TOYOTA AVALON 2001 Service Repair Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: AVALON, Model: TOYOTA AVALON 2001Pages: 1897, PDF Size: 26.61 MB
Page 251 of 1897
BE1DL-01
I13328
w/ Sliding roof:
w/o Sliding roof:
N12373
ON
N20159
ON
OFFOhmmeter
I13329
ON
OFF
Z07389
- BODY ELECTRICALINTERIOR LIGHT SYSTEM
BE-31
1635 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT FRONT PERSONAL LIGHT CONTINUITY
Switch positionTester connectionSpecified condition
OFF1 - 3No continuity
-2 - 3No continuity
ON1 - 3Continuity
If continuity is not as specified, replace the light assembly or
bulb.
2. INSPECT REAR INTERIOR LIGHT CONTINUITY
Switch positionTester connectionSpecified condition
OFF1 - 2No continuity
ON1 - 2Continuity
If continuity is not as specified, replace a bulb or rear personal
light.
3. INSPECT DOOR COURTESY SWITCH CONTINUITY
(a) Check that continuity exists between terminal and the
switch body with the switch ON (switch pin released:
opened door).
(b) Check that no continuity exists between terminal and the
switch body withe the swtich OFF (switch pin pushed in:
closed doors).
If operation is not as specified, replace the switch.
4. INSPECT VANITY LIGHT CONTINUITY
Switch positionTester connectionSpecified condition
OFF1 - 2No continuity
ON1 - 2Continuity
If continuity is not as specified, replace bulb or vanity light.
5. INSPECT LUGGAGE COMPARTMENT LIGHT CONTI-
NUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
ON1 - 2Continuity
If continuity is not as specified, replace the light.
Page 252 of 1897
Z05876
ON
OFF
I14261
1
N01732
2
1 BE-32
- BODY ELECTRICALINTERIOR LIGHT SYSTEM
1636 Author: Date:
2001 AVALON (RM808U)
6. INSPECT LUGGAGE COMPARTMENT DOOR COUR-
TESY SWITCH CONTINUITY
ConditionTester connectionSpecified condition
OFF-No continuity
ON1 - Switch bodyContinuity
If operation is not as specified, replace the switch.
7. INSPECT INTERIOR LIGHT ASSEMBLY CONTINUITY
(a) Disconnect the connector from room light assembly.
(b) Turn the room light switch ON, check that there is continu-
ity between terminal 1 and body ground.
(c) Turn the room light switch DOOR, check that there is con-
tinuity between terminal 1 and 2.
If operation is not as specified, replace the switch.
8. INSPECT ILLMINATION ENTRY SYSTEM
(See Page BE-2)
Page 253 of 1897
BE0I2-03
I12527
Front Personal Light
Vanity LightInterior Light Assembly
Door Courtesy LightDoor Courtesy Switch
Door Courtesy Light
Door Courtesy Switch
Driver Side Junction Block
DOME Fuse
Body ECU
Rear Interior Light Assembly
Luggage Compartment Light
BE-30
- BODY ELECTRICALINTERIOR LIGHT SYSTEM
1634 Author: Date:
2001 AVALON (RM808U)
INTERIOR LIGHT SYSTEM
LOCATION
Page 254 of 1897
BE1DI-01
I01256
1 3
867 4
5 2
LOCKACC
START
ON
N20125
ONOFF
1 2
I05741
1 2
3 4
1
2 3
4
BE-16- BODY ELECTRICALIGNITION SWITCH AND KEY UNLOCK WARNING
SWITCH
1620 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT IGNITION SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
LOCK-No continuity
ACC2 - 3Continuity
ON2 - 3 - 4
6 - 7Continuity
START1 - 2 - 4
6 - 7 - 8Continuity
If continuity is not as specified, replace the switch.
2. INSPECT KEY UNLOCK WARNING SWITCH CONTI-
NUITY
ConditionTester connectionSpecified condition
Switch OFF
(Key removed) -No continuity
Switch ON
(Key set)1 - 2Continuity
If continuity is not as specified, replace the switch.
3. INSPECT IG1 RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant3 - 4Continuity
Apply B+ between
terninal 3 and 41 - 2Continuity
If continuity is not as specified, replace the switch.
Page 255 of 1897
BE0HT-04
I12523
Ignition Switch
Key Unlock Warning Switch
Driver Side Junction Block
ECU ACC Fuse
ECU I/G No.2 Fuse
IG1 Relay
BODY ECU
- BODY ELECTRICALIGNITION SWITCH AND KEY UNLOCK WARNING
SWITCHBE-15
1619 Author: Date:
2001 AVALON (RM808U)
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH
LOCATION
Page 256 of 1897
BE1EH-01
I03433
Not turned
Unlock
I13485
1
2
I13334
I04020
1
- BODY ELECTRICALLUGGAGE COMPARTMENT DOOR OPENER SYSTEM
BE-125
1729 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT LUGGAGE COMPARTMENT DOOR KEY
LOCK AND UNLOCK SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
Not turned-No continuity
UNLOCK1 - 2Continuity
If continuity is not as specified, replace the switch.
2. INSPECT LUGGAGE COMPARTMENT DOOR OPEN-
ER MAIN SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
ON1 - 2Continuity
If continuity is not as specified, replace the switch.
3. INSPECT LUGGAGE COMPARTMENT DOOR OPEN-
ER CANCEL SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
ON1 - 2Continuity
If continuity is not as specified, replace the switch.
4. INSPECT LUGGAGE COMPARTMENT DOOR OPEN-
ER MOTOR OPERATION
Connect positive (+) lead to the terminal 1 and negative (-) lead
to the opener motor body, and check that the motor operateds.
If operation is not as specified, replace the lock.
Page 257 of 1897
BE1EG-01
I13482
Driver Side Junction Block
OPENER Fuse
Luggage Compartment Main Switch
Luggage Compartment Cancel Switch
Luggage Compartment Door
Unlock Motor
BE-124
- BODY ELECTRICALLUGGAGE COMPARTMENT DOOR OPENER SYSTEM
1728 Author: Date:
2001 AVALON (RM808U)
LUGGAGE COMPARTMENT DOOR OPENER SYSTEM
LOCATION
Page 258 of 1897
BE212-01
BE-88
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
1692 Author: Date:
ADJUSTMENT
ENABLING/DISABLING AUTO DOOR LOCK FUNCTION
(a) To disable auto door lock:
(1) Enter the vehicle and shut all doors.
(2) Insert the key into the ignition cylinder and turn it to
the ON position (not ACC).
(3) Open the driver's door and keep it open.
(4) Turn the key to the LOCK position and remove it
from the ignition cylinder.
(5) Insert the key into the ignition cylinder and remove
it. Repeat this operation three more times. (End this
step with the key out of the ignition cylinder.)
(6) Push the ºUNLOCKº button on the driver's door
master switch 5 times within 10 seconds. Wait at
least 10 seconds and shut the driver's door.
(7) Verify auto lock operation has been disabled by
starting the engine, putting the vehicle into a gear
and releasing the brake pedal.
(b) To enable auto door lock:
Follow the same sequence as above, except step 6. In step 6,
push the ºLOCKº button on the driver's door master switch 5
times within 10 seconds. Wait at least 10 seconds and shut the
driver 's door.
Page 259 of 1897
I12841
UNLOCKLOCK1 2 3 4 5 6
BE1DY-02
I12842
LOCK
UNLOCK1 2 3 4 5 6
I12843
UNLOCK
1 2 3 4 5 6
I12844
UNLOCK
1 2 3 4 5 6
I07301
LOCK
BE-82
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
1686 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. Driver 's door:
INSPECT DOOR KEY LOCK AND UNLOCK SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
LOCK3 - 5Continuity
OFF-No continuity
UNLOCK3 - 6Continuity
If continuity is not as specified, replace the switch.
2. Passenger 's Door:
INSPECT DOOR KEY LOCK AND UNLOCK SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
LOCK2 - 4Continuity
OFF-No continuity
UNLOCK1 - 4Continuity
If continuity is not as specified, replace the switch.
3. Driver 's Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)3 - 4Continuity
If continuity is not as specified, replace the switch.
4. Passenger 's Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)3 - 4Continuity
If continuity is not as specified, replace the switch.
5. Rear LH Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)1 - 2Continuity
If continuity is not as specified, replace the switch.
Page 260 of 1897
I07302
LOCK
I12845
UNLOCK
LOCK
UNLOCKLOCK
22
11
I12846
UNLOCK
LOCK
UNLOCK
LOCK
6565
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
BE-83
1687 Author: Date:
2001 AVALON (RM808U)
6. Rear RH Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)3 - 4Continuity
If continuity is not as specified, replace the switch.
7. Driver 's Door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (-) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
8. Passenger 's door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
5 and the negative (-) lead to terminal 6, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
