TOYOTA AVALON 2021 Accessories, Audio & Navigation (in English)

1113-4. Setup
3
Navigation system
AVALON_AVALON HV_Navi_(U)
Points on the map can be regis-
tered.
1Display the navigation set-
tings screen. ( P.109)
2 Select “Favorites”.
3 Select the desired item.
Select to edit the favorites
list.
“Add New”: Select to register
favorites list entries. ( P. 1 1 1 )
“Sort”: Select to sort (date,
name, icon) favorite list
entries.
“Delete All”: Select to delete
all favorite list entries. 1
Select “Add New/Sort/Delete
All”.
2 Select “Add New”.
3 Select the desired item to
search for the location.
( P.86)
4 Select “OK” when the editing
favorites list screen appears.
( P. 1 1 1 )
●Up to 100 favorites list entries can
be registered.
The icon, name, location and/or
phone number of a registered
favorites list entry can be edited.
1Select the desired favorites
list entry.
 Each time a star icon is
selected, its color will change.
Colored star icons indicate
that the favorite is registered
to the corresponding preset
destination button. Up to 2
entries can be registered as
quick favorite destinations.
( P.94)
Setting up favorites list
A
5HJLVWHULQJIDYRULWHVOLVW
HQWULHV
(GLWLQJIDYRULWHVOLVW
HQWULHV

1123-4. Setup
AVALON_AVALON HV_Navi_(U)
2Select the desired item to be
edited.
Select to edit the favorites list
entry name.
Select to edit location infor-
mation.
Select to edit the phone num-
ber.
Select to change the icon to
be displayed on the map
screen. ( P.112)
Select to set display of the
favorites list entry name
on/off.
Select to delete the favorites
list entry.
3 Select “OK”. 1
Select “Icon”.
2 Select the desired icon.
■Icons with sound
A sound for some favorites list
entries can be set. When the
vehicle approaches the location
of the favorites list entry, the
selected sound will be heard.
: Select to play the sound.
●When “Bell (with Direction)” is
selected, select an arrow to adjust
the direction and select “OK”.
●The bell sounds only when the
vehicle approaches this point in
the direction that has been set.
A
B
C
D
E
F
Changing the icon

1133-4. Setup
3
Navigation system
AVALON_AVALON HV_Navi_(U)
Areas to be avoided because of
traffic jams, construction work or
other reasons can be registered
as “Areas to Avoid”.
1Display the navigation set-
tings screen. ( P.109)
2 Select “Areas to Avoid”.
3 Select the desired item.
Select to edit the list of areas
to avoid.
“Add New”: Select to register
areas to avoid. ( P.113)
“Delete All”: Select to delete
all areas to avoid. 1
Select “Add New/Delete All”.
2 Select “Add New”.
3 Select “Recent Destinations”
( P.89) or “Current Location”
to search for the location.
4 Select either “+” or “-” to
change the size of the area to
be avoided and select “OK”.
5 Select “OK” when the area to
avoid screen appears.
●If a destination is entered in the
area to avoid or the route calcula-
tion cannot be made without run-
ning through the area to avoid, a
route passing through the area to
be avoided may be shown.
●Up to 10 locations can be regis-
tered as points/areas to avoid.
Setting up areas to avoid
A
5HJLVWHULQJDUHDVWRDYRLG

1143-4. Setup
AVALON_AVALON HV_Navi_(U)
The name, location and/or area
size of a registered area can be
edited.
1Select the desired area.
2 Select the desired item to be
edited.
Select to edit the name of the
area to avoid.
Select to edit area location.
Select to edit area size.
Select to set the area to
avoid function on/off.
Select to set display of the
area to avoid name on/off.
Select to delete the area to
avoid.
3 Select “OK”. 1
Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Detailed Navi. Set-
tings”.
5 Select the desired items to
be set.
Editing areas to avoid
A
B
C
D
E
F
Detailed navigation
settings
Settings are available for
pop-up information, favor-
ite POI categories, low fuel
warning, etc.
Displaying the detailed
navigation settings
screen

1153-4. Setup
3
Navigation system
AVALON_AVALON HV_Navi_(U)
“Low Fuel Warning Pop-up”
Select to set display of low fuel
warning on/off. ( P.116)
 “Unverified Roads Guidance
Warning”
Select to set unverified roads guid-
ance warning on/off.
“Guidance on Unverified
Roads”
Select to set IPD road (roads that
are not completely digitized in our
database) guidance on/off.
“Guidance with Street Names”
Select to set the voice guidance for
the next street name on/off.
“Favorite POI Categories”
Select to set favorite POI catego-
ries that are used for POI selection
to display on the map screen.
(  P. 1 1 6 )
 “Calibration”
Select to adjust the current position
mark manually or to adjust miscal-
culation of the di stance caused by
tire replacement. ( P.117)
 “Adaptive Route”
Select to enable/d isable adaptive
routes. When enabled, the naviga-
tion system will provide frequently
used routes.
 “Reset Adaptive Route”
Select to erase adaptive route data.
“Automatic Destination List
Info”
Select to set automatic destination
list information on/off. When set to
on, the estimated time of arrival to
the registered ho me and preset
destinations from the current posi-
tion will be displayed.
 “Intersection Zoom Map”
Select to set display of a guidance
screen on/off.
“Automatic Zoom”
Select to set automatic zoom func-
tion on/off. When it is enabled, as
the vehicle approaches a guidance
point, the map will change to a
detailed map automatically.
 “Automatic Freeway Exit List”
Select to set disp lay of a freeway
information screen on/off. ( P.101)
 “State Border Guidance”
Select to set cross-border guidance
on/off.
“Map Color Customization”
Select to set the map display color.
“Map Animation”
Select to set map animation on/off.
“Weather Incident Warnings”
Select to set weather incident warn-
ings on/off. ( P.180)
 “Dynamic Route”*
Select to enable/disable routes
sourced from the Cloud. ( P. 9 9 )
 “Restore the default settings”
Select to reset all setup items.
*: This function is not available in
some countries or areas.
Detailed navigation set-
tings screen

1163-4. Setup
AVALON_AVALON HV_Navi_(U)
When the fuel level is low, a
warning message will pop up on
the screen.
1Display the detailed naviga-
tion settings screen.
( P.114)
2 Select “Low Fuel Warning
Pop-up”.
3 Select “On” or “Off”.
A nearby gas station can be
selected as a destination when
the fuel level is low.
1 Select “Yes” when the low
fuel warning appears.
2 Select the desired nearby
gas station.
3 Select “Enter” to set as a
destination.
“Info”: Select to display gas station
information. ( P. 8 2 )
Up to 6 POI icons, which are
used for selecting POIs on the
map screen, can be selected as
favorites.
1 Display the detailed naviga-
tion settings screen.
( P. 1 1 4 )
2 Select “Favorite POI Catego-
ries”.
3 Select the desired category
to be changed.
“Default”: Select to set the default
categories.
4 Select the desired POI cate-
gory.
“List All Categories”: Select to dis-
play all POI categories.
5Select the desired POI icon.
6 Select “OK”.
Low fuel warning
Searching gas station in low
fuel warning
Favorite POI categories
(Select POI icons)

1173-4. Setup
3
Navigation system
AVALON_AVALON HV_Navi_(U)
The current position mark can
be adjusted manually. Miscalcu-
lation of the distance caused by
tire replacement can also be
adjusted.
1Display the detailed naviga-
tion settings screen.
( P.114)
2 Select “Calibration”.
3 Select the desired item.
 For additional information on
the accuracy of a current
position:  P.123
When driving, the current posi-
tion mark will be automatically
corrected by GPS signals. If
GPS reception is poor due to
location, the current position
mark can be adjusted manually.
1 Select “Position/Direction”.
2 Scroll the map to the desired
point ( P.78) and select
“OK”.
3 Select an arrow to adjust the
direction of the current posi-
tion mark and select “OK”. The tire change calibration func-
tion will be used when replacing
the tires. This function will adjust
miscalculation caused by the
circumference difference
between the old and new tires.
1
Select “Select after a Tire
Change”.
 The message appears and
the quick distance calibration
starts automatically.
●If this procedure is not performed
when the tires are replaced, the
current position mark may be
incorrectly displayed.
Current position/Tire
change calibration
Position/Direction calibra-
tionTire change calibration

1183-4. Setup
AVALON_AVALON HV_Navi_(U)
*: This function is not available in some countries or areas.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Traffic”.
4 Select the desired items to
be set. Select to set specific routes
(such as frequently used
routes) on which you wish to
receive traffic information.
(
P. 1 1 9 )
Select to set the avoid traffic
function auto/manual.
( P.121)
Select to set the usage of
traffic information for the esti-
mated arrival time on/off.
Select to set the display of an
arrow of free flowing traffic
on/off.
Select to set to on/off
whether to consider the pre-
dictive traffic information
( P.84) with estimated
arrival time and detoured
route search.
Select to set traffic incident
Traffic settings*
Traffic information such as
traffic congestion or traffic
incident warnings can be
made available.
Displaying the traffic set-
tings screen
Screen for traffic settings
A
B
C
D
E
F

1193-4. Setup
3
Navigation system
AVALON_AVALON HV_Navi_(U)
voice warning on/off.
Select to reset all setup
items.
Specific routes (such as fre-
quently used routes) on which
you wish to receive traffic infor-
mation can be registered as “My
Traffic Routes”. A route is set by
defining a start point and end
point, and can be adjusted by
setting up to 2 preferred roads.
1 Display the traffic settings
screen. ( P.118)
2 Select “My Traffic Routes”.
3 Select the desired item.
Select to register personal
traffic routes. ( P.119)
Select to edit personal traffic
routes. ( P.120)
Select to delete personal traf-
fic routes. ( P.120) 1
Select “New”.
2 Select “Name”.
3 Enter the name and select
“OK”.
4 Select “Start”.
5 Select the desired item to
search for the location.
( P.86)
6 Select “End”.
7 Select the desired item to
search for the location.
( P.86)
8 Select “OK”.
9 Confirm the route overview
displayed.
Select the desired route from
3 possible routes. ( P.97)
Select to modify the route.
The routes can be adjusted
by setting preferred roads.
( P.120)
10Select “OK”.
●Up to 5 routes can be registered.
My traffic routes
G
A
B
C
5HJLVWHULQJSHUVRQDOWUDIILF
URXWHV
A
B

1203-4. Setup
AVALON_AVALON HV_Navi_(U)
1Select “Edit”.
2 Select the desired traffic
route.
3 Select the desired item to be
edited.
Select to edit the name of the
personal traffic route.
( P.119)
Select to edit start location.
( P.119)
Select to edit end location.
( P.119)
Select to see and modify the
entire route. ( P.120)
4 Select “OK”.
5 Follow the steps in “Register-
ing personal traffic routes”
from step 9. (P.119) 1
Select “Delete”.
2 Select the desired traffic
route to be deleted and
select “Delete”.
3 Select “Yes” when the confir-
mation screen appears.
“My Traffic Routes” can be
adjusted by setting up to 2 pre-
ferred roads.
1 Select “Set Preferred
Roads”.
2 Select the desired item.
Select to add preferred
roads. ( P.121)
Select to modify preferred
roads. ( P.121)
Select to delete preferred
Editing personal traffic
routes
A
B
C
D
'HOHWLQJSHUVRQDOWUDIILF
URXWHV
6HWWLQJSUHIHUUHGUR\
DGV
A
B
C
