TOYOTA CAMRY 2021 Owners Manual (in English)

1312. Instrument cluster
2
Instrument cluster
CAMRY_U
NOTICE
■To prevent damage to components
■ When changing the settings of the head-up display
To prevent battery discharge, ensure that the engine is running while the
changing the settings of the head-up display.
● Do not place any drinks near the head-
up display projector. If the projector gets
wet, electrical malfunctions may result.
● Do not place anything on or put stickers
onto the head-up display projector.
Doing so could interrupt head-up dis-
play indications.
● Do not touch the inside of the head-up
display projector or thrust sharp edges
or the like into the projector.
Doing so could cause mechanical mal-
functions.

1322. Instrument cluster
CAMRY_U
Audio (vehicles without Data Communication Module) or Audio
Plus (vehicles without Data Communication Module)
Press the “MENU” button.
Select “Info” on the “Menu”
screen.
If the “History” screen is displayed,
select “Trip Information”.
Fuel consumption information
Fuel consumption information can be displayed on the audio
system screen.
Trip information
1
2

1332. Instrument cluster
2
Instrument cluster
CAMRY_U
Audio (vehicles with Data Communication Module), Audio Plus
(vehicles with Data Communicat ion Module) and Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu”
screen.
Select “ECO” on the “Informa-
tion” screen.
If the “History” screen is displayed,
select “Trip Information”.
Resetting the consumption data
Average vehicle speed since
the engine was started
Elapsed time since the engine
was started
Fuel consumption in the past 15
minutes
Cruising range ( P. 135)
Current fuel consumption
Vehicles without a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last turned to the “ON” position. Use the displayed average fue l con-
sumption as a reference.
Vehicles with a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last turned to IGNITION ON mode. Use the displayed average fuel
consumption as a reference.
This image is an example only.
1
2
3
1
2
3
4
5
6

1342. Instrument cluster
CAMRY_U
Audio (vehicles without Data Communication Module) or Audio
Plus (vehicles without Data Communication Module)
Press the “MENU” button.
Select “Info” on t he “Menu” screen.
If the “Trip Information” screen is displayed, select “History” .
Audio (vehicles with Data Communication Module), Audio Plus
(vehicles with Data Communicat ion Module) and Premium Audio
Press the “MENU” button.
Select “Info” on t he “Menu” screen.
Select “ECO” on the “Information” screen.
If the “Trip Information” screen is displayed, select “History” .
Resetting the past record data
Best recorded fuel consumption
Current fuel economy
Previous fuel consumption
record
Audio and Audio Plus
Displays the daily average fuel
consumption. (In stead of the date,
“Trip 1” through “Trip 5” will be dis-
played.)
Premium Audio
Displays the daily average fuel consumption. Updating the average fuel consumption data
The average fuel consumption histo ry is divided by color into past
averages and the average fuel co nsumption since the last updated.
Use the displayed average fuel consumption as a reference.
This image is an example only.
History
1
2
1
2
3
1
2
3
4
5

1352. Instrument cluster
2
Instrument cluster
CAMRY_U
■Updating the past record data
Update the average fuel consumption by selecting “Clip” to meas ure the cur-
rent fuel consumption again.
■ Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.
■ Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumptio n.
As a result, the actual distance that can be driven may differ from that dis-
played.

1362. Instrument cluster
CAMRY_U

137
3
Operation of
each component
CAMRY_U 3-1. Key information
Keys .................................. 138
3-2. Opening, closing and locking the doors
Doors ................................ 147
Trunk ................................. 156
Smart key system ............. 161
3-3. Adjusting the seats Front seats ........................ 169
Rear seats......................... 171
Head restraints.................. 173
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 175
Inside rear view mirror ...... 177
Outside rear view mirrors ............................. 179
3-5. Opening and closing the windows
Power windows ................. 181
Moon roof .......................... 185
Panoramic moon roof........ 189

138
CAMRY_U
3-1. Key information
The following keys are provided with the vehicle.
Vehicles without a smart key system
Keys
Operating the wireless remote con-
trol function (P. 139)
Key number plate
Vehicles with a smart key system
Electronic keys
• Operating the smart key system
(P. 161)
• Operating the wireless remote control function ( P. 139)
Mechanical keys
Key number plate
Keys
The keys
1
2
1
2
3

1393-1. Key information
3
Operation of each component
CAMRY_U
Vehicles without a smart key system
Locks all the doors (P. 1 4 8 )
Unlocks all the doors ( P. 1 4 8 )
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Opens the windows*1 and the
moon roof
*1, 2 (  P. 148)
Opens the trunk ( P. 1 5 7 )
Sounds the alarm ( P. 141)
*1: This setting must be customized at your Toyota dealer.
*2: If equipped
Vehicles with a smart key system
Locks all the doors ( P. 1 4 8 )
Unlocks all the doors ( P. 1 4 8 )
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Opens the windows*1 and the
moon roof
*1, 2 or panoramic
moon roof
*1, 2 (  P. 148)
Opens the trunk ( P. 1 5 7 )
Sounds the alarm ( P. 141)
*1: This setting must be customized at your Toyota dealer.
*2: If equipped
Wireless remote control
1
2
3
4
5
1
2
3
4
5

1403-1. Key information
CAMRY_U
Releasing
To release the key, press the but-
ton.
Folding
To stow the key, press the button
then fold the key.
To take out the mechanical key,
slide the release lever and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and re-
attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electro nic key bat-
tery is depleted or the entry function does not operate properl y, you will
need the mechanical key. ( P. 569)
Using the key (vehicles without a smart key system)
1
2
Using the mechanical key (vehic les with a smart key system)
