TOYOTA AVALON 2001 Service Repair Manual

Listing TOYOTA hand-held tester select sub-key regis-
tration.
Remove the master key.
Insert key to be registered in key cylinder.
(Security indicator blinks)
After 60 secs., additional sub-key is registered.
(Security indicator OFF)
The registration mode completes when pulling out the key
within 10 secs. and the brake pedal is depressed or after
indicator is off 10 secs. pass.Within 20 secs.
Within 10 secs.
Insert already registered master key in the key cylinder
and turn the ignition switch ON.
HINT:
Please follow the screen of the hand-held tester for more detailed procedure.
- BODY ELECTRICALENGINE IMMOBILISER SYSTEM
BE-177
1781 Author
: Date
:
2001 AVALON (RM808U)
(2) Using hand-held tester:

1. Insert master key in the key cylinder.
2. Depress and release the acceleration pedal 6 times.
3. Depress and release the brake pedal 7 times.
4. Remove the master key.
HINT:
If the key cannot be pulled out within 30 sec. from the first brake
depression in the step 3, the key code deletion is canceled.(Key code erased)
Within 15 sec.
Within 20 sec.
Within 10 sec.
END
5. Leave the vehicle more than 20 sec. without any
operation.
BE-178
- BODY ELECTRICALENGINE IMMOBILISER SYSTEM
1782 Author
: Date
:
2001 AVALON (RM808U)
4. ERASURE OF TRANSPONDER KEY CODE
There are 2 ways for erasure of transponder key code, one is depressing brake pedal and acceleration pedal
and the other is using hand-held tester.
NOTICE:
All other master and sub-key codes are deleted leaving the master key code to use the operation.
When using the key which was used before deleting, it is necessary to register the code again.
HINT:

When any operation time described below is over, registration mode completes.

When the next procedure is performed while the timer is working, the timer completes counting time,
then next timer starts.
(1) Depressing brake pedal and acceleration pedal:

2. Require key code deletion from hand-held tester.
(Security indicator blinks)
3. Remove the master key.
HINT: END
Within 10 secs.
(Key code erased) 1. Insert already registered master key in the key cylinder
and turn the ignition switch ON.

When the key cannot be pulled out in the step 3, key code deletion is canceled.
(Security indicator is OFF)

Please follow the screen of the hand-held tester for more detailed procedure.
- BODY ELECTRICALENGINE IMMOBILISER SYSTEM
BE-179
1783 Author
: Date
:
2001 AVALON (RM808U)
(2) Using hand-held tester:

BE052-07
I12791
A
- BODY ELECTRICALFOG LIGHT SYSTEM
BE-27
1631 Author
: Date
:
2001 AVALON (RM808U)
ADJUSTMENT
ADJUST FOG LIGHT AIM
A-bolt: Vertical Direction

BE0HZ-04
I12795
OFFON
54
1 2 3
15 166
7 8
9 10
11 17
14 13 12
I05027
1 2
3 55
2 13
BE-26
- BODY ELECTRICALFOG LIGHT SYSTEM
1630 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT FOG LIGHT SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
ON10 - 11Continuity
If continuity is not as specified, replace the switch.
2. INSPECT FOG LIGHT RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant1 - 2Continuity
Apply B+ between
terminals 1 and 2.3 - 5No continuity
If continuity is not as specified, replace the relay.

BE050-07
I12525
Fog Light
Combination Switch

Fog Light Switch
Driver Side Junction Block

Fog Light Relay

FOG Fuse
- BODY ELECTRICALFOG LIGHT SYSTEM
BE-25
1629 Author
: Date
:
2001 AVALON (RM808U)
FOG LIGHT SYSTEM
LOCATION

BE0G5-04
I12836
I12837
I12838
BE-170
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
1774 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT GARAGE DOOR OPENER SWITCH
Press the switch and check that each LED (red) lights up.
Even if only one switch is found not to light up, replace it.
2. INSPECT GARAGE DOOR OPENER REGISTRATION
AND TRANSMITTING
HINT:
Use the home link tester made by KENT MORE for this test.
As it is necessary to record the code of the hand held transmit-
ter, customer's code will be erased. When the inspection com-
pletes, please register the customer's again.
(a) Check that the code of hand held transmitter for inspec-
tion can be recorded.
(See page
If the code can not be registered, replace garage door opener.
(b) Press the switch which an inspection code has been reg-
istered for and check that LED (green) of the home link
tester lights up.
If the LED (green) does not light up, replace the garage door
opener.

I04194
Wire Harness Side
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
BE-171
1775 Author
: Date
:
2001 AVALON (RM808U)
3. INSPECT GARAGE DOOR OPENER SWITCH CIRCUIT
Disconnect the connector from the switch and inspect the con-
nector on the wire harness side, as shown.
Tester connectionConditionSpecified condition
1 - GroundConstantContinuity
2 - GroundConstantBattery positive voltage
If the circuit is not as specified, inspect the power source or wire
harness.

BE0D3-03
I12840
Garage Door Opener
Enjine Room Junction Block

ECU-B Fuse
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
BE-169
1773 Author
: Date
:
2001 AVALON (RM808U)
LOCATION

BE0D2-03
I12837
BE-166
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
1770 Author
: Date
:
2001 AVALON (RM808U)
GARAGE DOOR OPENER SYSTEM
REGISTRATION PROCEDURE
1. NEW CODE REGISTRATION
NOTICE:

If pressing the switch of the original transmitter to
register the code, the system might operate.

When registering the transmitter codes such as for
garage or gate, check that there is nobody around
those places then register.
(a) Press the switch for the item to be registered for 20 se-
conds
HINT:
When transferring to registration mode, LED (red) blinks in 1 Hz
cycle.
(b) In the condition of (a), bring the original transmitter to with-
in 1-inch area around the garage door opener and press
the switch. (code transmitting).
HINT:
When code registration completes correctly, LED (red) blinks in
5.6 Hz cycle.
