TOYOTA AVENSIS 2005 Service Repair Manual

1509W−02
A85748
30 (302, 22)43 (440, 32)zGasketzGasket
Floor Panel Brace Front Exhaust Pipe Assy Front
Compression Spring
N·m (kgf·cm, ft·lbf)
: Specified torque
zNon−reusable part
43 (440, 32)
Compression Spring
Exhaust Pipe Assy Tail
Air−fuel Ratio Sensor
43 (440, 32)
44 (449, 33)
− EXHAUSTEXHAUST PIPE ASSY (1CD−FTV)(From September,
2003)15−5
AVENSIS Supplement (RM1045E)
EXHAUST PIPE ASSY (1CD−FTV)(From September, 2003)
COMPONENTS

141NN−01
A61184
A85928
−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)14 −177
AVENSIS Supplement (RM1045E)
CRANKSHAFT SEAL (1CD −FTV)(From September, 2003)
REPLACEMENT
1. DRAIN ENGINE OIL
(a) Install a new gasket and the drain plug after draining engine oil.
Torque: 34 N
m (350 kgf
cm, 25 ft
lbf)
2. REMOVE FRONT WHEEL RH
3. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
4. REMOVE ENGINE UNDER COVER RH
5. REMOVE RADIATOR SUPPORT OPENING COVER
6. REMOVE ENGINE ROOM COVER SIDE
7. REMOVE ENGINE COVER NO.1 (See page 14 −90)
8. REMOVE INJECTOR DRIVER (See page 14 −108)
9. REMOVE V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See Pub. No. RM1018E on page 14 −269)
10. REMOVE GENERATOR V BELT (See Pub. No. RM1018E on page 14 −269)
11. SEPARATE POWER STEERING IDLE PULLEY BRACKET (See page 14 −138)
12. DISCONNECT ENGINE WIRE (See page 14 −138)
13. DISCONNECT VACUUM HOSE (See page 14 −108)
14. REM O VE ENG I NE M O UNTI NG I NSULATO R SUB−ASSY RH
(a) Place a wooden block on a jack underneath the engine.
(b) Remove the 3 bolts and 3 nuts, then detach the engine mounting insulator sub −assembly.
15. REMOVE CRANKSHAFT PULLEY (See page 14 −138)
SST 09213 −54015 (09213 −70020), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05031)
16. REMOVE IDLER PULLEY SUB −ASSY (See page 14 −138)
17. REMOVE TIMING BELT NO.2 COVER (See page 14 −138)
18. REMOVE TIMING BELT NO.1 COVER (See page 14 −138)
19. REMOVE TIMING BELT GUIDE
20. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)

SST
A09582
B07973
Cut PositionPry
SST
A08528
SST
A09583
Angle
SensorInward
14
−178−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
21. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −138)
22. REMOVE TIMING CHAIN COVER PLATE (See page 14 −138)
23. REMOVE TIMING BELT (See page 14 −138)
24. REMOVE CRANKSHAFT TIMING PULLEY
(a) If the timing pulley cannot be removed by hand, use SST to remove the pulley.
SST 09950 − 50013 ( 09951 − 05010, 09952 − 05010,
09953 −05010, 09953 −05020, 09954 −05021)
25. REMOVE CRANKSHAFT SEAL
(a) Using a knife, cut off the oil seal lip.
(b) Using a screwdriver, pry out the oil seal.
NOTICE:
Be careful not to damage the crankshaft. Wrap the tip of the
screwdriver with tape.
26. INSTALL CRANKSHAFT SEAL
(a) Apply multipurpose grease to a new oil seal lip.
NOTICE:
Keep the lip free of foreign objects.
(b) Using SST and a hammer, tap in the oil seal until its sur- face is flush with the oil pump edge.
SST 09316 −60011 (09316 −00011)
27. INSTALL CRANKSHAFT TIMING PULLEY
(a) Align the keyway of the timing pulley with the key located on the crankshaft, then slide the pulley into place.
(b) Using SST and a hammer, tap in the timing pulley with the
angle sensor facing inward.
SST 09223 −46011
28. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −138)
SST 09960 −10010 (09962 −01000, 09963 −01000)
29. INSTALL TIMING BELT (See page 14 −138)
30. CHECK VALVE TIMING (See page 14 −138)

−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)14 −179
AVENSIS Supplement (RM1045E)
31. INSTALL TIMING CHAIN COVER PLATE (See page 14 −138)
32. INSTALL TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)
33. INSTALL TIMING BELT GUIDE (See page 14 −138)
34. INSTALL TIMING BELT NO.1 COVER (See page 14 −138)
35. INSTALL TIMING BELT NO.2 COVER (See page 14 −138)
36. INSTALL IDLER PULLEY SUB −ASSY (See page 14 −138)
37. INSTALL CRANKSHAFT PULLEY (See page 14 −138 )
SST 09213 −54015 (09213 −70020), 09330 −00021
38. INSTALL ENGINE MOUNTING INSULATOR SUB −ASSY RH (See page 14 −138)
39. INSTALL POWER STEERING IDLE PULLEY BRACKET (See page 14 −108)
40. ADJUST V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1 (See Pub. No. RM1018E on page 14 −269)
41. INSTALL INJECTOR DRIVER (See page 14 −108)
42. INSTALL ENGINE COVER NO.1 (See page 14 −90)
43. INSTALL FRONT WHEEL RH
Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)
44. ADD ENGINE OIL
45. CHECK FOR ENGINE OIL LEAKS

551AN−01
I35326
I35327
I35328
55 −4
−
HEATER & AIR CONDITIONER W/PULLEY COMPRESSOR ASSY (2AZ −FSE)
AVENSIS Supplement (RM1045E)
REPLACEMENT
1 . DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM
(See Pub. No. RM 1018E, page 55 −38)
SST 07110 −58060 ( 07117 −58080, 07117 −58090, 07117 −78050, 07117 −88060, 07117 −88070,
07117 −88080)
2. DI SCO NNECT CO O L ER REFRI G ERANT SUCTI O NHOSE NO. 1
(a) Remove the bolt and disconnect the cooler refrigerant
suction hose No.1 from the w/pulley compressor assy.
(b) Remove the O −ring from the cooler refrigerant suction
hose No.1.
NOTICE:
Seal the opening of the disconnected parts using vinyl tape
to prevent moisture and foreign matters from entering.
3. DISCONNECT COOLER REFRIGERANT DISCHARGE HOSE NO. 1
(a) Remove the bolt and disconnect the cooler refrigerant discharge hose No.1 from the w/pulley compressor assy.
(b) Remove the O −ring from the cooler refrigerant discharge
hose No.1.
NOTICE:
Seal the opening of the disconnected parts using vinyl tape
to prevent moisture and foreign matters from entering.
4. REMOVE RADIATOR SUPPORT OPENING COVER (See page 14− 5)
5. REMOVE ENGINE ROOM COVER SIDE (See page 14− 5)
6. REMOVE ENGINE UNDER COVER RH (See page 14− 5)
7. REMOVE FAN AND GENERATOR V BELT (See page 14− 5)
SST 09249 −63010
8. REMOVE W/PULLEY COMPRESSOR ASSY
(a) Disconnect the connector.
(b) Remove the 4 bolts and the w/pulley compressor assy.

I35328
(1)(2)
(3)
(4)
−
HEATER & AIR CONDITIONER W/PULLEY COMPRESSOR ASSY (2AZ −FSE)
55 −5
AVENSIS Supplement (RM1045E)
9. INSPECT COMPRESSOR OIL
(a) When replacing the w/pulley compressor assy with a new one, after gradually removing the refrigerant
gas from the service valve, drain the following amount of oil from the new w/pulley compressor assy
before installation.
Standard:
(Oil capacity inside new w/pulley compressor assy: 90 + 15 cc (3.0 + 0.5 fl. oz.) ) − (Remaining
oil amount in the removed w/pulley compressor assy) = (Oil amount to be removed when replac-
ing)
NOTICE:
S When checking the compressor oil level, observe the precautions on the cooler removal/instal-
lation.
S Since compressor oil remains in the pipes of the vehicle, if a new w/pulley compressor assy
is installed without removing some oil inside, the oil amount becomes excessive, preventing
heat exchange in the refrigerant cycle and causing refrigerant failure.
S If the remaining oil in the removed w/pulley compressor assy is too small in volume, check for
oil leakage.
S Be sure to use ND −OIL 8 for compressor oil.
10. INSTALL W/PULLEY COMPRESSOR ASSY
(a) Install the w/pulley compressor assy with the 4 bolts.
Torque: 29 N
m (300 kgf
cm, 2 1 ft
lbf)
NOTICE:
Tighten the bolts in the order shown in the illustration to
install the w/pulley compressor assy.
(b) Connect the connector.
11 . INSTALL FAN AND GENERATOR V BELT (See page 14− 5)
SST 09249 −63010
12. INSTALL COOLER REFRIGERANT DISCHARGE
HOSE NO. 1
(a) Remove the attached vinyl tape from the hose.
(b) Sufficiently apply compressor oil to a new O −ring and the
fitting surface of the w/pulley compressor assy.
Compressor oil: ND −OIL 8 or equivalent
(c) Install the O −ring on the cooler refrigerant discharge hose
No.1.

I35327
I35326
55−6
− HEATER & AIR CONDITIONERW/PULLEY COMPRESSOR ASSY (2AZ−FSE)
AVENSIS Supplement (RM1045E)
(d) Install the cooler refrigerant discharge hose No.1 on the
w/pulley compressor assy with the bolt.
Torque: 9.8 N
m(100 kgf
cm, 87 in.
lbf)
13. INSTALL COOLER REFRIGERANT SUCTION HOSE
NO.1
(a) Remove the attached vinyl tape from the hose.
(b) Sufficiently apply compressor oil to a new O−ring and the
fitting surface of the w/pulley compressor assy.
Compressor oil: ND−OIL 8 or equivalent
(c) Install the O−ring on the cooler refrigerant suction hose
No.1.
(d) Install the cooler refrigerant suction hose No.1 on the w/
pulley compressor assy with the bolt.
Torque: 9.8 N
m(100 kgf
cm, 87 in.
lbf)
14. CHARGE REFRIGERANT (See Pub. No. RM1018E, page 55−38)
SST 07110−58060 (07117−58060, 07117−58070, 07117−58080, 07117−58090, 07117−78050,
07117−88060, 07117−88070, 07117−88080)
Specified amount: 440á30 g (15.51á1.06 oz.)
15. WARM UP ENGINE (See Pub. No. RM1018E, page 55−38)
16. INSPECT LEAKAGE OF REFRIGERANT (See Pub. No. RM1018E, page 55−38)

4018A−01
D31327
D31328
D31328
D31327
40 −26
−
AUTOMATIC TRANSMISSION / TRANS TRANSMISSION OIL COOLER (U151E)
AVENSIS Supplement (RM1045E)
TRANSMISSION OIL COOLER (U 151E)
REPLACEMENT
1. DRAIN AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
2. DRAIN COOLANT (SEE PAGE 16− 7)
3. REMOVE TRANSMISSION OIL COOLER
(a) Loosen the clips and disconnect the 4 hoses from the transmission oil cooler.
(b) Remove the 3 bolts and the oil cooler from the bracket.
4. INSTALL TRANSMISSION OIL COOLER
(a) Install the oil cooler to the bracket with the 3 bolts. Torque: 12N
m( 122 kgf
cm, 9 ft
lbf)
(b) Connect the 4 hoses with the clips to the transmission.

−
AUTOMATIC TRANSMISSION / TRANS TRANSMISSION OIL COOLER (U151E)
40−27
AVENSIS Supplement (RM1045E)
5. ADD COOLANT (SEE PAGE 16− 7)
6. ADD AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
7. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)

40189−01
D25831
SST
D25832
SST
D25833
SST
40 −24
−
AUTOMATIC TRANSMISSION / TRANS FRONT DIFFERENTIAL OIL SEAL (U151E)
AVENSIS Supplement (RM1045E)
FRONT DIFFERENTIAL OIL SEAL (U 151E)
REPLACEMENT
1. REMOVE FRONT WHEELS
2. REMOVE ENGINE UNDER COVER RH
3. REMOVE ENGINE UNDER COVER LH
4. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug. Torque: 47 N
m (480 kgf
cm, 35 ft
lbf)
5. REMOVE FRONT DRIVE SHAFT ASSY RH (SEE PAGE 30 −4)
6. REMOVE FRONT DRIVE SHAFT ASSY LH (SEE PAGE 30 −4)
7. REMOVE TRANSAXLE HOUSING OIL SEAL
(a) Using SST, pull out the oil seal. SST 09308 −00010
8. REMOVE DIFFERENTIAL SIDE BEARING RETAINER OIL SEAL
(a) Using SST, pull out the oil seal.
SST 09308 −00010
9. INSTALL TRANSAXLE HOUSING OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal. SST 09316 −60011 (09316 −00011)
Oil seal drive in depth:
0 á 0.5 mm (0 á0.020 in.)
(b) Coat the lip of the oil seal with MP grease.
