Page 401 of 620
401
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12J84U)
6-2. Using the interior lights
Front interior light/personal lights (P. 402)
Rear interior light ( P. 403)
Engine switch light (vehicles with a smart key system)
Interior li ghts list
1
2
3
Page 402 of 620
4026-2. Using the interior lights
COROLLA_TMMMS_TMMC_U (OM12J84U)n
Front interior light
Off
Door position
On
nPersonal lights
When a light is on due to its door link switch, the light will not turn off
even if the lens or switch is pressed.
Front interior light/personal lights
Ty p e AType B
1
2
3
Ty p e AType B
On/off On Off
1
2
Page 403 of 620

4036-2. Using the interior lights
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12J84U)
On
Door position
Off
nIlluminated entry system
Vehicles without a smart key system
When the interior light switch is in the door position, the interior light automat-
ically turns on/off according to the engine switch position, whether the doors
are locked/unlocked and whether the doors are open/closed.
Vehicles with a smart key system
When the interior light switch is in the door position, the interior light and
engine switch light automatically turn on/off according to engine switch mode,
the presence of the electronic key, whether the doors are locked/unlocked
and whether the doors are open/closed.
n To prevent battery discharge
The following lights will go off automatically after 20 minutes:
lFront interior light/personal lights
l Rear interior light
l Trunk light
n Customization
Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 576)
Rear interior light
1
2
3
Page 404 of 620
404
COROLLA_TMMMS_TMMC_U (OM12J84U)
6-3. Using the storage features
List of storage features
Glove box ( P. 405)
Bottle holders ( P. 406) Console box (
P. 405)
Cup holders ( P. 407)
CAUTION
nItems that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
lGlasses may be deformed by heat or cracked if they come into contact
with other stored items.
l Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
n When driving or when the storag e compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4
Page 405 of 620
4056-3. Using the storage features
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12J84U)
Pull up the lever to open the glove
box.
Console box
Lift the lid while pulling up the
knob on the right side.
Upper level box
Lift the lid while pulling up the
knob on the left side.
Glove box
Console box
Page 406 of 620
4066-3. Using the storage features
COROLLA_TMMMS_TMMC_U (OM12J84U)n
Front
nRear
n
When using the holder as a bottle holder
lWhen storing a bottle, close the cap.
l The bottle may not be stored depending on its size or shape.
Bottle holders
CAUTION
n Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
nItems that should not be st owed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glass or paper cups containing liquid. The contents may spill
and glass cups may break.
Page 407 of 620
4076-3. Using the storage features
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12J84U)n
Front
nRear
Cup holders
With console boxWith armrest (if equipped)
Pull the lid to open. Pull the armrest down.
Page 408 of 620
4086-3. Using the storage features
COROLLA_TMMMS_TMMC_U (OM12J84U)
nAdjusting the size of the cup holder (front)
n Removing the cup holder insert (front)Remove the cup holder insert.
Change the cup holder insert position.
The cup holder insert may be removed for
cleaning.
CAUTION
n Items unsuitable for the cup holders
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.
1
2
Page 409 of 620
409
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12J84U)
6-4. Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
Slide the cover.
The clock can be adjusted. Adjusts the hours
Adjusts the minutes
Rounds to the nearest hour*
*: e.g.1:00 to 1:29 1:00
1:30 to 1:59 2:00
Other interior features
Sun visors
1
2
Vanity mirrors
Clock
1
2
3
Page 410 of 620
4106-4. Other interior features
COROLLA_TMMMS_TMMC_U (OM12J84U)
The temperature display shows temperatures within the range of -40F
(-40 C) to 122 F (50C).
n The outside temperature is displayed when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
n Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
lWhen the vehicle is stopped, or moving at low speeds (less than 9 mph [15
km/h]).
l When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
n When “-- F” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Outside temperature display
Ty p e AType B
Ty p e CType D
