TOYOTA BZ4X 2023 Owners Manual

3615-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
on the condition of the parking
space, etc., if it is necessary to
change the direction of travel of
the vehicle, the shift position can
be changed by assistance con-
trol.
■Parking using the parallel
parking function
1 Stop the vehicle with it
aligned near the center of the
target parking space.
If there are parking space
lines
Approximately 3.3 ft. (1 m)
*
Approximately 16.4 to 19.7 ft.
(5 to 6 m)
*
Approximately 14.8 ft. (4.5 m)
or more
*
Approximately 26.2 ft. (8 m)
or more
*
*: This is a reference measurement for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.
If there is an adjacent parked
vehicle
Approximately 3.3 ft. (1 m)
*
Approximately 23.0 ft. (7 m)
or more
*
Approximately 14.8 ft. (4.5 m)
or more
*
Approximately 26.2 ft. (8 m)
or more
*
*: This is a reference measurement for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.
2 Press the Advanced Park
main switch and check that a

3625-4. Using the driving support systems
Owners Manual_USA_M42C01_en
possible parking space is dis-
played on the multimedia dis-
play.
 If a space which your vehicle
can be parked is detected, a
target parking space box will
be displayed.
 If it is possible to perpendicu-
lar parking (forward/reverse)
in the space, select the park-
ing space, and then select
to change to the perpen-
dicular parking (for-
ward/reverse) function.
 Depending on the surround-
ing environment, it may not be
possible to use this function.
According to the information
displayed on the multimedia
display, use the function on
another parking space.
3 Select “Start” button.
A buzzer will sound, an operation
message will be dis played on the
multi-information display, and assis- tance will begin operating.

When the brake pedal is
released, “Moving Forward...”
will be displayed and the vehi-
cle will begin moving forward.
 To cancel assistance, press
the Advanced Park main
switch.
If assistance is canceled,
“Advanced Park Cancelled” will be
displayed.
If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter: P.363
4 Perform operations as indi-
cated by the advice displays
until the vehicle stops in the
target parking space.
When the vehicle stops, “Advanced
Park Finished” will be displayed
and parking assistance will end.
If you select on the multimedia
display, the vehicle displayed on
the parking assist completion

3635-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
screen will rotate.
■If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter
Depress the brake pedal to stop the
vehicle and then ch ange the shift
position to change the direction of
travel of the vehicle.
At this time, assist will be sus-
pended. However, if the “Start” but-
ton is selected, assist will resume
and the vehicle will move in the
direction corresponding to the
selected shift position.
■If “No available parking space”
is displayed
Even if the vehicle is stopped paral-
lel to a parking space, an adjacent
parked vehicle may not be detected.
In this case, if the vehicle is moved
to a position that a parked vehicle
can be detected, assistance can be
started.
NOTICE
■When using the parallel park-
ing function
●Make sure that there are no
obstructions within the yellow
guide lines and between the
vehicle and target parking spot.
If any obstructions are detected
within the yellow guide lines or
between the vehicle and the tar-
get parking space, the parallel
parking function will be can-
celled.
●As the tar get parking space will
not be able to be set correctly if
the surface of the parking space
is on a slope or has differences
in height, the veh icle may stray
from the target parking space or
be slanted. Therefore, do not
use the parallel parking func-
tion for this kind of parking spot.
●When parking in a narrow park-
ing space, the vehicle may
closely approach an adjacent
parked vehicle. if a collision
seems likely, depress the brake
pedal to stop the vehicle.

3645-4. Using the driving support systems
Owners Manual_USA_M42C01_en
■Function description
When exiting from a parallel
parking space, if the system
determines that exit is possible
the parallel exiting function can
be used. Also, depending on the
surrounding environment, if it is
necessary to change the direc- tion of travel of the vehicle, the
shift position can be changed by
assistance control.
■Leaving a parking space
using the parallel exiting
function
1 With the brake pedal
depressed and P shift posi-
tion selected, press the
Advanced Park main switch
and check that the exit direc-
tion selection screen is dis-
played on the multimedia
display.
2 Select an arrow on the multi-
media display to select the
direction you wish to exit.
If the turn signal lever is operated,
only exit to the left or right can be
selected.
3Depress the brake pedal and
select “Start” button.
A buzzer will sound, an operation
message will be displayed on the
multi-information display, and assis-
tance will begin operating.
To cancel assistance, press the
Advanced Park main switch.
NOTICE
●If an adjacent parked vehicle is
narrow or parked extremely
close to the curb, the position at
which assistance will park the
vehicle will also be close to the
curb. If it seems likely the vehi-
cle will collide with the curb or
drive off of the road, depress
the brake pedal to stop the vehi-
cle, and then press the
Advanced Park main switch to
disable the system.
●If there is a wall or other barrier
on the inner side of the parking
space, the vehicle may stop at a
position slightly outside of the
set target parking space.
Advanced Park Parallel
exiting function

3655-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
If assistance is canceled,
“Advanced Park Cancelled” will be
displayed.
If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter:  P. 3 6 5
4Perform operations as indi-
cated by the advice displays
until the vehicle is in a posi-
tion where exit is possible.
If the steering w heel is not oper-
ated, the vehicle will stop at the exit
position. When the vehicle reaches
a position where ex it is possible,
“You can exit by moving the steer-
ing wheel” will be displayed. If the
steering wheel is operated,
“Advanced Park Finished” will be
displayed and ass istance will end.
Grip the steering wheel and drive
forward.
■If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter
Depress the brake pedal to stop the vehicle and then change the shift
position to change
the direction of
travel of the vehicle.
At this time, assist will be sus-
pended. However, if the “Start” but-
ton is selected, a ssist will resume
and the vehicle will move in the
direction corresponding to the
selected shift position.
■Parallel exiting function
Do not use parallel exiting function
in any situation other than when
exiting a parallel parking spot. If
assistance is started unintention-
ally, depress the brake pedal and
stop the vehicle, then press the
Advanced Park main switch to can-
cel assistance.
■Situations in which the parallel
exiting function will not operate
In situations such as the following,
the parallel exiti ng function will not
operate:
●When vehicles waiting at a traffic
signal in the exit direction
●When a vehicle is stopped in the
area behind where the vehicle will
exit
●When a wall, column, or person is
detected as near a front or rear
side sensor

3665-4. Using the driving support systems
Owners Manual_USA_M42C01_en
●When the vehicle has been
parked on a curb and a side sen-
sor detects the road surface
●When a vehicle is not parked in
front of the vehicle
●When there is excessive space
between the front of the vehicle
and a parked vehicle
■Function description
The memory function can be
used to park in a previously reg-
istered parking space, even if
there are no parking space lines
or adjacent parked vehicles.
Up to 3 parking spaces can be
registered.
■Registering a parking space
1 Stop the vehicle with it
aligned near the center of the
target parking space.
Approximately 3.3 ft. (1 m)
2 Press the main switch and
then select
If the Advanced Park main switch is
pressed at a parking space without
parking lines or any adjacent
parked vehicles, “No available
parking space” may be displayed.
Continuously select and hold .
3Select perpendicular parking
(forward/reverse) function or
parallel parking function.
Only parking spaces for which
Advanced Park Memory
function

3675-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
assist can be pe rformed are dis-
played.
4 Select the parking direction.
When perpendicular parking (for-
ward/reverse) was selected in step
3
When parallel parking was selected
in step 3
5Using the arrow buttons,
adjust the position of the
parking space to be regis- tered, and then select “OK”
button.
6 Select “Start” button.
A buzzer will sound, an operation
message will be displayed on the
multi-information display, and assis-
tance will begin operating.
When the brake pedal is released,
“Moving Forward...” will be dis-
played and the vehicle will begin
moving forward.
If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter: P.369
7 Perform operations as indi-
cated by the advice displays

3685-4. Using the driving support systems
Owners Manual_USA_M42C01_en
until the vehicle stops in the
target parking space.
8 Check the position that the
vehicle has stopped. If nec-
essary, adjust the position of
the parking spot to be regis-
tered using the arrow but-
tons, and then select
“Registration” button.
“Registration Completed” will be
displayed on the multimedia dis-
play.
Register the parking space
only if there are no obstruc-
tions within the area shown by
the thick lines.
 The amount that the position
of the parking spot to be reg-
istered can be adjusted is lim-
ited.
■When parking in a parking
space registered to the
memory function
1 Stop the vehicle with it
aligned near the center of the
target parking space.
Approximately 3.3 ft. (1 m)
2 Press the Advanced Park
main switch and check that a
possible parking space is dis-
played on the multimedia dis-
play.
If the “MODE” button is displayed,
the button can be touched to
change between t he memory func-
tion, perpendicular parking (for-
ward/reverse) function and parallel
parking function.

3695-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
3 Select the desired parking
space, and then select “Start”
button.
Perform the procedure for the per-
pendicular parking (for-
ward/reverse) function from step 3.
(  P.356)
■If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter
Depress the brake pedal to stop the
vehicle and then ch ange the shift
position to change the direction of
travel of the vehicle.
At this time, assist will be sus-
pended. However, if the “Start” but-
ton is selected, assist will resume
and the vehicle will move in the
direction corresponding to the
selected shift position.
■When overwriting a registered
parking space
If the maximum number of parking
spaces have been registered and is selected, a registered parking
space can be selected and then
overwritten with a new parking
space.
■When multiple parking spaces
are registered
Select the desired parking space,
and then select “Start” button.
NOTICE
■When using the memory
function
●The memory function is a func-
tion which provides assistance
in parking in a previously regis-
tered parking space.
If the condition of the road sur-
face, vehicle, or surrounding
area differs from when registra-
tion was performed, the parking
space may not be able to be
detected correctly or assis-
tance may not be provided to
the point that the vehicle is fully
parked.
●Do not register a parking space
in situations such as the follow-
ing, as the set parking space
may not be able to be registered
or assistance may not be possi-
ble later.
• When a camera lens is dirty or covered with water droplets
• When it is raining or snowing
• When the surrounding area is dark (at night, etc.)
●In situations such as the follow-
ing, it may not be possible to
register a parking space.
• When there is insufficient space between the road and parking
space
• When the road surface around the parking space does not
have any differences the sys-
tem can recognize

3705-4. Using the driving support systems
Owners Manual_USA_M42C01_en
NOTICE
●If a parking space has been reg-
istered in situations such as the
following, assistance may not
be able to be started later or
assistance to the registered
position may not be possible.
• When shadows are cast on the parking space (there is a carport
over the parking space, etc.)
• When there are leaves, gar- bage, or other objects which will
likely move, in the parking
space
• When the road surface around the parking space has the same
repeating pattern (brick, etc.)
●In situations such as the follow-
ing, it may not be possible for
the system to provide assis-
tance to a registered parking
spot:
• When the appearance of the parking space is affected by the
shadow of the vehicle or trees
• When an object is detected in the registered parking space
• When a pedestrian or passing vehicle is detected during assis-
tance
• When the position the vehicle is stopped when assistance is
started differs from the position
when registration was per-
formed
• When the registered parking space cannot be reached due to
the existence of parking blocks,
etc.
• When the road surface around the parking space has changed
(road surface has degraded or
been resurfaced)
• When the sunlight conditions differ from when registration
was performed (due to weather
or time of day)
• When the sun is shining directly into a camera, such as in the
early morning or evening
• When the color or brightness of the road surface is uneven
• When a light is temporarily shined on the parking space
(lights of another vehicle, secu-
rity light, etc.)
• When the road surface around the parking space has the same
repeating pattern
• When there is a low protrusion on the road surface near the
parking space
• When the parking space is on a slope
• When a camera has been splashed by hot o r cold water
and the lens has fogged up
• When a camera lens is dirty or covered with water droplets
