TOYOTA CAMRY 1999 Service Repair Manual

PP0CD±01
PP±56
± PREPARATIONCHARGING (1MZ±FE)
108 Author: Date:
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.

PP0CE±02
± PREPARATIONCHARGING (1MZ±FE)
PP±57
109 Author: Date:
EQUIPMENT
Ammeter(A)
Battery specific gravity gaugeExcept maintenance free battery
Belt tension gauge
Torque wrench
Vernier calipersRotor (Slip ring), Brush

PP0HC±01
PP±58
± PREPARATIONCLUTCH
11 0 Author: Date:
CLUTCH
SST (Special Service Tools)
09023±00100Union Nut Wrench 10 mmClutch line
09301±00210Clutch Guide Tool5S±FE Engine
09301±00220Clutch Guide Tool1MZ±FE Engine
09333±00013Clutch Diaphragm Spring Aligner

PP0HD±01
± PREPARATIONCLUTCH
PP±59
111 Author: Date:
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.
09905±00013Snap Ring Pliers .

PP0HE±01
PP±60
± PREPARATIONCLUTCH
11 2 Author: Date:
EQUIPMENT
Calipers
Dial indicator
Torque wrench

PP0H7±03
± PREPARATIONMANUAL TRANSAXLE (E153)
PP±61
11 3 Author: Date:
MANUAL TRANSAXLE (E153)
SST (Special Service Tools)
09223±15020Oil Seal & Bearing ReplacerDifferential case oil seal
09308±00010Oil Seal PullerOutput shaft front bearing outer
race
09316±20011Transfer Bearing ReplacerDifferential case tapered roller
bearing
09316±60011Transmission & Transfer Bearing
Replacer
(09316±00011)Replacer Pipe
(09316±00021)Replacer ºAº
(09316±00041)Replacer ºCº1st gear
No.1 hub sleeve
Differential case tapered roller
bearing outer race
(09316±00071)Replacer ºFºOutput shaft front bearing
09506±30012Differential Drive Pinion Rear
Bearing Cone ReplacerOutput shaft rear bearing
09506±35010Differential Drive Pinion Rear
Bearing ReplacerNo.2 hub sleeve
3rd gear
Input shaft rear bearing
09608±00081Differential Side Bearing Cone
ReplacerInput shaft oil seal
09612±65014Steering Worm Bearing PullerInput shaft bearing
Differential case tapered roller
bearing outer race

PP±62
± PREPARATIONMANUAL TRANSAXLE (E153)
11 4 Author: Date:
09950±00020Bearing Remover
09950±00030Bearing Remover AttachmentOutput shaft front bearing
09950±30010Puller A Set5th driven gear
No.3 clutch hub
09950±40011Puller B SetDifferential case tapered roller bearing
09950±60010Replacer Set
(09951±00310)Replacer 31Control shaft cover oil seal
Installation
(09951±00580)Replacer 58Input shaft bearing
09950±70010Handle Set
(09951±07150)Handle 150

PP0H8±01
± PREPARATIONMANUAL TRANSAXLE (E153)
PP±63
11 5 Author: Date:
RECOMMENDED TOOLS
09025±00010Torque Wrench (30 kgf±cm)Differential preload
09031±00030Pin Punch .
09040±00010Hexagon Wrench Set .
09042±00040Torx Socket T50 .
09042±00050Torx Socket T45 .
09090±04010Engine Sling Device .
09905±00012Snap Ring No.1 Expander .

PP0H9±01
PP±64
± PREPARATIONMANUAL TRANSAXLE (E153)
11 6 Author: Date:
EQUIPMENT
Dial indicator with magnetic base
Feeler gauge
Micrometer
Torque wrench
Precision straight edge
Magnetic finger

PP0HA±01
± PREPARATIONMANUAL TRANSAXLE (E153)
PP±65
11 7 Author: Date:
LUBRICANT
ItemCapacityClassification
Manual transaxle oil
(w/ Differential oil)4.2 liters (4.4 US qts, 3.7 Imp. qts)API GL±4 or GL±5
SAE 75W±90
