TOYOTA C-HR 2019 Owners Manual (in English)

1313-2. Opening, closing and locking the doors
3
Operation of each component
C-HR_OM_USA_OM10569U■
When the vehicle is not driven for extended periods
●To prevent theft of the vehicle, do not leave the electronic ke y within 6 ft.
(2 m) of the vehicle.
● The smart key system can be deactivated in advance. ( P. 486)
■ To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from the
outside of the vehicle.
Depending on the position and holding condition of the electron ic key, the key
may not be detected correctly and the system may not operate pr operly. (The
alarm may go off accidentally, or the door lock prevention may not operate.)
■ If the smart key system does not operate properly
●Locking and unlocking the doors: Use the mechanical key. ( P. 448)
● Starting the engine system: P. 449
■ Customization
Settings (e.g. smart key system) can be changed.
(Customizable features: P. 486
■ If the smart key system has been d eactivated in a customized setting
● Unlocking and locking the doors:
Use the wireless remote control or mechanical key. ( P. 112, 448)
● Starting the engine and changing engine switch modes: P. 449
● Stopping the engine: P. 176

1323-2. Opening, closing and locking the doors
C-HR_OM_USA_OM10569U■
Certification for the smart key system
For vehicles sold in the U.S.A.
For vehicles sold in the U.S.A.
For vehicles sold in Canada

1333-2. Opening, closing and locking the doors
3
Operation of each component
C-HR_OM_USA_OM10569U
For vehicles sold in the U.S.A.
For vehicles sold in Canada

1343-2. Opening, closing and locking the doors
C-HR_OM_USA_OM10569U
WARNING
■Caution regarding interfer ence with electronic devices
● People with implantable cardiac pacemakers, cardiac resynchroni zation
therapy-pacemakers or implantable cardioverter defibrillators s hould keep
away from the smart key system antennas. ( P. 125)
The radio waves may affect the operation of such devices. If ne cessary,
the entry function can be disabled. Ask your Toyota dealer for details, such
as the frequency of radio waves and timing of the emitted radio waves.
Then, consult your doctor to see if you should disable the entr y function.
● Users of any electrical medical device other than implantable c ardiac
pacemakers, cardiac resynchronization therapy-pacemakers or implant-
able cardioverter defibrillators should consult the manufacture r of the
device for information about its operation under the influence of radio
waves.
Radio waves could have unexpected effects on the operation of such
medical devices.
Ask your Toyota dealer for details on disabling the entry function.

1353-3. Adjusting the seats
3
Operation of each component
C-HR_OM_USA_OM10569U
Front seats
Seat position adjustment lever
Seatback angle adjustment
lever
Vertical height adjustment lever
Lumbar support adjustment
switch (if equipped)
Adjustment procedure
WARNING
■When adjusting the seat position
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts t o avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● Make sure to leave enough space around the feet so they do not get stuck.
■ Seat adjustment
● Be careful that the seat does not hit passengers or luggage.
● To reduce the risk of sliding under the lap belt during a colli sion, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hi ps and apply
restraint forces directly to the abdomen, or your neck may cont act the
shoulder belt, increasing the risk of death or serious injury i n the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
● After adjusting the seat, make sure that the seat is locked in position.

1363-3. Adjusting the seats
C-HR_OM_USA_OM10569U
Rear seats
Park the vehicle in a safe place.
Apply the parking brake firmly and shift the shift lever to P. (P. 181)
Adjust the position of the front seat and the angle of the seatback.
( P. 135)
Depending on the position of the f ront seat, if the seatback is folded
backward, it may interfere wit h the operation of the rear seat.
Lift up and push down the head restraints of the rear outboard
seats, and lower the head rest raint of the rear center seat.
(  P. 138)
Pull the seatback lock release
lever and fold t he seatback down.
To avoid trapping the seat belt
between the seat and the inside of
the vehicle, pass the seat belt
inside the seat belt guide and then
return the seatback securely to
the locked position.
The seatbacks of the rear seats can be folded down.
Before folding down the seatbacks
Folding down the seatbacks
1
2
3
Returning the rear seatbacks
Seat belt
guide

1373-3. Adjusting the seats
3
Operation of each component
C-HR_OM_USA_OM10569U
WARNING
Observe the following precautions. Failure to do so may result in death or
serious injury.
■ When folding the rear seatbacks down
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shi ft the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the lugga ge compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
● Do not allow anyone to sit on the rear center seat if the rear right seat is
folded down, as the seat belt buckle for the rear center seat belt is then
concealed under the folded seat and cannot be used.
● Be careful not to get your hand caught when folding the rear seatbacks.
● Adjust the position of the front seats before folding down the rear seat-
backs so that the front seats do not interfere with the rear se atbacks when
folding down the rear seatbacks.
■ After returning the rear seat back to the upright position
●Make sure that the seatback is securely
locked in position by lightly rocking it
back and forth.
If the seatback is not securely locked,
the red marking will be visible on the
seatback lock release knob. Make sure
that the red marking is not visible.
● Check that the seat belts are not twisted
or caught in the seatback.
If the seat belt gets caught between the
seatback’s securing hook and latch, it
may damage the seat belt.

1383-3. Adjusting the seats
C-HR_OM_USA_OM10569U
Head restraints
Up
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
■
Rear outboard seats To f o l d
Pull the head restraint up while
pressing the lock release button.
To u s e
Lift up and push down the head
restraint to the lowest lock posi-
tion.
■
Rear center seat Up
Pull the head restraints up.
Down
Push the head restraint down
while pressing the lock release
button.
Head restraints are provided for all seats.
Front seats
Lock release button
Rear seats
Lock release button
Lock release button

1393-3. Adjusting the seats
3
Operation of each component
C-HR_OM_USA_OM10569U
■Removing the head restraints
Front seats
Rear outside seats
Rear center seat
Pull the head restraint up while pressing
the lock release button.
Pull the head restraint up while pressing
the both lock release buttons.
Pull the head restraint up while pressing
the lock release button.
Lock release button
Lock release button
Lock release button

1403-3. Adjusting the seats
C-HR_OM_USA_OM10569U■
Installing the head restraints
Front seats
Rear outside seats
Rear center seat
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Lock release button
Lock release button
