TOYOTA AVALON 2008 XX30 / 3.G Navigation Manual

ADVANCED FUNCTIONS
95
The current vehicle position mark will
be automatically corrected while driv-
ing on reception of GPS signals. If your
vehicle cannot receive GPS signals,
you can correct the current position
mark manually.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch.
3. Select the “Calib.” switch on the
right side of the screen.
The next screen appears.
4. Select the “Position/Direction”switch.
INFORMATION
For additional information on current
position accuracy, see “Limitations
of the navigation system” on page 58.
Current position calibration

ADVANCED FUNCTIONS
96
POSITION/DIRECTION CALIBRATION
1. Move the cursor mark to your de-
sired point by operating the select and
scroll lever of the navigation controller.
Push the
“ENTER” button on the navi-
gation controller.
2. Operate the select and scroll lever
of the navigation controller, so that the
screen direction is facing to your de-
sired direction.
Push the
“ENTER” button on the navi-
gation controller, and then the map screen
will be displayed.TIRE CHANGE CALIBRATION
The tire change calibration function
should be used when the tires are re-
placed. This will adjust for any possible
change in tire circumference from the
old tires to the new ones. If this proce-
dure is not performed when tires are re-
placed, the current vehicle position
mark may become incorrect.
To execute the fast distance tire calibration
procedure, select the
“Tire change”switch on the “Calibration” screen.
The message appears and the fast dis-
tance calibration is automatically started.
A few seconds later, the map screen will be
displayed.

ADVANCED FUNCTIONS
97
1. Push the “MENU” button on the
navigation controller.
2. Select the “Edit route” switch on
the screen.(a) Adding a destination
1. Select the “Add” switch of “Des-
tination”.
2. Input an additional destination in
the same way as the destination input.
(See page 39.)
3. The “Add destination” screen ap-
pears. Select the “Add” switch on the
right side of the screen that you want to
add as destination.
Edit route

ADVANCED FUNCTIONS
98
(b) Reordering a destination
1. Select the “Reorder” switch of
“Destination”.
2. Choose the destinations in the or-
der of arrival by selecting the
switch
on the left side of the screen.
After you finished selecting the destina-
tions, select the
“OK” switch.
The previous screen will be displayed.(c) Deleting a destination
1. Select the “Delete” switch of
“Destination”.
2. Select the switch of the destina-
tion that you want to delete.
Select the
“Del. all” switch if you want
to delete all destinations.
3. Messages appear depending on the
type of deletion. If you want to delete,
select the
“Yes” switch. To cancel the
deletion, select the “No” switch.
To delete a previous destination:
1. Push the
“MENU” button to dis-
play the “Menu” screen and select the
“Marked points” switch on the
screen.
2. Select the
“Del. prev. dest.”switch.
3. Do the same procedure as deleting
a destination.

ADVANCED FUNCTIONS
99
1. Push the “MENU” button on the
navigation controller.
2. Select the “Edit route” switch on
the screen.(a) Adding a preferred road
1. Select the “Add” switch of the “Set
preferred road” and then the following
screen appears.
2. Move the cursor to your desired
location and push “ENTER” button
on the navigation controller.
Messages appear to confirm your request
on the screen.
Select the
“Enter” switch to register the
road.
Select the
“Next” switch if you want to
change the road.
3. The “Add preferred road” screen
appears. Select the “Add” switch if
you want to add as preferred road.
Setting a preferred road

ADVANCED FUNCTIONS
100
(b) Modifying a preferred road
1. Select the “Modify” switch of the
“Set preferred road”. The “Modify pre-
ferred road” screen appears.
2. Select the preferred road which you
want to modify and select the
switch.
3. Do the same procedure as “(a) Add-
ing a preferred road”. (See page 99.)(c) Deleting a preferred road
1. Select the “Delete” switch of the
“Set preferred road”. The “Delete pre-
ferred road” screen appears.
2. Select the preferred road which you
want to delete.
Select the
“Del. all” switch if you want
to delete all the preferred roads.
3. Messages appear depending on the
type of deletion. If you want to delete,
select the
“Yes” switch. To cancel the
deletion, select the “No” switch.

ADVANCED FUNCTIONS
101
1. Push the “MENU” button on the
navigation controller.
2. Select the “Edit route” switch on
the screen.
3. Select the “Search condition”switch of “Condition”. The “Search
condition” screen appears.
“Quick”: A route on which you can reach
the destination in the shortest time.
“Short”: A route on which you can reach
the destination in the shortest distance.
4. Select the
“Quick” or “Short”switch and select the “OK” switch.
Search condition

ADVANCED FUNCTIONS
102
You can see the entire route from the
starting point to the destination.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Route overview”switch on the screen. The route over-
view screen appears.
The entire route from the starting point to
the destination is displayed.You can preview the route from the
starting point to the destination.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Route preview”switch on the screen. The route preview
screen appears.
Route overviewRoute preview

ADVANCED FUNCTIONS
103
To display the next destination
To preview the route to the
next destination
To preview the route to the
next destination fast
To stop previewing
To preview the route to the
previous departure position
To preview the route to the
previous departure position
To display the previous de-
parture position
3. Select the “Edit” switch. The “Edit
route preview” screen appears.
“To next POI”: To preview the next POI
“To next
”: To preview the next destina-
tion
If the points of interest you selected are on
the route, they are displayed on the
screen.
“Select POI”: To select the POI icon
“Delete”: To delete the POI icon
4. Select your desired category of
point of interest.
5. Select your desired icon from the
list and select the “OK” switch.

ADVANCED FUNCTIONS
104
