- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-485
641 Author: Date:
2001 AVALON (RM808U)
INSPECTION PROCEDURE
If the DTC is not displayed, do the following troubleshooting.
1 Does SRS warning light light up for approx. 6 seconds?
PREPARATION:
Check operation of the SRS warning light after ignition switch
is turned from LOCK position to ACC or ON position.
NO Check SRS warning light system (See page
DI-479).
YES
2 Check voltage between terminals Tc and E1 of DLC1.
PREPARATION:
Turn the ignition switch to ACC or ON.
CHECK:
Measure the voltage between terminals Tc and E1 of DLC1.
OK:
Voltage: 10 - 14 V
OK Go to step 4.
NG
Page 1222 of 1897
AB0118
R14304AB0119
H00031
ACCON
orTc
(+)
(-)
AB0117 AB0118 AB0119H01302H01303
LOCK
ACCON
or
Airbag Sensor Assembly
Tc
DI-486
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
642 Author: Date:
2001 AVALON (RM808U)
3 Check voltage between terminal Tc of DLC1 and body ground.
CHECK:
Measure the voltage between terminal Tc of DLC1 and body
ground.
OK:
Voltage: 10 - 14 V
OK Check harness between terminal E1 of DLC1
and body ground.
NG
4 Check airbag sensor assembly.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Disconnect the airbag sensor assembly connector.
(d) Insert service wire into terminal Tc from back side as
shown in the illustration.
(e) Connect the airbag sensor assembly connector with ser-
vice wire.
(f) Connect negative (-) terminal cable to the battery.
(g) Turn the ignition switch to ACC or ON and wait at least for
20 seconds.
(h) Connect service wire of terminal Tc to body ground.
CHECK:
Check operation of the SRS warning light.
OK:
SRS waning light comes on.
NOTICE:
Pay due attention to the terminal connecting position to
avoid a malfunction.
OK Check harness between the airbag sensor as-
sembly and DLC1.
NG
Replace airbag sensor assembly.
Page 1223 of 1897
AB0119H01304H01305
LOCKAirbag Sensor Assembly
Tc
(+)
(-)
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-487
643 Author: Date:
2001 AVALON (RM808U)
If the DTC is displayed without a DTC check procedure, perform the following
troubleshooting.
1 Check resistance between terminal Tc of airbag sensor assembly and body
ground.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Disconnect the airbag sensor assembly connector.
CHECK:
Check resistance between terminal Tc of the airbag sensor as-
sembly connector and body ground.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector.
OK
Replace airbag sensor assembly.
Page 1224 of 1897
DI15Z-10
Supplemental Restraint System Check Sheet
Date Problem Occurred
Customer 's Name
Registration No.
Registration Year
Frame No.
Odometer Reading
Weather
Temperature
Vehicle Operation
Road Conditions
Details Of Problem
Vehicle Inspection and Repair
History Prior to Occurrence of
Malfunction (Including Supple-
mental Restraint System)
Diagnosis System Inspection
SRS Warning Light
Inspection
DTC Inspection1st Time
2nd Time
1st Time
2nd TimeInspector 's
Name
Fine Cloudy Rainy Snowy Other
Approx.
Starting Idling
Driving [ Constant speed Acceleration Deceleration
Other ]
Remains ON Sometimes Lights Up Does Not Light Up
Remains ON Sometimes Lights Up
Does Not Light Up
Normal Code Malfunction Code
Normal Code Malfunction Code[ Code. ]
[ Code. ]km
Miles //
//
// Date Vehicle Brought In
DI-348
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
504 Author: Date:
2001 AVALON (RM808U)
CUSTOMER PROBLEM ANALYSIS CHECK
Page 1225 of 1897
DI161-31
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-355
511 Author: Date:
2001 AVALON (RM808U)
DIAGNOSTIC TROUBLE CODE CHART
If a malfunction code is displayed during the DTC check, check the circuit listed for that code in the table
below (Proceed to the page given for that circuit.).
DTC No.
(See Page)Detection ItemTrouble AreaSRS
Warning Light
B0100/13
(DI-362)
Short in D squib circuitSteering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
B0101/14
(DI-367)
Open in D squib circuitSteering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
B0102/11
(DI-371)
Short in D squib circuit (to ground)Steering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
B0103/12
(DI-375)
Short in D squib circuit (to B+)Steering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
B0105/53
(DI-379)Short in P squib circuitFront passenger airbag assembly (squib)
Airbag sensor assembly
Wire harness
ON
B0106/54
(DI-383)Open in P squib circuitFront passenger airbag assembly (squib)
Airbag sensor assembly
Wire harness
ON
B0107/51
(DI-386)Short in P squib circuit (to ground)Front passenger airbag assembly (squib)
Airbag sensor assembly
Wire harness
ON
B0108/52
(DI-389)Short in P squib circuit (to B+)Front passenger airbag assembly (squib)
Airbag sensor assembly
Wire harness
ON
B0110/43
(DI-392)Short in side squib (RH) circuitSide airbag assembly RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0111/44
(DI-396)Open in side squib (RH) circuitSide airbag assembly RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0112/41
(DI-402)Short in side squib (RH) circuit
(to ground)Side airbag assembly RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0113/42
(DI-402)Short in side squib (RH) circuit
(to B+)Side airbag assembly RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0115/47
(DI-405)Short in side squib (LH) circuitSide airbag assembly LH (squib)
Airbag sensor assembly
Wire harness
Blink
B0116/48
(DI-409)Open in side squib (LH) circuitSide airbag assembly LH (squib)
Airbag sensor assembly
Wire harness
Blink
Page 1226 of 1897
DI-356
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
512 Author: Date:
2001 AVALON (RM808U)DTC No.
(See Page)
Detection ItemTrouble AreaSRS
Warning Light
B0117/45
(DI-412)Short in side squib (LH) circuit
(to ground)Side airbag assembly LH (squib)
Airbag sensor assembly
Wire harness
Blink
B0118/46
(DI-415)Short in side squib (LH) circuit
(to B+)Side airbag assembly LH (squib)
Airbag sensor assembly
Wire harness
Blink
B0130/63
(DI-418)Short in P/T squib (RH) circuitSeat belt pretensioner RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0131/64
(DI-422)Open in P/T squib (RH) circuitSeat belt pretensioner RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0132/61
(DI-425)Short in P/T squib (RH) circuit
(to ground)Seat belt pretensioner RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0133/62
(DI-428)Short in P/T squib (RH) circuit
(to B+)Seat belt pretensioner RH (squib)
Airbag sensor assembly
Wire harness
Blink
B0135/73
(DI-431)Short in P/T squib (LH) circuitSeat belt pretensioner LH (squib)
Airbag sensor assembly
Wire harness
Blink
B0136/74
(DI-435)Open in P/T squib (LH) circuitSeat belt pretensioner LH (squib)
Airbag sensor assembly
Wire harness
Blink
B0137/71
(DI-438)Short in P/T squib (LH) circuit
(to ground)Seat belt pretensioner LH (squib)
Airbag sensor assembly
Wire harness
Blink
B0138/72
(DI-441)Short in P/T squib (LH) circuit
(to B+)Seat belt pretensioner LH (squib)
Airbag sensor assembly
Wire harness
Blink
B1100/31
(DI-444)Airbag sensor assembly malfunctionAirbag sensor assemblyON
B1140/32
(DI-446)Side airbag sensor assembly (RH)
malfunctionSide airbag sensor assembly (RH)
Airbag sensor assembly
Wire harness
Blink
B1141/33
(DI-454)Side airbag sensor assembly (LH)
malfunctionSide airbag sensor assembly (LH)
Airbag sensor assembly
Wire harness
Blink
B1156/B1157/
15
(DI-462)Front airbag sensor (RH) malfunctionFront airbag sensor (RH)
Airbag sensor assembly
Wire harness
ON
B1158/B1159/
16
(DI-467)Front airbag sensor (LH) malfunctionFront airbag sensor (LH)
Airbag sensor assembly
Instrument panel wire harness
Engine room main wire harness
ON
NlSystem normal-OFFNormal
(DI-475)Voltage source dropBattery
Airbag sensor assemblyON
Page 1227 of 1897
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-357
513 Author: Date:
2001 AVALON (RM808U)
HINT:
When the SRS warning light remains lit up and the DTC is the normal code, this means a voltage source
drops.
This malfunction is not stored in memory by the airbag sensor assembly and if the power source volt-
age returns to normal, the SRS warning light will automatically go out.
When 2 or more codes are indicated, the codes will be displayed in numeral order starting from the
lowest numbered code.
If a code not listed on the chart is displayed, the airbag sensor assembly is faulty.
Page 1228 of 1897
DI1MX-12
Warning Light Check
P. DI-349
END
: Diagnostic steps permitting the use
of the TOYOTA hand-held tester.
P. DI-348
P. DI-349
Symptom SimulationNormal
DTC Check
Warning Light
ONMalfunction CodeWarning Light
Remains OFF
Circuit Inspection
Identification of Problem
Repair
Warning Light Check
P. DI-349
DTC Check (Read Past DTC)
Confirmation Test
Remains ON
Remains OFF
Clear DTC (Present and Past DTC)Items inside are titles of pages in this manual,
with the page number in the bottom portion. See the
pages for detailed explanations.
1
2
43
5
7
8
9
10
DTC Chart
11
6P. DI-355
P. IN-20 P. DI-362 to DI-484Remains OFF
Remains ON
Vehicle Brought to Workshop
Customer Problem Analysis
DTC Check (Read Present DTC)
Step 3, 4, 6, 8, 9, 11
P. DI-349
DTC Check (Read Past DTC)
P. DI-349
P. DI-349
P. DI-349
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-347
503 Author: Date:
2001 AVALON (RM808U)
SUPPLEMENTAL RESTRAINT SYSTEM
HOW TO PROCEED WITH TROUBLESHOOTING
Page 1229 of 1897
DI1N1-10
H11973
Spiral Cable Accessory Meter
(Warning Light)Front Passenger Airbag Assembly
Side Airbag Assembly (RH)
Side Airbag Sensor
Assembly (RH)
Seat Belt Pretensioner (RH) Side Airbag Sensor
Assembly (LH)
Seat Belt
Pretensioner (LH)
Side Airbag Assembly (LH)Airbag Sensor Assembly Front Airbag Sensor (RH)
Steering Wheel Pad
(with Airbag)Front Airbag
Sensor (LH)
DI-358
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
514 Author: Date:
2001 AVALON (RM808U)
PARTS LOCATION
Page 1230 of 1897
H11969
DI1MZ-1 1
R13006
DLC1
E1 Tc
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-349
505 Author: Date:
2001 AVALON (RM808U)
PRE-CHECK
1. SRS WARNING LIGHT CHECK
(a) Turn the ignition switch to the ACC or ON position and
check that the SRS warning light lights up.
(b) Check that the SRS warning light goes out after approx.
6 seconds.
HINT:
When the ignition switch is at ACC or ON and the SRS
warning light remains on or flashes, the airbag sensor as-
sembly has detected a malfunction code.
If, after approx. 6 seconds have elapsed, the SRS warn-
ing light sometimes lights up or the SRS warning light
lights up even when the ignition switch is OFF, a short in
the SRS warning light circuit can be considered likely.
Proceed to ºSRS warning light circuit malfunctionº on
page DI-479.
2. DTC CHECK (Using diagnosis check wire)
(a) Present troubles codes:
Output the DTC.
(1) Turn the ignition switch to the ACC or ON position
and wait for approx. 20 seconds.
(2) Using SST, connect terminals Tc and E1 of the
DLC1.
SST 09843-18020
NOTICE:
Pay due attention to the terminal connecting position to
avoid a malfunction.
(b) Past troubles codes:
Output the DTC.
(1) Using service wire, connect terminals Tc and E1 of
the DLC1.
SST 09843-18020
(2) Turn the ignition switch to the ACC or ON position
and wait for approx. 20 seconds.
NOTICE:
Pay due attention to the terminal connecting position to
avoid a malfunction.
