TOYOTA CAMRY 1999 Service Repair Manual

PP±86
± PREPARATIONBRAKE
138 Author: Date:
09990±00430ABS Actuator Checker Sheet ºPºDENSO type ABS
09990±00450ABS Actuator Checker Sub±harness
ºPºABS & TRAC type

PP0I8±01
± PREPARATIONBRAKE
PP±87
139 Author: Date:
RECOMMENDED TOOLS
09042±00030Torx Socket T20 .BOSCH type ABS
09082±00040TOYOTA Electrical Tester.
09905±00013Snap Ring Pliers .

PP0I9±03
PP±88
± PREPARATIONBRAKE
140 Author: Date:
EQUIPMENT
Torque wrench
MicrometerBrake disc
Dial indicatorBrake disc
Brake drum gaugeBrake drum and disc
Vernier calipersBrake drum

PP0IA±01
± PREPARATIONBRAKE
PP±89
141 Author: Date:
LUBRICANT
ItemCapacityClassification
Brake fluid±SAE J1703 or FMVSS No.116 DOT3

PP0DB±03
PP±90
± PREPARATIONSTEERING
142 Author: Date:
STEERING
SST (Special Service Tools)
09249±63010Torque Wrench AdaptorPS vane pump
09521±24010Drive Shaft Boot Clamping ToolPS gear
09527±20011Rear Axle Shaft Bearing RemoverPS gear
09612±00012Rack & Pinion Steering Rack
Housing StandPS gear
09612±22011Tilt Handle Bearing ReplacerPS gear
09612±24014Steering Gear Housing Overhaul
Tool Set
(09613±22011)Steering Rack Shaft Bushing
PullerPS gear
09616±00010Steering Worm Bearing Adjusting
SocketPS gear
09631±10021Rack Stopper WrenchPS gear
09631±12071Steering Rack Oil Seal Test ToolPS gear
09631±20081Seal Ring ToolPS gear
09631±22020Power Steering Hose Nut
14 x 17 mm Wrench SetPS vane pump
PS gear

± PREPARATIONSTEERING
PP±91
143 Author: Date:
09631±33010Steering Rack Cover ºIºPS gear
09633±00020Power Steering Hose Nut WrenchPS gear
09640±10010Power Steering Pressure Gauge
Set
(09641±01010)Gauge AssyPower steering fluid
(09641±01030)Attachment BPower steering fluid
(09641±01060)Attachment EPower steering fluid
09922±10010Variable Open WrenchPS gear
09950±50012Puller C Set
(09951±05010)Hanger 150Tilt steering column
(09952±05010)Slide ArmTilt steering column
(09953±05020)Center Bolt 150Tilt steering column
(09954±05020)Claw No.2Tilt steering column
09950±60010Replacer Set

PP±92
± PREPARATIONSTEERING
144 Author: Date:
(09951±00180)Replacer 18PS gear
(09951±00240)Replacer 24PS gear
(09951±00250)Replacer 25PS gear
(09951±00260)Replacer 26PS gear
(09951±00290)Replacer 29PS gear
(09951±00310)Replacer 31PS gear
(09951±00320)Replacer 32PS gear
(09951±00330)Replacer 33PS vane pump
(09951±00340)Replacer 34PS gear
(09951±00400)Replacer 40PS gear
(09951±00430)Replacer 43PS gear
(09952±06010)AdapterPS gear
09950±70010Handle Set

± PREPARATIONSTEERING
PP±93
145 Author: Date:
(09951±07100)Handle 100PS vane pump
(09951±07200)Handle 200PS gear
(09951±07360)Handle 360PS gear
09960±10010Variable Pin Wrench Set
(09962±01000)Variable Pin Wrench Arm AssyPS vane pump
(09963±01000)Pin 10PS vane pump

PP0DC±03
PP±94
± PREPARATIONSTEERING
146 Author: Date:
RECOMMENDED TOOLS
09025±00010Torque Wrench (30 ) .PS vane pump
PS gear
09042±00010Torx Socket T30 .Tilt steering column
09904±00010Expander Set .
09905±00012Snap Ring No.1 Expander .
09905±00013Snap Ring Pliers .

PP0DD±05
± PREPARATIONSTEERING
PP±95
147 Author: Date:
EQUIPMENT
Belt tension gaugeOn±vehicle inspection
Caliper gaugePS vane pump
CalipersPS vane pump
Dial indicatorPS gear
Feeler gaugePS vane pump
MicrometerPS vane pump
Torque wrench
