TOYOTA AVALON 2001 Service Repair Manual

Z07425
Wire harness side:
12 123 45
67 891011
Z05732
Warning Light
Ignition
Switch
Battery
1
I14605
Warning Light
Ignition
Switch
Battery
1 2
- BODY ELECTRICALCOMBINATION METER
BE-61
1665 Author
: Date
:
2001 AVALON (RM808U)
22. INSPECT LIGHT FAILURE SENSOR CIRCUIT
Disconnect the connector from the sensor and inspect the con-
nector on the wire harness side, as shown.
Tester connectionConditionSpecified condition
1 - GroundConstantContinuity*
2 - GroundConstantContinuity*
9 - GroundConstantContinuity*
10 - GroundConstantContinuity*
11 - GroundConstantContinuity
12 - GroundConstantContinuity*
3 - GroundLight control switch OFFNo voltage
3 - GroundLight control switch TAIL or HEADBattery positive voltage
4, 8 - GroundIgnition switch LOCK or ACCNo voltage
4, 8 - GroundIgnition switch ONBattery positive voltage
7 - GroundStop light switch OFFNo voltage
7 - GroundStop light switch ONBattery positive voltage
*: There is resistance because this circuit is grounded through
the bulb.
If the circuit is as specified, replace the sensor.
If the circuit is not as specified, inspect the circuits connected
to other parts.
23. INSPECT OPEN DOOR WARNING LIGHT
Disconnect the connector from the door courtesy switch, and
ground terminal 1 on the wire harness side connector and
check that the warning light lights up.
If the warning light does not light up, inspect the bulb or wire har-
ness.
24. INSPECT DOOR COURTESY SWITCH
(See page BE-31)
25. INSPECT SEAT BELT WARNING LIGHT
(a) Disconnect the connector from the terminals buckle
switch and ground terminal on the wire harness side con-
nector as shown in the illustration.
(b) Turn the ignition switch ON and check that the warning
light lights up.
If the warning light does not light up, check the bulb circuit.

Z14380
ON OFF
BE1217
Warning Light
Ignition
Switch
Battery
N20217
OFF
ONOhmmeter
Z10258
Wire harness side:
12 BE-62
- BODY ELECTRICALCOMBINATION METER
1666 Author
: Date
:
2001 AVALON (RM808U)
26. INSPECT BUCKLE SWITCH CONTINUITY
(a) Check that continuity exists between the terminals on the
switch side connector with the switch ON (belt unfas-
tened).
(b) Check that no continuity exists between the terminals on
the switch side connector with the switch OFF (belt fas-
tened).
27. INSPECT WASHER LEVEL WARNING LIGHT
(a) Disconnect the connectors from the level warning switch.
(b) Connect terminals on the wire harness side connector of
the level warning switch connector.
(c) Turn the ignition switch ON, check that the warning light
come on.
If the warning light does not light up, test the bulb.
28. INSPECT WASHER LEVEL WARING SWITCH
(a) Check that no continuity exists between terminals with the
switch OFF (float up).
(b) Check that continuity exists between terminals with the
switch ON (float down).
If operation is not as specified, replace the switch.
29. INSPECT WASHER FLUID LEVEL WARNING SWITCH
CIRCUIT
Disconnect the switch connector and inspect the connector on
wire harness side.
Tester connectionConditionSpecified condition
2 - GroundConstantContinuity
If the warning light does not light up, test the bulb or inspect wire
harness.

N08958
270°
1 2
3
I14604
Press
1 2
- BODY ELECTRICALCOMBINATION METER
BE-63
1667 Author
: Date
:
2001 AVALON (RM808U)
30. INSPECT LIGHT CONTROL RHEOSTAT OPERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative lead (-) to terminal 3.
(b) Connect the positive (+) lead from the voltmeter to termi-
nal 2 and the negative lead (-) to terminal 3.
(c) Turn the rheostat knob and check that the voltage
changes.
If operation is not as specified, replace switch.
31. Passenger 's seat only:
INSPECT SEAT BELT WARNING OCCUPANT DETEC-
TION SENSOR CONTINUITY
Check that continuity exists between the terminals 1 and 2
when pressing the sensing part (electric resistance <100W).
If continuity is not as specified, replace the sensor.

BE0IE-03
I12531
Brake Master Cylinder

Brake Fluid Level
Warning Switch
Engine Room
Junction Block

SRS WRN Fuse
Washer Tank

Washer Fluid Level
Warning Switch
Combination Meter

Meter Circuit
Light Control
Rheostat
Driver Side Junction Block

GAUGE No.1 Fuse

PANEL Fuse

ECU-B No.1, 2 Fuss

ECU-IG No.2 Fuse

RAD No.1 Fuse

DOME Fuse

ECU ACC Fuse Parking Brake
Switch
Ignition Switch
Multi Information Display
- BODY ELECTRICALCOMBINATION METER
BE-41
1645 Author
: Date
:
2001 AVALON (RM808U)
COMBINATION METER
LOCATION

I12532
Door Courtesy Switch
Fuel Sender Gauge
Light Failure Sensor Seat Belt Buckle Switch
Engine Coolant Temperature Sender Gauge
Park/Neutral Position Switch Low Oil Pressure Warning Switch
Occupant Detection Sensor
BE-42
- BODY ELECTRICALCOMBINATION METER
1646 Author
: Date
:
2001 AVALON (RM808U)

BE216-01
I21290
Calendar
LIGHT Button
MODE Button RESET/ADJ Button
I21291
I21283
I21284
BE-64
- BODY ELECTRICALCOMPASS
1668 Author
: Date
:
2001 AVALON (RM808U)
COMPASS
ADJUSTMENT
1. MULTI INFORMATION DISPLAY ILLUMINATION
Turn the ignition switch to the ON position and illuminate the all
parts of the display by pushing the ºLIGHTº button.
2. PERFORM CIRCLING CALIBRATION
(a) Push the ºMODEº button several times until ºCOM-
PASSºappears and blinks on the calendar display.
(b) Then push the ºRESET/ADJº button. ºCALIBRATEº ap-
pears and blinks together with the compass display.
(c) Drive the vehicle in a circle until the blinking stops.
(d) If there is not enough space to drive in a circle, drive
around the block until the blinking stops.
(e) When the compass and the calendar display return to
normal mode, calibration is complete

I21285
I21286
Hawaii, A. Samoa: 7
Guam, Saipan: 9
Puerto Rico: 11
Taiwan (R.O.C): 9
- BODY ELECTRICALCOMPASS
BE-65
1669 Author
: Date
:
2001 AVALON (RM808U)
NOTICE:

Do not perform circling calibration of the compass in
a place where the earth's magnetic field is subject to
interference by artificial magnetic fields (under-
ground parking, under a steel tower, between build-
ings, roof parking, near a crossing, near a large ve-
hicle, etc.).

During calibration, do not operate electric systems
(moonroof, power windows, etc.) as they may inter-
fere with the calibration.

If you want to cancel the calibration before it is com-
plete, push the ºMODEº button again.
HINT:
A compass could be magnetized during by vessels of freight
cars. Before delivery, therefore, make sure to perform calibra-
tion and ensure that calibration can be done. If cannot be done
(cannot complete in spite of driving round several times), it may
be caused by magnetization. Demagnetize the vehicle using a
demagnetizer and preform calibration again.
3. PERFORM DEVIATION CALIBRATION
(a) Stop the vehicle and push the ºMODEº button several
times until ºZONE XXº appears on the calender display.
(b) Then push the ºRESET/ADJº button, referring to the fol-
lowing map to select the number of the zone where the
vehicle is.
(c) After calibration, push the ºMODEº button several times
until the calendar display returns to the normal mode.

I12825
34 4017 18
BE0IG-03
I12826
34
17 18
40
ON
ON
W/ Mirror Heater:
W/O Mirror Heater:
I057411
2 34
4 321
I13308
3
6
I13307
5
10
- BODY ELECTRICALDEFOGGER SYSTEM
BE-67
1671 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. A/C control panel assembly:
INSPECT DEFOGGER SWITCH OPERATION
(a) Connect the positive (+) lead from the battery to terminal
17, 18 and negative (-) lead to terminal 40.
(b) Connect the positive (+) lead from the battery to terminal
24 through a 1.4 W test bulb.
(c) Turn the defogger switch ON and check that the test bulb
and indicator light turn ON, then turn OFF after about 15
minutes.
If operation is not as specified, proceed to the next inspection.
2. INSPECT DEFOGGER RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant3 - 4Continuity
Apply B+ between
terminals 3 and 4.1 - 2Continuity
If continuity is not as specified, replace the relay.
3. W/ Mirror defogger:
INSPECT MIRROR DEFOGGER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (-) lead to terminal 6.
(b) Check that the mirror becomes warm.
HINT:
It will take a short time for the mirror to become warm.
If the mirror does not become warm, replace the mirror assem-
bly.
4. W/ Mirror defogger and driving position memory:
INSPECT MIRROR DEFOGGER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
5 and the negative (-) lead to terminal 10.
(b) Check that the mirror becomes warm.
HINT:
It will take a short time for the mirror to become warm.
If the mirror does not become warm, replace the mirror assem-
bly.

BE4029
Tester Probe
Tin FoilHeat Wire
BE0123
At Center
BE0124
Broken
WireServeral
Volts
v0 Volt
BE0150
Repair Point
Masking TapeBroken
Wire
BE-68
- BODY ELECTRICALDEFOGGER SYSTEM
1672 Author
: Date
:
2001 AVALON (RM808U)
5. INSPECT DEFOGGER WIRE
NOTICE:
When cleaning the glass, use a soft, dry cloth, and wipe the
glass in the direction of the wire. Take care not to damage
the wires. Do not use detergents or glass cleaners with
abrasive ingredients. When measuring voltage, wind a
piece of tin foil around the top of the negative probe and
press the foil against the wire with your finger, as shown.
(a) Turn the ignition switch ON.
(b) Turn the defogger switch ON.
(c) Inspect the voltage at the center of each heat wire, as
shown.
VoltageCriteria
Approx. 5 VOkay (No break in wire)
Approx. 10 V or 0 VBroken wire
HINT:
If there is approximately 10 V, the wire is broken between the
center of the wire and the positive (+) end. If there is no voltage,
the wire is broken between the center of the wire and ground.
(d) Place the voltmeter positive (+) lead against the defogger
positive (+) terminal.
(e) Place the voltmeter negative (-) lead with the foil strip
against the heat wire at the positive (+) terminal end and
slide it toward the negative (-) terminal end.
(f) The point where the voltmeter deflects from zero to sever-
al V is the place where the heat wire is broken.
HINT:
If the heat wire is not broken, the voltmeter indicates 0 V at the
positive (+) end of the heat wire but gradually increases to about
12 V as the meter probe is moved to the other end.
6. IF NECESSARY, REPAIR DEFOGGER WIRE
(a) Clean the broken wire tips with a grease, wax and silicone
remover.
(b) Place the masking tape along both sides of the wire to be
repaired.
(c) Thoroughly mix the repair agent (Dupont paste No.
4817).

BE0151
- BODY ELECTRICALDEFOGGER SYSTEM
BE-69
1673 Author
: Date
:
2001 AVALON (RM808U)
(d) Using a fine tip brush, apply a small amount to the wire.
(e) After a few minutes, remove the masking tape.
(f) Do not repair the defogger wire for at least 24 hours.
