TOYOTA COROLLA iM 2017 11.G Owners Manual

1914-6. Using the driving support systems
4
Driving
COROLLA iM_U (OM12K64U)
WARNING
■Replacing tires
Make sure that all tires are of the specified size, brand, tread pattern and
total load capacity. In addition, make sure that the tires are inflated to the
recommended tire inflation pressure level.
The ABS, TRAC and VSC systems will not function correctly if different tires
are installed on the vehicle.
Contact your Toyota dealer for further information when replacing tires or
wheels.
■Handling of tires and the suspension
Using tires with any kind of problem or modifying the suspension will affect
the driving assist systems, and may cause a system to malfunction.

192
COROLLA iM_U (OM12K64U)
4-7. Driving tips
●Use fluids that are appropriate to the prevailing outside tempera-
tures.
• Engine oil
• Engine coolant
• Washer fluid
●Have a service technician inspect the condition of the battery.
●Have the vehicle fitted with four snow tires.
Ensure that all tires are the same size and brand.
Perform the following according to the driving conditions:
●Do not try to forcibly open a window or move a wiper that is frozen.
Pour warm water over the frozen area to melt the ice. Wipe away
the water immediately to prevent it from freezing.
●To ensure proper operation of the climate control system fan,
remove any snow that has accumulated on the air inlet vents in
front of the windshield.
●Check for and remove any excess ice or snow that may have accu-
mulated on the exterior lights, vehicle’s roof, chassis, around the
tires or on the brakes.
●Remove any snow or mud from the bottom of your shoes before
getting in the vehicle.
Winter driving tips
Carry out the necessary preparations and inspections before
driving the vehicle in winter. Always drive the vehicle in a man-
ner appropriate to the prevailing weather conditions.
Preparation for winter
Before driving the vehicle

1934-7. Driving tips
4
Driving
COROLLA iM_U (OM12K64U)
Accelerate the vehicle slowly, keep a safe distance between you and
the vehicle ahead, and drive at a reduced speed suitable to road con-
ditions.
●Park the vehicle and move the shift lever to P (continuously variable
transmission), 1 or R (manual transmission) without setting the park-
ing brake. The parking brake may freeze up, preventing it from
being released. If the vehicle is parked without setting the parking
brake, make sure to block the wheels.
Failure to do so may be dangerous because it may cause the vehi-
cle to move unexpectedly, possibly leading to an accident.
●Vehicles with a continuously variable transmission: If the vehicle is
parked without setting the parking brake, confirm that the shift lever
cannot be moved out of P
*.
*: The shift lever will be locked if it is attempted to be shifted from P to any
other position without depressing the brake pedal. If the shift lever can be
shifted from P, there may be a problem with the shift lock system. Have the
vehicle inspected by your Toyota dealer immediately.
Tire chains cannot be mounted.
Snow tires should be used instead.
When driving the vehicle
When parking the vehicle
Selecting tire chains
WARNING
■Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehicle control and cause death or
serious injury.
●Use tires of the size specified.
●Maintain the recommended level of air pressure.
●Do not drive in excess of 75 mph (120 km/h), regardless of the type of
snow tires being used.
●Use snow tires on all, not just some wheels.

1944-7. Driving tips
COROLLA iM_U (OM12K64U)
NOTICE
■Driving with tire chains
Do not fit tire chains. Tire chains may damage the vehicle body and
adversely affect driving performance.
■Repairing or replacing snow tires
Request repairs or replacement of snow tires from Toyota dealers or legiti-
mate tire retailers.
This is because the removal and attachment of snow tires affects the opera-
tion of the tire pressure warning valves and transmitters.

195
5Interior features
COROLLA iM_U (OM12K64U)5-1. Using the air conditioning
system and defogger
Automatic air conditioning
system............................. 196
5-2. Using the interior lights
Interior lights list ................ 203
• Front interior light/front
personal lights............... 204
• Rear interior light .......... 205
• Vanity lights .................. 205
5-3. Using the storage features
List of storage features ..... 206
• Glove box...................... 207
• Console box .................. 207
• Bottle holders ................ 208
• Cup holders .................. 209
• Auxiliary boxes.............. 210
Luggage compartment
features ........................... 2115-4. Other interior features
Other interior features ....... 215
• Sun visors ..................... 215
• Vanity mirrors................ 215
• Clock ............................. 215
• Power outlet .................. 216
• Armrest ......................... 216
• Assist grips ................... 217
• Using the AUX port/
USB port ....................... 217
• Steering wheel audio
switches ........................ 218
• Using the microphone ... 218

196
COROLLA iM_U (OM12K64U)
5-1. Using the air conditioning system and defogger
■Adjusting the temperature setting
Increases the temperature
Decreases the temperature
Automatic air conditioning system
Air outlets are automatically selected and fan speed is automati-
cally adjusted according to the set temperature setting.
Air conditioning controls
1
2

1975-1. Using the air conditioning system and defogger
5
Interior features
COROLLA iM_U (OM12K64U)■
Fan speed setting
Increases the fan speed
Decreases the fan speed
■Change the airflow mode
To change the airflow mode,
move the airflow change knob
upward or downward.
The air outlets used are
changed each time the knob is
operated.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger oper-
ates.
1
2
Airflow change knob
1
2
3
4

1985-1. Using the air conditioning system and defogger
COROLLA iM_U (OM12K64U)
Press .
The dehumidification function begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set-
ting.
Adjust the temperature setting.
To stop the operation, press .
■Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.
■Adjusting the temperature for driver and passenger seats sep-
arately
To turn on the dual control mode, perform any of the following pro-
cedures:
●Press .
●Adjust the passenger’s side temperature setting.
The indicator comes on when the dual control mode is on.
Using automatic mode
1
2
3

1995-1. Using the air conditioning system and defogger
5
Interior features
COROLLA iM_U (OM12K64U)■
Switching between outside air and recirculated air modes
Press to change to recirculated air mode.
Press to change to outside air mode.
When recirculated air mode is selected, the indicator on illu-
minates.
When outside air mode is selected, the indicator on illumi-
nates.
■Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the front side windows early, turn the air
flow and temperature up.
To return to the previous mode, press again when the windshield
is defogged.
■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
Other functions

2005-1. Using the air conditioning system and defogger
COROLLA iM_U (OM12K64U)■
Location of air outlets
The air outlets and air volume
change according to the
selected airflow mode.
(→P. 197)
■Adjusting the position of and opening and closing the air out-
lets
Front center outlets
Direct air flow to the left or right,
up or down.
Front side outlets
Direct air flow to the left or right,
up or down.
Air outlets
