TOYOTA AVALON 2008 XX30 / 3.G Navigation Manual

MORE ADVANCED FUNCTIONS
125
INFORMATION
Before changing to the “Memo list”
screen, there is a case where “List
searching” screen and “Period”
screen will be displayed.
Select your desired search condition to
list the memo. The “Memo list” is dis-
played on the screen.
In case of selecting the “Period”switch, you can display the memo list
as long as you desired. Select number
keys to input your desired search peri-
od.
After inputting a search period of time,
select the
“OK” switch. The “Memo
list” screen will be displayed.
You can input a search period from Janu-
ary 1. 2000 through December 31. 2020.
If you want to delete and/or edit the
memo, select the
switch of the
memo.
If you want to delete all of the memo, se-
lect the
“Del. all” switch. A message
appears on the display.
To delete, select the
“Yes” switch. If
not, select the “No” switch.
If you want to remove all of the colors of
date you inputted, select the
“Re-
move color” switch on the “Memo
list” screen. A message appears on the
display.
To remove, select the
“Yes” switch. If
not, select the “No” switch.

MORE ADVANCED FUNCTIONS
126
To edit: Select the “Edit” switch. (See
page 124 for details.)
To delete: Select the
“Delete” switch.
(See page 123 for details.)

SECTION 4
OTHER FUNCTIONS
127
OTHER FUNCTIONS
Other functions
Clock adjustment 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trip information 129. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen adjustment 131. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speech command system 132. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OTHER FUNCTIONS
128
The clock can be corrected manually or
by using signals from the GPS. Daylight
Saving Time setting or your desired
time setting is available.
1. Push the “INFO” button on the
navigation controller.
2. Select the “Adjust Clock”
switch.
“Auto Adjust”: Before you use the auto
adjust function, select the time zone (see
“Time Zone” described below). When you
select the
“ON” switch, the time is auto-
matically adjusted by the GPS clock.
When you select the
“OFF” switch, you
can adjust the clock manually with “H”,
“M” and “:00” switches.
“H”: To set the hour with “Auto Adjust
OFF”, select this switch.
“M”: To set the minute with “Auto Adjust
OFF”, select this switch.
“:00”: To adjust the time to the nearest
hour, select this switch.
“Daylight Saving Time”: Daylight saving
time can be set or canceled.
“Time Zone”: You can select the time
zone. When you select this switch, the dis-
play will be change to the time zone selec-
tion screen. The initial setting is “Eastern
Standard Time”.
Clock adjustment

OTHER FUNCTIONS
129
For vehicle sold in U.S.A.
For vehicle sold in Canada
Select the switch of your desired area. The
time zone for the area is set and the pre-
vious screen returns.Trip information such as driving dis-
tance, average vehicle speed, fuel con-
sumption, etc. can be displayed on the
screen.
1. Push the “INFO” button on the
navigation controller.
2. Select the “Trip Information”switch.
Trip information

OTHER FUNCTIONS
130
“Consumption”
The instantaneous fuel consumption is
calculated and displayed based on dis-
tance and fuel consumption for 1 second
with the engine running.
The displayed value is updated every 1
second.
Note that an accurate figure may not be
shown in the following cases.
When the vehicle is stopped with the en-
gine running, the display will indicate
the extremely high fuel consumption.
When the vehicle is driving down a long
slope, applying the engine brake, the
display will indicate the extremely
low fuel consumption.
The calculation is reset when the engine
switch is turned off.
“After Refueling”
The average fuel consumption is calcu-
lated and displayed based on total driving
distance and total fuel consumption with
the engine running.
The displayed value is updated every 10
seconds.
Every time you refuel the vehicle, the cal-
culation is reset. When refueling, be sure
to stop your vehicle and turn the engine
switch off.“Cruising Range”
The distance the vehicle can travel with the
remaining fuel is calculated and displayed
based on the quantity of remaining fuel
and past fuel consumption.
The driving range display indicates the
approximate distance that you can drive
until the fuel gauge reaches “E”. It is differ-
ent from the actual distance traveled.
The displayed value is updated every time
the fuel equivalent for 1 mile or 1 km is con-
sumed.
Every time you refuel the vehicle, the cal-
culation is reset. When refueling, be sure
to stop your vehicle and turn the engine
switch off.
The actual driving range varies with driving
habits and road conditions. If fuel con-
sumption is good, the driving range will be
longer. If fuel consumption is poor, the driv-
ing range will be shorter.
If the low fuel level warning light comes on,
refuel even if the display indicates that the
vehicle can be driven further.
“Average Speed”
The average speed is calculated and dis-
played based on the total driving distance
and the total driving time with the engine
running.
The displayed value is updated every 10
seconds.
To reset the calculation, push the
“EN-
TER”
button.
“Distance”
The trip distance is displayed.
To reset the calculation, push the
“EN-
TER” button. The average speed is also
reset.

OTHER FUNCTIONS
131
You can adjust the brightness or con-
trast of the screen depending on the
brightness of your surroundings. You
also can turn the display off.
Push the “DISP” button on the naviga-
tion controller.
INFORMATION
The display may be tinged in purple
due to the reflection of sunlight, but
this is not a malfunction.
Contrast and brightness adjustment
“Contrast” “+”: Strengthens the contrast
of the screen.
“Contrast” “”: Weakens the contrast of
the screen.
“Brightness” “+”: Brightens the screen.
“Brightness” “”: Darkens the screen.
The screen turns off when you select the
“SCREEN OFF”. To turn the display
screen back on, push any buttons on the
navigation controller such as “MAP/
VOICE”, etc. The selected screen ap-
pears.
Screen adjustment

OTHER FUNCTIONS
132
When the headlight switch is at “ON”
position, the screen changes to the day
mode or night mode.
To display the screen in the day mode even
with the head light switch on, select
“DAY
MODE” switch on the adjustment screen
for brightness and contrast control.
If the screen is set in the day mode with the
headlight switch turned to on, this condi-
tion is memorized in the system even with
the engine turned off.The speech command system allows
you to operate the navigation system
with your voice.1. Push the talk switch.
A beep sounds and an indicator is shown
on the screen.
Speech command system

OTHER FUNCTIONS
133
2. Give a command while an indicator
is shown on the screen.
If the navigation system does not respond
or the confirmation screen does not disap-
pear, please push the talk switch and try
again.
If no command is given, a beep sounds
and the indicator disappears 6 seconds
later.
If the system does not recognize your
speech, the system will respond with this
message (“System does not recognize
this command, please rephrase your com-
mand.”). Start the operation from the be-
ginning.
See page 136 for the command list.
Microphone
It is unnecessary to speak directly into
the microphone when giving a com-
mand.
Speech command example: Searching
for a route to your home.
1. Push the talk switch.
2. Say “Go home”.
If your home is not registered, you will hear
“Home is not registered”.

OTHER FUNCTIONS
134
3. If you hear “Are you sure that you
want a route to home?” (also shown on
the screen), push the talk switch and
say “Yes”.
If you say “No”, the search will be can-
celed.
4. You will hear “Calculating route to
home” and then the system starts
searching for a route.
INFORMATION
In the following conditions, the sys-
tem may not recognize the command
properly.
The command is not correct or
clear.
There are some noises such as
wind noise, etc.
