turn signal TOYOTA C-HR 2021 (in English) Owner's Manual

4156-3. Do-it-yourself maintenance
6
Maintenance and care
C-HR_OM_USA_OM10684U
Insert a flathead screwdriver
and remove the lens to the
outside.
Remove the socket from the
side turn signal light housing.
Remove the bulb.
Replace the bulb and install
the socket to the side turn
signal light housing.
Align the grooves of the socket
to the side turn signal light hous-
ing.
4
5
6
7

4176-3. Do-it-yourself maintenance
6
Maintenance and care
C-HR_OM_USA_OM10684U
Attach the cover claws span-
ning over the entire perime-
ter.
Finally, confirm that the outside
claw is securely fitted.
■
Replacing the following bulbs
If any of the lights listed below has burnt out, have it replac ed by
your Toyota dealer.
● Headlights
● Parking lights/daytime running lights
● Front turn signal lights (vehicles with LED type)
● Front side marker lights (vehicles with LED type)
● Front fog lights
● Stop/tail lights
● High mounted stoplight
● Outer mirror illumination (if equipped)
11

4186-3. Do-it-yourself maintenance
C-HR_OM_USA_OM10684U
■LED light bulbs
The following lights consist of a number of LEDs. If any of the LEDs burns
out, take your vehicle to your Toyota dealer to have the light replaced.
● Headlights
● Parking lights/daytime running lights
● Front turn signal lights (vehicles with LED type)
● Front side marker lights (vehicles with LED type)
● Front fog lights
● Stop/tail lights
● High mounted stoplight
● Outer mirror illumination (if equipped)
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction.
Contact your Toyota dealer for more information in the followin g situations:
● Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.
■ When replacing light bulbs
P. 404

4227-1. Essential information
C-HR_OM_USA_OM10684U
Emergency flashers
Press the switch.
All the turn signal lights will flash.
To turn them off, press the switch
once again.
■Emergency flashers
If the emergency flashers are used for a long time while the en gine is not
operating, the battery may discharge.
The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in the road due to a breakdown, etc.

4838-1. Specifications
8
Vehicle specifications
C-HR_OM_USA_OM10684U
Light bulbs
Light bulbsBulb No.WTy p e
ExteriorFront side marker lights
(bulb type)
―5 A
Front turn signal lights
(bulb type) ―21 B
Side turn signal lights ― 5 B
Rear side marker lights ― 5 A
Rear turn signal lights ― 21 B
Back-up lights 921 16 A
License plate lights ― 5 A
InteriorVanity lights
*―8 A
Front interior lights/
front personal lights ―5 A
Rear interior light ― 8C
Luggage compartment
light ―5 A
A: Wedge base bulbs (clear)
C: Double end bulbs
*: If equipped B: Wedge base bulbs (amber)

5068-2. Customization
C-HR_OM_USA_OM10684U■
Power windows (
P. 157)
*1: Vehicles without a smart key system
*2: Vehicles with a smart key system
■
Turn signal lever ( P. 195)
FunctionDefault settingCustomized
setting
Key*1 or mechanical
key
*2 linked operation
(open)OffOn——O
Key*1 or mechanical
key
*2 linked operation
(close)OffOn——O
Wireless remote con-
trol linked operation
(open only)
OffOn——O
Key*1 or mechanical
key
*2, wireless
remote control linked
operation signal
(buzzer)
OnOff——O
FunctionDefault settingCustomized setting
Times of flashing of
the lane change sig-
nal flashers
3
Off
——O5
7
