TOYOTA CAMRY V20 1986 Service Information

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±4
382
Wire Harness Repair Manual (RM1022E)
Repair Wire (Waterproof Type)
Type6.3II
MaleFemale
Sleeve : Medium (Blue)
P/N82998±24160
Type8.0
MaleFemale
Sleeve : Large (Yellow)Sleeve : Large (Yellow)
P/N82998±1249082998±12500
TypeHEAD LAMP
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±24150(160mm) 82998±24190(500mm)
F

F±5
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
383
Repair Wire (Waterproof Type)
TypeHB3, HB4
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±12550(160mm) 82998±12610(500mm)
TypeTLC
MaleFemale
Sleeve : Small (Red)Sleeve : Small (Red)
P/N82998±1228082998±12290
F

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±6
384
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
Type0.64
MaleFemale
Sleeve : Medium (Blue)
P/N82998±12750
82998±12760*
Type0.64 IDC
MaleFemale
Sleeve : Medium (Blue)
P/N82998±12770
Type1.0
MaleFemale
Sleeve : Medium (Blue)
P/N82998±12310
82998±12320*
F

F±7
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
385
Repair Wire (Non±waterproof Type)
Type1.0II
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
Size : S
P/N82998±2401082998±24020
82998±24110*
Type1.0II
MaleFemale
Sleeve : Medium (Blue)
Size : M
P/N82998±24120*
Type1.0III
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±12670
82998±12680*82998±12690
82998±12700*
F

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±8
386
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
Type1.0III IDC
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1266082998±12640
Type1.0IV
MaleFemale
Sleeve : Medium (Blue)
P/N82998±12740
Type1.3
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1241082998±12420
F

F±9
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
387
Repair Wire (Non±waterproof Type)
Type1.8
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1218082998±12190
82998±12300*
Type1.8II
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)
Size : S, MSleeve : Medium (Blue) or Large (Yellow)
Size : S, M
P/N82998±24090
82998±24130*82998±24100
Type1.8II
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)
Size : LSleeve : Medium (Blue) or Large (Yellow)
Size : L
P/N82998±2403082998±24040
F

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±10
388
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
Type2.3
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±12160
82998±24050*82998±12170
Type2.3II
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±12330
82998±12350*82998±12340
82998±12360*
Type2.3II IDC
MaleFemale
Sleeve : Medium (Blue)
P/N82998±24220
F

F±11
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
389
Repair Wire (Non±waterproof Type)
Type4.8
MaleFemale
Sleeve : Large (Yellow)Sleeve : Large (Yellow)
P/N82998±1237082998±12380
Type6.3
MaleFemale
Sleeve : Large (Yellow)Sleeve : Large (Yellow)
P/N82998±1205082998±12060(160mm) 82998±12580(500mm)
Type6.3
MaleFemale
Sleeve : Large (Yellow)
P/N82998±12070

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±12
390
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
Type6.3II
MaleFemale
Sleeve : Large (Yellow)
P/N82998±24170
Type7.7 Terminal Lance
MaleFemale
Sleeve : Large (Yellow)Sleeve : Large (Yellow)
P/N82998±1201082998±12020
Type7.7 Housing Lance
MaleFemale
Sleeve : Large (Yellow)Sleeve : Large (Yellow)
P/N82998±1203082998±12040

F±13
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
391
Repair Wire (Non±waterproof Type)
Type8.0
MaleFemale
Sleeve : Large (Yellow)Sleeve : Large (Yellow)
P/N82998±1239082998±12400
TypeBLADE FUSE
MaleFemale
Sleeve : Large (Yellow)
P/N82998±12140
TypeC±Type
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1256082998±12570
