TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±14
392
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
TypeFOG±LP
MaleFemale
Sleeve : Medium (Blue) or
Large (Yellow)
P/N82998±24210
TypeFTC
MaleFemale
Sleeve : Medium (Blue) or
Large (Yellow)
P/N82998±12510
TypeHEAD LAMP
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±24140(160mm) 82998±24200(500mm)

F±15
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
393
Repair Wire (Non±waterproof Type)
TypeLAC
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±1210082998±12110
TypeMFPC
MaleFemale
Sleeve : Medium (Blue)
P/N82998±12150
TypeMIC
MaleFemale
Sleeve : Medium (Blue) or
Large (Yellow)
P/N82998±12120

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±16
394
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
TypePULSE LOCK
Female (Power)Female (Signal)
P/N82998±1220082998±12210
TypeSFPC
MaleFemale
Sleeve : Medium (Blue)
P/N82998±24180
TypeSL
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±12130

F±17
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
395
Repair Wire (Non±waterproof Type)
TypeSP
Female (Power)Female (Signal)
Sleeve : Medium (Blue) or Large (Yellow)Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±1252082998±12530
TypeTLC
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1222082998±12230
TypeTNS
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1224082998±12250

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±18
396
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
TypeTODC
MaleFemale
Sleeve : Medium (Blue) or
Large (Yellow)Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±1208082998±12090

G±1
APPENDIX±WIRE HARNESS REPAIR KIT WITH CASE
Wire Harness Repair Manual (RM1022E)
397
WIRE HARNESS REPAIR KIT WITH CASE (REFERENCE ONLY)
We would like to recommend to you use of the ºWire Harness Repair Kit with the Caseº
according to your after service market demand.
Example:
or
[portable type] [stationary type]
Remark: This kind of kit is not available from Toyota Motor Corporation.
G

APPENDIX±REPORTING OF WIRE HARNESS PROBLEM
G±2
398
Wire Harness Repair Manual (RM1022E)
REPORTING OF WIRE HARNESS PROBLEM
It is more difficult to understand the cause of wire harness problems and to make
production improvements, due to the number of wire harness routings and connectors and
their wide scope of use.
The position of the problem occurrence and the problem cause will be very clear if you
proceed with wire harness/connector repairs.
We request that when you perform repairs, you fill in the attached ºWIRE
HARNESS/CONNECTOR PROBLEM CHECK SHEETº and send it to your distributor.
Toyota Motor Corporation will be able to make production improvements more quickly and
surely based on the results of the above mentioned reports (Check Sheets).
G

G±3
APPENDIX±REPORTING OF WIRE HARNESS PROBLEM
Wire Harness Repair Manual (RM1022E)
399
G

APPENDIX±REPORTING OF WIRE HARNESS PROBLEM
G±4
400
Wire Harness Repair Manual (RM1022E)
G

G±5
APPENDIX±REPORTING OF WIRE HARNESS PROBLEM
Wire Harness Repair Manual (RM1022E)
401
