TOYOTA AVALON 2014 XX40 / 4.G Owners Manual

3716-3. Do-it-yourself maintenance
6
Maintenance and care
AVALON (U)_(OM41452U)■
Rear turn signal light
Open the trunk lid and
remove the luggage trim
cover clip.
Pull the hook while depress-
ing the button.
Partly remove the luggage
trim cover.
1
2
3

3726-3. Do-it-yourself maintenance
AVALON (U)_(OM41452U)
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reverse the steps listed.4
5
6

3736-3. Do-it-yourself maintenance
6
Maintenance and care
AVALON (U)_(OM41452U)■
Back-up light
Open the trunk lid and
remove the clips. Then partly
remove the trunk panel
cover.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
3
4

3746-3. Do-it-yourself maintenance
AVALON (U)_(OM41452U)■
License plate light
Remove the cover.
To prevent damaging the vehi-
cle, wrap the flathead screw-
driver with a tape.
Remove the lens.
Insert a properly sized screw-
driver into the hole of the lens,
and pry off the lens as shown in
the illustration.
To prevent damaging the vehi-
cle, wrap the screwdriver with a
tape.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
3
4

3756-3. Do-it-yourself maintenance
6
Maintenance and care
AVALON (U)_(OM41452U)■
Replacing the following bulbs
If any of the lights listed below
has burnt out, have it replaced by
your Toyota dealer.
● Headlight low beams (discharge bulb)
● Daytime running lights (vehic les with discharge headlights)
● Side marker lights
● Side turn signal lights
● Stop/tail lights
● High mounted stoplight
● Outer foot lights (if equipped)

3766-3. Do-it-yourself maintenance
AVALON (U)_(OM41452U)
■Discharge headlights (if equipped)
If voltage to the discharge bulbs is insufficient, the bulbs may not come on, or
may go out temporarily. The discharge bulbs will come on when normal
power is restored.
■ LED light bulbs
The daytime running lights (vehicles with discharge headlights), stop/tail
lights, high mounted stoplight and outer foot lights each consist of a number
of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer
to have the light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the lens does not indicate a
malfunction. Contact your Toyota dealer for more information in the following
situations:
●Large drops of water have built up on the inside of the lens.
● Water has built up inside the lens.
■ Removing and installing the clips
The fender liner, luggage trim cover and trunk panel cover clip
■ When replacing light bulbs
P. 360Removing
Installing
1
2

3776-3. Do-it-yourself maintenance
6
Maintenance and care
AVALON (U)_(OM41452U)
CAUTION
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immediately after
turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
●Vehicles with discharge headlights:
While the low beam headlights are
turned on, and for a short time after
they have been turned off, metal com-
ponents at the rear of the headlight
assembly will be extremely hot. To pre-
vent burns, do not touch these metal
components until you are certain they
have cooled down.
Metal components

3786-3. Do-it-yourself maintenance
AVALON (U)_(OM41452U)
CAUTION
■Discharge headlights (if equipped)
● Contact your Toyota dealer before replacing the discharge headlights
(including light bulbs).
● Do not touch the discharge headlight’s high voltage socket when the head-
lights are turned on.
An extremely high voltage of 30000 V will be discharged and could result
in death or serious injury by electric shock.
● Do not attempt to take apart or repair the headlight bulbs, connectors,
power supply circuits, or related components.
Doing so could result in electric shock and death or serious injury.
■ To prevent damage or fire
● Make sure bulbs are fully seated and locked.
● Check the wattage of the bulb before installing to prevent heat damage.

379
When trouble arises7
AVALON (U)_(OM41452U)7-1. Essential information
Emergency flashers .......... 380
If your vehicle has to be stopped in an
emergency ...................... 381
7-2. Steps to take in an emergency
If your vehicle needs to be towed ......................... 382
If you think something is wrong .......................... 385
Fuel pump shut off system ............................ 386
If a warning light turns on or a warning buzzer
sounds ............................ 387
If a warning message is displayed ..................... 398
If you have a flat tire.......... 399
If the engine will not start ................................. 412
If the shift lever cannot be shifted from P............. 414
If the electronic key does not operate properly........ 415
If the vehicle battery is discharged ...................... 418
If your vehicle overheats ........................ 422
If the vehicle becomes stuck ............................... 425

380
AVALON (U)_(OM41452U)
7-1. Essential information
Press the switch.
All the turn signals will flash.
To turn them off, press the switch
once again.
■Emergency flashers
If the emergency flashers are used for a long time while the engine is not
operating, the battery may discharge.
Emergency flashers
The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in th e road due to a breakdown, etc.
