TOYOTA COROLLA HATCHBACK 2019 Accessories, Audio & Navigation (in English)

2118-3. What to do if...
COROLLA_H/B_Navi_U
8
Phone
■Connection confirmation
display on this system is
set to on.
To turn off the display, set con-
nection confirmation display on
this system to off. ( P.46)
*: The engine switch is in ACC or
ON.
■The cellular phone is not
close enough to this sys-
tem.
Bring the cellular phone closer
to this system.
■Radio interference has
occurred.
Turn off Wi-Fi
® devices or other
devices that may emit radio
waves.
■The cellular phone is the
most likely cause of the
symptom.
Turn the cellular phone off,
remove and reinstall the battery
pack, and then restart the cellu-
lar phone.
Enable the cellular phone’s
Bluetooth
® connection.
Disable the Wi-Fi
® connection of
the cellular phone.
Stop the cellular phone’s secu-
rity software and close all appli-
cations.
Before using an application
installed on the cellular phone,
carefully check its source and
how its operation might affect
this system.
●For details, refer to the owner’s
manual that came with the cellular
phone.
In other situations
The Bluetooth
® connection
status is displayed at the top
of the screen each time the
system is activated
*.
Even though all conceivable
measures have been taken,
the symptom status does not
change.

2128-3. What to do if...
COROLLA_H/B_Navi_U

213
COROLLA_H/B_Navi_U
9
9
Toyota Entune
Toyota Entune
.9-1. Toyota Entune overviewFunctional overview .... 214
Type A: Function achieved by using a smart phone or
DCM .......................... 216
Type B: Function achieved by using DCM and the sys-
tem ............................ 220
Type C: Function achieved by using DCM............ 222
Type D: Function achieved by using DCM and a smart
phone ........................ 224
9-2. Toyota Entune operation Toyota Entune App Suite Connect ......... ............226
Toyota Entune Destinations .................................. 230
9-3. Setup Toyota Entune App Suite Connect settings ....... 232

2149-1. Toyota Entune overview
COROLLA_H/B_Navi_U
9-1.Toyota Entune overview
The functions included in
Toyota Entune are classified
into the following four types.
• Type A: Function achieved by
using a smart phone or an
embedded cellular device in the
vehicle (DCM: Data Communica-
tion Module) and the system
• Type B: Function achieved by using DCM and the system
• Type C: Function achieved by using DCM
• Type D: Function achieved by using DCM and a smart phone
●Availability of functions of the
Toyota Entune is dependent on
network reception level.
●Each function is a vailable in the
following areas:
• Toyota Entune App Suite Connect is available in the contiguous
United States, Washington D.C.,
Alaska, Hawaii, Puerto Rico and
Canada.
• Toyota Entune App Suite Connect is not available in the United
States Virgin Islands.
• Destination Assist Connect is available in the contiguous United
States, Washington D.C., Puerto
Rico, Hawaii, Canada, and limited
areas of Alaska for vehicles that
contain the appropriate map data.
• Destination Assist Connect is not available in the United States Vir-
gin Islands.
• Dynamic Navigation is available in the contiguous United States,
Washington D.C. and Alaska.
• Dynamic Navigat ion is not avail-
able in Puerto Rico, Canada, and
in the United States Virgin Islands.
•Wi-Fi
® Hotspot is available in the
contiguous United States, Wash-
ington D.C., Alaska and Hawaii.
•Wi-Fi
® Hotspot is not available in
Puerto Rico, Can ada, and in the
United States Virgin Islands.
Functional over view
Toyota Entune is a service
that includes Toyota Entune
App Suite Connect, Destina-
tion Assist Connect, Toyota
Entune Service Connect,
Dynamic Navigation, Wi-Fi
®
Hotspot, Safety Connect,
and Toyota Entune Remote
Connect.
Functional overview
FunctionTy p e
Toyota Entune App
Suite ConnectType A
Destination Assist Con-
nect, Dynamic Naviga-
tion, Wi-Fi
® Hotspot
Type B
Safety ConnectTy p e C
Toyota Entune Remote
Connect, Toyota
Entune Service Con-
nect
Ty p e D
FunctionTy p e

2159-1. Toyota Entune overview
COROLLA_H/B_Navi_U
9
Toyota Entune
• Safety Connect features include: Automatic Collision Notification,
Emergency Assistance, S.O.S,
Stolen Vehicle Location (available
in the contiguous United States,
Washington D.C., Hawaii, Alaska,
Puerto Rico and Canada) and
Enhanced Roadside Assistance
(available in the contiguous
United States, Wa shington D.C.,
Alaska, Puerto Rico and Canada).
• Safety Connect is not available in
the United States Virgin Islands.
• Toyota Entune Remote Connect is available in the contiguous United
States, Washington D.C. and
Alaska.
• Toyota Entune Remote Connect is
not available in P uerto Rico, Can-
ada, and in the United States Vir-
gin Islands.
• Toyota Entune Service Connect is available in the contiguous United
States, Washington D.C., and
Alaska.
• Toyota Entune Service Connect is not available in P uerto Rico, Can-
ada, and the United States Virgin
Islands.

2169-1. Toyota Entune overview
COROLLA_H/B_Navi_U
Content provider
Type A: Function achieved by using a smar t
phone or DCM
Of the functions included with Toyota Entune, the Toyota
Entune App Suite Connect relies on the use of a smart phone
or DCM.
 Using a smart phone
• Toyota Entune App Suite Connect enables applicable apps
installed on a smart phone to be displayed on and operated from
the screen via a Bluetooth
®.
 Via DCM
• Toyota Entune App Suite Connect enables applicable apps
installed on the system to be displayed on and operated from th e
screen.
A few settings must be performed before Toyota Entune App
Suite Connect can be used. ( P.218)
By using a smart phone or DCM
A

2179-1. Toyota Entune overview
COROLLA_H/B_Navi_U
9
Toyota Entune
Provides contents to the application server.
Application server
Provides applications to the system or a smart phone.
Smart phone
*
Using the Toyota Entune App Su ite Connect, communication is
relayed between the system, application server and contents pro-
vider. The smart phone cannot be operated while communicating.
Applications
Display usable content from the content providers on the screen
using the data connection of t he connected smart phone or DCM.
System
Content received, via a smart phone or DCM, from content pro-
vider servers is displayed on the screen. The system is equippe d
with an application player to run applications.
Via DCM
*: For known compatible phones, refer to http://www.toyota.com/Entune/
in the United States, http://www.toyota.ca/entune
in Canada, and
http://www.toyo tapr.com/entune
in Puerto Rico.
The required operations to acti-
vate applications and connect a
smart phone to the system, and
the registration steps for the
Toyota Entune App Suite Con-
nect are explained in this sec-
tion.
■Subscription
 User registration is required to
start using the Toyota Entune
App Suite Connect function.
( P.218)
 Toyota Entune App Suite
Connect does not require an
activation fee or monthly
recurring fees. 
Services requiring a separate
contract can also be used.
*
*: For details, refer to
http://www.toyota.com/Entune/
or call 1-800-331-4331 in the
United States,
http://www.toyota.ca/entune
or call 1-888-869-6828 in Can-
ada, and
http://www.toyotapr.com/entune
or call 1-877-855-8377 in Puerto
Rico.
B
C
D
E
F
Before using the function

2189-1. Toyota Entune overview
COROLLA_H/B_Navi_U
■Availability of function
 Toyota Entune App Suite
Connect is available in the
contiguous United States,
Washington D.C., Alaska,
Hawaii, Puerto Rico and Can-
ada.
 Toyota Entune App Suite
Connect is not available in the
United States Virgin Islands.
●Data usage fees may apply while
using Toyota Entune App Suite
Connect function. Confirm data
usage fees before using this func-
tion.
●For details regarding operation of
the Toyota Entune App Suite Con-
nect and the applications, refer to
http://www.toyota.com/Entune/
in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyo tapr.com/entune
in Puerto Rico.
●These functions are not made
available in some countries or
areas. Availability of functions of
the Toyota Entune App Suite Con-
nect service is dependent on net-
work reception level.
■Initializing personal data
The personal data used in appli-
cations can be reset. ( P.59)
 The following personal data
can be deleted and returned
to their default settings:
• Downloaded contents
• Radio stations that were listened
to
●Once initialized, the data and set-
tings will be erased. Pay much attention when init
ializing the data.
■Settings required to use
Toyota Entune App Suite
Connect
Perform the settings in the fol-
lowing order.
1 Download the Toyota Entune
App Suite Connect applica-
tion to your smart phone or
the system.
2 Register the smart phone
with the system.
In order to use Toyota Entune App
Suite Connect, the following must
first be performed:
Download the Toyota Entune
App Suite Connect applica-
tion onto your smart phone or
the system, and login to the
application. ( P.218)
 Register the smart phone, on
which the Toyota Entune App
Suite Connect application
was installed, with the sys-
tem. ( P.218)
 Register a Bluetooth
® phone
with the hands-free system.
( P.36)
■Registering the Toyota
Entune App Suite Connect
application
 Registration is optional.
Preparation before using
Toyota Entune App Suite
Connect

2199-1. Toyota Entune overview
COROLLA_H/B_Navi_U
9
Toyota Entune
1 Download the Toyota Entune
App Suite Connect applica-
tion to your smart phone or
the system.
2 Run the Toyota Entune App
Suite Connect application on
your smart phone or the sys-
tem.
3 Enter the information
required into the Toyota
Entune App Suite Connect
application. Login to the
application.
●Applications can only be used
when the Toyota Entune App
Suite Connect application has
been downloaded to your smart
phone or the system, and the
application is running.
●Toyota Entune App Suite Connect
operational procedures can also
be confirmed by visiting
http://www.toyota.com/Entune/
in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyo tapr.com/entune
in Puerto Rico.
●If a Toyota Entune App Suite Con-
nect application is used while iPod
audio/video is being played back,
system operation may become
unstable.

2209-1. Toyota Entune overview
COROLLA_H/B_Navi_U
*: Vehicles with DCM
■Subscription
 After you have signed the Telemati cs Subscription Service Agree-
ment and are enrolled, you can begin receiving services. A vari ety
of subscription terms are available. Contact your Toyota dealer , or
call 1-800-331-4331 in the United States, 1-888-869-6828 in Can -
ada, and 1-877-855-8377 in Puerto Rico, for further subscription
details. ( P.217)
■Availability of functions
 Destination Assist Connect is av ailable in the contiguous United
States, Washington D.C., Puerto Rico, Hawaii, Canada, and lim-
ited areas of Alaska for vehicles that contain the appropriate map
data.
 Destination Assist Connect is not available in the United State s
Virgin Islands.
Type B: Function achiev ed by using DCM and the
system*
The functionality of Destination Assist Connect, Dynamic
Navigation, and Wi-Fi
® Hotspot is made possible through the
shared work of the DCM and the system.
Destination Assist Connect and Dynamic Navigation are sub-
scription-based telematics services that use Global Position-
ing System (GPS) data and embedded cellular technology to
provide safety and security as well as convenience features.
These services are available by subscription on select,
telematics hardware-equipped vehicles and supported by the
Toyota Entune center, which operates 24 hours a day, 7 days
a week.
For details about:
 Dynamic Navigation: P.80, 89, 114
 Wi-Fi
® Hotspot: P. 4 7
Before using the function
