):
Lever at H4Lº
Use this for greater traction when you
experience a loss of power, such as
wheel slipping, in the H2´H4º (four- wheel
drive) mode.
Nº mode (neutral position): Lever at
Nº
No power is delivered to the wheels. The
vehicle must be stopped.
L4Lº mode (low speed position, four-
wheel drive, center differential locked):
Lever at L4Lº
Use this for maximum power and traction.
Use L4Lº mode for hard pulling in situa-
tions the vehicle cannot negotiate even in
the H4Lº mode.
The indicator shows which transfer and
center differential mode the vehicle is in.
See (c) Shifting procedureº for further in-
structions.
Steel wheels
Aluminum wheels
(b) A.D.D. (automatic
disconnecting differential)
ProCarManuals.com

1112000 4Runner (OM35762U)
The A.D.D. can be engaged or disen-
gaged by the shifting operations des-
cribed in (c) Shifting procedureº.
You should drive in four- wheel drive for
at least 16 km (10 miles) each month.
This will assure that the front drive com-
ponents are lubricated.SHIFTING BETWEEN H2º AND H4º
To shift from H2º to H4º, reduce your
speed to less than 80 km/h (50 mph) and
move the front drive control lever. You
need not depress the clutch pedal.
If you have trouble shifting in cold weath-
er, reduce your speed or stop the vehicle
and reshift.
CAUTION
Never move the front drive control
lever if wheels are slipping. Stop the
slipping or spinning before shifting.
To shift from H4º to H2º, simply move
the front drive control lever.
This can be done at any vehicle speed.
You need not depress the clutch pedal.
If the indicator light does not go off when
you shift the transfer into H2º, drive
straight ahead while accelerating or decel-
erating, or drive in reverse.SHIFTING BETWEEN H4º AND L4º
To shift from H4º to L4º, stop the
vehicle or reduce your speed to less than
8 km/h (5 mph). With your foot off the
accelerator pedal, depress the clutch ped-
al and move the front drive control lever.
To shift from L4º to H4º, depress the
clutch pedal and move the front drive con-
trol lever.
This can be done at any vehicle speed.
(c) Shifting procedure
(lever type with manual
transmission)
ProCarManuals.com

11 22000 4Runner (OM35762U)
SHIFTING BETWEEN H2º AND H4º
To shift from H2º to H4º, reduce your
speed to less than 80 km/h (50 mph) and
move the front drive control lever.
If you have trouble shifting in cold weath-
er, reduce your speed or stop the vehicle
and reshift.
CAUTION
Never move the front drive control
lever if wheels are slipping. Stop the
slipping or spinning before shifting.
To shift from H4º to H2º, simply move
the front drive control lever.
This can be done at any vehicle speed.
If the indicator light does not go off when
you shift the transfer into H2º, drive
straight ahead while accelerating or decel-
erating, or drive in reverse.
SHIFTING BETWEEN H4º AND L4º
To shift between H4º and L4º, stop
the vehicle and put the transmission in
Nº. With your foot holding down the
brake pedal, move the front drive control
lever.SHIFTING BETWEEN H2º MODE AND
H4º MODE
To shift from H2º mode to H4º mode,
reduce your speed to less than 100 km/h
(62 mph) and push in the 4WDº button.
If the indicator light flashes when you
push in the 4WDº button, drive straight
ahead while accelerating or decelerating.
If the indicator light flashes and the buzz-
er sounds when you push in the 4WDº
button, reduce your speed or stop the
vehicle and reset.
CAUTION
Never push the 4WDº button if
wheels are slipping. Stop the slipping
or spinning before shifting.
To shift from H4º mode to H2º mode,
push the 4WDº button again to turn it off.
This can be done at any vehicle speed.
If the indicator light flashes when you
push in the 4WDº button, drive straight
ahead while accelerating or decelerating,
or drive in reverse.
SHIFTING BETWEEN H2´H4º AND
H4Lº
To shift from H2´H4º to H4Lº, reduce
your speed to less than 100 km/h (62
mph) and move the front drive control
lever.
If the indicator light flashes when you
move the front drive control lever, drive
straight ahead while accelerating or decel-
erating.
If the indicator light flashes and the buzz-
er sounds when you move the front drive
control lever, reduce your speed or stop
the vehicle and reset.
CAUTION
Never move the front drive control
lever if wheels are slipping. Stop the
slipping or spinning before shifting.
(c) Shifting procedure
(lever type with automatic
transmission)(c) Shifting procedure
(lever/button type)
ProCarManuals.com

11 32000 4Runner (OM35762U)
NOTICE
Do not drive on a dry paved surface
in H4Lº mode. This may damage the
locking mechanism and the drive sys-
tem.
To shift from H4Lº to H2´H4º move
the front drive control lever.
This can be done at any vehicle speed.
If the indicator light flashes when you shift
the transfer into H2´H4º, drive straight
ahead while accelerating or decelerating,
or drive in reverse.
SHIFTING BETWEEN H4Lº AND L4Lº
To shift from H4Lº to L4Lº, stop the
vehicle and put the transmission in Nº.
With your foot holding down the brake
pedal, move the front drive control lever.
NOTICE
Do not drive on a dry paved surface
in H4Lº or L4Lº mode. This may
damage the locking mechanism and
the drive system.
To shift from L4Lº to H4Lº, stop the
vehicle and put the transmission in Nº.
With your foot holding down the brake
pedal, move the front drive control lever.
NOTICE
Do not drive on a dry paved surface
in H4Lº or L4Lº mode. This may
damage the locking mechanism and
the drive system.
Rear differential lock system
The rear differential lock system is pro-
vided for use only when wheel spinning
occurs in a ditch or on a slippery or
ragged surface.
This differential lock system is effective in
case one of the rear wheels is spinning.
Before using the rear differential lock sys-
tem, first shift the front drive control into
L4º (lever type) or L4Lº (lever/button
type) to see if it works. If this has no
effect, additionally use the rear differential
lock system.
ProCarManuals.com

11 42000 4Runner (OM35762U)
CAUTION
Do not use the rear differential lock
in the conditions other than above.
Large steering effort and careful cor-
nering control will be required.
To lock the rear differential, push the
switch.
Be sure to stop the wheels before locking
the differential.
Vehicles with manual transmissionÐFor
easy locking, depress the clutch pedal,
push the lock switch and slowly release
the clutch pedal.
The indicator light will blink when the
switch is turned on. Wait a few seconds
for the system to complete operation. Af-
ter the differential is locked, the light will
stop blinking and remain on.The anti- lock brake system does not oper-
ate when the rear differential is locked. It
is normal operation for the ABSº warning
light to be on at this time.
CAUTION
Do not lock the differential until the
wheels have stopped spinning.
Otherwise, the vehicle may move in
an unexpected direction when the
differential lock is engaged, result-
ing in an accident. This may also
lead to possible damage to differen-
tial lock component parts.
Do not drive over 8 km/h (5 mph)
when the differential is locked.
To unlock the differential, push the
switch once again.
Unlock the differential as soon as the ve-
hicle moves out.
For easy unlocking, slightly turn the steer-
ing wheel in either direction while the ve-
hicle is in motion.
When the differential lock is disengaged,
the indicator light will go out.
ProCarManuals.com

11 52000 4Runner (OM35762U)
The differential will also unlock if you shift
the front drive control lever out of L4º
(lever type) or L4Lº (lever/button type).
Never forget to turn off the switch after
using this feature.
To check the indicator bulb, turn the igni-
tion key to the ONº position, but do not
start the engine.
CAUTION
Do not keep driving with the differen-
tial lock switch on.
Parking brake
When parking, firmly apply the parking
brake to avoid inadvertent creeping.
To set: Pull up the lever. For better hold-
ing power, first depress the brake pedal
and hold it while setting the parking
brake.
To release: Pull up the lever slightly,
press the thumb button, and lower.
To remind you that the parking brake is
set, the parking brake reminder light in
the instrument panel remains on until you
release the parking brake.
CAUTION
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.
ProCarManuals.com

11 62000 4Runner (OM35762U)
Cruise control
The cruise control allows you to cruise
the vehicle at a desired speed over 40
km/h (25 mph) even with your foot off
the accelerator pedal.
Your cruising speed can be maintained up
or down grades within the limits of engine
performance, although a slight speed
change may occur when driving up or
down the grades. On steeper hills, a
greater speed change will occur so it is
better to drive without the cruise control.
CAUTION
To help maintain maximum control
of your vehicle, do not use the
cruise control when driving in
heavy or varying traffic, or on slip-
pery (rainy, icy or snow- covered) or
winding roads.
Avoid vehicle speed increases when
driving downhill. If the vehicle
speed is too fast in relation to the
cruise control set speed, cancel the
cruise control then downshift the
transmission to use engine braking
to slow down.
TURNING ON THE SYSTEM
To operate the cruise control, press the
CRUISE ON- OFFº button. This turns the
system on. The indicator light in the
instrument panel shows that you can now
set the vehicle at a desired cruising
speed. Another press will turn the system
completely off.
CAUTION
To avoid accidental cruise control en-
gagement, keep the CRUISE ON-
OFFº switch off when not using the
cruise control.
SETTING AT A DESIRED SPEED
On vehicles with automatic transmission,
the transmission must be in Dº before
you set the cruise control speed.
Bring your vehicle to the desired speed,
push the lever down in the SET/COASTº
direction and release it. This sets the ve-
hicle at that speed. If the speed is not
satisfactory, tap the lever up for a faster
speed, or tap it down for a slower speed.
Each tap changes the set speed by 1.6
km/h (1.0 mph). You can now take your
foot off the accelerator pedal.
ProCarManuals.com
