TOYOTA CAMRY 1996 Owners Manual

85 The preset station will be cancelled when
the power source is severed (battery dis-
connected, burnt fuse, etc.).
(d) Adjusting the tone
To adjust a low-pitched tone, push the
BASS TREBº knob (if pushed in) and turn
it.
To adjust a high-pitched tone, push the
BASS TREBº knob (if pushed in), pull it
fully out and turn it.
(e) Adjusting the sound balance
To balance the sound between the right
and left speakers, pull out the BALº knob
and turn it.
To balance the sound between the front
and rear speakers, turn the FADEº knob.
(f) Listening to the cassette tape
1. Put the cassette into the slot, with the
tape side to the right and lightly push it in.
The tape player will grab the cassette and
slide it into place to play it. If the radio is
on when inserting the cassette, the radio
will automatically turn off.
If the cassette is already in the slot, push
the TAPEº button.
At this time, PLAYº will appear on the dis-
play.The tape player can also be turned on by
pushing the PWR VOLº knob if the tape
player was playing when the system was
turned off by pushing the knob.
2. If using a tape recorded with Dolby


NR*, push the button marked with the
double-D symbol. The display will indi-
cate that the Dolby noise reduction sys-
tem is on.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with the Dolby

NR*
on or off according to the mode used for
recording the tape.
To play a tape recorded without Dolby


NR*, push the button again to turn off the
Dolby
NR*.
*: Dolby noise reduction manufactured under license from Dolby Lab-
oratories Licensing Corporation. DOLBYº and the double-D symbol
are trademarks of Dolby Laboratories Licensing Corporation.
3. Turn the PWR VOLº knob to adjust the
volume.
4. Select your program. (See (g) Select-
ing a programº.)
5. Adjust the tone and sound balance.
(See (d)º Adjusting the toneº and (e) Ad-
justing the sound balanceº.)6. To turn the player off, push the PWR
VOLº knob.
7. To eject the cassette, push the EJECT
button. As this is done, the player will turn
off. If the radio was on when the cassette
tape was inserted, it will automatically turn
on again.
You can eject the cassette only once after
the system is turned off.
(g) Selecting a program
1. Push the PROGº button to select a
side to play. The tape operation indicator
display shows you which side is being
played.
The player will automatically reverse di-
rection at the end of the tape to play the
other side.
2. Push the REW FF (TUNE)º button on
either side to fast forward or rewind the
tape. At this time, FFº or REWº will ap-
pear on the display. To stop the tape while
it is fast forwarding, push FFº or TAPEº;
to stop the tape while it is rewinding, push
REWº or TAPEº. The tape will immedi-
ately begin to play.
ProCarManuals.com

86
AM-FM radio with electronic tuner and cassette tape player (type B)
ProCarManuals.com

87ProCarManuals.com

88(a) Listening to the radio
1. Push the AMFMº button to turn the
radio on and select either an AM or FM
broadcast.
AMº or FMº will appear on the display.
The radio can also be turned on by push-
ing the PWR VOLº knob if the radio was
on when the system was turned off.
2. Turn the PWR VOLº knob to adjust the
volume.
3. Tune in the desired station. (See (b)
Selecting a stationº and (c) Presetting a
stationº.)
The radio will change automatically to ste-
reo reception when an FM stereo broad-
cast is being received. At the same time,
STº will appear on the display. When the
receiving signal gets weak, the channel
separation will automatically be reduced
for the lowest noise. If the signal becomes
extremely weak, the radio will switch over
to monaural reception.
4. Adjust the tone and sound balance.
(See (d) Adjusting the toneº and (e) Ad-
justing the sound balanceº.)
5. To turn the radio off, push the PWR
VOLº knob.(b) Selecting a station
Tune in the desired station using one of
the following methods. The frequency will
appear on the display.
Preset tuning: Use for tuning-in to a de-
sired preset station. (See (c) Presetting
a stationº.)
1. Push the AMFMº button repeatedly
until the desired selection appears on the
display.
2. Push the station selector button which
has been preset to the desired station.
The radio will tune in to the station and the
button number will appear on the display.
Seek tuning: Use for automatic station
search and stop.
Push the TUNE (REW FF)º button on ei-
ther side and hold it until a beep is heard.
The radio will begin seeking up or down for
a station of the nearest frequency and will
stop on reception. Each time you push the
button, stations will be sought out one af-
ter another.
Scan tuning: Use for station-to-station
scanning.Scanning for all frequenciesÐPush the
SCANº button and hold it until a beep is
heard. With SCANº on the display, the ra-
dio will automatically seek out a station of
a higher frequency, hold it for 5 seconds
and scan to the next. To continue listening
to the broadcast of your choice, simply
push the SCANº button once again.
If the radio scans over all frequencies
without stop because the signals are too
weak or just because you leave it going,
the radio will begin scanning again with
sensitivity boosted for searching out weak
stations.
Scanning for preset stationsÐPush the
SCANº button within 2 seconds. With
SCANº on the display, the radio will auto-
matically seek out a preset station, hold it
for 5 seconds and scan to the next. To
continue listening to the station of your
choice, simply push the SCANº button
once again.
Manual tuning
Push the TUNE (REW FF)º button on ei-
ther side for less than 0.5 second. Each
time you push the button, the radio will
step up or down to another frequency
where stations could exist.ProCarManuals.com

89 (c) Presetting a station
1. Push the AMFMº button repeatedly
until the desired selection, AMº, FM1º or
FM2º, appears on the display.
The radio has two FM selections, FM1º
and FM2º. You can preset any desired six
stations in each selection. When you pre-
set an FM station, check which selection
you have used.
2. Tune in the desired station. (See (b)
Selecting a stationº.)
3. Push one of the station selector but-
tons and hold it until a beep is heard. This
sets the station to the button and the but-
ton number will appear on the display.
To change the preset station to a different
one, follow the same procedure.
The preset station will be cancelled when
the power source is severed (battery dis-
connected, burnt fuse, etc.).
(d) Adjusting the tone
To adjust the low-pitched tone, push the
BASS TREBº knob (if pushed in) and turn
it.
To adjust the high-pitched tone, push the
BASS TREBº knob (if pushed in), pull it
fully out and turn it.(e) Adjusting the sound balance
To balance the sound between the right
and left speakers, pull the BALº knob and
turn it.
To balance the sound between the front
and rear speakers, turn the FADEº knob.
(f) Listening to the cassette tape
1. Put the cassette into the slot, with the
tape side to the right and lightly push it in.
The tape player will grab the cassette and
slide it into place to play it. If the radio is
on when inserting the cassette, it will auto-
matically turn off.
If the cassette is already in the slot, push
the TAPEº button.
At this time, PLAYº will appear on the dis-
play.
The tape player can also be turned on by
pushing the PWR VOLº knob if the tape
player was playing when the system was
turned off by pushing the knob.
When a metal or chrome equivalent tape
is inserted, the player will automatically
adapt to it and MTLº will appear on the
display.
2. If using a tape recorded with Dolby


NR*, push the button marked with the
double-D symbol to select the Dolby B
NR or Dolby C NR mode. The display will
indicate which Dolby noise reduction sys-
tem is operating.The Dolby B NR mode reduces tape noise
by about 10 dB. The Dolby C NR mode re-
duces tape noise by another 10 dB, or
about 20 dB total. For best sound repro-
duction, select the same NR mode that
was used to record the tape.
To play a tape recorded without Dolby


NR*, push the button until the Dolby NR
indicator disappears.
*: Dolby noise reduction manufactured under license from Dolby Lab-
oratories Licensing Corporation. DOLBYº and the double-D symbol
are trademarks of Dolby Laboratories Licensing Corporation.
3. Turn the PWR VOLº knob to adjust the
volume.
4. Select your program. (See (g) Select-
ing a programº.)
5. Adjust the tone and sound balance.
(See (d) Adjusting the toneº and (e) Ad-
justing the sound balanceº.)
6. If desired, other functions may be used
for your convenience. (See (h) Other
tape player functionsº.)
7. To eject the cassette, push the EJECT
button. As this is done, the player will turn
off. If the radio was on when the cassette
tape was inserted, it will automatically turn
on again.
8. To turn the player off, push the PWR
VOLº knob.
ProCarManuals.com

90You can eject the cassette only once after
the system is turned off.
(g) Selecting a program
1. Push the PROGº button to select a
side to play. The tape operation indicator
display shows you which side is being
played.
The player will automatically reverse di-
rection at the end of the tape to play the
other side.
2. Have a desired program played using
either of the following methods.
Manual program selection
Push the REW FF (TUNE)º button on ei-
ther side to rewind or fast forward the
tape. At this time, REWº or FFº will ap-
pear on the display. To stop the tape while
it is fast forwarding, push FFº or TAPEº;
to stop the tape while it is rewinding, push
REWº or TAPEº. The tape will immedi-
ately begin to play.
Automatic program selection: Use for
quick access to a desired program.
1. Push the APSº button. APSº and pro-
gram number 1º will appear on the dis-
play.
2. Repeat the push until the number indi-
cates how many programs ahead of/be-
hind the one currently being played you
wish to listen to (include the program you
are currently listening to when counting
back previous programs).The maximum number of settings is nine.
The tenth push on the button will cancel
the function and APSº will disappear on
the display.
3. Push the REW FF (TUNE)º button on
either side to get the tape going in the di-
rection of the program. The player will au-
tomatically stop at the beginning of the se-
lected program and play it.
If the number you set exceeds the number
of the programs remaining on the side
currently being played, the tape will fast
forward to the beginning of the other side
(when fast forwarding) or rewind to the be-
ginning of that side (when rewinding).
This function does not work properly un-
less the blank portions on the tape have 3
seconds or more between one program
and another.
(h) Other tape player functions
RPTº button: Use for automatic repeat
of the program currently being listened to.Push the RPTº button while the program
is being played. As this is done, RPTº will
appear on the display. When the program
is finished, the tape will automatically be
rewound to the beginning of the program
and the program will be played again. To
cancel it, push the button once again.
This function does not work properly un-
less the blank portions on the tape have 3
seconds or more between one program
and another.
SKIPº button: Use for automatic skip-
ping of blank portions between programs.
Push the SKIPº button. SKIPº appears
on the display. The player will automati-
cally skip any blank portions of 15 sec-
onds or more and play the next program,
even if it is on the other side. To cancel it,
push the button once again.
SCANº button: Use for program-to-
program scanning.
Push the SCANº button. With SCANº on
the display, each program will be played
for 12 seconds and scan to the next. To
continue listening to the program of your
choice, simply push the SCANº button
once again.
The player will automatically reverse di-
rections at the end of the tape and keep
scanning.ProCarManuals.com

91 RVMº button (radio monitor system):
Use for automatic station reception.
Push the RMº button. RMº appears on
the display. In this mode, if you push the
REW FF (TUNE)º button on either side
when listening to the tape, the system will
change the radio mode and automatically
receive the last station which was set. At
the time, the received station condition
appears on the display.
The system will be cancelled out when the
power source is severed (battery discon-
nected, burnt fuse etc.)(i) Anti-theft system
To deter theft of your radio unit, the sys-
tem is designed so that the radio unit be-
comes inoperable if the unit is stolen from
the vehicle.
The system is not preset at factory. You
must input a three-digit identification
number decided by you.
NOTICE
If you pushed any wrong buttons on
the anti-theft system, the following
messages will appear on the
display.
ErrºÐYou have pushed wrong
buttons.
1-9ºÐIndicates the number of er-
rors you have made. You may
make up to nine errors, but no
more!
HELPºÐThe number of errors
you can make was exceeded. The
audio system is completely inop-
erable. Contact you Toyota dealer.
Setting the anti-theft system
1. Make sure the radio unit is turned off
with the ignition switch in ACCº.
2. While holding the 1º and 6º buttons
in, push and hold the PWR VOLº knob in
until SECº appears on the display.
ProCarManuals.com

92
3. Press the 1º button while holding the
right side of TUNEº button in. - - -º and
the tape operation indicator will appear on
the display.4. Input your identification number by
pressing the 1º, 2º and 3º buttons re-
peatedly. Use the 1º button for the first
digit, the 2º button for the second digit
and the 3º button for the last digit. For ex-
ample, if your number is 824, press the 1º
button nine times, the 2º button three
times and the 3º button five times. if the
display returns to - - -º while inputting,
try again.
We recommend that your identification
number be associated with something
easy to remember. In case you are unsure
of the number, write it in a notebook you
normally carry. Do not leave it behind in
your vehicle.5. With your identification number ap-
pearing on the display, press the SCANº
button and hold it in until SECº appears
on the display. SECº will go off to indicate
the system is set. If invalid buttons have
been used, Errº will appear on the display
before SECº appears. Try again from the
step 3.
Once the system is set, the indicator light
turns on and off with the ignition switch in
OFFº and SECº will appear each time
the key is turned to the ACCº position.
To change the identification number for
some reason, cancel the system (See
Cancelling the anti-theft systemº) and
set it again with a new number.
ProCarManuals.com

93
The system will be activated if the electri-
cal power source is disconnected from the
radio unit. When the system is activated,
the audio system cannot be turned on
even after the power supply resumes and
SECº will appear on the display. If this
happens, such as when the battery is dis-
charged, see If the anti-theft system is
activatedº.Cancelling the anti-theft system
1. Follow the steps 1 to 4 described in
Setting the anti-theft systemº.
2. With your identification number ap-
pearing on the display, press the SCANº
button and hold it in until - - -º appears
on the display. - - -º will go off to indicate
the system is cancelled. If invalid buttons
have been used, Errº will appear on the
display and SECº appears. Try again
from step 3 in Setting the anti-theft sys-
temº.The figure with Errº indicates how many
errors you have made. You may make up
to nine errors, but no more!
NOTICE
A tenth error will activate the
anti-theft system and HELPº will
appear on the display. The audio
system will be completely
inoperable. At this time, the
indicator light also comes on. If this
occurs, contact your Toyota dealer.
At the time of resale of your vehicle, can-
cel the system for the new owner.
ProCarManuals.com

94
If the anti-theft system is activated
The audio system made inoperable by the
activated anti-theft system will be oper-
able if you give it the correct identification
number.
1. Follow the steps 3 and 4 described in
Setting the anti-theft systemº.
2. With your identification number ap-
pearing on the display, press the SCANº
button and hold it in until SECº appears
on the display. SECº will go off to indicate
that the system is reset and the audio sys-
tem is operable. If invalid buttons have
been used, Errº will appear on the display
before SECº appears. Try again from the
beginning.See Cancelling the anti-theft systemº for
notes on the figure with Errº.
ProCarManuals.com
