start stop button TOYOTA COROLLA HATCHBACK 2020 Owners Manual (in English)

1484-2. Driving procedures
COROLLA H/B_U
:While the engine switch is in
ON and the brake pedal
depressed
*, shift the shift lever
while pushing the shift release
button on the shift knob.
:Shift the shift lever while
pushing the shift release button
on the shift knob.
:Shift the shift lever normally.
When shifting the shift lever
between P and D, make sure that
the vehicle is completely stopped
and the brake pedal is depressed.
*: For the vehicle be able to be
shifted from P, the brake pedal
must be depresse d before the
shift release button is pushed. If
the shift release button is pushed
first, the shift lock will not be
released.
■Shift lock system
The shift lock syste m is a system to
prevent accidental operation of the
shift lever in starting.
The shift lever can be shifted from P
only when the engi ne switch is in
ON and the brake pedal is being
depressed.
■If the shift lever cannot be
shifted from P
First, check whether the brake pedal
is being depressed.
If the shift lever cannot be shifted
with your foot on the brake pedal,
there may be a p roblem with the
shift lock system. Have the vehicle
inspected by your Toyota dealer
immediately.
The following steps may be used as
an emergency measure to ensure
that the shift lev er can be shifted.
Releasing the shift lock:
1 Set the parking brake.
2 Turn the engine switch off.
3 Depress the brake pedal.
4 Ply the cover up with a flathead
screwdriver or equivalent tool.
To prevent damaging the cover,
wrap the tip of the flathead
screwdriver with a tape.
5 Press and hold the shift lock
override button and then push
the button on the shift knob.
The shift lever can be shifted while
Shifting the shift lever

1494-2. Driving procedures
COROLLA H/B_U
4
Driving
the button is pressed.
 P.240
To drive using temporary shift
range selection, operate the “-”
or “+” paddle shift switch.
When the “-” paddle shift switch
is operated, the shift range
switches to a range that enables
engine braking force that is suit-
able to driving conditions. When
the “+” paddle shift switch is operated, the shift range
switches to a range that is one
range higher than the current
range.
Changing the shift range allows
restriction of the highest gear,
preventing unnecessary upshift-
ing and enabling the level of
engine braking force to be
selected.
1
Upshifting
2 Downshifting
The selected shift range, from D1 to
D10, will be displayed on the
multi-information display.
■Gear step functions
●You can choose from 10 levels of
engine braking force.
●A lower gear step will provide
greater engine braking force than
a higher gear step, and the engine
speed will also increase.
■Deactivation of temporary
10-speed Sport Sequential
Shiftmatic mode (vehicles with
paddle shift switches)
In the following situations, tempo-
rary 10-speed Sport Sequential
Shiftmatic mode will be deactivated:
●When the vehicle is stopped
●If the accelerator pedal is
depressed continuously for more
than a certain amount of time
WARNING
■To prevent an accident when
releasing the shift lock
Before pressing the shift lock
override button, make sure to set
the parking brake and depress the
brake pedal.
If the accelerator pedal is acci-
dentally depressed instead of the
brake pedal when the shift lock
override button is pressed and the
shift lever is shifted out of P, the
vehicle may suddenly start, possi-
bly leading to an accident result-
ing in death or serious injury.
Selecting the driving
mode
Selecting shift ranges in
the D position (vehicles
with paddle shift
switches)

560Alphabetical Index
COROLLA H/B_U
Glove box ................................ 398
Glove box light ....................... 398
Grocery bag hooks ................ 400
H
Hands-free system ................. 343
Head restraints ....................... 118
Headlights Adaptive Front-lighting System (AFS) .................................. 162
Automatic High Beam system ........................................... 163
Light switch .......................... 160
Replacing light bulbs ............ 455
Head-up display ....................... 89 Driving information display area............................................. 89
Driving support system display area ...................................... 91
Eco Driving Indicator .............. 92
Navigation system-linked display ............................................. 89
Pop-up display ....................... 91
Settings .................................. 90
Heated steering wheel ........... 393
Heaters Automatic air conditioning sys-tem ..................................... 386
Heated steering wheel ......... 393
Outside rear view mirrors ..... 389
Seat heaters ......................... 393
High mounted stoplight Replacing light bulbs ............ 455
Hill-start assist control .......... 241
HOME button .......................... 260
Home screen ........................... 260
Hood Open .................................... 427
Hooks Cargo hooks ......................... 400
Coat hooks ........................... 411
Grocery bag hooks ............... 400 Retaining hooks (floor mat) ....22
Horn .........................................121
I
I/M test .....................................423
Identification Engine .................................. 511
Vehicle ..................................510
Ignition switch (engine switch) ...............................................142Auto power off fun ction .........146
Changing the engine switch modes.................................145
If your vehicle has to be stopped in an emergency .................460
Illuminated entry system .......396
Indicators ..................................72
Info button (Menu screen) .....253
Initial screen............................257 Caution screen .....................257
Restarting the system ...........257
Initialization Items to initialize ...................539
Maintenance .........................420
Power windows ....................125
Tire pressure w arning system
...........................................442
Inside rear view m irror ...........122
Instrument panel light control76, 81
Intercooler coolant Capacity ...............................513
Interior lights...........................395 Front interior light .................395
Rear interior light ..................395
Internet radio...........................307
iPod/iPhone(Apple Carplay ...310
J
Jack Positioning a floor jack .........428

565Alphabetical Index
COROLLA H/B_U
Wattage ................................ 516
Side mirrors Adjustment ........................... 123
BSM (Blind Spot Monitor)..... 227
Folding ................................. 123
Side turn signal lights Replacing light bulbs ............ 455
Turn signal lever ................... 153
Side windows ...... ................... 125
SiriusXM (SXM) ....................... 302
Smart key system Antenna location .................. 108
Entry functions ............. 101, 106
Starting the engine ............... 142
Snow tires ............................... 246
Spare tire Inflation pressure.................. 515
Storage location ................... 491
Spark plug ............................... 513
Specifications ......................... 510
Speedometer ...................... 74, 78
Status icon .............................. 254 Status icon explanation ........ 254
Steering lock Column lock release............. 142
Steering lock system warning message............................. 142
Steering switch ............... 318, 334 Audio switch ......................... 318
Talk switch ............................ 334
Steering wheel Adjustment ........................... 121
Heated steering wheel ......... 393
Meter control switches ........... 83
Stop lights Replacing light bulbs ............ 455
Storage features ..................... 397
Stuck If the vehicle becomes stuck 508
Sun visors ............................... 410 Switches
Automatic High Beam system...........................................163
Brake Hold switch .................157
Display change button ......75, 80
Door lock switches ...............103
Driving mode select switch ...240
Dynamic radar cruise control switch .................................215
Dynamic radar cruise control with full-speed range switch205
Emergency flashers switch...460
Engine switch .......................142
Heated steering wheel switch ...........................................393
Ignition switch .......................142
Instrument panel light control switches..........................76, 81
Light switches .......................160
LTA (Lane-Tracing Assist) switch ...........................................191
Meter control switches............83
Outside rear v iew mirror
switches..............................123
Paddle shift switches ....149, 150
Parking brake switch ............154
PCS OFF switch ...................180
Power door lock switch.........103
Power window switches .......125
Rear window and outside rear view mirror defoggers switch...........................................386
Seat heater switches ............393
“SOS” button ..........................58
Tire pressure warning reset switch .................................442
Vehicle-to-vehicle distance switch .........................205, 215
VSC OFF switch ...................242
Window lock switch ..............127
Windshield wiper and washer switch .................................166
