KEYS AND DOORS15
Window lock switch
For driver’s use
For passenger’s use
OPERATING THE PASSENGER’S
WINDOW
Use the switch on the passenger ’s door
or the driver ’s door that controls the
passenger ’s window.
The window moves as long as you hold
the switch.
To open: Push down the switch.
To close: Pull up the switch.
If you push in the window lock switch on
the driver ’s door, the passenger ’s window
cannot be operated.
CAUTION
To avoid death or serious injury, you
must do the following.
DBefore you close the power win-
dows, always make sure there is
nobody around the power windows.
You must also make sure the
heads, hands and other parts of the
bodies of all occupants are kept
completely inside the vehicle. If
someone’s neck, head or hands get
caught in a closing window, it
could result in death or serious in-
jury. When anyone closes the power
windows, make sure he or she op-
erates the windows safely.
DWhen small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock switch to
prevent them from making unex-
pected use of the switches.
DBe sure to remove the key from the
engine switch when you leave your
vehicle.
DNever leave anyone (particularly a
small child) alone in your vehicle,
especially with the key still in-
serted. Otherwise, he/she could use
the power window switches and get
trapped in a window. Unattended
person (particularly a small child)
can be involved in a serious acci-
dent.
Dyna100/150_EE

16KEYS AND DOORS
Tailgate—single cab models

Tailgate—double cab models

Side gates—single cab models
only
To lower the tailgate and side gates,
unlock the latches as shown.
On some models, the chains will hold the
tailgate in a straight open position.
See “Luggage stowage precautions” on
page 127 in Section 2 for precautions
when loading luggage.
When closing the gate, make sure it is
securely latched.
CAUTION
If the open tailgate hides the stop/tail
lights, back−up lights, rear retro re-
flectors, rear fog light or rear turn
signal lights while you are parked,
other road users must be warned of
the presence of your vehicle by a
warning triangle or other device.
NOTICE
Avoid driving with the tailgate or side
gates open.

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
Dyna100/150_EE
Tailgate and side gates

KEYS AND DOORS17
1. To open the engine access hole cov-
er, release the latches and raise the
cover.
NOTICE
Always stow the cup holder in the
instrument panel before opening the
engine access hole cover. If this is
not done, the cover will hit the cup
holder and damage it. (See “Cup hold-
er” on page 110 in Section 1−9for
details.)
2. After lifting the cover up, hold it
open with the strap.
Before closing the engine access hole
cover, check to see that you have not
forgotten any tools, rags, etc.
CAUTION
DMake sure the strap supports the
engine access hole cover securely.
DAfter closing the cover, make sure
it is securely locked by pulling the
seat cushion upward.
Dyna100/150_EE
Engine access hole cover

18KEYS AND DOORS
Before tilting the cab, observe the fol-
lowing.
1. Park the vehicle on a level ground.
2. Set the parking brake firmly.
3. Put the transmission in neutral.
4. Stop the engine.
5. Remove or secure all the loose items
in the vehicle.
6. Close the doors.
CAUTION
Make sure that no one is around and
in the cab.
NOTICE
Make sure that there is no interfering
object on and in front of the cab.

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
Handle latch lever
Cab lock
handle
1. Pull the cab lock handle up while
holding the handle latch lever up,
and the cab will spring up slightly.
Dyna100/150_EE
Tilt cab—
(single cab models
)—Tilting the cab

KEYS AND DOORS19
Safety
catch lever
Cab stay
lock lever
2. Hold the cab down, pull the safety
catch lever out and raise the cab to
tilt forward. Make sure that the cab
stay lock lever locks securely.
The cab will automatically lock when it
tilts fully forward.
CAUTION
When the cab tilts fully forward, make
sure the cab stay lock lever securely
locks and that the cab does not low-
er.
Cab stay lock
lever stopper
3. Plug the opening with the cab stay
lock lever stopper for additional se-
curity.
CAUTION
When tilting the cab, make sure that
the cab stay lock lever stopper has
immobilized the cab stay lock lever.
If it is not immobilized, the cab could
lower and cause death or serious in-
juries.
Dyna100/150_EE

20KEYS AND DOORS
1. Pull the cab stay lock lever stopper
up and return it to the upper hole.
While holding the cab with the grip,
pull the cab stay lock lever up to
unlock, then lower the cab slowly.
Before lowering the cab, check to see that
you have not forgotten any tools, rags,
etc.
CAUTION
When lowering the cab, make sure
that no one is around the cab.
2. Press down the cab lock handle
firmly.
Make sure the cab is securely locked.
CAUTION
Do not drive the vehicle without lock-
ing the cab securely. Otherwise, the
cab may be tilted unexpectedly, possi-
bly causing an accident.
Dyna100/150_EE
—Lowering the cab

KEYS AND DOORS21
1. To unlock the fuel tank cap, insert
the key and turn it counterclockwise.
When refueling, turn off the engine.
CAUTION
DDo not smoke, cause sparks or al-
low open flames when refueling.
The fumes are flammable.
DWhen opening the cap, do not re-
move the cap quickly. In hot weath-
er, fuel under pressure could cause
injury by spraying out of the filler
neck if the cap is suddenly re-
moved.
2. To remove the fuel tank cap, turn
the cap slowly counterclockwise,
then pause slightly before removing
it.
It is not unusual to hear a slight swoosh
when the cap is opened.When installing,
make sure the tabs in the cap are proper-
ly aligned with the cutouts in the tank
opening. Then lock the cap by turning the
key clockwise.
CAUTION
DMake sure the cap is tightened se-
curely to prevent fuel spillage in
the event of an accident.
DDue to the regulation of fuel tank
pressure that these caps provide,
Toyota recommends to use a genu-
ine Toyota fuel tank cap. Another
fuel tank cap of matching quality
can also be used.
Dyna100/150_EE
Fuel tank cap

22KEYS AND DOORS
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS23
Section 1−3
OPERATION OF INSTRUMENTS AND
CONTROLS
Seats, Seat belts, Steering wheel and Mirrors
DSeats 24..............................................
DDriver’s seat 24.......................................
DFolding up rear seat 26.................................
DHead restraints 27.....................................
DSeat belts 28..........................................
DSRS driver airbag 38...................................
DChild restraint 44......................................
DTilt and telescopic steering wheel 58....................
DOutside rear view mirrors 59............................
Dyna100/150_EE

24SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION
DDo not drive the vehicle unless the
occupants are properly seated. Do
not allow any occupants to sit on
top of a folded−down seatback, or
in the luggage compartment or car-
go area. If the occupants are im-
properly seated or restrained by
seat belts, death or serious injury
could result in the event of emer-
gency braking, sudden swerving or
an accident.
DDuring driving, do not allow any
passengers to stand up or move
around between seats. Otherwise,
death or serious injuries can occur
in the event of emergency braking,
sudden swerving or an accident.
Adjust the driver ’s seat so that the foot
pedals, steering wheel and instrument
panel controls are within easy reach of
the driver.
CAUTION
DDo not adjust the seat while the
vehicle is moving as the seat may
unexpectedly move and cause the
driver to lose control of the vehicle.
DWhen adjusting the seat, be careful
that the seat does not hit a lug-
gage.
DAfter adjusting the seat position, re-
lease the lever and try sliding the
seat forward and backward to make
sure it is locked in position.
DMake sure the seatback is securely
locked by pushing forward and rear-
ward on the top of the seatback.
Failure to do so will prevent the
seat belt from operating properly.
DDo not put objects under the driv-
er ’s seat. Otherwise, the objects
may interfere with the seat−lock
mechanism or unexpectedly push
up the seat position adjusting lever
and the seat may suddenly move,
causing the driver to lose control of
the vehicle.
DWhile adjusting the seat, do not put
your hands under the seat or near
the moving parts. Otherwise, you
may catch and injure your hands or
fingers.
Dyna100/150_EE
SeatsDriver’s seat—
—Seat adjustment precautions
