1112. Instrument cluster
2
Instrument cluster
WARNING
■Caution for use while driving
● When operating the multi-information di splay while driving, pay extra
attention to the safety of the area around the vehicle.
● Do not look continuously at the multi-information display while driving as
you may fail to see pedestrians, objects on the road, etc. ahead of the
vehicle.
■ The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.
■ Cautions during setting up the display
As the hybrid system needs to be running during setting up the display,
ensure that the vehicle is parked in a place with adequate ventilation. In a
closed area such as a garage, exhaust gases including harmful carbon
monoxide (CO) may collect and enter the vehicle. This may lead to death or
a serious health hazard.
NOTICE
■While setting up the display
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while setting up the display features.

1122. Instrument cluster
The multi-information display presents the driver with a variety of driv-
ing-related data, such as the curr ent outside temperature. The multi-
information display can also be used to change the display settings
and other settings.
Indicators ( →P. 90)
Dynamic radar cruise control with full-speed range/LDA (Lane
Departure Alert with steering control) display area
Displays the operational status of the following systems: • Dynamic radar cruise control with full-speed range ( →P. 270)
• LDA (Lane Departure Alert with steering control) ( →P. 260)
Speed limit display (vehicles with a navigation system)
Speedometer
The speedometer display can be enabled/disabled in on the multi-
information display. ( →P. 119)
Content display area
A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.
• Menu icon content ( →P. 114)
• Suggestion function ( →P. 125)
• Warning message ( →P. 490)
Multi-information disp lay (7-inch display)
Summary of functions
1
2
3
4
5

1132. Instrument cluster
2
Instrument cluster
Odometer/trip meter (→P. 125)
Shift position (→ P. 213)
Outside temperature ( →P. 9 6 )
Menu icons ( →P. 11 4 )
“ODO/TRIP” switch ( →P. 113)
Meter control switches ( →P. 1 1 3 )
◆Using the content display area
The content display area is op erated using the meter control
switches.
Scroll screens
*, change the
displayed content
* and move
the cursor
Press: Enter/Set
Press and hold: Reset/Dis-
play the next screen
Return to the previous
screen
Pressing and holding the switch will display the first screen of the
selected menu icon.
*: When the screen can be scrolled or different content can be displayed, a mark, such as an arrow, will be displayed to suggest which switch to
operate.
◆Using the odometer/trip meter
Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item
Each time the switch is pressed,
the displayed item will be
changed.
Press and hold: Reset
Display the desired trip meter
and press and hold the switch to
reset the trip meter.
Using the multi-information display
6
7
8
9
10
11
1
2
3

1142. Instrument cluster
Select a menu icon to display its content.Warning message display ( →P. 490)
This menu icon will be displayed only when a warning message can be
displayed.
Select to display warning messages and measures to be taken if a mal-
function is detected.
Eco-friendly drivin g information (→P. 1 1 5 )
Select to display fuel consumption data in various forms.
Driving assist sy stem information
Select to perform the following:
Display the operational status of the following systems:
• Dynamic radar cruise control with full-speed range ( →P. 270)
• LDA (Lane Departure Alert with steering control) ( →P. 260)
Display the following navigation system-linked information (if equipped): • Route guidance
• Compass display (heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the meter
using the meter control switches.
Vehicle information
Select to perform the following:
Display the following information:• Energy monitor ( →P. 135)
• Tire inflation pressure ( →P. 429)
Enable/Disable the following systems: • Intuitive parking assist (if equipped) ( →P. 304)
• BSM (Blind Spot Monitor) function (if equipped) ( →P. 290)
• RCTA (Rear Cross Traffic Aler t) function (if equipped) (→P. 290)
This function can also be enabled/disabled on .
Settings display ( →P. 119)
Select to change the meter display settings and other settings.
Menu icons

1152. Instrument cluster
2
Instrument cluster
■Fuel consumptionCurrent fuel consumption
Displays the instantaneous cur-
rent fuel consumption.
Average fuel economy (after
start)
Displays the average fuel con-
sumption since hybrid system
start.
*1
Driving range
Displays the driving range with remaining fuel.*2, 3
Gadget*4
The following items can be displayed by changing the settings for gad-
get content and fuel economy type on . ( →P. 119)
Eco-friendly driving information ( )
1
2
3
4
Displayable item
ContentGadget
contentFuel economy
type
Average
vehicle
speed Trip
(after start)
Displays the average vehicle speed since
hybrid system start.
To t a l
(after reset)Displays the average vehicle speed since the
display was reset.
*5
Distance
Trip
(after start)Displays the distance driven since vehicle
start.
To t a l
(after reset)Displays the distance driven since the display
was reset.
*5
Elapsed
time
Trip
(after start)Displays the elapsed time since hybrid system
start.
To t a l
(after reset)Displays the elapsed time since the display
was reset.
*5

1162. Instrument cluster
Average fuel economy
Displayed item (listed below) can be changed on the fuel economy type
screen of . (→P. 119)
●Total (after reset)
Displays the average fuel consumption since the display was reset.*1, 5
●Tank (after refuel)
Displays the average fuel consumption since the vehicle was refu-
eled.
*1, 2
*1: Use the displayed fuel consumption as a reference only.
*2: When only a small amount of fuel is added to the tank, the display may
not be updated.
When refueling, turn the power switch off. If the vehicle is refueled with-
out turning the power switch off, the display may not be updated.
*3: This distance is computed based on your average fuel consumption. Asa result, the actual distance that can be driven may differ from that dis-
played.
*4: The default setting is no display.
*5: This display can be reset by pressing and holding while it is dis-played.
5

1172. Instrument cluster
2
Instrument cluster
■Eco guide
The Eco guide displays a guide for eco-friendly acceleration and
scores which represent an evaluation of how the vehicle has been
driven ecologically in different states.
ECO Accelerator Guidance
Eco score
● ECO Accelerator Guidance
Eco area
Indicates that the vehicle is
being driven in an Eco-friendly
manner.
Power area
Indicates that the Eco-friendly
driving range is being exceeded
(during full power driving, etc.)
Eco driving ratio based on acceleration
Zone of Eco acceleration
Suggests a range in which Eco-friendly acceleration can be performed.
The zone of Eco acceleration changes according to situations, such as
starting off or cruising.
Eco-friendly acceleration can be achieved by keeping the Eco driving
ratio based on acceleration bar within the zone of Eco acceleration.
(→P. 191)
1
2
1
2
3
4

1182. Instrument cluster
●Eco score
The following 3 Eco driving methods are evaluated in 5 levels:
Smooth start-off acceleration, driving without sudden acceleration,
and smooth stopping. When the vehi cle is stopped, an Eco score
out of 100 points will be displayed.
Eco start status
Eco cruise status
Eco stop status
Score result
How to read the bar display:
• After the hybrid system is star ted, the Eco score will not be dis-
played until the vehicle speed exceeds approximately 12 mph
(20 km/h).
• The Eco score will be reset ea ch time the hybrid system is
started.
• When the hybrid system is stopped, the total score of the current trip will be displayed.
1
2
3
4
Not yet evaluatedLowHigh

1192. Instrument cluster
2
Instrument cluster
◆Changing settings
Use the meter control switches on the steering wheel to change
settings.Press or to select .
Operate the switches to select a desired item.
Press or press and hold .
The available settings will differ depending on if is pressed or
pressed and held. Follow the instructions on the display.
◆Setting items
■ LDA (Lane Departure Alert with steering control) ( →P. 260)
Press and hold to change the settings of the following items:
Settings display ( )
1
2
3
ItemSettingsDetails
Steering assist On
Select to enable/disable steering
wheel assistance.
Off
Alert sensitivityHighSelect to set the warning sensi-
tivity.
Normal
Sway warningOnSelect to enable/disable the vehi-
cle sway warning.
Off
Sway sensitivity
High
Select to set the vehicle sway
warning sensitivity.Medium
Low

1202. Instrument cluster
■ PCS (Pre-Collision System) (→P. 249)
Press and hold to change the settings of the following items:
■ BSM (Blind Spot Monitor) (if equipped) ( →P. 290)
Press to enable/disable the Blind Spot Monitor function.
Press and hold to change the se ttings of the following item:
ItemSettingsDetails
PCS On
Select to enable/disable the pre-
collision system.
Off
Warning sensitivitySelect to change the warning
timing.
ItemSettingsDetails
BSM On
Select to enable/disable the
Blind Spot Monitor function.
Off
ItemSettingsDetails
Outside rear view
mirror indicator
brightness Bright Select to change the brightness
of the outside rear view mirror
indicators.
Dim
