Page 1371 of 1897
P18752
A07431
A07432
A07433
Engine
Hanger
EM-74
- ENGINE MECHANICALENGINE UNIT
1058 Author: Date:
2001 AVALON (RM808U)
19. DISCONNECT REAR ENGINE MOUNTING BRACKET
FROM FRONT FRAME
(a) Remove the 2 hole plugs.
(b) Remove the 4 nuts holding the front frame to the mount-
ing bracket.
20. REMOVE ENGINE MOUNTING ABSORBER
Remove the 4 bolts and mounting absorber.
21. DISCONNECT FRONT ENGINE MOUNTING INSULA-
TOR FROM FRONT FRAME
Remove the 3 bolts holding the mounting insulator to the front
frame.
22. ATTACH ENGINE SLING DEVICE TO ENGINE HANG-
ERS
(a) Install the No.2 engine hanger in the correct direction.
Part No.:
No.2 engine hanger12282-20020
Bolt90080-1 1331
Torque: 19.5 N´m (200 kgf´cm, 14 ft´lbf)
(b) Attach the sling device to the engine hangers.
CAUTION:
Do not attempt to hang the engine by hooking the chain to
any other part.
Page 1372 of 1897
A07435
A07438
Lift
- ENGINE MECHANICALENGINE UNIT
EM-75
1059 Author: Date:
2001 AVALON (RM808U)
23. REMOVE ENGINE MOVING CONTROL ROD AND
NO.2 RH ENGINE MOUNTING BRACKET
Remove the 4 bolts, control rod and mounting bracket.
24. REMOVE ENGINE AND TRANSAXLE ASSEMBLY
FROM VEHICLE
(a) Lift the engine out of the vehicle slowly and carefully.
NOTICE:
Be careful not to hit the PNP switch.
Make sure the engine is clear of all wiring, hoses and
cables.
(b) Place the engine and transaxle assembly onto the stand.
25. REMOVE FRONT ENGINE MOUNTING INSULATOR
FROM ENGINE
Remove the 4 bolts and mounting insulator.
26. REMOVE REAR ENGINE MOUNTING INSULATOR
AND BRACKET ASSEMBLY FROM ENGINE
Remove the 4 bolts, the mounting insulator and bracket assem-
bly.
27. SEPARATE ENGINE AND TRANSAXLE
Page 1373 of 1897
EM0ZR-02
A10836
Gasket
Non-reusable part
N´m (kgf´cm, ft´lbf) : Specified torque Gasket
Bracket
Front Exhaust Pipe Heat Insulator
Center Exhaust Pipe Gasket Heat Insulator
Heated Oxygen Sensor
(Bank 1 Sensor 2)Tailpipe
Ring Ring
33 (330, 24)
Heat Insulator Heated Oxygen Sensor (Bank 1 Sensor 2)
Before installing the oxygen sensor, twist
the sensor wire counterclockwise 3 and
1/2 turns.
If it is twisted, remove the oxygen sensor
and reinstall it. After installing the sensor wire is not twisted.HINT:
43 (440, 32)
21 (210, 15)
62 (630, 46)
33 (330, 24)
44 (450, 33)
Stay
Pipe Support
Bracket
39 (400, 29)
22 (220,16)
Pipe Support
Bracket
33 (330, 24)
62 (630, 46)
43 (440, 32)
Compression Spring
Compression Spring
Damper
19 (190, 14)
Heat Insulator
No.1 Exhaust Pipe
Support Bracket
Type A
Type B
Ring
Pipe Support
Bracket
EM-1 10
- ENGINE MECHANICALEXHAUST SYSTEM
1094 Author: Date:
2001 AVALON (RM808U)
EXHAUST SYSTEM
COMPONENTS
Page 1374 of 1897
EM0CF-02
EM-12
- ENGINE MECHANICALIDLE SPEED
996 Author: Date:
2001 AVALON (RM808U)
IDLE SPEED
INSPECTION
1. INITIAL CONDITIONS
(a) Engine at normal operating temperature
(b) Air cleaner installed
(c) All pipes and hoses of air induction system connected
(d) All accessories switched OFF
(e) All vacuum lines properly connected
(f) SFI system wiring connectors fully plugged
(g) Ignition timing check correctly
(h) Transmission in neutral position
(i) Air conditioning switched OFF
2. CONNECT TOYOTA HAND-HELD TESTER OR OBDII SCAN TOOL (See page EM-10)
3. INSPECT IDLE SPEED
(a) Race the engine speed at 2,500 rpm for approx. 90 seconds.
(b) Check the idle speed.
Idle speed: 650 ± 50 rpm
If the idle speed is not as specified, check the IAC valve and air intake system.
4. DISCONNECT TOYOTA HAND-HELD TESTER OR OBDII SCAN TOOL
Page 1375 of 1897
A10518
5 mm
Hexagon
Wrench
EM15O-01
A10838
TOYOTA
Hand-Held Tester
DLC3
A10536
Lead Wire
A07285
E1DLC1
TE1
DLC1SST
A05184
EM-10
- ENGINE MECHANICALIGNITION TIMING
994 Author: Date:
2001 AVALON (RM808U)
IGNITION TIMING
INSPECTION
1. REMOVE V-BANK COVER
(a) Using a 5 mm hexagon wrench, remove the 3 cap nuts.
(b) Loosen the V-bank cover fastener counterclockwise.
(c) Remove the V-bank cover.
2. WARM UP ENGINE
Allow the engine to warm up to normal operating temperature.
3. CONNECT TOYOTA HAND-HELD TESTER OR OBDII
SCAN TOOL
(a) Connect the TOYOTA hand-held tester or OBDII scan
tool to the DLC3.
(b) Please refer to the TOYOTA hand-held tester or OBDII
scan tool operator's manual for further details.
4. CONNECT TIMING LIGHT TO ENGINE
Connect the clip of a timing light to the lead wire as shown.
5. CHECK IDLE SPEED
(a) Race the engine speed at 2,500 rpm for approx. 90 se-
conds.
(b) Check the idle speed.
Idle speed: 650 ± 50 rpm
6. INSPECT IGNITION TIMING
(a) Using SST, connect terminals TE1 and E1 of the DLC1.
SST 09843-18020
(b) Using a timing light, check the ignition timing.
Ignition timing: 8 - 12° BTDC @ idle
(Transmission in neutral position)
(c) Remove the SST from the DLC1.
SST 09843-18020
Page 1376 of 1897
- ENGINE MECHANICALIGNITION TIMING
EM-1 1
995 Author: Date:
2001 AVALON (RM808U)
7. FURTHER CHECK IGNITION TIMING
Ignition timing: 10 - 25° BTDC @ idle
(Transmission in neutral position)
HINT:
The timing mark moves in a range between 10° and 25°.
8. DISCONNECT TIMING LIGHT FROM ENGINE
9. DISCONNECT TOYOTA HAND- HELD TESTER OR
OBDII SCAN TOOL
10. REINSTALL V-BANK COVER
(a) Using a 5 mm hexagon wrench, install the V-bank cover
with the 3 cap nuts.
(b) Press down the V-bank cover fastener.
Page 1377 of 1897
EM03Y-03
A10834
RH Fender Apron Seal
Generator Drive Belt
Engine Moving
Control Rod
No.2 RH Engine
Mounting Bracket
Ground Strap
Connector PS Pump Drive Belt
Engine Coolant Reservoir Hose
: Specified torque
64 (650, 47)
32 (320, 23)
N´m (kgf´cm, ft´lbf)
- ENGINE MECHANICALTIMING BELT
EM-13
997 Author: Date:
2001 AVALON (RM808U)
TIMING BELT
COMPONENTS
Page 1378 of 1897
A06659
No.2 Timing Belt CoverTiming Belt
Timing Belt Guide
No.2 Generator
Bracket RH Engine Mounting Bracket
Crankshaft
PulleyGasket
Engine Wire
Protector
RH Camshaft Timing Pulley
No.2 Idler Pulley
Crankshaft
Timing PulleyDust Boot
Timing Belt Plate Plate Washer
215 (2,200, 159)
43 (440, 32)
27 (280, 20)
Timing Belt Tensioner
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
28 (290, 21)
No.1 Timing Belt Cover
125 (1,300, 94)
*88 (900, 65)
LH Camshaft
Timing Pulley
No.1 Idler Pulley
34 (350, 25)
Precoated part
* For use with SST
125 (1,300, 94)
EM-14
- ENGINE MECHANICALTIMING BELT
998 Author: Date:
2001 AVALON (RM808U)
Page 1379 of 1897
EM0ZC-02
EM3336
NO!
P20042A02309
P12604
- ENGINE MECHANICALTIMING BELT
EM-19
1003 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT TIMING BELT
NOTICE:
Do not bend, twist or turn the timing belt inside out.
Do not allow the timing belt to come into contact with
oil, water or steam.
Do not utilize timing belt tension when installing or re-
moving the mount bolt of the camshaft timing pulley.
If there are any defects, as shown in the illustrations, check
these points:
(a) Premature parting
Check for proper installation.
Check the timing cover gasket for damage and
proper installation.
(b) If the belt teeth are cracked or damaged, check to see if
either camshaft is locked.
(c) If there is noticeable wear or cracks on the belt face,
check to see if there are nicks on the side of the idler
pulley lock and water pump.
(d) If there is wear or damage on only one side of the belt,
check the belt guide and the alignment of each pulley.
(e) If there is noticeable wear on the belt teeth, check timing
cover for damage and check gasket has been installed
correctly and for foreign material on the pulley teeth.
If necessary, replace the timing belt.
2. INSPECT IDLER PULLEYS
(a) Visually check the seal portion of the idler pulley for oil
leakage.
If leakage is found, replace the idler pulley.
(b) Check that the idler pulley turns smoothly.
If necessary, replace the idler pulley.
Page 1380 of 1897
P18782
P18764
P18770
Protrusion EM-20
- ENGINE MECHANICALTIMING BELT
1004 Author: Date:
2001 AVALON (RM808U)
3. INSPECT TIMING BELT TENSIONER
(a) Visually check the seal portion of the tensioner for oil leak-
age.
HINT:
If there is only the faintest trace of oil on the seal on the push
rod side, the tensioner is all right.
If leakage is found, replace the tensioner.
(b) Hold the tensioner with both hands and push the push rod
strongly as shown to check that it doesn't move.
If the push rod moves, replace the tensioner.
NOTICE:
Never hold the tensioner push rod facing downward.
(c) Measure the protrusion of the push rod from the housing
end.
Protrusion: 10.0 - 10.8 mm (0.394 - 0.425 in.)
If the protrusion is not as specified, replace the tensioner.
