Tire size, cold tire inflation pressure and wheel size:
Ti r e siz e
Cold tire inflation pressure kPa (kgf/cm2 or bar, psi)Wheel size
FrontRearSpare
P265/70R16 111S220 (2.2, 32)220 (2.2, 32)220 (2.2, 32)16 7J∗
1
16 7JJ∗
2
P265/65R17 110S220 (2.2, 32)220 (2.2, 32)220 (2.2, 32)17 71/2JJ
P265/60R18 109H220 (2.2, 32)220 (2.2, 32)220 (2.2, 32)18 71/2J
∗
1: Vehicles with steel wheels∗2: Vehicles with aluminum wheels
NOTE: For a complete information on tires (e.g. replacing ti res or replacing wheels), see “Checking tire inflation pres-
sure” through “Aluminum wheel precautions”, pages 425 through 432 in Section 7 −2.
Wheel nut torque, N·m (kgf·m, ft·lbf): 11 0 ( 11 . 5 , 8 3 )
Tires
Page 462 of 470
’06 4Runner_U (L/O 0508)
452
Engine compartment
Fuses (type A)
1. SPARE 10 A: Spare fuse
2. SPARE 15 A: Spare fuse
3. STOP 10 A: Stop/tail lights, high
mounted stoplight, shift lock control
system, anti −lock brake system, trac-
tion control system (two −wheel drive
models), active traction control system
(four −wheel drive models), vehicle sta-
bility control system, rear height control
air suspension, multiport fuel injection
system/s equential multiport fuel injec-
tion system, trailer brake controller,
trailer lights (tail lights)
Instrument panel
4. AC115V INV 15 A: AC inverter
5. FR FOG 15 A: Front fog lights
6. OBD 7.5 A: On−board diagnosis sys-
tem
7. HEAD (LO RH) 10 A: Right −hand
headlight (low beam)
8. HEAD (LO LH) 10 A: Left−hand head-
light (low beam)
9. HEAD (HI RH) 10 A: Right −hand head-
light (high beam)
10. HEAD (HI LH) 10 A: Left −hand head-
light (high beam) 11. EFI NO.2 10 A:
Multiport fuel injection
system/s equential multiport fuel injec-
tion system
12. HEATER NO.2 7.5 A: Air conditioning
system
13. AIRSUS NO.2 10 A: Rear height con-
trol air suspension
14. SEAT HEATER 25 A: Seat heaters
15. DEFOG 30 A: Back window defogger,
multiport fuel injection system/sequen-
tial multiport fuel injection system
16. MIR HEATER 10 A: Outside rear view
mirror heater
17. DOME 10 A: Interior light, personal
lights, wireless remote control system,
door courtesy lights, gauge and meter,
vanity lights, instrument panel lights,
running board lights, multiplex commu-
nication system
18. RADIO NO.1 20 A: Audio system, nav-
igation system, rear seat entertainment
system
Fuses
