TOYOTA CAMRY 2012 XV50 / 9.G Owners Manual

491
6-1. Specifications
6
Vehicle specifications
Tire related termMeaning
Ply A layer of rubber-coated parallel cords
Ply separation A parting of rubber compound between adja-
cent plies
Pneumatic tire A mechanical device made of rubber, chemi-
cals, fabric and steel or
other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load
Radial ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread
Reinforced tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Section width The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
Sidewall That portion of a tire between the tread and
bead
Sidewall separation The parting of the rubber compound from the
cord material in the sidewall
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire

492 6-1. Specifications
*:Table 1  Occupant loading and distribution for vehicle normal load
for various designated seating capacities
Tire related termMeaning
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehi- cle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

493
6
Vehicle specifications
6-2. Customization
Customizable features
Customizable FeaturesVehicles with a Display Audio system: Settings that can be
changed using the Display Audio system
(For further information on custom izing settings using the Display
Audio system, refer to the “Dis play Audio System Owner’s Man-
ual”.)
Vehicles with a navigation syst em: Settings that can be changed
using the navi gation system
(For further information on cust omizing settings using the naviga-
tion system, refer to the “Navig ation System Owner’s Manual”.)
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available, — = Not available
Your vehicle includes a variety of electronic features that can be per-
sonalized to suit your prefer ences. Programming these preferences
requires specialized equipment and may be performed by your
Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

494 6-2. Customization
ItemFunctionDefault set-tingCustomizedsetting
Smart key
system
*1
and wire-
less remote
control
(
P. 32,
46) Operation sig-
nal
(Emergency
flashers)
On Off — O O
Operation sig-
nal
(Buzzer) On Off — — O
Operation
buzzer volume Level 5 Off to level 7 O O O
Time elapsed
before auto-
matic door lock
function is acti-
vated if door is
not opened
after being
unlocked 60 seconds
Off
—O O
30 seconds
120 seconds
Open door
warning buzzer On Off — — O
Smart key
system
*1
(
P. 32) Smart key sys-
tem
On Off — — O
Number of per-
missible times
of continuous
smart lock Twice Unlimited — — O

495
6-2. Customization
6
Vehicle specifications
Wireless
remote
control
(
P. 4 6 )
Wireless
remote control
On Off — — O
Unlocking
operation Driver's door
unlocked in
one step, all doors
unlocked in two steps All doors
unlocked in one step. OOO
Panic function On Off — — O
Trunk unlock-
ing operation Press and
hold (short) Off
—— O
Press twice
One short press
Press and
hold (long)
ItemFunctionDefault set- tingCustomizedsetting

496 6-2. Customization
Door lock
(
P. 52)Unlocking
using a key
Driver's door
unlocked in
one step, all doors
unlocked in two steps All doors
unlocked in one step. —O O
Speed-detect-
ing automatic
door lock func-
tion Off On OOO
Opening
driver's door
unlocks all
doors Off On — O O
Shifting gears
to P unlocks all
doors. On Off OOO
Shifting gears
to position
other than P
locks all doors. On Off OOO
Automatic
light con-
trol sys-
tem
*1
(
P. 185) Light sensor
sensitivity
Level 3 Level 1 to 5 O O O
Time elapsed
before head-
lights automati-
cally turn off
after doors are
closed 30 seconds
0 seconds
OOO
60 seconds
90 seconds
Lights
(
P. 185) Daytime run-
ning light sys-
tem (except
Canada)
On Off OOO
ItemFunctionDefault set-
tingCustomizedsetting

497
6-2. Customization
6
Vehicle specifications
Illumination
(
P. 285)
Time elapsed
before lights
turn off
15 seconds Off
—O O
7.5 seconds
30 seconds
Operation
when the doors
are unlocked On Off — — O
Vehicles with-
out smart key
system: Opera-
tion after the
engine switch
turned to the
“LOCK” posi-
tion
Vehicles with
smart key sys-
tem: Operation
after the
“ENGINE
START STOP”
switch turned
off On Off — — O
Operation
when you
approach the
vehicle with the
electronic key
on your per-
son
*2
On Off — — O
Seat belt
reminder
(
P. 423) Vehicle speed
linked seat belt
reminder
buzzer
On Off — — O
ItemFunctionDefault set-
tingCustomizedsetting

498 6-2. Customization
*1: If equipped
*2: Vehicles with a smart key system
Automatic
air condi-
tioning sys-
tem
*1
(
P. 233) Switching
between out-
side air and
recirculated air
mode linked to
“AUTO” switch
operation
Auto Manual — O O
A/C auto switch
operation Auto Manual — O O
Power win-
dow
(driver’s
door) &
moon
roof
*1
(
P. 81,
84) Key linked
opening
Off On — — O
Wireless
remote control
linked opening Off On — — O
Key linked clos-
ing Off On — — O
Wireless
remote control
linked opening
buzzer On Off — — O
Moon
roof
*1
( P. 84) Linked opera-
tion of compo-
nents when
door key is
used
Slide only Tilt only
—— O
Linked opera-
tion of compo-
nents when
wireless
remote control
is used Slide only Tilt only
—— O
ItemFunctionDefault set-
tingCustomizedsetting

499
6
Vehicle specifications
6-3. Initialization
Items to initialize
ItemWhen to initializeReference
Maintenance data After the maintenance is performed P. 340
Tire pressure warning
system (U.S.A. only) • When changing tire pressure (such
as when changing traveling speed,
load weight, etc.)
• When changing the tire size P. 368
The following items must be initia
lized for normal system operation
after such cases as the battery being reconnected, or maintenance
being performed on the vehicle:
