TOYOTA CAMRY 2018 Owners Manual (in English)

1212. Instrument cluster
2
Instrument cluster
CAMRY_U (01999-06139)
Entune Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu”
screen.
Select “ECO” on the “Informa-
tion” screen.
If the “History” screen is displayed,
select “Trip Information”.
Resetting the consumption data
Average vehicle speed since
the engine was started
Elapsed time since the engine
was started
Fuel consumption in the past 15
minutes
Cruising range (→P. 123)
Current fuel consumption
Vehicles without a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages at tained since the engine switch was
last turned to the “ON” position. Use the displayed average fuel con-
sumption as a reference.
Vehicles with a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages at tained since the engine switch was
last turned to IGNITION ON mode. Use the displayed average fuel
consumption as a reference.
This image is an example only.
1
2
3
1
2
3
4
5
6

1222. Instrument cluster
CAMRY_U (01999-06139)
Entune Audio or Entune Audio Plus (vehicles without Data Commu-
nication Module)
Press the “INFO” button.
If the “Trip Information” screen is displayed, select “History”.
Entune Audio Plus (vehicles with Data Communication Module)
Press the “INFO” button.
Select “ECO” on the “Information” screen.
If the “Trip Information” screen is displayed, select “History”.
Entune Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu” screen.
Select “ECO” on the “Information” screen.
If the “Trip Information” screen is displayed, select “History”.
Resetting the past record data
Best recorded fuel consumption
Current fuel economy
Previous fuel consumption
record
Entune Audio and Entune
Audio Plus
Displays the daily average fuel consumption. (Instead of the date,
“Trip 1” through “Trip 5” will be displayed.)
Entune Premium Audio
Displays the daily average fuel consumption. Updating the average fu el consumption data
The average fuel consumption history is divided by color into past
averages and the average fuel cons umption since the last updated.
Use the displayed average fuel consumption as a reference.
This image is an example only.
History
1
2
1
2
3
1
2
3
4
5

1232. Instrument cluster
2
Instrument cluster
CAMRY_U (01999-06139)
■Updating the past record data
Update the average fuel consumption by selecting “Clip” to measure the cur-
rent fuel consumption again.
■ Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.
■ Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.

1242. Instrument cluster
CAMRY_U (01999-06139)

125
3
Operation of
each component
CAMRY_U (01999-06139) 3-1. Key information
Keys .................................. 126
3-2. Opening, closing and locking the doors
Doors ................................ 135
Trunk ................................. 144
Smart key system ............. 149
3-3. Adjusting the seats Front seats ........................ 158
Rear seats......................... 160
Head restraints.................. 162
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 164
Inside rear view mirror ...... 166
Outside rear view mirrors ............................. 168
3-5. Opening and closing the windows
Power windows ................. 170
Moon roof .......................... 174
Panoramic moon roof........ 178

126
CAMRY_U (01999-06139)
3-1. Key information
The following keys are provided with the vehicle.
Vehicles without a smart key system
Keys
Operating the wireless remote con-
trol function (→P. 127)
Key number plate
Vehicles with a smart key system
Electronic keys
• Operating the smart key system
(→P. 149)
• Operating the wireless remote control function ( →P. 127)
Mechanical keys
Key number plate
Keys
The keys
1
2
1
2
3

1273-1. Key information
3
Operation of each component
CAMRY_U (01999-06139)
Vehicles without a smart key system
Locks all the doors (→P. 136)
Unlocks all the doors ( →P. 136)
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Opens the windows*2 and the
moon roof
*1, 2 ( → P. 136)
Opens the trunk ( →P. 145)
Sounds the alarm ( →P. 129)
*1: If equipped
*2: This setting must be customized at your Toyota dealer.
Vehicles with a smart key system
Locks all the doors ( →P. 136)
Unlocks all the doors ( →P. 136)
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Opens the windows*2 and the
moon roof
*1, 2 or panoramic
moon roof
*1, 2 ( → P. 136)
Opens the trunk ( →P. 145)
Sounds the alarm ( →P. 129)
*1: If equipped
*2: This setting must be customized at your Toyota dealer.
Wireless remote control
1
2
3
4
5
1
2
3
4
5

1283-1. Key information
CAMRY_U (01999-06139)
Releasing
To release the key, press the but-
ton.
Folding
To stow the key, press the button
then fold the key.
To take out the mechanical key,
slide the release lever and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and re-
attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electronic key bat-
tery is depleted or the entry function does not operate properly, you will
need the mechanical key. (→P. 526)
Using the key (vehicles without a smart key system)
1
2
Using the mechanical key (vehic les with a smart key system)

1293-1. Key information
3
Operation of each component
CAMRY_U (01999-06139)
■Panic mode
Vehicles without a smart key system
Vehicles with a smart key system
■ When required to leave the vehicle’s key with a parking attendant (vehi-
cles with a smart key system)
Lock the glove box as circumstances demand. ( →P. 374)
Remove the mechanical key for your own use and provide the attendant with
the electronic key only. When is pressed for longer than
about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.
When is pressed for longer than
about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

1303-1. Key information
CAMRY_U (01999-06139)■
If you lose your keys
New genuine keys can be made by your Toyota dealer using the other key
(vehicles without a smart key system) or the other mechanical key (vehicles
with a smart key system) and the key number stamped on your key number
plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
■ When riding in an aircraft
When bringing a key with wireless remote control function onto an aircraft,
make sure you do not press any button on the key while inside the aircra\
ft
cabin. If you are carrying the key in your bag etc., ensure that the buttons are
not likely to be pressed accidentally. Pressing a button may cause the key to
emit radio waves that could interfere with the operation of the aircraft.
■ Conditions affecting operation
Vehicles without a smart key system
The wireless remote control function may not operate normally in the follow-
ing situations:
● When the wireless key battery is depleted
● Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise
● When carrying a portable radio, cellul ar phone or other wireless communi-
cation devices
● When the wireless key is in contact with, or is covered by a metallic object
● When other wireless key (that emit radio waves) is being used nearby
● If window tint with a metallic content or metallic objects are attached to the
rear window
Vehicles with a smart key system
→P. 151
